Carrier HDB Manuel utilisateur

HDB Controller

2 WAY

INSTALLATION MANUAL MONTAGE-INSTRUCTIES

MANUALE DI INSTALLAZIONE  OK

MANUEL D’INSTALLATION MANUAL DE INSTALAÇÃO

INSTALLATIONSANWEISUNG INSTALLATIONSMANUAL

MANUAL DE INSTALACIÓN ASENNUSOHJE

HDB Controller

ENGLISH

Installation Manual

ITALIANO

Manuale di installazione

FRANÇAIS

Manuel d’installation

DEUTSCH

Installationsanweisung

ESPAÑOL

Manual de instalación

NEDERLANDS

Montage - instructies

 K

OK

PORTUGUÊS

Manual de instalação

SVENSKA

Installationsmanual

SUOMI

Asennusohje

I - 1

ENGLISH

GB - 1

HDB controller

Contents

Page

Units where the controller is installed................................................. 2

Satellite and 42N electric panel.......................................................... 2

Satellite and 42N main connections ................................................... 2

Satellite and 42N power connection ................................................... 3

Cassette electric panel ....................................................................... 3-4

Cassette Small electric panel ............................................................. 4

Cassette Large electric panel............................................................. 4

Grouping connection .......................................................................... 5

Fault codes: ........................................................................................ 6

HDB controller

GB - 2

Units where the controller is installed

Satellite and 42N main connections (mod.42DW...DB, 42DWE..DB, 42DW...DBV and 42DWE..DBV) and Fan Coil mod.42N







After removing cover 1 the following connections can be reached: 1 - 230 – 1 – 50/60Hz power supply and valves

2 - Connection to CRC 2-way remote control.

3 - Window contact, Presence detecting contact

Satellite and 42N electric panel

For normal installation (CCN bus connection, power supply, remote

controls…) ONLY the ﬁrst cover must be removed by loosening

the corresponding screw and pressing the two clips at the electric

The voltage rating of the units is 230V – 50Hz.

The HDB electric panel is used only for hydronic units. For connection of the two remote controls, IR remote control and

CRC2 wire control, refer to the relevant Installation manuals.

panel’s sides.

For other operations, make sure power supply is disconnected

before handling the electric components inside the electric panel.

GB - 3

HDB controller

ENGLISH

Satellite and 42N power connection

IMPORTANT:

• Dependingontheunityouareworkingwith,refertothe

appropriate manual and safety instructions.

• Makeearthconnectionpriortoanyotherelectricalconnections.

• Disconnectthepowersupplytoallcircuitspriortohandlingany

electrical components.

• Beforeproceedingwiththeunitconnectiontothemainssupply

locate live L and neutral N, then make connections as shown in

the wiring diagram.

• Withasmallatbladescrewdriverprizeoneofthepointsshown

in the ﬁgure. Insert the cable into the open contact.

Remove the screwdriver and check the connection solidity.

• Ensurethatthemainssupplyconnectionismadethrougha

switch that disconnects all poles, with contact gap of a least 3 mm.

• The fan coil connecting cables, as well as accessory wires,

must be of the H05 VVF type with PVC insulation according

to the EN 60335-2-40 standard.

• For the unit power supply, it is recommended to use cables

with a minimum size of 2.5 mm2.

• IftheCassetteunitisprovidedwithelectricheaters,use

terminals L and N as shown in Figure 1; power supply must be

split in two according to the cable sections shown in the table.

• Routethepowersupplycablethroughthespecialcableholder.

10 120

10 100

Power supply cable stripping

Cassette electric panel

Open the grille after removing the two screws shown in the ﬁgure.

