Canon TS8200 Series Manuel utilisateur

Guía de inicio

Lea primero Información de seguridad e

información importante (apéndice).

Conguración de la web

Hay vídeos e instrucciones detalladas

enel sitio web de Canon.

Congurar un ordenador

Congurar un teléfono inteligente

Getting Started

Read Safety and Important Information

(addendum) rst.

Web Setup

Detailed instructions and videos are

available on the Canon website.

Setup a Computer

Setup a Smartphone

TS8200_GS_book.indb 1 30/03/2018 10:30:24

Instalación de la impresora ...............................................................................................página 1

Conexión con el ordenador y con el teléfono inteligente o la tableta.......... página 4

Vídeos instructivos

Cómo sujetar la impresora

Installing the Printer................................................................................................................... page 1

Connecting with Computer and Smartphone/Tablet .........................................page 4

How to Hold Printer

Instructional Videos

TS8200_GS_book.indb 2 30/03/2018 10:30:25

ENGLISH

1. Box Contents

•

Power cord •

Ink tanks for setup

•

Safety and Important Information

•

Getting Started (this manual)

•

Setup CD-ROM

2. Removing Packing Materials

Important

When printing starts, the operation panel opens and the paper

output tray comes out automatically. Do not put things in front of

the printer.

1 Remove and dispose of the packing materials

from the device.

• Operating the printer while the orange tape and

protective lm are still on it causes malfunctions. Be

sure to remove them.

2 Open the scanning unit / cover and remove the

orange tape.

3 Close the scanning unit / cover.

• Lift up the scanning unit / cover briey, and then

close it.

Caution

Watch your ngers.

3. Turning on the Printer

1 Connect the power cord.

Back

Important

At this time, do not connect any other cables.

2 Open the operation panel and press the ON

button.

3 Scroll and tap to select your language, and then

tap OK.

4. Installing the Ink Tanks

1 Open the scanning unit / cover.

Caution

Do not touch the print head holder until it stops moving.

Setting up the printer

Web Setup

TS8200_GS_book.indb 1 30/03/2018 10:30:26

Setting up the printer

2 Remove the tape and lm on the ink tanks.

• Check that no tape is left over.

3 Slowly remove the orange cap.

Important

• Do not push both sides of the ink tank

with the Y-shape air hole blocked.

• Do not touch the red areas shown in the

gure.

4 Install the ink tanks.

• Insert the ink tank into the print head and press it

from above until it clicks.

5 Make sure that the color of the ink tank you

installed appears on the screen.

Important

If the color is not displayed on the screen even though you

have installed the ink tank, the color of the ink tank may be

wrong or you may have installed an ink tank, such as one

with a dierent model number, that is not supported by this

printer. Either install an ink tank for the correct color or use the

provided ink tank for setup.

6 Repeat steps 2 through 5 to install all the ink

tanks.

• Make sure that all the colors appear.

7 Close the scanning unit / cover.

• When you close the scanning unit / cover, the

internal operations start.

Caution

Watch your ngers.

5. Loading Paper

Check!

If there is any orange tape, remove

it.

1 Tap OK.

2 Pull the cassette out of the device and remove

the cassette cover.

Cassette cover

TS8200_GS_book.indb 2 30/03/2018 10:30:27

ENGLISH

3 Slide apart the paper guides.

• Slide the right paper guide to the right edge. Align

the front paper guide with the LTR or A4 mark.

4 Load paper.

• Load plain LTR or A4 size paper with the print side

facing down.

• Place the paper against the front paper guide, and

align the right paper guide to the width of the paper.

5 Load the cassette.

• Attach the cassette cover and put the cassette back

in.

• Look at it from the side to conrm it looks like the

diagram.

6 Tap OK.

7 Tap Next.

• Next, follow the onscreen instructions to continue

operations. During these operations, you will need

to make selections related to sending information.

Read "Sending Information To Canon" in Safety and

Important Information.

8 Tap Next.

TS8200_GS_book.indb 3 30/03/2018 10:30:27

6-a

6-b

page 6

Setting up the printer

Tap the Stop button,

and then select Do not

connect > Yes, in this

order.

Computer Computer and

smartphone

Smartphone

No device

Connecting to a Computer

If you are using multiple computers, perform these steps on each computer. There are

two methods, " Online Setup" and " Using the Setup CD-ROM (Windows Only)

Provided".

1 Access the Canon website from a

computer.

2 Select Set Up.

3 Enter your printer's model name and

click Go.

4 Click Start.

5 Click If you have already prepared

your printer, go to Connect.

Note

When you are using a computer with Windows

(except for Windows 10 S) or macOS, proceed to

the next step. When you are using a computer with

another OS, continue the setup by following the on-

screen instructions.

6 Click Download.

• The setup le is downloaded to your

computer.

7 Run the downloaded le.

8 Proceed to step 9 on page 5.

Online Setup

What device are you connecting?

Select a device and follow the relevant section.

TS8200_GS_book.indb 4 30/03/2018 10:30:27

ENGLISH

1 Insert the Setup CD-ROM

into your computer.

2 Follow the instructions for your version

of Windows.

Windows 10/Windows 8.1

aClick on the following message when it

appears on the right-hand side of your

computer screen.

Note

If the message does not appear (or is no longer

visible), click the File Explorer icon in the

taskbar. On the left-hand side of the window, click

This PC. Double click the CD icon that is

displayed on the right-hand side (when the

content of the CD is displayed, and then double

click Msetup4.exe). Proceed to c.

bClick Run

Msetup4.exe.

cIf the User Account Control dialog box

appears, click Yes .

