Canon N1240U - CanoScan Flatbed Scanner Manuel utilisateur

ScanGear CS-U 6.2

for CanoScan N670U/N676U/N1240U Color Scanner

User’s Guide

for Windows

for Macintosh

Troubleshooting

Glossary

Contents

Index

laws, this manual may not be copied, in whole or in part, without written

consent of Canon Inc. Under the law, copying includes translating into

another language or format.

In this manual, screen shots are taken with Windows Millennium Edition

(Me). When you use Windows 98, Windows 2000 Professional or

Macintosh, screen designs are slightly different from this manual.

Microsoft and Windows are registered trademarks or trademarks of the

Microsoft Corporation in the United States and other countries.

Macintosh, Power Macintosh, Mac OS and ColorSync are trademarks of

Apple Computer, Inc., registered in the U.S. and other countries.

iMac is a trademark of Apple Computer, Inc.

Adobe ® and Adobe ® Photoshop are trademarks of Adobe Systems

Incorporated.

Canon, and CanoScan are registered trademarks of Canon, Inc.

ColorGear and ImageTrust are registered trademarks of Canon Inc.

All other names are trademarks of their respective companies.

Troubleshooting

Glossary

Contents

Index

Chapter 1 Before You Begin......................................5

Welcome to ScanGear CS-U 6.2 ..................................................... 6

System Requirements ..................................................................... 7

Windows .................................................................................. 7

Macintosh ................................................................................8

Starting and Closing ScanGear CS-U ............................................. 9

Windows .................................................................................. 9

Macintosh ..............................................................................10

Getting Help in ScanGear CS-U.................................................... 11

Windows ................................................................................ 11

Macintosh ..............................................................................11

Chapter 2 Simple Mode and Advanced Mode.......12

What are the Simple Mode and Advanced Mode? .................... 13

Switching Between the Simple and Advanced Modes ............. 14

Simple Mode Main Window ........................................................ 15

Advanced Mode Main Window................................................... 16

Chapter 3 What is on the screen?...........................18

Main Window ...............................................................................19

Toolbar ..........................................................................................20

Scanning Buttons.......................................................................... 23

Simple Mode Main Window ........................................................ 24

Advanced Mode Main Window................................................... 30

The Main Sheet ......................................................................30

The Scanner Sheet .................................................................. 34

The Tone Sheet .......................................................................40

Contrast/Brightness Sheet .............................................. 43

Gamma Sheet ................................................................44

Histogram Sheet ............................................................46

Special Tone Curves Sheet .............................................. 48

Editing a Special Tone Curve Directly .............................. 49

The Halftone Sheet ................................................................. 51

Troubleshooting

Glossary

Contents

Index

Chapter 4 Scanning an Original..............................52

Preparing for the Scanning Job ...................................................53

Quick Start ....................................................................................54

Previewing and Scanning an Original .........................................56

Scanning in the Simple Mode .................................................56

Scanning in the Advanced Mode ............................................61

Chapter 5 Multi-Photo Mode ..................................65

Multi-Photo Mode ........................................................................ 66

Operations .............................................................................66

Placing the Photos ..................................................................68

Chapter 6 Settings in the Windows Control Panel

(Windows only) ....................................69

Opening Scanners and Cameras Properties ................................ 70

General Settings ...........................................................................72

Events Settings..............................................................................73

Preferences Settings .....................................................................75

Color Management Settings ........................................................77

Chapter 7 Uninstalling ScanGear CS-U...................78

Uninstalling ScanGear CS-U ......................................................... 79

Chapter 8 Troubleshooting .....................................80

Pre-Scan Checklist ......................................................................... 81

How to Avoid Problems ...............................................................82

Troubleshooting Checklist ...........................................................84

Glossary ...............................................................90

Index .............................................................104

Customer Support Help Desk ...............................109

Troubleshooting

Glossary

Contents

Index

chapter 1

Before You Begin

Welcome to ScanGear CS-U 6.2

System Requirements

Starting and Closing ScanGear CS-U

Getting Help in ScanGear CS-U

chapter 1

Before You Begin

Troubleshooting

Glossary

Contents

Index

Welcome to ScanGear CS-U 6.2

Welcome to Canon ScanGear CS-U 6.2.

