Canon Canoscan CS8000F Manuel utilisateur

CS8000F

SERVICE

MANUAL

Canon

shall be retained for reference purposes byAuthorized Service Facilities of Canon U.S.A. Its unauthorized use is prohibited.

OCT. 2002 JY8-1321-00Z

REVISION 0

SERVICE

MANUAL

CanoScan 8000F

JPN 8131A001AA

USA 8131A002AA

EUR 6683A003AA UYV000001-

UK 8131A004AA

AUS 8131A005AA

CAN/CLA 8131A006AA

Printed in Japan

Imprimè au Japon

Use of this manual should be strictly supervised

to avoid disclosure of confidential information.



2002 CANON INC. CANOSCAN 8000F REV.0 OCT. 2002 PRINTED IN JAPAN (IMPRIME AU JAPON)

CONTENTS

I. SPECIFICATIONS....................... 1-1

II. PARTS CONFIGURATION ........... 1-2

A. Front View .......................... 1-2

B. Back View ........................... 1-3

C. Rear View ............................ 1-3

III. SETTING UP THE SCANNER ...... 1-4

CHAPTER 2 : OPERATION AND TIMING

CHAPTER 1 : GENERAL DESCRIPTIONS

I. BASIC OPERATION .................... 2-1

A. Functions ............................ 2-1

B. Electrical System ................ 2-2

C. Main PCB Input and Output. 2-4

D. Document Scanning Sequence

........................................... 2-5

II. OPTICAL SYSTEM ..................... 2-6

A. Outline ................................ 2-6

B. Lamp Lighting Circuit ......... 2-7

C. FARE (Film Automatic Retouch-

ing and Enhancement) ......... 2-9

D. Motor Control Circuit ........ 2-11

III. IMAGE PROCESSING ............... 2-12

A. Outline .............................. 2-12

B. Image Processing............... 2-12

IV. CONTROL SYSTEM .................. 2-17

A. Control System Diagram.... 2-17

B. Main PCB .......................... 2-17

V. INTERFACE ............................. 2-18

A. Outline of USB Standard .... 2-18

B. Signal Definitions .............. 2-18

C. Interface Connection ......... 2-18

VI. POWER SUPPLY ....................... 2-19

A. Precautions ......................... 1-4

B. Unlocking the Lock Switch .. 1-4

C. Connecting the Cables ......... 1-5

D. Scanning ............................. 1-6

IV. CUSTOMER’S DAILY MAINTENANCE

........................................... 1-9

CHAPTER 3 : MECHANICAL SYSTEM

I. PARTS REPLACEMENT .............. 3-1

A. Precautions ......................... 3-1

II. EXTERNALS .............................. 3-2

A. Removing the Film Adapter Unit

........................................... 3-2

B. Removing the Top Cover and

Document Glass Unit ........... 3-3

C. Removing the Front Panel ... 3-6

III. PCBs ......................................... 3-8

A. Removing the Main PCB ...... 3-8

B. Removing the Button PCB ... 3-9

IV. OPTICAL SYSTEM ................... 3-10

A. Removing the Scanning Unit,

Pulley Unit, and Motor Unit 3-10

B. Cautions When Attaching the

Motor Unit ........................ 3-16

C. Cautions When Attaching the

Pulley Unit ........................ 3-18



2002 CANON INC. CANOSCAN 8000F REV.0 OCT. 2002 PRINTED IN JAPAN (IMPRIME AU JAPON)

I. INTRODUCTION ........................ 5-1

A. Initial Check ....................... 5-1

B. Others ................................. 5-1

II. TROUBLESHOOTING FLOWCHART

........................................... 5-2

A. Power LED Failure ............... 5-2

B. Communication Failure ....... 5-3

III. PROBLEM, CAUSE AND

CORRECTIVE ACTION ............... 5-4

A. Power LED Not Lighting....... 5-4

B. Communication Failure ....... 5-4

C. Scanning Unit Movement Failure

........................................... 5-5

D. Poor Image Quality .............. 5-5

E. Acoustic Noise ..................... 5-5

IV. CANON SCANNER TEST ............. 5-6

A. Outline ................................ 5-6

B. Operating Environment ....... 5-6

C. Functions ............................ 5-7

D. Functions Descriptions ....... 5-8

E. Error Message ................... 5-16

CHAPTER 5 : TROUBLESHOOTING

CHAPTER 4 : MAINTENANCE AND SERVICING

I. PERIODICAL REPLACEMENT

PARTS ....................................... 4-1

