fx-570MS

fx-991MS

CA 310030-001V08

User’s Guide 2

(Additional Functions)

http://world.casio.com/edu_e/

CASIO ELECTRONICS CO., LTD.

Unit 6, 1000 North Circular Road,

London NW2 7JD, U.K.

Please keep your manual and all information handy for

future reference.

Important!

E-1

Contents

Before getting started... .......................... 3

kModes .................................................................... 3

Mathematical Expression Calculations

and Editing Functions ............................ 4

kReplay Copy .......................................................... 4

kCALC Memory ....................................................... 5

kSOLVE Function .................................................... 5

Scientific Function Calculations............ 6

kInputting Engineering Symbols .............................. 6

Complex Number Calculations .............. 8

kAbsolute Value and Argument Calculation ............. 9

kRectangular Form ↔Polar Form Display .............. 9

kConjugate of a Complex Number ........................ 10

Base-nCalculations .............................. 10

Statistical Calculations ......................... 12

Normal Distribution .................................................. 12

Differential Calculations ....................... 13

Integration Calculations ....................... 14

Matrix Calculations ............................... 15

kCreating a Matrix ................................................. 15

kEditing the Elements of a Matrix .......................... 16

kMatrix Addition, Subtraction, and Multiplication ... 16

kCalculating the Scalar Product of a Matrix ........... 16

kObtaining the Determinant of a Matrix ................. 17

kTransposing a Matrix ........................................... 17

kInverting a Matrix ................................................. 18

kDetermining the Absolute Value of a Matrix ......... 18

E-2

Vector Calculations ............................... 18

kCreating a Vector ................................................. 19

kEditing Vector Elements ....................................... 19

kAdding and Subtracting Vectors .......................... 19

kCalculating the Scalar Product of a Vector .......... 20

kCalculating the Inner Product of Two Vectors ...... 20

kCalculating the Outer Product of Two Vectors ..... 21

kDetermining the Absolute Value of a Vector ........ 21

Metric Conversions ............................... 22

Scientific Constants.............................. 23

Power Supply ........................................ 25

Specifications ........................................ 27

See the “fx-95MS/fx-100MS/fx-115MS/fx-570MS/fx-991MS

User’s Guide” for details about the following items.

Removing and Replacing the Calculator’s Cover

Safety Precautions

Handling Precautions

Two-line Display

Before getting started... (except for “Modes”)

Basic Calculations

Memory Calculations

Scientific Function Calculations

Equation Calculations

Statistical Calculations

Techn ical Information

E-3

Before getting started...

kModes

Before starting a calculation, you must first enter the correct

mode as indicated in the table below.

• The following table shows the modes and required

operations for the fx-570MS and fx-991MS.

fx-570MS and fx-991MS Modes

• Pressing the Fkey more than three times displays

additional setup screens. Setup screens are described

where they are actually used to change the calculator

setup.

• In this manual, the name of the mode you need to enter

in order to perform the calculations being described is

indicated in the main title of each section.

Example:

To perform this type of Perform this To enter

calculation: key operation: this mode:

Basic arithmetic F1COMP

calculations

Complex number F2CMPLX

calculations

Standard deviation FF1SD

Regression calculations FF2REG

Base-ncalculations FF3BASE

Solution of equations FFF1EQN

Matrix calculations FFF2MAT

Vector calculations FFF3VCT

CMPLX

Complex Number

Calculations

Note!

• To return the calculation mode and setup to the initial

defaults shown below, press AB2(Mode) =.

Calculation Mode: COMP

Angle Unit: Deg

Exponential Display Format: Norm 1, Eng OFF

Complex Number Display Format: a+bi

Fraction Display Format: ab/c

Decimal Point Character: Dot

E-4

•Mode indicators appear in the upper part of the display,

except for the BASE indicators, which appear in the

exponent part of the display.

•Engineering symbols are automatically turned off while

the calculator is the BASE Mode.

•You cannot make changes to the angle unit or other

display format (Disp) settings while the calculator is in

the BASE Mode.

•The COMP, CMPLX, SD, and REG modes can be used

in combination with the angle unit settings.

