Casio PV-100 Feuille d'instructions

Read this first!

•Be sure to read this part of the User’s Guide before doing anything

else! It includes important information that you need to know in order

to use the PV-100/PV-200 (hereinafter referred to as the “PV Unit”)

correctly.

• You can find more detailed information about other PV Unit operations

in “Chapter 11 – General Operations” on page 137 and “Chapter 13 –

Technical Reference” on page 165.

Important!

Please keep this User’s Guide and all information handy for future reference.

Chapter

1Getting Acquainted

Make backup copies of important data! ....................................... 10

Important Precautions.................................................................... 10

Data Errors...................................................................................... 11

To reset after viewing data.......................................................................... 12

General Guide ................................................................................. 13

Power Supply................................................................................... 14

Low Battery Warning.................................................................................. 14

Battery Precautions..................................................................................... 14

To replace the batteries ............................................................................... 16

To turn power on and off ............................................................................ 19

Auto Power Off........................................................................................... 19

Using the Backlight (PV-200 only)................................................. 19

Action Control and Stylus .............................................................. 19

Stylus .......................................................................................................... 20

Action Control ............................................................................................ 20

Using the Icon Menu....................................................................... 21

Modes ............................................................................................... 22

To enter a mode using the icon menu ......................................................... 22

To enter a mode using the on-screen icon menu......................................... 22

To enter a mode using the Mode List ......................................................... 23

Make backup copies of important data!

Your PV Unit employs flash memory, which makes it possible to store large

volumes of data and to recall data quickly and easily. Data is retained when power

is turned off and even when batteries go dead, but it can be corrupted or lost

entirely due to operational mistakes or malfunction. Data contents can also be

corrupted or lost due to strong electrostatic charge, strong impact, or extremes in

temperature and humidity.All of this means that you should always keep back-up

copies of important data by transferring it to a personal computer or by writing it

down somewhere.

Important Precautions

Note the following important precautions whenever using your PV Unit.

• Never expose the PV Unit to fire.

• Avoid temperature extremes. Do not locate the PVUnit in direct sunlight,

near a window, near a heater, etc.

• In very low temperatures display response may slow down or fail entirely.

This condition is temporary and operation should resume under normal

temperatures.

• Avoid areas subject to excessive moisture, dirt, and dust.

• Avoid dropping the PVUnit and otherwise subjecting it to strong impact.

• Never bend or twist the PV Unit.

• Never try to take the PV Unit apart.

• Do not use a pen, pencil, or other sharp object to touch or press the

display.

• To clean the exterior of the PV Unit, wipe it with a soft cloth dampened

in a weak solution of a mild neutral detergent and water. Be sure to

wring out any excess moisture from the cloth before wiping off the PV

Unit. Never use benzene, thinner, or any other volatile agent to clean the

unit. Doing so can remove the figures printed on the case or otherwise

damage the case finish.

• The contents of this manual are subject to change without notice.

• CASIO COMPUTER CO., LTD. assumes no responsibility for any loss

or claims by third parties that may arise from the use of this product.

Chapter 1 Getting Acquainted

Data Errors

The PV Unit performs a self-check routine whenever you turn it on. The message

shown below appears if the PV Unit detects a problem with data stored in its

memory.

Once data is lost due to a data error it cannot be recovered. Data errors are generally

caused by one of the following problems.

• Interruption of battery power

• Severe electrostatic charge, strong impact, changes in temperature, or

changes in humidity

• Hardware problems

Once the data error message appears, the PV Unit will not accept any input or

editing of data. In order to return memory to normal (and permit further data

editing and input), you have to perform the RESET operation to clear all data.

Before doing so, you may want to recall important data and write it down (if you

don’t yet have a copy). You can then re-input the data after clearing PV Unit

memory.

Continued problems after performing the RESET operation can indicate a serious

hardware problem. Consult with your nearest CASIO dealer if problems persist.

To reset after viewing data

1. After the Data error message appears, tap Yes.

2. In response to the message that appears (Data error! Consult your

User’s Guide for correct procedure.), tap OK.

• This displays the pop up tool screen.

