Canon CanoScan FB 1200S Manuel utilisateur

f o r W i n d o w s

User'sGuide

ScanGearCS-S4.3

for CanoScan FB1200S Color Image Scanner

User'sGuide

CONTENTS

GLOSSARY

INDEX

Describes operating procedure from set up

and software installation to scanning and

confirmation of operation. Please read before

using the scanner for the first time.

Printed Manual

CanoScan FB1200S

Getting Started

Detailed information on how to use

Plug-in Module CS-S.

Plug-in Module CS-S 3.6

User's Guide

Electronic Manual

MacintoshWindows

Detailed information on the scanner

and the CD-ROM.

CanoScan FB1200S

Product Guide

Electronic Manual

Detailed information on how to use

ScanGear CS-S and ScanGear Toolbox CS.

ScanGear CS-S 4.3

User's Guide

Tells you how to use Adobe Photoshop 5.0 LE

and Caere OmniPage Limited Edition.

Electronic Manuals

Manual for Each

Application Software

After you have read this

book and mastered the

use of ScanGearCS-S.

After reading this

guide and scanner is set

up and ready for use.

Tells you how to get the

best scanning results.

Detailed information

on care of the

scanner and handling

the accompanying

CD-ROM.

When using the

accompanying

application software.

After you have read

this book and

mastered the use of

Plug-in Module CS-S.

When you open the box

Detailed information on how to use

CanoScan Toolbox CS.

CanoScan Toolbox CS

User's Guide

Electronic Manual

This Guide

How to Make Best Use of the Manuals

CONTENTS

GLOSSARY

INDEX

this manual may not be copied, in whole or in part, without written consent

of Canon, Inc. Under the law, copying includes translating info another

language or format.

CanoScan, and Bubblejet are trademarks of Canon, Inc. Adobe, Adobe

Acrobat and Adobe Photoshop are trademarks of Adobe Systems

Incorporated. Microsoft is a registered trademark of, and Windows is a

trademark of Microsoft Corporation. All other names are trademarks of their

respective companies.

GLOSSARY

INDEX

Contents

Chapter 1 Introduction to ScanGear CS-S 4.3 ..................... 7

Welcome to ScanGear CS-S ................................................................ 7

System Requirements ......................................................................... 7

About ScanGear CS-S ......................................................................... 8

About this User’s Guide ...................................................................... 9

Obtaining Customer Support .............................................................. 9

Chapter 2 Installing ScanGear CS-S 4.3 ............................. 12

Before You Install ............................................................ 12

Installing ScanGear CS-S .................................................. 12

Selecting ScanGear CS-S .................................................. 14

Removing ScanGear CS-S................................................. 14

Where to Go From Here .................................................. 15

Next Steps ........................................................................................15

Getting Help in ScanGear CS-S .........................................................15

Chapter 3 Scanning............................................................. 16

About Scanning ............................................................... 16

Features of the ScanGear CS-S Window ......................... 17

Quickstart to Scanning .................................................... 19

Preparing the Scanner ...................................................................... 19

Previewing an Image ........................................................................ 19

Where is the Scanned Image? ..........................................................23

Scanning in “Windowless” (UI-less) Mode ..................... 23

Working with Preview Images ........................................ 24

Changing the Preview Image Shape and Size ....................................24

Cropping Part of an Image................................................................ 25

Moving an Image ............................................................................. 25

Zooming In and Out ......................................................................... 25

Creating a Negative Image................................................................ 25

Reversing an Image .......................................................................... 26

Rotating an Image Left or Right ........................................................26

Displaying or Hiding the Rulers .........................................................26

Selecting Automatic Tone Correction ................................................26

Viewing ScanGear CS-S Help Topics ..................................................26

Specifying How the Image is Previewed ............................................27

Setting Scan Mode, Resolution, and Dimensions .......... 28

GLOSSARY

INDEX

Setting Scanning Mode .................................................................... 28

Selecting Scan Resolution ................................................................. 30

Selecting Output Dimensions ............................................................32

Setting Image Tones ........................................................ 35

Setting General Preferences ........................................... 47

Using Text Enhanced for Scans .........................................................47

Using Canon ColorGearTM Color Matching ........................................ 48

Chapter 4 Scanning Devices ............................................... 51

Configuring Scanning Devices ........................................ 51

Configuring a Device with ScanGear CS-S ........................................ 51

