MP160

SERVICE REFERENCE MANUAL

(Differences from the base model, PIXMA MP150, only)

1. PRODUCT LIST

2. PRODUCT SPECIFICATIONS

3. ERROR DISPLAY

4. REPAIR

APPENDIX 1: SHIPMENT INSPECTION PATTERN 1

APPENDIX 2: EEPROM INFORMATION PRINT

QY8-13AY-010

First Edition: June 16, 2006

Second Edition: June 23, 2006

Canon Inc.

(2/2)

1. PRODUCT LIST

1-1. Main Units

Product name Product code Destination Remarks

1447B002AA US

1447B003AA CA

1447B004AA LAM-LV

1447B005AA LAM-HV

1447B006AA EUM

1447B007AA EMB

1447B008AA GB

1447B011AA AU

1447B012AA ASA

1447B013AA HK

1447B014AA CN

1447B015AA TW

Canon Multifunction Inkjet Printer

PIXMA MP160

1447B016AA

1447B017AA KR

(3/3)

2. PRODUCT SPECIFICATIONS

2-1. Machine Specifications

Printing speed Approx. 52 sec. (PP-101, 4 x 6, borderless printing, default print quality

settings)

For reference:

Custom setting 5 Standard

Black (J/E) 22 ppm 13.7 ppm

Color (J/E) 17 ppm 9.0 ppm

Interface Direct print port (PictBridge)

Paper weight

Transparency Not supported.

Acoustic noise level

Printing from a computer Approx. 44.5 dB (highest print quality settings)

Copying Approx. 48.0 dB (highest print quality settings)

Weight Approx. 6.3 kg (including the ink cartridges)

Scanner

Optical resolution 600 x 1,200 dpi (max.)

Scanning resolution 600 x 1,200 dpi (max.)

Copy

Number of continuous copying Monochrome / color: 1 to 9 sheets, 20 sheets

Throughput *1 Approx. 53 seconds

Camera Direct printing

Supported digital cameras Digital cameras and digital video cameras supporting PictBridge

Throughput *2 Approx. 52 66 seconds, with the following conditions and settings:

-A photo from a 6 mega-pixel digital camera

-PP-101 4”x 6”

-Exif Print, Standard

- Process from pressing the printing start button to ejecting paper

Note: Not Blue Angel compliant.

*1: Document copy speed is based on copying the manuscript "ISO/IEC FCD24712: Newsletter" (digital data printed

by offset) using default settings on plain paper.

Copy speed may vary depending on document complexity, copy mode, page coverage, type of paper used, etc.

and does not take into account warming up time.

*2: When printing a 6 megapixel image taken by certain Canon digital camera from PictBridge on default settings

using Photo Paper Plus Glossy without border.

Actual print speed may vary depending on image data, print mode, type of paper used and device that the printer

is connected to.

2-2 Product Life

Same as the MP150.

Units: pages

Standard High capacity

BK CL BK CL

PG-40 CL-40 PG-50 CL-51

Black document (ISO/IEC 19752)*1 348 (3,350) 510 (5,590)

Color document (ISO/IEC FCD24712)*1 355 308 547 560

Photo (4" x 6")*2 (2,165) 120 (3,275) 198

Note: ( ): Estimated supplemental yield

*1: Black/Color document: Declared yield value in accordance with ISO/IEC FCD24711. Values are obtained

by continuous printing.

*2: Photo (4" x 6"): When printing Canon standard patterns on 4" x 6" Photo Paper Plus Glossy continuously

with the default settings of Photo Paper Plus Glossy using Windows XP printer driver in borderless

printing mode and Windows XP Photo Printing Wizard.

Declared yield value is determined based on Canon standard method referring to ISO/IEC FCD24712.

(4/4)

3. ERROR DISPLAY

"E" and numeric value(s) are alternately displayed on the LED.