3. Now you can enter other modes to recall data and make handwritten

copies if you want.

4. After recalling the data you want, perform the RESET operation under

“To reset the PV Unit” on page 172.

Chapter 1 Getting Acquainted

General Guide

Stylus

Touch screen

Action control

Cradle contacts RESET button

Battery switch

Pbutton

Battery compartment cover

Off

Esc

Light

Scheduler

Contacts

Memo Quick

Memo

Ber

Power Supply

Your PV Unit can be powered by two AAA-size alkaline batteries.

Important!

• Normally the flash memory of the PV Unit retains its data even when power

is turned off and when batteries go dead. Mis-operation or other problems,

however, can cause data to become corrupted or lost. Always keep separate

copies of important data.

Low Battery Warning

The message shown below appears whenever battery power drops below a

certain level. Replace the batteries immediately after this message appears:

Batteries are getting weak! Replace them as instructed in the User’s

Guide.

Important!

• If you continue using the PV Unit after the low battery warning message

appears, power may suddenly turn off or the contrast adjustment screen

may suddenly appear. Should this happen, replace batteries immediately.

• Be sure to use alkaline batteries. Manganese batteries provide very short

battery life.

Battery Precautions

Incorrectly using batteries can cause them to burst or leak, possibly damaging

the interior of the PV Unit. Note the following precautions.

• Be sure to use alkaline batteries only to power this PV Unit.

• Be sure that the positive (+) side of each battery is

facing in the correct directions.

• Never mix batteries of different types.

Chapter 1 Getting Acquainted

• Never mix old batteries and new ones.

• Do not expose batteries to direct heat, let them become shorted, or try to

take them apart.

• Never leave dead batteries in the battery

compartment.

• Remove the batteries if you do not plan to use the PV Unit for a long

time.

• Replace batteries at least once every 1 year, no matter how much you

use the PV Unit during that period.

• Never try to recharge the batteries that come with

the PV Unit.

• Should a battery leak, clean out the battery compartment of the PV Unit

immediately, taking care to avoid letting battery fluid come into direct

contact with your skin.

Keep batteries out of the reach of small children. If swallowed, consult

with a physician immediately.

• Frequent data synchronization using the PC sync for Windows

application that comes with the PV Unit shortens battery life.

• The batteries that come with this unit discharge slightly during

shipment and storage. Because of this, they may require replacement

sooner than the normal expected battery life.

To replace the batteries

Important!

• Always make sure the battery switch is in the NORMAL OPERATION

position at all times, except when replacing batteries.

1. Turn off PV Unit power.

2. Slide the battery switch on the back of the PV Unit to the REPLACE

BATTERIES position.

REPLACE BATTERIES NORMAL OPERATION

3. While pressing at the point marked (A) in the illustration, slide the battery

compartment cover in the direction indicated by the arrow to remove it.

REPLACE BATTERIES NORMAL OPERATION

Battery switch

(A)

Chapter 1 Getting Acquainted

4. Remove both of the old batteries.

5. Load two new batteries, making sure that their positive (+) and negative

(–) ends are facing in the proper directions.

REPLACE BATTERIES NORMAL OPERATION

6. Taking care not to damage its tabs, replace the battery compartment

cover back onto the PV Unit.

7. Slide the battery switch back to the NORMAL OPERATION position.

REPLACE BATTERIES NORMAL OPERATION

8. Open the cover and touch the screen with the stylus to turn on power.

• If the above does not appear on the display, remove the batteries and

then reload them into the PV Unit, making sure you follow proper

procedures. If this does not solve the problem, refer to “Troubleshooting”

on page 182.

9. Tap the center of each of the four cross marks as they appear on the

screen.

• The contrast adjustment screen appears next.

10. Tap Hor Jto adjust the contrast of the display, and then tap OK.

• This causes the system language selection screen to appear.

11. Tap the button next to the language you want to select as the system

language, and then tap Set.

12. In response to the message that appears (Check your home time setting

and correct it if necessary!), tap OK to change to the pop up tool screen.

13. Check the time setting and correct it if necessary (page 156).
