Cover

Printer User Guide

ENGLISH

©CANON INC. 2013 CDD-E538-010

• Make sure you read this guide, including the “Safety

Precautions” section, before using the printer.

• Reading this guide will help you learn to use the printer

properly.

• Store this guide safely so that you can use it in the

future.

• Click the buttons in the lower right to access other pages.

: Next page

: Previous page

: Page before you clicked a link

• To jump to the beginning of a chapter, click the chapter

title at right.

From chapter title pages, you can access topics by

clicking their titles.

COPY

Package Contents

Before use, make sure the following items are included in the package.

If anything is missing, contact the retailer where you purchased the printer.

□ SELPHY Printer □ Compact Power

Adapter

CA-CP200 B

□ Power Cord

□ Paper Cassette

PCP-CP400 □ SELPHY CP820

Solution Disk □ Getting Started

□ Cleaner Unit*1□ Dust Protection Cover

(For Back)*

□ Dust Protection Cover

(For Front)*1

*1 May not be included in some regions.

*2 May not be included in some regions. Purchase if needed.

Contents

Part Names

Basic Operations

Print Settings

Printing via USB

Cable

Troubleshooting

Appendix

Cover

Ink and Paper (Sold Separately)

Before use, purchase a Color Ink / Paper Set.

Color Ink / Paper Set Necessary Paper

Cassette

Product Name Paper Size Number of

Possible

Prints

Color Ink / Paper Set KP-36IP

(Postcard)

Postcard Size

Paper Cassette

PCP-CP400

(included with

SELPHY)

Color Ink / Paper Set RP-54

(Photo Paper) 54

Color Ink / Paper Set

RP-108 (Photo Paper) 108

Color Ink / Paper Set

RP-1080V (Photo Paper) 1080

Color Ink / Paper Set KP-72IN

(Photo Paper) 72

Color Ink / Paper Set KP-108IN

(Photo Paper) 108

Color Ink / Paper Set KL-36IP

L Size

36 Paper Cassette

PCPL-CP400*

Color Ink / Paper Set KL-36IP

3-pack 108

Color Ink / Paper Set KC-36IP

Card Size

Paper Cassette

PCC-CP400*

Color Ink / Label Set KC-18IF

(Full-Page Label) 18

Color Ink / Label Set KC-18IL

(8 Labels per Page) 18

Color Ink / Label Set KC-18IS

(Square Labels) 18

* Purchase with the Color Ink / Paper Set.

Accessory availability varies by region.

COPY

Contents

Part Names

Basic Operations

Print Settings

Printing via USB

Cable

Troubleshooting

Appendix

Cover

Safety Precautions

• Before using the product, please ensure that you read the safety

precautions described below. Always ensure that the product is used

correctly.

• The safety precautions noted on the following pages are intended

to prevent injuries to yourself and other persons, or damage to the

equipment.

• Be sure to also check the guides included with any separately sold

accessories you use.

Warning Denotes the possibility of serious injury or death.

• Store this equipment out of the reach of children and infants.

Mistakenly putting the power cord around a child’s neck could result in

asphyxiation.

• Use only recommended power sources.

• Do not attempt to disassemble, alter, or apply heat to the product.

• Avoid dropping or subjecting the product to severe impacts.

• To avoid the risk of injury, do not touch the interior of the product if

it has been dropped or otherwise damaged.

• Stop using the product immediately if it emits smoke, a strange

smell, or otherwise behaves abnormally.

• Do not use organic solvents such as alcohol, benzine, or thinner to

clean the product.

• Do not let the product come into contact with water (e.g. sea water)

or other liquids.

• Do not allow liquids or foreign objects to enter the product.

This could result in electrical shock or re.

If liquid comes into contact with the product, unplug it from the outlet and

consult your retailer or a Canon Customer Support Help Desk.

Before Use

• Images printed with this product are to be used for personal enjoyment.

Unauthorized printing of copyrighted material is prohibited.

• The printer warranty is valid only in the country or area of purchase. In

case of printer problems while abroad, return to the area of purchase

before contacting a Canon Customer Support Help Desk.

• Although the LCD monitor is produced under extremely high-precision

manufacturing conditions and more than 99.99% of the pixels meet

design specications, in rare cases some pixels may be defective or may

appear as red or black dots. This does not constitute a malfunction or

affect printed images.

• The LCD monitor may be covered with a thin plastic lm for protection

against scratches during shipment. If so, remove the lm before use.