Unscrew the 3 or 4 screws left to remove the metal cover, as shown

in the ﬁgure. Cassette Small

Cassette Large

230 V - 1 - 50/60 Hz / min. 198V - max. 264V

NNLL

HW CW

GC I123

WS ECO

1HW

1CW

NHW NCW

Auxiliary contact wiring diagram

WS: Window contact

ECO: ECO contact

Valve wiring diagram

HW: Hot valve

CW: Cold valve

HDB controller

GB - 4

Cassette electric panel

 HDB board

 Electricheaterboard

 Supply terminal block

 Transformer

Cassette Small electric panel - Cassette Large electric panel

















10 120

10 100

Power supply cable

Cassette Small Cassette Large

Fig. 1

GB - 5

HDB controller

ENGLISH

GND

12V

GND

12V

GND

12V

Grouping connection

 Mainboard

 Communication board

 5-wire wiring

 Auxiliary terminal block









GND

12V

BLUE

GREY

WHITE

BLACK

RED

Connect the units in daisy chain conﬁguration (white and blue cables in parallel) for grouping. Refer to the ﬁgure below.

 First indoor unit

 Second indoor unit

 Third indoor unit

Fit the communication board into the special connector which can

be reached only after cover 1 and cover 2 have been removed.

Proceed as follows:

• Removecover1

• Removecover2(screw+clips)

• FittheboardontoconnectorJ8

For the Cassette unit, remove the metal cover as previously

described, and remove the board from its seat.

Install the communication board.

For more information refer to the manual provided with the grouping

kit.

Grouping conﬁguration of several units

WHITE

GREY

BLUE

RED

BLACK

WHITE

GREY

BLUE

RED

BLACK

WHITE

GREY

BLUE

RED

BLACK

 A Comunication board

 B To the other terminal block

HDB controller

GB - 6

Fault codes:

InthecaseoffailureandwiththeunitON,theredLEDonthe

boardstartsashingaccordingtothefaultcode:0.5secondsON

and 0.5 seconds OFF followed by 5 seconds OFF.

The fault code table is shown below:

Fault Code Description Resettable

2 Air temperature sensor Yes

3 Changeover sensor Yes

4 Cold Draft thermistor Yes

5 Condensate pump error No

6Electricheatercongurationerror Yes

7EEpromerror Yes

8Chilled Beam conﬁguration error Yes

I - 1

ITALIANO

I - 1

Controllo HDB

Indice

Pagina

Unità su cui il controllo è installato ..................................................... 2

Quadro elettrico Satellite e 42N ......................................................... 2

Principali connessioni Satellite e 42N ................................................ 2

Collegamento alimentazione Satellite e 42N...................................... 3

Quadro elettrico Cassette................................................................... 3-4

Quadro elettrico Cassette Small......................................................... 4

Quadro elettrico Cassette Large ........................................................ 4

Collegamento Grouping...................................................................... 5

Codice errore ..................................................................................... 6

Controllo HDB

I - 2

Unità su cui il controllo è installato

Principali connessioni Satellite e 42N(mod. 42DW...DB,42DWE..DB,42DW...DBV e 42DWE..DBV) e Fan Coil mod. 42N







Rimosso il coperchio 1 si ha accesso alle seguenti connessioni: 1 - Alimentazione 230 –1 –50/60Hz e valvole.

2 - Connessione al comando remoto CRC 2 - vie.

3 - Contatto ﬁnestra, rilevazione presenza

Quadro elettrico Satellite e 42N

Le normali operazioni di installazione (collegamento CCN bus,

alimentazione, comandi remoti…) sono effettuabili tramite la

rimozione SOLO del primo coperchio svitando l’apposita vite e

Tutte le unità hanno una tensione nominale di 230V ~ 50Hz.

Il quadro elettrico HDB equipaggerà solo unità idroniche. Per collegare i due telecomandi, il comando IR e il comando a ﬁlo

CRC2, fare riferimento ai relativi manuali di installazione.

facendo leva sulle due clip ai ﬁanchi del quadro elettrico.

Per operazioni successive, prima di accedere ai componenti elettrici

del quadro elettrico, assicurarsi che non vi sia alimentazione.
