Canon MultiPASS C755 Manuel utilisateur

MultiPASS C755

SERVICE

MANUAL

Canon

I. MEANING OF MARKS

The marks used in this manual have the following meanings.

Mark Meaning

States a precaution to be taken to prevent danger to personnel, damage to the product, or

damage to electronic components by discharge of static electricity. for example.

States a precaution to be taken to prevent damage to electronic components by

electrostatic discharge.

Informs you of fire-related cautions.

Informs you that the plug must be removed from the power outlet before starting an

operation.

Gives useful information to understand descriptions.

Indicates sections to be read to obtain more detailed information.

NOTE

REFERENCE

II. ABOUTTHIS MANUAL

This manual is divided into five parts, and contains information required for servicing the product.

Each of the above parts is further divided into the following four chapters:

Chapter 1: General Description

This part explains product specifications and the how to service the unit safely. It is very important, so

please read it.

Chapter 2: Assembly and Disassembly

This part explains the assembly and disassembly of the product.

Chapter 3: Maintenance and Service

This part explains how to maintain the products for adjustment and troubleshooting and service operations

and service switches.

Chapter 4: Appendix

This part explains the informations of the optional products and user data flow.

• For more details of user operations and user reports, see the separate volume of

USER'S

GUIDE

• Greasing points is not given in this manual. See the illustrations in the separate volume of

PARTS CATALOG

• Detailed description of each SSSW/parameter is not given in this manual except the new

SSSWs/parameters added to this model.

See

G3 Facsimile Service Data Handbook (supplied separately)

for details them.

• See the

G3 Facsimile Error Code List (Rev.1, supplied separately)

for details of the

error codes not shown in this manual.

REFERENCE

III

III. REVISION HISTORY

REVISION CONTENT

0 Original

IV.TABLE OF CONTENTS

Page

Chapter 1: General Description

1 - 1 1. FEATURES

1 - 1 1.1 Overview

1 - 2 2. SPECIFICATIONS

1 - 2 2.1 General Specification

1 - 2 2.2 Communication Specification

1 - 3 2.3 Color Communication Specification

1 - 4 2.4 Scanner Specification

1 - 6 2.5 Printer Specification

1 - 9 2.6 Copy Specification

1 -10 2.7 Function

1 -12 3. OVERVIEW

1 -12 3.1 External View

1 -14 3.2 Operation Panel

1 -17 3.3 Consumables

1 -17 3.3.1 BJ cartridge and ink cartridge

1 -19 3.3.2 Print media

Chapter 2: Assembly and Disassembly

2 - 1 1. ATTENTION TO BE PAID DURING ASSEMBLY/DISASSEMBLY

2 - 1 1.1 Safety Cautions

2 - 2 1.2 General Cautions

2 - 3 1.3 Product-Inherent Cautions

2 - 3 1.4 Action in the Event of Abnormality (All Clear)

2 - 4 2. DISASSEMBLY/ASSEMBLY

2 - 4 2.1 Parts Layout

2 - 6 2.2 Disassembly Work-Flow

2 - 7 2.3 Disassembly Procedure

Chapter 3: Maintenance & Service

3 - 1 1. MAINTENANCE LIST

3 - 1 1.1 Consumables

3 - 1 1.2 Cleaning

3 - 2 1.3 Periodic Inspection

3 - 2 1.4 Periodic Replacement Parts

3 - 2 1.5 Adjustment Items

3 - 3 1.6 General Tools

3 - 3 1.7 Special Tools

3 - 4 2. HOW TO CLEAN PARTS

3 - 4 2.1 Main Unit Outer Covers

3 - 4 2.2 Separation Roller

3 - 4 2.3 Document Feed/Eject Roller

3 - 4 2.4 Separation Guide

3 - 4 2.5 Scanning Glass (Contact Sensor)

