Canon Color imageCLASS LBP674Cdw Manuel utilisateur

Setup Guide

• After you finish reading this guide, store it in a safe

place for future reference.

• The information in this guide is subject to change

without notice.

https://oip.manual.canon/

1Important Safety Instructions

Be sure to read these instructions before using

the machine.

3User's Guide

This section explains all the ways this machine

can be used.

FAQ

This section describes problems that may arise

and how to resolve these problems.

2Setup Guide (this document)

See p. 7“Accessing the Online Manual” for details.

Checking the Items

Included

x 4

Removing the Packing

Material

1. Install the machine in the location where it

will be used.

2. Remove all packing material.

Remove all of the tape.

Do not remove the sticker that covers the USB port

until you actually use the USB port.

Rear

Loading Paper

A4/LGL

1234567 11

Ensure that the

amount of paper

loaded is not above

this line

Installing the Optional

Part

If you are not using optional part, proceed to

step .

Before Installing the Optional Part

After the machine has been installed, perform the following

before installing the optional part:

1. Turn OFF the machine and your computer.

2. Unplug the machine from the mains power outlet.

3. Disconnect all cords and cables from the machine.

Paper Feeder

1. Remove all packing material.

2. Install the paper feeder in the location

where it will be used.

1234567 11

Connecting the Power

Cord

Rear

Specifying the Basic

Settings

When you turn on the machine for the first time, the Setup

Guide appears on the operation panel. Perform the initial

machine setup by following the on-screen instructions.

Operation panel

1. Select the language, the country or region,

and then the time zone.

2. Set the current date/time.

Specifying the Security

Settings

To prevent unauthorized access to the machine, set access

restrictions for Remote UI.

What is Remote UI?

Remote UI allows you to use your computer’s Web

browser to check the machine’s operating status

and change settings.

1. To use the Remote UI, select <Yes>.

To continue without using the Remote UI, select

<No> and proceed to step 8.

2. To use System Manager mode, select <Yes>.

• Set the System Manager ID and PIN so that you

can configure the settings for extended functions

and the management of access privileges, etc.

• To continue without using System Manager mode,

select <No> and proceed to step 5.

3. Set the System Manager ID.

Enter any number and then select <Apply>.

4. Set the System Manager PIN.

• Enter any number and then select <Apply>.

• Re-enter the same PIN on the next screen as

confirmation and select <Apply>.

5. To use General User mode, select <Yes>.

• Set the PIN to be used by general users to access

the Remote UI.

• To continue without using General User mode,

select <No> and proceed to step 8.

6. Set the Remote UI Access PIN.

• Enter any number and then select <Apply>.

• Re-enter the same PIN on the next screen as

confirmation and select <Apply>.

45678 111

Specifying the Network

Settings

Specify the settings for connecting the machine to a

network. Before proceeding, check that the computer and

router are correctly connected to the network.

• You cannot use a wired LAN and a wireless LAN at the

same time.

Wireless LAN

1. Check the router's "SSID" and "Network

ke y."

SSID : XXXXXXXXXXXX

Network key : XXXXXXXXXXXX

2. To configure the settings, select <Yes> on

the operation panel.

3. Select the network with a matching SSID.

4. Enter the password (network key) and select

<Apply>.

Wired LAN

Connect the router to the machine with a LAN cable and

then select <No> in the screen for choosing how to

connect to the network.

Rear

8Setting Up the Toner

Replenishment Service

Use this procedure to set up the toner replenishment

service. To use this service, you must enter into an

agreement beforehand.

1. Check the message and select <Next>.

2. Check the conditions of use, and then

choose whether or not to use the service.

• To use the service: <Accept>.

• To not use the service or not enter into an

agreement: Select <Do Not Accept> and proceed

to step 10 .

3. When <Connection was successful.> appears,

select <OK>.

Ending the Setup Guide

Check the description in the Application Library and then

select <End>.

Installing the Software/

Drivers

To use the print function of the machine, you must install

the printer driver.

Downloading from the Canon website

1. Search for“(model name) download.”

Example: LBP674Cdw download

XXXXXXX download

If you cannot find the download site, go to

https://global.canon/en/support/

2. Download the software and drivers, and

install them on your computer.

5 6 7 8 109111

Installing from the Bundled CD/DVD-

ROM

1. Load the CD/DVD-ROM into your computer,

and install the software and drivers.

For normal installation, select “Easy Installation.”

Selecting “Easy Installation” installs the drivers along

with the standard software and manuals.

If a problem arises during the installation, see “See

Troubleshooting (FAQ) for drivers” in“FAQ.”

Accessing the FAQ

p. 7 “Accessing the Online Manual”

5678 109111

Useful Functions and Helpful Information

Accessing the Online Manual

1. Scan the QR code to open the website to the

Canon online manual.

If the site does not open, go to

https://oip.manual.canon/

2. Select the manual.

User’s Guide

This section lists the functions of the machine,

including machine operations, settings, and

operating procedures.

FAQ

This section lists frequently asked questions and

their answers.

If a problem arises during driver installation,

see “See Troubleshooting (FAQ) for drivers.”

See Troubleshooting (FAQ) for

drivers

Using this Machine from a

Mobile Device (Linking with

Mobile Devices)

This machine can be used from mobile devices such as

smartphones. This makes it easy to print documents or

photos from a mobile device.

User’s Guide

See “Linking with Mobile Devices.”

Managing the Machine from

a Computer (Remote UI)

Remote UI allows this machine to be managed using the

Web browser on a computer. You can use it to check the

machine’s operating status and change settings.

User’s Guide

See “Managing the Machine from a

Computer (Remote UI).”

• Après avoir lu ce guide, rangez-le dans un

endroit sûr pour information.

• Les informations figurant dans ce guide sont

sujettes à modifications sans préavis.

Guide de

configuration

Consignes de sécurité importantes

Veillez à lire ces instructions avant d'utiliser l'appareil.

2Guide de configuration

(ce document)

https://oip.manual.canon/

3Guide de l’utilisateur

Cette section explique toutes les façons dont

cette machine peut être utilisée.

FAQ

Cette section décrit les problèmes qui peuvent

survenir et la manière de les résoudre.

Voir p. 15 «Accès au manuel en ligne» pour plus de détails.

1234567 11

Vérification des articles

inclus

x 4

Retrait du matériel

d'emballage

1. Installez l'appareil là où il sera utilisé.

2. Retirez tout le matériel d'emballage.

Retirez tout le ruban adhésif.

Ne retirez l’autocollant qui recouvre le port USB

qui si vous avez besoin d’utiliser le port USB.

Arrière de

l’équipement

Chargement du papier