Testing the Scanner .......................................................................... 53

Scanning Multi-Page Documents.................................... 55

Using the Automatic Document Feeder (ADF) ...................................55

Connecting the Automatic Document Feeder ...................................55

Scanning with the Automatic Document Feeder ............................... 56

Chapter 5 Scanning Techniques ......................................... 59

About Scanning Techniques............................................ 59

Planning for the End Result ..............................................................59

Preparing the Material to Scan .........................................................59

Matching Scan Resolution to Purpose ............................................... 60

Optical and Enhanced Resolutions .................................................... 61

Estimating Image Sizes .................................................... 61

Resolution and Color ........................................................................ 61

File Size Estimates ............................................................................. 62

Cropping the Image Shape ............................................................... 63

Custom Tone Adjustments .............................................. 64

What Do Those Curves Mean? .........................................................64

Contrast and Brightness Adjustments ............................................... 64

Gamma Adjustments ........................................................................ 65

Histogram Techniques ....................................................................... 65

Enhancing Color Images.................................................. 69

About Image Color and Color Channels ............................................ 69

Chapter 6 Using ScanGear Toolbox CS .............................. 71

About ScanGear Toolbox CS ........................................... 71

Installing ScanGear Toolbox CS ......................................................... 71

Uninstalling ScanGear Toolbox CS..................................................... 71

Starting ScanGear Toolbox CS......................................... 72

About the ScanGear Toolbox CS Bar ................................................. 72

GLOSSARY

INDEX

Setting Up ScanGear Toolbox CS .................................... 73

Adding a Button to the ScanGear Toolbox CS Bar ............................. 73

Removing a Button from the ScanGear Toolbox CS Bar ....................73

Enabling or Disabling Easy Acquire ...................................................74

Configuring Copy Settings .............................................. 75

Copying Acquired Images ................................................................. 76

Configuring Mail Settings ............................................... 78

Linking a Mail Application ................................................................ 79

Mailing Acquired Images .................................................................. 80

Configuring Fax Settings ................................................. 81

Linking a Fax Application .................................................................. 81

Faxing Acquired Images .................................................................... 82

Configuring Edit or Custom Settings.............................. 83

Linking an Edit or Custom Application .............................................. 84

Acquiring Images for Editing or Customized Applications ................. 85

Changing ScanGear Toolbox CS Preferences ................. 86

Selecting a ScanGear Toolbox CS Source .......................................... 86

Specifying ScanGear Toolbox CS Appearance ................................... 87

Cleaning Up Temporary Files ............................................................. 87

Using ScanGear Toolbox CS Shortcut Menus ....................................88

Canon Scanner Monitor .................................................. 89

Canon Monitor Utility Display ........................................................... 89

Right-Clicking the Canon Scanner Monitor Icon................................ 89

ScanGear Toolbox CS Settings Summary ........................ 90

Copy Image ......................................................................................90

Mail Image .......................................................................................90

Fax Image ......................................................................................... 91

Edit or Custom Image ....................................................................... 91

Chapter 7 Frequently Asked Questions............................. 92

Pre-Scan Checklist ............................................................ 92

“Top Ten” List .................................................................. 93

Troubleshooting Q & A ................................................... 94

Glossary ............................................................................ 98

Index .......................................................................... 109

CONTENTS

GLOSSARY

INDEX

Chapter 1

Introduction to ScanGear CS-S 4.3

Chapter 1

Introduction to ScanGear CS-S 4.3

Welcome to ScanGear CS-S

Welcome to Canon ScanGear CS-S 4.3 for Windows 95, Windows 98 and

Windows NT 4.0! Working with your imaging application, the ScanGear CS-S

provides flexible capabilities for scanning with your Canon scanner and

interfacing with a wide variety of applications and devices. ScanGear CS-S

also gives you prescan image enhancement features and lets you produce

professional-quality images from your scanner.

System Requirements

Before you run install ScanGear CS-S, make sure your hardware and software

meet the system requirements listed below.

Hardware

• CPU: i486 or greater (Windows 95/98)

Pentium or greater (Windows NT 4.0)

• RAM: 32 MB or greater; 64 MB recommended (Windows 95)

32 MB or greater; 64 MB recommended (Windows 98)

32 MB or greater; 64 MB recommended (Windows NT 4.0)

• Data files: 50 MB or greater free space

The size of scanned images varies depending on the image type selected.