II. CONSUMABLE PARTS

DURABILITY .............................. 4-1

III. PERIODICAL SERVICING ........... 4-1

IV. SPECIAL TOOLS ........................ 4-1

V. SOLVENTS AND LUBRICANTS .... 4-1

CHAPTER 6 : PARTS CATALOG

FIGURE 001 .............................. 6-2 FIGURE 100 .............................. 6-4

APPENDIX

I. GENERAL CIRCUIT DIAGRAM .... A-1

II. MAIN PCB CIRCUIT DIAGRAM ... A-2

III. CCD PCB CIRCUIT DIAGRAM ..... A-9



2002 CANON INC. CANOSCAN 8000F REV.0 OCT. 2002 PRINTED IN JAPAN (IMPRIME AU JAPON)

CHAPTER 1

GENERAL DESCRIPTIONS

I. SPECIFICATIONS....................... 1-1

II. PARTS CONFIGURATION ........... 1-2

A. Front View .......................... 1-2

B. Back View ........................... 1-3

C. Rear View ............................ 1-3

III. SETTING UP THE SCANNER ...... 1-4

A. Precautions ......................... 1-4

B. Unlocking the Lock Switch .. 1-4

C. Connecting the Cables ......... 1-5

D. Scanning ............................. 1-6

IV. CUSTOMER’S DAILY MAINTENANCE

........................................... 1-9

CHAPTER 1

1 - 1



2002 CANON INC. CANOSCAN 8000F REV.0 OCT. 2002 PRINTED IN JAPAN (IMPRIME AU JAPON)

I. SPECIFICATIONS

Scanner Main Unit

Type : Flatbed image scanner

Scanning Part

Image sensor : 10,680-pixel 6-line CCD

Light source : Cold cathode fluorescent lamp

Document type : Sheet, Book

Document alignment position : Right-end corner

Max. document size : A4/Letter size (216 x 297mm)

Image output mode : Color 16-bit for RGB each

Grayscale (256 gradations)

Binary (black and white)

Optical resolution : 2400 dpi x 4800 dpi

Scanning time : 5.4ms/line (600 dpi or lower)

10.8ms/line (601 dpi or higher)

Film Scanning Part

Film type : Color and monochrome, negative and positive

Film size : 35mm sleeve (6 frames x 2)

35mm slide mount (4 frames)

Light source : Cold cathode fluorescent lamp

IR LED (for FARE function)

Scanning time : 5.4 to 172.8ms/line (automatically selected depending on

films)

Interface Part

Interface : USB connector (Universal Serial Bus 2.0)

FAU connector (6-pin)

Power connector (for AC adapter)

Front Panel

Scanner button : 4 buttons (COPY, SCAN, FILE, E-MAIL) on the scanner

unit

Others

Operating environment : Temperature : 10 to 35 degrees

Relative humidity : 10 to 90%RH

Air pressure : 613 to 1013 hPa

Power source : 100V to 120V

220V to 240V

Power consumption : 15W max. (during operation)

10W (during standby)

Dimensions : 284.0 (Width) x 498.0 (Depth) x 104.0 (Height) mm

(Height to the document glass: 72.0mm)

Weight : Approximately 4.6kg

CHAPTER 1

1 - 2



2002 CANON INC. CANOSCAN 8000F REV.0 OCT. 2002 PRINTED IN JAPAN (IMPRIME AU JAPON)

qDocument Cover

wProtective Sheet

eFilm Adapter Unit

rDocument Glass

tCOPY Button

ySCAN Button

uFILE Button

iE-MAIL Button

oAlignment Mark

II. PARTS CONFIGURATION

A. Front View

Figure 1-1

CHAPTER 1

1 - 3



2002 CANON INC. CANOSCAN 8000F REV.0 OCT. 2002 PRINTED IN JAPAN (IMPRIME AU JAPON)

B. Back View

Figure 1-2

C. Rear View

qFAU Cable

wFAU Connector

ePower Connector

rUSB Connector

qLock Switch

Figure 1-3

1234

CHAPTER 1

1 - 4



2002 CANON INC. CANOSCAN 8000F REV.0 OCT. 2002 PRINTED IN JAPAN (IMPRIME AU JAPON)

qLock Switch

B. Unlocking the Lock Switch

Scanning unit is locked by the lock switch to prevent a damage during transport. Unlock the

lock switch by pushing it toward the “unlock” mark to use the scanner.

Figure 1-4

Note : Ensure to lock the lock switch during transport.

III. SETTING UP THE SCANNER

A. Precautions

* Keep the scanner out of direct sunlight. Direct exposure to the sun or excessive heat may

cause damage to the scanner.

* Do not install the scanner in a humid or dusty environment.

* Use the supplied AC adapter only.

* Place the scanner securely on an even, flat surface. Tilted or uneven surface may cause a

mechanical problem.

* Keep the outer carton and packing material in case you may ship the scanner in the future.
