Please read this manual before installing and using the
projection screen. Retain this manual for future reference.
Instruction manual for One Zero, Acoustic
Zero, NovaStar Zero, Black Zero
Items listed here may change without prior notice.
The company reserves the right to all of the listed items.
Important Safety Tips
WARNING: Please strictly abide by the following safety rules. Wrong
installation and use will severely damage the product and/or cause personal
injury.
Considerations for installing / using this product
1. Fragile product. Handle with great care.
2. Avoid exposure to any form of water or moisture.
3. Avoid exposure to re or heat.
4. Avoid folding or scratching the screen.
5. Identify the front / back side of the screen before installation.
6. Ensure the screen is installed in a perfectly horizontal surface
The company will not be liable for any damages or injuries caused by a faulty
installation or operation.
Cleaning
Use a soft, dry cloth with non-corrosive components and neutral soap water to
gently clean the screen and the shell. DO NOT USE chemicals or corrosive
materials to avoid damaging the product.
1
The inter-frame view once the splicing is complete.
Inter-frame splicing angle
2
Complete view
Use PVC poles to x the screen
3
Clean the surface being used. Tile
the non-woven fabrics, screen
(Projection surface facing down),
interframe (front side facing
down).
4
Hook the spring. (Hook the 6
corner springs rst, then hook
the rest)
Outer frame view once splicing is complete.
5
Outer-frame splicing angle
Wall mount instructions
1. Use the screwdriver to install
the tiebacks in the desired
location on the wall. (Ensure the
tiebacks are rm).
2. Hang the frame on the tieback.