Black and white scans have the smallest file size; high-resolution color

scans have the largest file size. As an example, a 4 inches x 6 inches color

photograph scanned in high-resolution color at 600 dpi needs about 25

MB of hard disk space. For more information about scanned image file

sizes, see Chapter 5, “Scanning Techniques.”

• Program files: 3 MB required

• Monitor: Super VGA, 256 or more colors, 800 X 600 or higher

resolution.

For previewing the best color scans, it is recommended that you make sure

your monitor’s color palette is set to Full Color (24 bit).

• ASPI-compatible SCSI card

A compatible SCSI card is bundled with your scanner.

CONTENTS

GLOSSARY

INDEX

Chapter 1

Introduction to ScanGear CS-S 4.3

Software

Windows®95, Windows®98 or Windows NT®4.0 is required to run the

ScanGear CS-S. It is also recommended that you install the latest available

Windows 95/98 or Windows NT 4.0 Service Pack.

About ScanGear CS-S

ScanGear CS-S has a number of powerful features that help you get the most

out of your scanner’s capabilities. Using ScanGear CS-S, you can preview an

image and make changes before the image is scanned and acquired by the

application you are using.

Feature List

The following list describes some of ScanGear CS-S’s features:

• Flexible, fully automatic image acquisition, and pre-scan image

manipulation prior to passing data to the image application

• Sophisticated, Windows-compliant user interface

• Full support of TWAIN 1.6 specifications

• Support for Automatic Document Feeder (ADF) option

• Text Enhanced mode for OCR(optical character recognition)

applications

• Canon ColorGearTM Color Matching software technology

About ScanGear CS-S “Windowless” Mode

The ScanGear CS-S data source runs with or without its window (user

interface, or UI) displayed, depending on the acquiring application. When an

application requests a scan and the ScanGear CS-S window does not appear

before the scan occurs, you can not use the ScanGear CS-S settings described

in this manual. The host application provides the settings, and you can change

the image after it is acquired. This is called “windowless” or “UI-less”

scanning mode.

CONTENTS

GLOSSARY

INDEX

Chapter 1

Introduction to ScanGear CS-S 4.3

About this User’s Guide

This user’s guide has been designed to provide you essential information

about ScanGear CS-S. In addition, the context-sensitive online help provides

basic information on using ScanGear CS-S.

Assumptions

This guide assumes that you are familiar with the Microsoft Windows 95/98

or Windows NT 4.0 graphical user interface.

If you have Windows 95 for example, run the Windows tutorial by doing the

following:

1. Click the Start button, then click Help.

2. On the Contents tab, click Tour: Ten Minutes to Using Windows to run the

Windows 95 tutorial.

Obtaining Customer Support

If you are having problems setting up or running ScanGear CS-S, first read

Chapter 7, “Frequently-Asked Questions,” in this manual, or check the online

help troubleshooting section. These sources list the most common problems

and suggest solutions.

If the solution is not found in the Troubleshooting list, contact your nearest

Canon Help Desk.

CANON (UK) LTD.

Canon House, Manor Road, Wallington, Surrey SM6 0AJ, United Kingdom

For technical support, please contact Canon Helpdesk.

Helpdesk:

P.O. Box 431, Wallington, Surrey SM6 0XU

TEL: (0990) 143 723

(Calls may be recorded)

FAX: (0990) 143-340

BBS: (0990) 143-350

For sales inquiries: (0121) 666-6262

CANON FRANCE S.A.

17, quai du Président Paul-Doumer

92414 Courbevoie Cedex, France

Tél.01 4199 7777

Fax.01 4199 7951

Hotline:

Tél.01 4199 7070

CONTENTS

GLOSSARY

INDEX

Chapter 1

Introduction to ScanGear CS-S 4.3

CANON DEUTSCHLAND GmbH

Postfach 528, 47705 Krefeld, Germany

CANON- Hotline-Service

Customer Support: (0 21 51)349-555

Info-Desk: (0 21 51)349-566

Mailbox: (0 21 51)349-577

Telefax: (0 21 51)349-588

CANON ITALIA S.p.A

Palazzo L, Strada 6,

20089 Milano Fiori-Rozzano (MI), Italy

TEL: 02/8248. 1

FAX: 02/8248. 4604

Pronto Canon 02/8249. 2000

http://www.canon.it

CANON OY AB

Kornetintie, 3, 00380 Helsinki, Finland

Puhelin: 010 544 20

Help Desk: 0600-0-22606 (maksu 14,80 mk/min)

