CareCo ALPINE Manuel utilisateur
USER MANUAL
PRODUCT CODE WA01082
FOREARM ROLLATOR
P. 1
PRODUCT CODE WA01082
NOTES
Check all parts for shipping damage. In case of shipping damage,
Do NOT use. Contact Dealer further instruction.
SAFETY SUMMARY
To ensure the safe operation of the Alpine Forearm Rollator, these
instructions MUST be followed:
General warning
• DO NOT install or use this equipment without rst reading and understanding
• the instructions. If you are unable to understand the Warnings, Cautions or
Instructions, contact a healthcare professional, dealer or technical personnel
before attempting to install this equipment–otherwise, injury or damage may
occur.
• User should always consult with their physician or therapist to determine
proper adjustment and usage.
• This equipment is NOT intended to be self-propelled while seated.
• A physical/occupational therapist should assist in the height adjustment of
the rollator for maximum support and correct brake activation, the xture of
the screw and the position of the quick release/assembly kits.
• Always ensure screws are fastened to the connector, so that the connector
can’t move when forced. Ensure the correct position of the quick release/
assembly kits, and they will not fall even with opposite force. Ensure all snap
buttons fully protrude through adjustment holes. Ensure the braking system
is eective when brake handle is locked or released.
• Care should be taken to ensure that ALL handles, height adjustment locks,
wheels, brakes or any other functional or moving parts are in good working
order before operation.
• All wheels MUST be in contact with the oor at ALL TIMES during use. This will
ensure the upright rollator is properly balanced. The brakes MUST be in the
locked position BEFORE using the seat.
P. 2
PRODUCT CODE WA01082
General warning
• When using the rollator in a stationary position, the hand brakes MUST be locked.
• DO NOT put your full weight on the linkage component nor use it as a handle
to carry the Walker. It is designed only for the purpose of connecting the two
armrest supports, neither for supporting the user nor carrying the Walker.
• DO NOT go up or down inclines greater than 15% or diagonally across inclines
greater than 5% when using as a traditional upright rollator with armrest
locked in horizontal position.
• DO NOT ride the rollator with all your weight on the armrests or lean
disproportionately on one of the armrests.
FAILURE TO FOLLOW THESE WARNINGS CAN LEAD TO INJURY.
Stability warning
• The Rollator can provide ambulatory assistance to an individual weighing up
to 300 lbs. (136kg), INCLUDING the weight of the contents in the bag.
• The Rollator bag has a weight limitation of 10 lbs. (4.5kg)
Folding or assembling warnings
• After unfolding or assembling rollator, make sure the seat tubing is securely
locked at both side slots, and the quick release/assembly kits are in their
correct position. All screws must be tightly locked without movement.
• DO NOT hang an additional weight on either side of the frame. This may cause
the rollator unbalanced when it is fully unfolded, resulting in injury or damage.
Installation warning
• Periodically check the rollator and attachments are properly and securely
locked in place BEFORE using.
P. 3
PRODUCT CODE WA01082
OPENING/FOLDING THE ROLLATOR
OPENING
Note: Refer to the FOLDING/ASSEMBLY WARNINGS in the SAFETY SUMMARY of this
instruction sheet.
Notes: For clearer display, the bag is not attached to the rollator.
1. Install the hand grip with brake & armrest component to the top of the side tube, and rotate
the black lever by 90 degrees and then lock it to the slot, as shown in Figure 1.
2. Open the rollator by pushing the side
frames outwards, as shown in Figure 2.
FIGURE 2
FIGURE 1
3. Lower the seat and push it down until both
seat rails are fully locked into the plastic
slots, as shown in Figure 3.
FIGURE 3
P. 4
PRODUCT CODE WA01082
OPENING/FOLDING THE ROLLATOR
4. Press the snap button and adjust it to the appropriate position. Make sure the snap button
protrudes through the hole on the linkage component, as shown in Figure 4.
FIGURE 4
5. Before using, test the rollator by grasping
the side frames and attempt to pushing
slightly inward with some force. The
rollator will remain locked in OPEN position
when the seat is completely open and
table, as shown in Figure 5.
FIGURE 5
P. 5
PRODUCT CODE WA01082
OPENING/FOLDING THE ROLLATOR
FOLDING
Note: For clearer display, the bag is not attached to the rollator.
1. Press the snap button and adjust it to the appropriate position. Make sure the snap button
protrudes through the hole on the linkage component, as shown in Figure 6.
2. Lift the band on the middle of the seat and push both the side frames inwards until the
rollator is completely closed, as shown in Figure 7.
FIGURE 6
FIGURE 7
P. 6
PRODUCT CODE WA01082
ADJUSTING HANDRAIL/ HAND GRIP/ BRAKE CABLES
Notes: Refer to the INSTALLATION WARNINGS in the SAFETY SUMMARY of this instruction
sheet.
1. Release the knob and adjust the height handrails upward or downward to the desired
height. Ensure both handrails are at the same height and the knob is locked after height
adjustment, as shown in gure 8.
2. Open the quick-release lever, adjust the hand grip to the appropriate angle and fasten the
lever. Ensure the quick-release lever is locked after angle adjustment, as shown in Figure 9.
FIGURE 8 FIGURE 9
USING HAND BRAKES
1. Pull the top portion of the brake handles UP towards
the hand grips, as shown in Figure 10.
FIGURE 10
LOCKING HAND BRAKES
1. Push DOWN on the bottom
portion of the brake handle
until an audible “click” is heard,
as shown in Figure 11.
FIGURE 11
PRODUCT CODE WA01082
CABLE ADJUSTER UNIT
If the tension of the brake handle is STILL too loose/tight, perform the following adjustments:
1. Figure Use ngers or a 10 mm wrench to turn the larger locking nut until loosened. Then
use ngers or pliers to turn barrel adjuster nut and try the brake. If this does not correct
the problem, repeat turning the barrel adjuster nut until the brake functions as expected.
Then tighten the locking nut until it presses tightly against the housing to prevent the
barrel adjuster nut from loosening. As shown in Figure 12.
2. Use ngers or a 10 mm wrench to turn the larger locking nut until loosened. Then use
ngers or pliers to turn barrel adjuster nut and try the brake. If this does not correct the
problem, repeat turning barrel adjuster until the brake functions as expected.
Then tighten the locking nut until it presses tightly against the xed plate to prevent the
barrel adjuster nut from loosening. As shown in Figure 13.
CARE AND MAINTENANCE
1. Ensure that ALL attaching hardware is
secured at ALL times.
2. Check the seat rails locked into the plastic
slots securely. If not, push down the seat
again.
3. Check the wheels are locked and installed
properly.
4. Make sure the quick release kit is locked.
5. Replace any broken, damaged or worn
items immediately.
CARE OF WHEELED ACCESSORIES
1. Clean wheels with warm water and
neutral cleanser. Dry with clean rag.
2. Lubricate with 3-in-l oil periodically if
wheels begin to squeak.
FIGURE 12 FIGURE 13
0333 015 5000 | CareCo UK Limited , Hubert Road, Brentwood, Essex, CM14 4JE