Conventions in This Guide

• In this guide, the printer is referred to as “SELPHY” or “the printer”.

• Icons are used in this guide to represent buttons on SELPHY. Refer to

“Controls” (=

6) for details.

• On-screen text or icons are shown in square brackets, as in [ ].

• : Important information you should know

• : Notes and tips for expert use

• =xx: Pages with related information (In this example, “xx” represents a

page number.)

• Instructions in this guide apply to the printer under default settings.

• For convenience, all supported memory cards are simply referred to as

“memory card”.

COPY

Contents

Part Names

Basic Operations

Print Settings

Printing via USB

Cable

Troubleshooting

Appendix

Cover

This may cause overheating of or damage to the printer or adapter, which

may result in electric shock, burns or other injury, or re.

High temperature may deform the product or adapters.

Caution Denotes the possibility of damage to the equipment.

• Unplug the product from the power outlet when you are not using it.

• Do not place anything, such as cloth, on top of the printer while in

use.

Leaving the unit plugged in for a long period of time may cause it to

overheat and distort, resulting in re.

• Never reuse paper for printing, even if most of the paper is blank, as

shown.

Reusing paper may damage the printer if paper jams or the ink sheet

adheres to the paper.

• Do not unplug the printer while it is printing.

If you accidentally turn the printer off while printing, restart it and wait until

the paper is ejected. If paper jams and cannot be removed, contact your

retailer or a Canon Customer Support Help Desk. Do not attempt to remove

jammed paper by force, which may damage the printer.

• Do not use the printer near motors or other devices that generate

strongmagneticelds,orindustyenvironments.

This may damage the printer or cause malfunction.

• Do not touch the printer or the power plug during thunderstorms.

This could result in electrical shock or re. Immediately stop using the

equipment and distance yourself from it.

• Unplug the power cord periodically, and using a dry cloth, wipe away

any dust or dirt that has collected on the plug, the exterior of the

power outlet, and the surrounding area.

• Do not handle the power cord with wet hands.

• Do not use the equipment in a manner that exceeds the rated

capacity of the electrical outlet or wiring accessories. Do not use if

the power cord or plug are damaged, or not fully plugged into the

outlet.

• Do not allow dirt or metal objects (such as pins or keys) to contact

the terminals or plug.

• Do not cut, damage, alter, or place heavy items on the power cord.

This could result in electrical shock or re.

• Do not play the supplied CD-ROM(s) in any CD player that does not

support data CD-ROMs.

It is possible to suffer hearing loss from listening with headphones to the

loud sounds of a CD-ROM played on a music CD player. Additionally,

playing the CD-ROM(s) in an audio CD player (music player) could damage

the speakers.

Caution Denotes the possibility of injury.

• Do not stick any part of your hand into the printer interior.

• Place SELPHY in a safe location where people will not trip over the

power cord.

Failure to do this may lead to injury or printer damage.

• Avoid using, placing, or storing the product in the following places:

•Places subject to direct sunlight

•Places subject to temperatures above 40 °C (104 °F)

•Humid or dusty places •Places subject to strong vibration

COPY

Package Contents .........................2

Ink and Paper (Sold Separately)....2

Before Use.....................................3

Conventions in This Guide.............3

Safety Precautions.........................3

Contents.........................................5

Part Names....................................5

Basic Operations ............. 7

Initial Preparations.........................8

Supported Cards/Images.............13

Printing Images............................14

Storing Prints...............................17

After Printing................................17

Print Settings................. 19

Printing All Images.......................20

Cropping Images .........................21

Printing ID Photos........................22

Adjusting Settings........................24

Printing via USB

Cable .............................. 31

Printing from a Computer.............32

Printing from a Camera................34

Troubleshooting............. 35

Appendix ........................ 38

Printing without a Power Outlet ...39

Specications...............................40

Handling and Maintenance ..........42

Cover

Basic Operations

Print Settings

Printing via USB

Cable

Troubleshooting

Appendix

Contents

Part Names

Memory Card Slot (=

13)

Paper Cassette

Compartment (=

10)

Paper Cassette

Compartment Cover

10)

Ink Cassette Lock

15)

Ink Cassette

Compartment (=

10)

Ink Cassette

Compartment Cover

10)

Camera / Flash Drive

USB Port (=

16, 34)

DC IN (Power Input)

Terminal (=

10)

Computer USB Port

32)

Air Vent (=

42)

Paper Ejection Slot Security Slot*

* Security cables, such as a Kensington lock, can be attached to this slot.

