CareCo Secco 4 Guide de l'utilisateur

www.careco.co.uk

Rollator

OWNERS HANDBOOK

Product Code: WA01073

Your CareCo Secco4 Rollator

1. Brake Handle/Lever

2. Backrest

3. Tightening Handle

4. Seat

5. Underseat Bag

6. Rear Wheel

7. Front Castor

List of Parts

Thank you for purchasing the CareCo Secco4

Rollator. The Secco4 Rollator has been designed

and manufactured to meet our own high level

of specifications and we hope you will be

delighted with your purchase.

The Secco4 Rollator is a portable rollator to aid

the user to walk and offer stability and security.

The Secco4 is designed for use both indoor and

outdoor and will take a maximum user weight

of 110kg (17 stone).

The CareCo Secco4 Rollator will arrive

assembled with the exception of the height

adjustable handles.

Rollator Dimensions: 62cm (Length) x 62cm

(Width) x 78-93cm (Height)

Folded Dimensions: 20cm (Length) x 62cm

(Width) x 81cm (Height)

Seat Height: 53cm

Weight: 6.6kg

Max User Weight: 110kg

Introduction

Specification

Assembly

1. Remove all protective packaging and fold

out the rollator. Place upright with wheels on

the ground on a flat surface.

2. Ensure the star knob and bolt are removed

from the frame (they may or may not arrive

this way). (fig. A)

3. Insert the handle tube into the rollator frame

ensuring the cable is on the outside of the

rollator frame.

4. Select the required height and insert bolt

through the frame and handle, making sure the

hexagonal head on the bolt sits in it’s recess.

(figs. B & C)

5. Attach the star knob to the other side onto

the bolt and tighten. (fig. D)

For Safety:

• Ensure you adopt a comfortable posture

and can operate the brakes with ease.

• Ensure the handles are at equal heights and

securely locked in position.

• Ensure the rollator is fully folded out prior

to use.

1. Remove all protective packaging and fold

out the rollator. Place upright with wheels on

the ground on a flat surface.

2. Ensure the star knob and bolt are removed

from the frame (they may or may not arrive

this way). (fig. A)

3. Insert the handle tube into the rollator frame

ensuring the cable is on the outside of the

rollator frame.

4. Select the required height and insert bolt

through the frame and handle, making sure the

hexagonal head on the bolt sits in it’s recess.

(figs. B & C)

5. Attach the star knob to the other side onto

the bolt and tighten. (fig. D)

6. Repeat for the other handle.

7. Adjust the height of the handles, reverse the

above process.

For Safety:

• Ensure you adopt a comfortable posture

and can operate the brakes with ease.

• Ensure the handles are at equal heights and

securely locked in position.

• Ensure the rollator is fully folded out prior

to use.

ABD

6. Repeat for the other handle.

7. Adjust the height of the handles, reverse the

above process.

1. To operate the brakes squeeze the lever up

to engage the brake

2. To lock the brakes, push down on the brake

lever until it locks in place

3. To unlock the brakes, pull up on the brake

lever until the lock is removed

Operation

• Ensure the brakes are tested prior to use.

• Do not use on gradients greater than 7

degrees.

• Ensure the brakes are locked when using

the seat.

• When sitting, ensure the user is sat in the

centre of the seat

Folding

For ease of storage and transportation the

CareCo Secco4 has an easy fold mechanism.

Maintenance

Be sure your CareCo Secco4 Rollator is in

proper working order at all times. Please

contact CareCo for any reparies required.

• Ensure the walker is kept clean. Wipe down

the walker with a damp cloth on a regular

basis.

• Check the wheels and height adjustable

handles regularly.

• Ensure the brakes have been adjusted to

suit the wheels and user.

• Ensure all nuts, bolts and screws are

securely tightened at regular intervals.

• If the solid wheel becomes cracked or

severely worn, replace immediately

• Check the front castor wheel swivels freely.

To fold the Secco4, lift the seat up and pull

the black cord whilst holding the rollator

handles, lifting the rollator at the same time.

This will fold the rollator for easy storage and

transportation.

Your CareCo branded product is under

warranty to be free from defects in material

and workmanship for one year from date of

receipt. This warranty expresses our confidence

in the workmanship and materials used for our

products.

In the event of a defect covered by this

warranty, CareCo will, at our discretion,

replace the Rollator or supply parts to remedy.

This warranty does not cover device failure

due to owner misuse or negligence, or due to

normal wear and tear. The warranty does not

extend to non-durable parts, such as rubber

accessories, castors and grips, which are subject

to normal wear and tear and require periodic

replacement.

If you have any queries please contact CareCo.

The manufacturer reserves the right to alter

without notice any weights, measurements or

other technical data shown in this manual. All

figures, measurements and capacities shown

in this manual are approximate and do not

constitute specifications

Warranty

CareCo, Hubert Road, Brentwood,

Essex CM14 4JE

www.careco.co.uk