3-2. Service Call Errors

LED display Error (Error code) Parts which are likely to be faulty

E, 2, 2 Carriage error [5100] - Carriage unit (main unit)

- Timing slit strip film

- Logic board ass'y

- Carriage motor (main unit)

E, 2, 3 Paper feed error [6000] - Timing sensor ass'y

- Timing slit disk film (main unit)

- Feed roller ass'y (main unit)

- Platen (main unit)

- Logic board ass'y

- Paper feed motor (main unit)

E, 2, 4 Purge cam sensor error [5C00] - Carriage unit (main unit)

- Timing slit strip film

- Logic board ass'y

- Carriage motor (main unit)

E, 2, 5 ASF cam sensor error [5700] - Drive ass'y (main unit)

- PE sensor ass'y

- Pressure roller ass'y (main unit)

E, 2, 6 Internal temperature rise error [5400] - Logic board ass'y

E, 2, 7 Main ink absorber full [5B00] or

platen ink absorber full [5B10] Main ink absorber:

- Bottom case unit (main unit)

- Ink absorber kit

Platen ink absorber:

- Ink absorber

- Ink absorber kit

E, 2, 8 Ink cartridge temperature rise error

[5200] - Print head

- Logic board ass'y

E, 2, 9 EEPROM error [6800] - Logic board ass'y

E, 3, 2 AP position error [6A00] - Drive ass'y (main unit)

- PE sensor ass'y

- Logic board ass'y

E, 3, 5 USB Host VBUS overcurrent [9000] - Logic board ass'y

E, 3, 7 Abnormal motor driver error [6D00] - Logic board ass'y

E, 4, 0 Other hardware error [6500] - Logic board ass'y

E, 4, 2 Scanner error [5010] - Scanner unit

- Logic board ass'y

(5/5)

3-3. Ink Low Warning (Ink low warnings are displayed by the Status Monitor only when the

remaining ink level detection is enabled, and no Status Monitor display when disabled.)

Note: The Status Monitor display in the table below is for Windows.

Warning Display by Status Monitor

Ink low warning 1 (approx. 70% of ink remaining)

Ink low warning 2 (approx. 40% of ink remaining)

Ink low warning 3 (low remaining ink)

Ink low warning 4 (no ink remaining)

Remaining ink level unknown

(6/6)

4. REPAIR

4-1. Notes on Service Part Replacement (and Disassembling / Reassembling) in Asia

Service part Notes on replacement Adjustment/settings Operation check

Logic board ass’y

(QM3-1691) - Before removal of the logic

board ass'y, remove the power

cord, and allow for approx. 1

minute (for discharge of

capacitor's accumulated

charges), to prevent damages

to the logic board ass'y.

- Before replacement, check the

ink absorber counter value. If

the value is 7% or more, also

replace the ink absorber when

replacing the logic board ass'y.

If the ink absorber is not

replaced, then set the ink

absorber counter value to the

replaced new logic board

ass'y.

After replacement:

1. Initialize the EEPROM.

2. Reset the ink absorber

counter.

If the ink absorber is

not replaced, set the

ink absorber counter

value to the replaced

new logic board ass'y,

while referring to 4.2,

"Service Mode" below.

3. Set the destination in

the EEPROM.

4. Perform the print head

alignment in the user

mode.

- EEPROM print

- Service test print

- Printing via USB

connection

- Camera Direct print

Operation panel

unit

(QM3-1358)

After replacement:

1. Check the buttons and

the LCD.

See 4.2, "Service

Mode."

4-2. SERVICE MODE

Number of times the

Stop/Reset button is pressed LED Function Remarks

12 times Green Button and LCD test

13 times Orange Sets the ink absorber counter

value (ink amount in the ink

absorber)

See below for how to set

the ink counter value.

14 or more times Returns to the menu selection

1) In the ink absorber counter setting mode, press the Stop/Reset button the specified number of

time(s) according to the ink absorber whose counter value should be transferred to the EEPROM.

Times LED

0 times Green Main ink absorber

1 time Orange Platen ink absorber

2 times Green Both the main and platen ink absorbers

3 times or more Returns to the ink absorber counter setting mode

2) Press the ON/OFF button to proceed to the next step.

3) The ink absorber counter value can be set in 10% increments by pressing the Stop/Reset button.

Press the Stop/Reset button the appropriate number of time(s) to select the value which is

closest to the actual ink amount in the ink absorber.