Fax: 010 544 4571

CANON SVENSKA AB

Stensätravägen 13, S-127 88, Skärholmen, Sweden

CANON DANMARK

Vasekær 12, DK-2730 Herlev, Denmark

Hotline: 44 88 26 66

http://www.canon.dk

CANON NORGE AS

Hallagerbakken 110, Boks 33, Holmlia 1210 Oslo 12, Norway

Tlf: 2262 9321

FAX. 2262 0615

CANON BENELUX NEDERLAND N.V.

Neptunusstraat 1, 2132 JA Hoofddorp

The Netherlands

Tel: 023-5 670 123

Fax: 023-5 670 124

Helpdesk: 023-5 681 681

CANON BENELUX BELGIUM N.V./S.A.

Bessenveldstraat 7, 1831 Diegem, Belgium

Tel: 02 7220411

Fax: 02 7213274

Helpdesk: 02 7220404

CANON GmbH

Zetschegasse 11, 1232 Wien, Austria

Autres manuels pour CanoScan FB 1200S

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Canon Logiciel

Canon

Canon 3508B001 - PowerShot D10 Digital Camera Instructions de montage

Canon

Canon 9320A010 - EOS Rebel XSi Starter Manuel utilisateur

Canon

Canon EOS Rebel XS 18-55IS Kit Manuel utilisateur

Canon

Canon 2689B001 - DC 330 Camcorder Manuel utilisateur

Canon

Canon 2675B001 - SELPHY ES3 Photo Printer Guide de sécurité

Canon

Canon Powershot 500 Manuel utilisateur

Canon

Canon SD30 - PowerShot Digital ELPH Camera Manuel utilisateur

Canon

Canon 3421B001 - FS200 32GB Flash Memory Camcorder Manuel utilisateur

Canon

Canon EOS 5D Mark II Manuel utilisateur

Canon

Canon EOS 60D Manuel utilisateur

Canon

Canon PowerShot A460 Mode d’emploi

Canon

Canon Powershot A3100 IS Guide de démarrage rapide

Canon

Canon Networked Multi-Projection Guide de configuration

Canon

Canon VB-M40 Manuel utilisateur

Canon

Canon 2055B001 - DC 50 Camcorder Manuel utilisateur

Canon

Canon PowerShot A200 Instructions de montage

Canon

Canon 9540A003 - Optura 400 Camcorder Manuel utilisateur

Canon

Canon Vixia HG21 Manuel utilisateur

Canon

Canon EOS 5D - Focusing Screen Ee-A Manuel utilisateur

Canon

Canon POWERSHOT A75 Guide de sécurité

Canon

Canon 1236B001 - EOS Digital Rebel XTi Camera SLR Manuel utilisateur

Canon

Canon 3211B001 - PowerShot E1 Digital Camera Instructions de montage

Canon

Canon CR-1 Mark II Fiche technique

Canon

Canon FS 2710 Manuel utilisateur

Manuels Logiciel populaires d'autres marques

COMPRO

COMPRO COMPROFM Manuel utilisateur

Muratec

Muratec OFFICEBRIDGE ONLINE Manuel utilisateur

Oracle

Oracle Contact Center Anywhere 8.1 Manuel utilisateur

Adobe

Adobe 65007312 - Photoshop Lightroom Manuel

Avaya

Avaya NULL One-X for RIM Blackberry Manuel utilisateur

HP ProLiant BL420c Manuel utilisateur

PS Audio

PS Audio PowerPlay Manuel du propriétaire

Brady

Brady LOCKOUT PRO 3.0 Manuel de service

Avaya

Avaya Interaction Center Manuel utilisateur

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuel

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuel utilisateur

Oracle

Oracle Application 9i Manuel utilisateur

Acer

Acer RDM Manuel utilisateur

Samsung

Samsung Auto Backup Manuel utilisateur

Polycom

Polycom Vortex EF2201 Instructions d'installation et d'utilisation

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuel utilisateur

Novell

Novell SP2 - S Mode d’emploi

Lexmark

Lexmark Apps Manuel de service