•Be sure to check the current calculation mode (SD, REG,

COMP, CMPLX) and angle unit setting (Deg, Rad, Gra)

before beginning a calculation.

Mathematical Expression

Calculations and Editing

Functions

Use the Fkey to enter the COMP Mode when you

want to perform mathematical expression calculations

or edit expressions.

COMP ............................................................ F1

kReplay Copy

Replay copy lets you recall multiple expressions from replay

so they are connected as a multi-statement on the screen.

•Example:

Replay memory contents:

1 + 1

2 + 2

3 + 3

4 + 4

5 + 5

6 + 6

Multi-statement: 4 + 4:5 + 5:6 + 6

Use [and ]to display the expression 4 + 4.

Press A[(COPY).

•You can also edit expressions on the display and per-

form other multi-statement operations. For more details

COMP

E-5

COMP

CMPLX

about using multi-statements, see “Multi-statements” in

the separate “User’s Guide.”

•Only the expressions in replay memory starting from the

currently displayed expression and continuing to the last

expression are copied. Anything before the displayed

expression is not copied.

kCALC Memory

•CALC memory lets you temporarily store a mathematical

expression that you need to perform a number of times

using different values. Once you store an expression,

you can recall it, input values for its variables, and

calculate a result quickly and easily.

•You can store a single mathematical expression, with up

to 79 steps. Note that CALC memory can be used in the

COMP Mode and CMPLX Mode only.

•The variable input screen shows the values currently

assigned to the variables.

•Example: Calculate the result for Y = X2+ 3X – 12

when X = 7 (Result:

), and when X = 8 (Result:

(Input the function.)

pypupxK+3 px,12

(Store the expression.) C

(Input 7 for X? prompt.) 7 =

(Input 8 for X? prompt.) C8 =

•Note that the expression you store is cleared whenever

you start another operation, change to another mode, or

turn off the calculator.

kSOLVE Function

The SOLVE function lets you solve an expression using

variable values you want, without the need to transform or

simply the expression.

•Example: C is the time it would take for an object thrown

straight up with initial velocity A to reach height B.

Use the formula below to calculate initial velocity A for a

height of B = 14 meters and a time of C = 2 seconds.

Gravitational acceleration is D = 9.8 m/s2.

(Result: A =

16.8

)

E-6

COMP

B AC – DC2

p2pup1-pk,

R1 \2 T-ph-pkK

(B?) 14 =

(A?) ]

(C?) 2 =

(D?) 9 l8 =

[[

(A?) AI

•Since the SOLVE function uses Newton’s Method, cer-

tain initial values (assumed values) can make it impos-

sible to obtain solutions. In this case, try inputting an-

other value that you assume to be near the solution and

perform the calculation again.

•The SOLVE function may be unable to obtain a solution,

even though a solution exists.

•Due to certain idiosyncrasies of Newton’s method, solu-

tions for the following types of functions tend to be diffi-

cult to calculate.

Periodic functions (i.e. y= sin x)

Functions whose graph produce sharp slopes (i.e. y=

ex, y= 1/x)

Discontinuous functions (i.e. y= x )

•If an expression does not include an equals sign (=), the

SOLVE function produces a solution for expression = 0.

Scientific Function

Calculations

Use the Fkey to enter the COMP Mode when you

want to perform scientific function calculations.

COMP ............................................................ F1

kInputting Engineering Symbols

•Turning on engineering symbols makes it possible for

you to use engineering symbols inside your calculations.

COMP EQN

CMPLX

E-7

To input this symbol: Perform this key operation: Unit

k (kilo) Ak103

M (Mega) AM106

G (Giga) Ag109

T (Tera) At1012

m (milli) Am10–3

µ(micro) AN10–6

n (nano) An10–9

p (pico) Ap10–12

f (femto) Af10–15

Disp

•Press 1. On the engineering symbol setting screen that

appears, press the number key (

1or 2) that corre-

sponds to the setting you want to use.

1(Eng ON): Engineering symbols on (indicated by

“Eng” on the display)

2(Eng OFF): Engineering symbols off (no “Eng”

indicator)

•The following are the nine symbols that can be used

when engineering symbols are turned on.

•To turn engineering symbols on and off, press the F

key a number of times until you reach the setup screen

shown below.