Windows 7

aClick Run Msetup4.exe.

• When the AutoPlay screen appears, click

Run Msetup4.exe.

Note

If the AutoPlay screen does not appear, in the

Start menu, click Computer. On the right-hand

side of the window, double click the CD icon

(when the content of the CD is displayed, double

click Msetup4.exe).

bIf the User Account Control dialog box

appears, click Continue.

3 Proceed to step 9 below.

Using the Setup CD-ROM (Windows Only) Provided

9 Click Start Setup.

10 Follow the on-screen instructions.

• These operations may take some time.

11 When the following screen appears, click Exit.

Your printer is now connected to your computer.

To connect a smartphone as well, see

"6-b.

Connecting to a Smartphone" on page 6.

TS8200_GS_book.indb 5 30/03/2018 10:30:28

6-b

Setting up the printer

1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.

Note

You can also access the Canon website by scanning the QR code shown on the right to

download the app.

Search for "Canon PRINT" in the App Store.

Search for "Canon PRINT" in Google Play.

2 Check the printer's screen as you proceed through the steps.

• If the above screen appears,

• If appears,

• If does not appear,

Note

• The printer's screen turns o when the printer is idle for 10 minutes. Tap the touch screen to turn on the screen.

• If appears, The printer cannot communicate by Wi-Fi connection. For details, see "Frequently Asked Questions" at

"http://ij.start.canon".

Connecting to a Smartphone

If you are using multiple smartphones, perform these steps on each smartphone.

Prepare the following before starting.

aEnable the Wi-Fi setting on your smartphone*.

bConnect your smartphone to the wireless router* (if you have a wireless router).

* See your smartphone and wireless router manuals regarding these procedures for more details.

3 Open the installed app.

4 Follow the on-screen instructions to add

your printer.

5 Check that the following screen appears.

Your printer is now connected to your

smartphone. To print photos, see "Loading

Photo Paper" on page 8.

TS8200_GS_book.indb 6 30/03/2018 10:30:28

ENGLISH

3 Tap Settings on your smartphone's

home screen, and tap Canon_ij_XXXX

in the Wi-Fi settings.

Note

If Canon_ij_XXXX does not appear, follow the

procedure in , and then search for Canon_ij_

XXXX again.

4 Open the installed app.

• The printer is registered with the

most appropriate connection

method for the environment

you are using.

5 Check that the following screen appears.

3 Open the installed app.

• The printer is registered with the

most appropriate connection

method for the environment

you are using.

Note

If a message saying "No printer has been added.

Perform printer setup?" does not readily appear

after starting the application, follow the procedure in

, and then return to smartphone operations.

4 Check that the following screen appears.

Procedures vary for iOS and Android. Follow the instructions for your operating system.

3 Tap on the printer's touch screen.

4 Press and hold the on the HOME

screen for about 3 seconds.

5 When the following screen appears,

tap OK.

6 Proceed to .

Your printer is now connected to your smartphone. To print photos, see "Loading Photo Paper" on page 8.

TS8200_GS_book.indb 7 30/03/2018 10:30:28

Loading Photo Paper

1 Open the rear tray cover and extend the paper

support.

2 Open the feed slot cover and slide the right-

hand side paper guide to the far right.

3 Load several sheets of photo paper with the

print side facing up and slide the side paper

guide against the edge of the paper stack.

4 Close the feed slot cover.

• Follow the on-screen instructions to set information

for the loaded paper.

1 Turn on the printer.

2 Load several sheets of photo paper.

3 Insert the memory card into the card slot.

4 Flick right and left through the photos and

select one.

5 Tap the Color button to start printing.

Printing Photos Saved on a Memory Card

Photo paper can only be loaded in the rear tray.

TS8200_GS_book.indb 8 30/03/2018 10:30:29

Autres manuels pour TS8200 Series

Table des matières

Langues :

Autres manuels Canon Imprimante

Canon

Canon PIXMA MX431 Manuel utilisateur

Canon

Canon imagePRESS C7000VP Series Manuel technique

Canon

Canon SELPHY CP400 Manuel utilisateur

Canon

Canon IVY CLIQ CV-123 Manuel utilisateur

Canon

Canon i960 Series Manuel utilisateur

Canon

Canon imageRUNNER ADVANCE 6575i Guide d'installation

Canon

Canon PIXMA G2020 Series Guide de configuration

Canon

Canon PIXMA MG6120 Series Manuel utilisateur

Canon

Canon LASER SHOT LBP3500 Manuel utilisateur

Canon

Canon i-SENSYS LBP6680x Manuel utilisateur

Canon

Canon PIXMA GM4000 Series Manuel utilisateur

Canon

Canon PIXMA G3200 Guide de configuration

Canon

Canon Pro9500 Mark II Series Manuel utilisateur

Canon

Canon Arizona 1300 Series Manuel utilisateur

Canon

Canon PIXMA TS6151 Guide de configuration

Canon

Canon PIXMA G7000 Series Manuel utilisateur

Canon

Canon Color Laser Shot LBP-2160 Manuel utilisateur

Canon

Canon i470D Series Guide de configuration

Canon

Canon i900D Series Manuel utilisateur

Canon

Canon Mk2500 Manuel utilisateur

Canon

Canon SELPHY ES30 Manuel utilisateur

Canon

Canon MG6800 Series Manuel utilisateur

Canon

Canon imagePROGRAF iPF680 Manuel utilisateur

Canon

Canon TS700 Series Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
