Canon PIXMA PRO-200 Manuel utilisateur

Connexion à un smartphone

Connexion à un ordinateur

Des instructions détaillées et des vidéos

sont disponibles sur le site Web de Canon.

Conguration en ligne

Commencez par lire Sécurité et informations

importantes (addendum).

Démarrage

Getting Started

Read Safety and Important Information

(addendum) rst.

Online Setup

Detailed instructions and videos are

available on the Canon website.

Connecting to a Computer

Connecting to a Smartphone

Accéder

Instructions vidéo

Connexion à un ordinateur, un smartphone ou une tablette.........................page 7

Installation de l'imprimante..................................................................................................page 1

Installing the Printer...................................................................................................................page 1

Connecting to a Computer, Smartphone or Tablet...............................................page 7

Instructional Videos

ENGLISH

Setting Up the Printer

25 cm

(9.8 inches)

40 cm (15.7 inches)

Installation Space

1. Box Contents

•

Ink Tanks for setup

•

Print Head

•

Multi-purpose Tray

•

Power Cord

•

Setup CD-ROM

•

Safety and Important Information

•

Getting Started (this manual)

2. Removing Packing Materials

1 Remove and dispose of any packing materials

and orange tape.

2 Open the top cover, remove and dispose of the

orange tape and protective material inside.

3 Close the top cover.

3. Turning on the Printer

1 Connect the power cord.

Back

Important

At this time, do not connect any other cables.

2 Press the ON button.

Online Setup

Setting Up the Printer

3 Use the {, } and OK buttons to select a

language.

4 Press the OK button.

5 Set the date and time, and then press the OK

button.

4. Installing the Print Head

1 Open the paper output tray.

2 Open the top cover.

Caution

Do not touch the print head holder until it stops moving.

3 Firmly raise the print head lock lever until it

stops.

4 Remove the print head from its package.

Important

There may be some transparent or light color ink on the inside

of the bag the print head comes in - this has no eect on print

quality. Be careful not to get ink on yourself when handling

these items.

ENGLISH

5 Remove the protective cap.

6 Set the print head in the print head holder.

7 Lower the print head lock lever completely.

Important

Once you have installed the print head, do not remove it

unnecessarily.

5. Installing the Ink Tanks

1 Remove the tape and lm on the ink tank.

• Check that no tape or lm is left.

2 Twist the orange cap, and then remove.

Important

• Do not squeeze the ink tank

with the L-shaped air hole

blocked.

• Do not touch the areas

shown in red.

3 Install the ink tank.

• Insert the ink tank into the print head and press down

until it clicks.

Setting Up the Printer

4 Check that the color of the ink tank you installed

appears on the screen.

Important

If the color is not displayed on the screen even though you

have installed the ink tank, the color of the ink tank may be

wrong or you may have installed an ink tank, such as one

with a dierent model number, that is not supported by this

printer. Either install an ink tank for the correct color or use the

provided ink tank for setup.

5 Repeat steps 1 through 4 to install all the ink

tanks.

• Check that all the colors appear.

6 Close the top cover.

• The printer will start initializing.

6. Loading Paper

1 Press the OK button.

2 Open the paper support.

3 Open the feed slot cover.

4 Slide the right-hand side paper guide to the far

right.

ENGLISH

9 Press the OK button.

10 Press the OK button.

• Follow the on-screen instructions to continue setup.

This includes making selections related to sending

information.

Refer to "Sending Information To Canon" in Safety

and Important Information.

• When Select the connection method. appears on

the printer's screen, proceed to "7. Selecting a Printer

Connection Method" on page 6.

5 Load 2 or more sheets of Letter or A4 sized plain

paper.

• Load paper with the print side facing up.

6 Slide the side paper guide against the edge of

the paper stack.

7 Close the feed slot cover.

8 Open the output tray extension and extend the

paper output support.

Setting Up the Printer

7. Selecting a Printer Connection Method

Select a printer connection method from the table below. In the following descriptions, "smartphone" is used to refer

collectively to smartphones and tablets.

USB connection Wired LAN connection Wi-Fi connection

USB cable

Router

LAN cable

Router

1 Use the {, }and OK buttons to select a connection method.

Note

You can set up your connection later, even if you select Do not connect.

When setting up the connection at a later time, refer to "8-a. Connecting to a Computer" on page

7 or "8-b. Connecting to a Smartphone" on page 8, and continue setup from your computer

or smartphone.

2 Follow the on-screen instructions to proceed with the setup.

• If you select USB connection :

Do not connect a USB cable until instructed.

• If you select Wired LAN connection :

The wired LAN connector is on the back of the printer.

Back a

• If you select Wi-Fi connection :

When Continue to perform Wi-Fi setup from your

computer or smartphone. Please conrm. appears,

select Ye s.

3 When either of the following screens appears, proceed to the next page.

ENGLISH

8-a. Connecting to a Computer

8-a

Computer Smartphone

Computer and

smartphone

Connecting to a Computer

If you are using multiple computers, perform these steps on each computer.

1 Access the Canon website from a

computer.

2 Select Set Up.

3 Enter your printer's model name and

click Go.

• If prompted, select your country or region.

4 Click Start.

5 Click If you have already prepared

your printer, go to Connect.

Note

The following steps are for Windows users.

6 Click Download.

7 Run the downloaded le.

8 Click Start Setup.

9 Follow the on-screen instructions.

• These operations may take some time.

• To connect to a smartphone as well, see "8-b.

Connecting to a Smartphone" on page 8.

What device are you connecting?

Using the Setup CD-ROM

Double click EasySetup.exe in the CD-ROM, and then continue from step 3. If you do not have an

internet connection, open the win folder in the CD-ROM and double click SETUP.exe. This will install

the printer driver.

8-b

page 8

8-b

Setting Up the Printer

8-b. Connecting to a Smartphone

1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.

• Search for "Canon PRINT" in App Store, or Google Play.

• Access the Canon website to download the app.

2 Open your smartphone's Wi-Fi settings. Check that the network name (SSID) that starts

with "Canon_ij_" appears.

(Example of iOS screen)

The network name (SSID) that starts with "Canon_ij_"

• If "Canon_ij_" appears Proceed to step

• If "Canon_ij_" does not appear Proceed to step

3 Tap the network name (SSID) that starts with "Canon_ij_".

4 Open the installed app, and follow the on-screen instructions in the app to add your

printer.

Connecting to a Smartphone

If you are using multiple smartphones, perform these steps on each smartphone.

Once you have added your printer, you can print from your smartphone.