ScanGear CS-U 6.2 (hereafter referred to as ScanGear CS-U) will provide

flexible, efficient image enhancement tools for scanning with your

CanoScan N670U/N676U/N1240U Scanner by providing an interface with a

variety of software applications.

ScanGear CS-U has a number of powerful features that help you achieve

peak performance with your scanner. Using ScanGear CS-U, you can

preview and adjust an image before the image is scanned and acquired by

the parent software application.

Normally when you start a scanning job, you will see the ScanGear CS-U

main window with its toolbar, Preview Area, and tabs.

However, some software applications may not open the ScanGear CS-U

main window. When this occurs you cannot use the settings described in

this user’s guide because the host software application will provide the

settings so you can change the image after it is acquired. When a software

application uses ScanGear CS-U without opening the ScanGear CS-U main

window, this is called the windowless mode.

chapter 1

Before You Begin

Troubleshooting

Glossary

Contents

Index

System Requirements

The hardware and software listed below is required to use ScanGear

CS-U.

Windows

Computer: IBM PC/AT Compatible with USB port(s) standardly

OS: Windows 98

Windows Millenium Edition

Windows 2000 Professional

CPU: Pentium 150MHz or greater

RAM: 64MB or more

HDD Free Space: Approx. 10MB (When Installation) or more

Display: 800 x 600 dots

High Color (16 bit) or greater

Interface: USB 1.1

CD-ROM Drive: Necessary

• USB Expansion card is not guaranteed.

Note

chapter 1

Before You Begin

Troubleshooting

Glossary

Contents

Index

Macintosh

Computer: Macintosh with USB port(s) standardly

OS: Mac OS 8.6

Mac OS 9.0

Mac OS 9.1

Mac OS X (Classic Mode only)

CPU: Power PC G3 or greater

RAM: 64MB or more

With Mac OS X 128MB or more

HDD Free Space: Approx. 10MB (When Installation) or more

Display: 800 x 600 dots

32000 colors or greater

Interface: USB 1.1

CD-ROM Drive: Necessary

• USB Expansion card is not guaranteed.

Note

chapter 1

Before You Begin

Troubleshooting

Glossary

Contents

Index

Starting and Closing ScanGear CS-U

ScanGear CS-U is not a stand-alone program that can be started by itself. It

is used as a TWAIN driver (Windows) or plug-in (Macintosh). Start the

application program first, then start ScanGear CS-U from the program.

When starting ScanGear CS-U, confirm that the scanner is

correctly connected to the computer.

Windows

Starting

1. Start the TWAIN-compliant application software such as PhotoStudio

or Photoshop.

< If you have installed another scanner or a digital camera, select this

scanner. >

a. Click the [File] menu and select [Select Source] or such.

b. Click to highlight [CanoScan N670U/N676U] or [CanoScan

N1240U] and click [Select].

2. Click the [File] menu and select [Acquire] or such.

ScanGear CS-U will start.

Closing

Click the (close box) in the ScanGear CS-U window.

Note

chapter 1

Before You Begin

Troubleshooting

Glossary

Contents

Index

Macintosh

Starting

1. Start the parent application software such as PhotoStudio or

Photoshop.

2. Click the [File] menu and select [Acquire] or such, and [ScanGear CS-

U 6.2.0...].

ScanGear CS-U will start.

Closing

When scanning is completed, the ScanGear CS-U window automatically

closes (Macintosh only).

If the “Automatically quit ScanGear CS-U after scanning” (☞p.39) is

off, click the (close box) in the ScanGear CS-U window.