Contents

COPY

Cover

Contents

Basic Operations

Print Settings

Printing via USB

Cable

Troubleshooting

Appendix

Part Names

On-Screen Information

File number

Print settings (=

25 – 30)

(Dimmed when unavailable)

Total prints

Prints of current image

Port/slot in use

13, 16)

Cropping

21)

Paper orientation

Shooting date of current image

Print size

(Postcard size shown here)

Switching Display Modes

Press the <-> button for full-screen display at higher resolution. The print

area is outlined. Press the <-> button to restore single-image display.

Press the <0> button to view nine images at once. Press the <0> button

to restore single-image display.

Controls

Icons in This

Guide Name Function

–Screen (LCD monitor) Displays images, setting screens, or error

messages (=

37)

<q>Power button Turns SELPHY on or off (=

12)

<k>MENU button Displays the menu screen (=

12)

–EDIT button Displays the editing menu and rotates the

crop frame

<o>OK button Conrms the selected item

<u>Up / More prints button Species the print quantity or selects

setting items

<d>Down / Fewer prints button

<l>Left button Switches images, changes setting values

<r>Right button

<->Enlarge button Switches display modes, enlarges the

crop frame

<0>Reduce button Switches display modes, reduces the

crop frame

<v>Back button Restores the previous screen (=

24),

cancels printing (=

15)

<p>Print button Starts printing (=

15)

COPY

Cover

Contents

Part Names

Print Settings

Printing via USB

Cable

Troubleshooting

Appendix

Basic Operations

This chapter introduces basic printing operations such as preparing the printer, selecting images

on a memory card, and specifying the number of prints.

Initial Preparations....................................................................................8

Preparing the Ink Cassette................................................................................8

Preparing the Paper Cassette...........................................................................9

Loading the Cassettes ....................................................................................10

Installing and Plugging in SELPHY.................................................................10

Attaching the Dust Protection Covers.............................................................11

Display Language ...........................................................................................12

Supported Cards/Images........................................................................13

Checking Supported Memory Cards and the Slot to Use ...............................13

Supported Images...........................................................................................13

Printing Images.......................................................................................14

Avoiding Left Over Paper................................................................................16

Printing from USB Flash Drives ......................................................................16

Making One Print from a Selected Image.......................................................16

Storing Prints ..........................................................................................17

After Printing...........................................................................................17

Regular Cleaning ............................................................................................18

COPY

Cover

Contents

Part Names

Print Settings

Printing via USB

Cable

Troubleshooting

Appendix

Basic Operations

Initial Preparations

Prepare for printing as follows. This example shows a Postcard-size (4x6

in.) Color Ink / Paper Set (sold separately, =

2), but the same steps are

followed for other sizes.

Avoid getting dust on ink sheets or paper, which may cause banding or

damage the printer (=

4).

Preparing the Ink Cassette

Check the ink cassette and ink

sheet.

 Holding the ink cassette without touching

the ink sheet, check the size (such as

“Postcard (4x6 in.) Size” or “Card Size”)

to make sure it matches the size of paper

you will print on.

 Make sure the ink sheet is taut. Loose

ink sheets may tear when loaded. If

the sheet is loose, turn the sprocket as

shown.

 For an ink cassette that has a lock on

the bottom, press the lock (as shown)

to release it as you turn the sprocket to

make the sheet taut.

Ink sheet

• Do not hold the ink cassette with wet hands. Avoid touching the

ink sheet, and avoid getting dust on it. Dirt or moisture may cause

banding or affect print quality, tear ink sheets and prevent printing,

or damage the printer (=

4).

• When turning the sprocket, turn it gently, only until the sheet is taut.

Forcing the sprocket or overtightening it may tear ink sheets and

prevent printing, or SELPHY may run out of ink before paper.

• Never reuse ink cassettes, which may damage the printer or cause

malfunction.

COPY

Cover

Contents

Part Names

Print Settings

Printing via USB

Cable

Troubleshooting

Appendix

Basic Operations

Preparing the Paper Cassette

1Check the paper size.

 Check the size on the paper cassette

(such as “Postcard” or “Card Size”) to

make sure it matches the size of the ink

cassette.

2Open both covers.

 There are two layers of covers. First open

the outer cover ( ), and then the inner

cover ( ).

3Load the paper.

 Load the paper in the paper cassette.

 The paper cassette holds up to 18

sheets. Loading 19 or more sheets may

damage the printer or cause malfunction.