Times Ink absorber counter value to be set(%)

0 times 0%

1 time 10%

2 times 20%

3 times 30%

4 times 40%

5 times 50%

6 times 60%

7 times 70%

(7/7)

8 times 80%

9 times 90%

10 times or more Not valid. Press the ON/OFF button to return

to the ink absorber counter setting mode.

4) Press the ON/OFF button to set the selected value to the EEPROM.

(11/11)

APPENDIX 1: SHIPMENT INSPECTION PATTERN 1

On the service test print (sample below), confirm the EEPROM information as shown below. (The

information is given in the upper portion of the printout.)

MPxxx M=Vx.xx Dd=xxx.x USB(XXXXXX)

LEDTIME=xxxx xxxx xxxx SELF(H=xxx xxx xxx L=xxx xxx xxx)

US US US US US US US

On the service test print (sample below), confirm the following items:

-Check 1, nozzle check pattern: Ink shall be ejected from all nozzles.

-Check 2, top of form accuracy: The line shall not extend off the paper.

-Check 3, vertical straight lines: The line shall not be broken.

Ink amount in the main ink absorber (%)

ROM version

Model name

USB serial number

LED light control Scanner self check

Check 1. Nozzle check pattern

Check 3. Vertical straight lines

Check 2. Top pf form accuracy

Destination

(12/12)

APPENDIX 2: EEPROM INFORMATION PRINT

Print sample:

MP160 US V1.00 ST=2006/05/30-16:41 LPT=2006/07/04-10:25

ER(ER0=1000 ER1=5100) P_ON(S=00001) MSD(000)

IF(USB1=1) PC(M=000 R=000 T=011 D=000 C=000)

D=008.0 Ps 000.0

TPAGE(TTL=00022 COPY=00005)

CLT(2006/06/02-11:34)

CT(BK_ST=002 BK_HC=002 CL_ST=000 CL_HC=000)

IS(BK=0 M=0 C=0 Y=0)

IC(BK=02150 M=02435 C=02001 Y=02081)

A_REG=0 M_REG=1

CDIN(PB=000 OPB=000) BTIN=0

PAGE(All=00145 PP=00112 HR+MP=00000 PR+SP+SG=00033 GP=00000 PC=00000 EV=00000)

CDPAGE(All=00000)

EDGE=00000 L=00031 BTPAGE=00000

LG=00 Unknown CDI=000 CDP=000

CDD-PR (L=00020 2L=00000 PC=00000 A4=00000)

CDD-SP (L=00020 2L=00000 PC=00000 A4=00000)

CDD-MP (L=00020 2L=00000 PC=00000 A4=00000)

DCD-PP (L=00020 2L=00000 PC=00000 A4=00000)

DCD-FPP (L=00020 2L=00000 PC=00000 A4=00000)

DCD-MPP (L=00020 2L=00000 PC=00000 A4=00000)

PrnB=00000 SC=00000 Seal=00000

SC=00000 SCAN_ER(ER0=0000 ER1=0000)

SC-dpi(75=00000 150=00000 300=00000 600=00000 1200=00000 2400=00000)

SG(GY=00000 CL=00000)

<Copy>

MCASF(PP=00000 SP+PR+GP=00000 OTH=00000)

CCASF(PP=00000 HR+MP=00000 PR+SP+SG=00000 GP=00000 PC=00000)

- EEPROM Information <Hex.> -

Printed items:

1: Model name (Destination)

2: ROM version

3: Installation date

4: Last printing time

5: Operator call / service call error record

6: Power-on count (S = soft-power-on)

7: Longest period of non-printing

8: I/F connection (USB1)

9: Purging count (manual cleaning, deep cleaning, timer cleaning, cleaning by dot count, cleaning at

ink cartridge replacement)

10: Ink amount in the ink absorber (main, platen)

11: Number of all pages fed (total, number of copying sheets)

12: Last cleaning time

(13/13)

13: Ink cartridge replacement count (Black standard, black high capacity, color standard, color high

capacity)

14: Ink status (BK/M/C/Y)