•For displayed values, the calculator selects the engineer-

ing symbol that makes the numeric part of the value fall

within the range of 1 to 1000.

•Engineering symbols cannot be used when inputting frac-

tions.

•Example: 9 10 = 0.9 m (milli)

F..... 1(Disp) 1

Eng

9 \10 =

900.

⫼1 m

When engineering symbols are turned on, even standard (non-engineering)

calculation results are displayed using engineering symbols.

E-8

CMPLX

0.9

900.

⫼1 m

Complex Number

Calculations

Use the Fkey to enter the CMPLX Mode when you

want to perform calculations that include complex

numbers.

CMPLX ........................................................... F2

•The current angle unit setting (Deg, Rad, Gra) affects

CMPLX Mode calculations. You can store an expres-

sion in CALC memory while in the CMPLX Mode.

•Note that you can use variables A, B, C, and M only in

the CMPLX Mode. Variables D, E, F, X, and Y are used

by the calculator, which frequently changes their values.

You should not use these variables in your expressions.

•The indicator “R↔I” in the upper right corner of a

calculation result display indicates a complex number

result. Press Arto toggle the display between the

real part and imaginary part of the result.

•You can use the replay function in the CMPLX Mode.

Since complex numbers are stored in replay memory in

the CMPLX Mode, however, more memory than normal

is used up.

•Example: (23i)(45i)



(Real part 6)2 +3 i+4 +5 i=

(Imaginary part 8i)Ar

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Casio Calculatrice

Casio

Casio CFX-9850G PLUS Manuel d'instructions et de sécurité

Casio

Casio fx-88 Manuel utilisateur

Casio

Casio FX-9750G Manuel utilisateur

Casio

Casio TC-1000 Manuel utilisateur

Casio

Casio COLLEGE fx-80 Manuel utilisateur

Casio

Casio CFX-9850G PLUS Feuille d'instructions

Casio

Casio CFX-9850G PLUS Guide de dépannage

Casio

Casio ALGEBRA FX 2.0 Plus Manuel utilisateur

Casio

Casio FX-220 PLUS Manuel utilisateur

Casio

Casio DH-12 Manuel utilisateur

Casio

Casio CFX-9850G PLUS Manuel utilisateur

Casio

Casio fx-991ZA Plus Manuel utilisateur

Casio

Casio FX-D400 Guide de dépannage

Casio

Casio SF-7100SY Manuel utilisateur

Casio

Casio fx-115ES PLUS Manuel utilisateur

Casio

Casio H-1 Manuel utilisateur

Casio

Casio fx-CG50 Manuel utilisateur

Casio

Casio JW-200SC Manuel utilisateur

Casio

Casio FX-300ES PLUS Manuel utilisateur

Casio

Casio FX-9700GE Manuel utilisateur

Casio

Casio FX-201P Manuel utilisateur

Casio

Casio fx-83 Mode d’emploi

Casio

Casio DL-110S Manuel utilisateur

Casio

Casio MJ-12D Manuel utilisateur

Manuels Calculatrice populaires d'autres marques

HP 35s Manuel

LEXIBOOK

LEXIBOOK EL350 Manuel utilisateur

HP HP-97 Manuel utilisateur

Citizen

Citizen SDC-414N Manuel utilisateur

Canon

Canon P26-DHIII Manuel utilisateur

Citizen

Citizen 520DPA Manuel utilisateur

Sharp

Sharp EL-9900 Manuel utilisateur

Sharp

Sharp WriteView EL-W506 Manuel technique

HP HP-67 Guide de l'utilisateur

Royal

Royal CBC2000 Manuel utilisateur

Heathkit

Heathkit IC-2009 Manuel utilisateur

Universal

Universal UNV-15907 Manuel utilisateur

Sharp

Sharp EL-9650 Manuel utilisateur

Sharp

Sharp EL2192RII - Printing Calculator Manuel utilisateur

Ativa

Ativa AT-30i Manuel utilisateur

HP StreamSmart 400 Manuel utilisateur

HP 20b Business Consultant Manuel utilisateur

HP 9g Manuel utilisateur

Casio fx-570MS Manuel utilisateur

Manuels Calculatrice populaires d'autres marques