 Holding the paper as shown, load it with

the glossy side up. (Do not touch the

glossy side of the paper, which may affect

print quality.)

 Remove any protective sheets from

the paper, and load only paper into the

cassette.

 When making postcard prints with space

for a stamp, load the paper with the

stamp area facing as shown.

Glossy

side

4Close the inner cover.

 Close the inner cover rmly until it clicks

into place. Leave the outer cover open

when printing.

Printing on L-Size Paper

 You can use Paper Cassette PCPL-

CP400 (sold separately) to print on L-size

paper.

 To print on postcard paper, remove the

adapter as shown.

• Use only paper in a genuine Canon Color Ink / Paper Set for

SELPHY CP printers. Other paper, such as regular postcards or

paper for SELPHY ES printers, cannot be used.

• Never do the following, which may damage the printer or cause

malfunction.

- Loading paper upside-down, with the glossy

and back sides reversed

- Bending or separating paper at the

perforations before printing

- Using label paper whose upper label surface

is peeling off or has been partially pulled up

- Writing on paper before printing

- Reusing paper, as by printing on blank areas

4)Springs

COPY

Cover

Contents

Part Names

Print Settings

Printing via USB

Cable

Troubleshooting

Appendix

Basic Operations

• Do not touch the springs on the paper cassette.

Accidentally bending the springs may prevent efcient paper

feeding.

• Note that one spring is attached in the center on the top of card-size

paper cassettes.

• Avoid touching or rubbing the glossy, printing side of the paper. Do

not handle paper with wet hands, and keep paper free of dust. Dirt

or moisture may cause banding or affect print quality, or damage the

printer (=

4).

Loading the Cassettes

1Open the covers.

 Open the ink and paper compartment

covers.

2Load the ink cassette.

 Insert the ink cassette into the printer in

the direction of the arrow on the cassette

until it clicks into place.

 Close the ink cassette compartment

cover.

3Load the paper cassette.

 Making sure the outer cover is open

9), insert the paper cassette all

the way into the compartment.

Installing and Plugging in SELPHY

1Choose the right place to put

SELPHY.

 Place the printer on a table or other

at, stable surface. Never place the

printer on an unstable or tilted surface.

 Keep the printer away from sources

of electromagnetism or strong

magnetism.

 Leave at least 10 cm (4 in.) of open

space around the printer.

 Leave more open space behind the

printer than the length of paper used,

so that the paper can pass in and out

of the printer freely when printing.

2Plug the adapter cord into

SELPHY.

 Insert the adapter plug fully into the

power inlet on SELPHY.

3Connect the power cord.

 Connect the power cord to the compact

power adapter, and then plug the other

end into a power outlet.

Minimum

10 cm (4 in.)

Minimum

10 cm

(4 in.)

More than

length of

paper

COPY

Table des matières

Autres manuels Canon Imprimante

Canon

Canon MB5000 Series Manuel utilisateur

Canon

Canon imagePROGRAF iPF6400S Series Manuel utilisateur

Canon

Canon CLC 4000 Manuel utilisateur

Canon

Canon imagePROGRAF iPF6450 Guide de l'utilisateur

Canon

Canon PIXMA iX4000 Manuel utilisateur

Canon

Canon imageCLASS LBP122dw Manuel utilisateur

Canon

Canon imagePRESS C7000VP Series Manuel utilisateur

Canon

Canon Pixma MG2400 Series Manuel utilisateur

Canon

Canon TS8250 Guide de configuration

Canon

Canon imageCLASS MF419dw Manuel utilisateur

Canon

Canon LBP-2000 Manuel utilisateur

Canon

Canon Selphy CP600 Manuel de service

Canon

Canon PIXMA TS5300 Series Manuel utilisateur

Canon

Canon imagePROGRAF TC-20 M Manuel utilisateur

Canon

Canon Folder Professional 6011 Manuel utilisateur

Canon

Canon imageRUNNER 105 Instructions d'installation et d'entretien

Canon

Canon imageCLASS D1120 Instructions de montage

Canon

Canon Pixma IP4950 Manuel utilisateur

Canon

Canon varioPRINT 6000 TITAN Series Manuel utilisateur

Canon

Canon MultiPASS C2500 Manuel utilisateur

Canon

Canon PIXMA MX420 Series Manuel utilisateur

Canon

Canon TZ-5300 Manuel utilisateur

Canon

Canon iPF655 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon PIXMA MX340 Series Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