15: Total ink consumption amount (BK/M/C/Y)

16: Half-automatic print head alignment on the machine

17: Manual print head alignment via the MP driver

18: Camera Direct print-supported device connection record (Canon PictBridge, other PictBridge)

19: Bluetooth-supported device connection record (BTIN=BLUETOOTH INSERT)

20: Number of pages fed from ASF (total, plain paper, High Resolution Paper & Matte Photo Paper,

Photo Paper Pro & Photo Paper Plus Glossy & Photo Paper Plus Semi-gloss, Glossy Photo

Paper, Postcard, Envelope)

21: Camera Direct print pages in total

22: Borderless print pages

23: L & 4x6 print pages

24: Print pages via Bluetooth connection (BTPAGE=BLUETOOTH PRINT PAGE)

25: Language setting

26: Number of times a memory card is inserted (CDI=Card Install)

27: Total Card Direct print pages (CDP=Card Print)

28: Memory Card Direct print pages: Photo Paper Pro (4x6, 5x7, postcard, A4/LTR)

29: Memory Card Direct print pages: Photo Paper Plus Glossy (4x6, 5x7, postcard, A4/LTR)

30: Memory Card Direct print pages: Matte Photo Paper (4x6, 5x7, postcard, A4/LTR)

31: Camera Direct print pages: Photo Paper (4x6, 5x7, postcard, A4/LTR)

32: Camera Direct print pages: Fast Photo Paper (4x6, 5x7, postcard, A4/LTR)

33: Camera Direct print pages: Matte Paper (4x6, 5x7, postcard, A4/LTR)

34: Print Beam pages fed (PrnB=Print Beam)

35: Business Card / Credit Card size paper pages fed

36: Sticker pages fed

37: Total number of scanning

38: Scanning error status history

39: Number of scanning by the scanning resolution (75/150/300/600/1200/2400 dpi)

40: Number of scanning by the scanning tone (grayscale/color)

<Copy>

41: Number of monochrome copy pages fed from ASF (plain paper, Photo Paper Plus Glossy , Photo

Paper Pro, Glossy Photo Paper, other paper)

42: Number of color copy pages fed from ASF (plain paper, High Resolution Paper & Matte Photo

Paper, Photo Paper Pro & Photo Paper Plus Glossy & Photo Paper Plus Semi-gloss, Glossy

Photo Paper, postcard)

- Printer EEPROM information dump in hex -

Autres manuels pour PIXMA MP160

Table des matières

Autres manuels Canon Imprimante

Canon

Canon i960 Series Guide de configuration

Canon

Canon Océ Variolink Guide de l'utilisateur

Canon

Canon BJ-230 Manuel utilisateur

Canon

Canon PIXMA mg6150 Manuel utilisateur

Canon

Canon iPF8000S - imagePROGRAF Color Inkjet Printer Mode d’emploi

Canon

Canon PIXMA MG3000 SERIES Guide de configuration

Canon

Canon MAXIFY GX3070 Mode d’emploi

Canon

Canon W8200 Instructions d'installation et d'entretien

Canon

Canon imaqeRunner 1019J Manuel utilisateur

Canon

Canon BJC-4400 Series Manuel utilisateur

Canon

Canon PIXMA G3200 Guide de configuration

Canon

Canon PIXMA TS9570 Manuel utilisateur

Canon

Canon image Prograf iPF 685 Series Manuel utilisateur

Canon

Canon NP6317 Manuel utilisateur

Canon

Canon LBP-810 Manuel utilisateur

Canon

Canon TS3300 Series Guide de configuration

Canon

Canon imageRUNNER ADVANCE DX C7700 Series Manuel utilisateur

Canon

Canon imagePROGRAF TX-2000 Guide de configuration

Canon

Canon Pro900 Mark II Manuel utilisateur

Canon

Canon BJC-6200 Manuel utilisateur

Canon

Canon TS5350i Series Manuel utilisateur

Canon

Canon i455 Series Manuel utilisateur

Canon

Canon imagePRESS C7000VP Series Manuel utilisateur

Canon

Canon PIXMA G620 Guide de configuration

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
