Canon TR7000 Series Manuel utilisateur

Lea primero Información de seguridad

e información importante (apéndice).

Guía de inicio

Getting Started

Read Safety and Important Information

(addendum) ﬁrst.

Cómo sujetar la impresora

Conexión con un ordenador, teléfono inteligente o tableta....................... página 4

Instalación de la impresora ............................................................................................... página 1

Installing the Printer................................................................................................................... page 1

Connecting to a Computer, Smartphone or Tablet...............................................page 4

Holding the Printer

ENGLISH

Setting Up the Printer

1. Box Contents

•

FINE Cartridges

Color Black

•

Power Cord

•

Safety and Important Information

•

Getting Started (this manual)

2. Removing Packing Materials

1 Remove and dispose of any packing materials

and orange tape.

2 Open the scanning unit / cover, remove and

dispose of the orange tape and protective

material inside.

3 Close the scanning unit / cover.

• Open the scanning unit / cover fully and then close it.

Caution

Watch your ngers.

3. Turning on the Printer

1 Connect the power cord.

Back

2 Press the ON button.

3 Use the {and }buttons to select a language,

and then press the OK button.

For Setup, visit the URL

https://ij.start.canon/TR7020

or scan the code with your mobile device

•

For users without an Internet-connected environment, follow the instructions below.

Setting Up the Printer

Installing the FINE Cartridges

1 Open the scanning unit / cover.

Caution

Do not touch the FINE cartridge holder until it stops moving.

2 Pinch and open the ink cartridge locking cover

on the left-hand side.

3 Remove the Color FINE cartridge from the

container and remove the protective tape.

aColor

Important

• Do not touch the ink on the protective tape. It could stain

your hands or surrounding objects.

• Do not touch the areas shown in the

gure. Otherwise, the printer may not

print correctly.

4 Set the Color FINE cartridge in the FINE

cartridge holder.

Important

Do not bump the FINE cartridge.

Doing so may cause a malfunction.

5 Push down the ink cartridge locking cover ﬁrmly

until it snaps into place to close it completely.

6 Repeat steps 2 to 5 and install the Black FINE

cartridge as well, on the right-hand side.

7 Close the scanning unit / cover.

• The printer will start initializing.

Caution

Watch your ngers.

ENGLISH

5. Loading Paper

1 Press the OK button.

2 Remove the cassette from the printer.

3 Slide apart the paper guides.

• Slide the right paper guide to the right edge. Align

the front paper guide with the Letter or A4 mark.

4 Load paper.

• Load 2 or more sheets of Letter or A4 sized plain

paper.

• Place the paper against the front paper guide, and

align the right paper guide to the width of the paper.

a b

5 Replace the cassette.

6 Pull out the paper output tray.

7 Press the OK button.

Note

The alignment process prints out two double sided sheets.

Do not pull out the paper or use the printer until alignment is

complete.

8 Check that the following screen appears.

If you will use the printer without connecting any other

devices, setup is now complete.

Select the connection method that best matches how you

will use the printer.

• To use the printer without connecting to any other

devices

Setup is now complete.

• To use the printer connecting to a computer or

smartphone

Proceed to the next page.

6-a

Setting Up the Printer

Computer Smartphone

Computer and

smartphone

Connecting to a Computer

If you are using multiple computers, perform these steps on each computer.

1 Access the Canon website from your

computer.

2 Select Set Up.

3 Enter your printer's model name and

click Go.

4 Click Start.

5 Click (B) Connecting to a Computer/

Smartphone.

• The following steps are for Windows users.

6 Click Download.

7 Run the downloaded ﬁle.

8 Click Start Setup.

9 Follow the on-screen instructions.

• These operations may take some time.

• To connect to a smartphone as well, see "6-b.

Connecting to a Smartphone" on page 5.

What device are you connecting?

6-a. Connecting to a Computer

6-b

ENGLISH

6-b. Connecting to a Smartphone

1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.

• Search for "Canon PRINT" in App Store, or Google Play.

• Access the Canon website to download the app.

2 Open the installed app, and follow the on-screen instructions in the app to add your

printer.

Once you have added your printer, you can print from your smartphone.

To print photos, see "Loading Photo Paper" on page 6.

Connecting to a Smartphone

If you are using multiple smartphones, perform these steps on each smartphone.

Loading Photo Paper

1 Open the rear tray cover and extend the paper

support.

2 Open the feed slot cover and slide the right-

hand side paper guide to the far right.

3 Load several sheets of photo paper with the

print side facing up.

4 Align the paper guide to the paper, and then

close the feed slot cover.

• Follow the on-screen instructions to set information

for the loaded paper.

Copying

Photo paper can only be loaded in the rear tray.

1 Turn on the printer.

2 Load Letter or A4 sized plain paper.

3 Open the document cover and place the

document face down on the platen. Align the

document with the alignment mark ( ).

4 Close the document cover.

5 Press the OK button.

6 Select Copy settings, and then press the OK

button.

7 Specify print settings using the {, }and OK

buttons.

8 Press the Start button.

ESPAÑOL

Instalación de la impresora

1. Contenido de la caja

•

Cartuchos FINE

Color Negro

•

Cable de alimentación

•

Información de seguridad e información

importante

•

Guía de inicio (este manual)

2. Retirar los materiales de

protección

1 Retire y tire los materiales de protección y la

cinta naranja.

2 Abra la cubierta/unidad de escaneado, retire y

tire la cinta naranja y el material de protección

que hay dentro.

3 Cierre la cubierta/unidad de escaneado.

• Abra la cubierta/unidad de escaneado

completamente y luego ciérrela.

Precaución

Tenga cuidado con

los dedos.

3. Encender la impresora

1 Conecte el cable de alimentación.

Atrás

2 Pulse el botón ACTIVADO (ON).

3 Utilice los botones {y }para seleccionar un

idioma y, a continuación, pulse el botón OK.

Para la conﬁguración, visite la URL

https://ij.start.canon/TR7020

o bien escanee el código con su dispositivo móvil

•

Los usuarios que no dispongan de un entorno conectado a Internet pueden seguir las instrucciones que se

proporcionan a continuación.

Instalación de la impresora

Instalar los cartuchos FINE

1 Abra la cubierta/unidad de escaneado.

Precaución

No toque el soporte de cartucho FINE hasta que se detenga.

2 Pellizque y abra la tapa de bloqueo del cartucho

de tinta del lado izquierdo.

3 Retire el cartucho FINE de color del contenedor

y retire la cinta protectora.

aColor

Importante

• No toque la tinta de la cinta protectora. Podría manchar sus

manos o los objetos que se encuentran a su alrededor.

• No toque las áreas que se muestran

en la imagen. Si lo hace, puede que la

impresora no imprima correctamente.

4 Coloque el cartucho FINE de color en el soporte

de cartucho FINE.

Importante

No golpee el cartucho FINE. Si se

golpea, puede funcionar mal.

5 Empuje hacia abajo la tapa de bloqueo del

cartucho de tinta ﬁrmemente hasta que encaje

en su lugar para cerrarla por completo.

6 Repita los pasos del 2 al 5 e instale el cartucho

FINE negro también en el lado derecho.

7 Cierre la cubierta/unidad de escaneado.

• La impresora comenzará a iniciarse.

Precaución

Tenga cuidado con

los dedos.