3 - 4 2.6 White Sheet

3 - 4 2.7 Printer Platen

3 - 6 3. ADJUSTMENT

3 - 6 3.1 CS LED Lights-on Duration Adjustment

3 - 7 3.2 When Adjustment of the Print Head Position is Required

3 - 9 3.3 When the Carriage Belt Tension Needs Adjustment

3 - 9 3.4 When the ASF Gear Initial Position Adjustment is Required

3 -11 3.5 When the Head Gap Needs Adjustment

3 -14 4. TROUBLESHOOTING

3 -14 4.1 Troubleshooting Index

3 -16 4.2 Errors Shown on the Display

3 -16 4.2.1 User error message

3 -22 4.2.2 Error codes

3 -30 4.3 Errors not Shown on the Display

3 -30 4.3.1 General errors

3 -31 4.3.2 Printing problems

3 -33 4.3.3 Scanning problems

3 -35 4.4 Processing Communication Problems

3 -35 4.4.1 Initial identification of problems

3 -36 4.4.2 Procedures for processing communication problems

3 -39 5. COMMUNICATION SYSTEM OPERATIONS

3 -39 5.1 FAX/TEL Switching

3 -39 5.1.1 Settings

3 -39 5.1.2 Parameters

3 -40 5.2 Answering Machine Connection

3 -40 5.2.1 Settings

3 -40 5.2.2 Parameters

3 -40 5.3 Manual/Auto Reception Switching

3 -40 5.3.1 Settings

3 -40 5.3.2 Parameters

3 -41 5.4 Operations Where Other Machine Does not Have Color Communications Ability

3 -41 5.5 Conditions Necessary for Color Reception

3 -42 5.6 Specifications for Color Communications

3 -43 6. SERVICE SWITCHES

3 -43 6.1 Hardware Switches

3 -43 6.2 Service Data Setting

3 -43 6.2.1 Service data overview

3 -44 6.2.2 Service data registration/setting method

3 -45 6.2.3 Service data setting

3 -52 6.2.4 Explanation of service data

3 -53 6.2.5 New SSSWs/parameters added to this model

3 -57 7. TEST FUNCTIONS

3 -57 7.1 User Test Print Functions

3 -57 7.1.1 Nozzle check

3 -58 7.2 Service Test Functions

3 -58 7.2.1 Test mode overview

3 -59 7.2.2 Test mode flowchart

3 -61 7.2.3 D-RAM tests

3 -61 7.2.4 CS tests

3 -62 7.2.5 PRINT test

3 -64 7.2.6 Modem and NCU tests

3 -67 7.2.7 Faculty tests

3 -72 7.2.8 Printer test

3 -73 8. SERVICE REPORT

3 -73 8.1 Report Output Function

3 -73 8.1.1 User report output functions

3 -75 8.1.2 Service report output functions

3 -83 9. WIRING DIAGRAM

3 -83 9.1 Wiring Diagram

3-84

.BLOCK DIAGRAM

3 -84 10.1Block Diagram

3 -85 10.2Circuit Board Components

Chapter 4: Appendix

4 - 1 1. USER DATA FLOW

4 - 1 1.1 User Data Flow (by Operation Panel)

4 - 4 1.2 User Data Flow (by MultiPASS Suite)

INDEX

1-1

MultiPASS C755 Chapter 1: General Description

1. FEATURES

1.1 Overview

This product is a G3 transreceiving facsimile based on the ITU-T recommendations. It can be used in

telephone networks.

*: This mark indicates a new function.

Picture Quality Color Printer

High quality printing can be accomplished with the Canon Bubble Jet (BJ) method using the maximum

1440dpi ×720dpi resolution. Various kinds of media can be printed with the high speed of a maximum

8.7 pages per minute. The printing paper tray can hold up to 100 sheets of plain paper, 50 sheets of OHP

film, or 10 back print films or envelopes.

*Plain paper fax which can transmit/receive in color

Conforming to ITU-T recommendations, this fax is able to transmit/receive in color. Due to containing

extremely high-speed 33.6kbps modems, transmission time can be shortened. Pictures and photographs

can both be send and received clearly by UHQ(Ultra High quality), Canon’s vivid image processing

technology. Up to 20 letter- or A4- size sheets, or up to 10 legal-size sheets, can be set in the ADF. 12

one-touch dial entries and 100 speed dial entries can be registered, and group dial and broadcasting

transmission can also be done. When paper and ink run out, the data is saved to memory, so there is no

worry. When a external-phone is attached, fax communication and normal telephone reception are

possible due to DRPD service and FAX/TEL switching.

BJ Cartridge

Printing quality superior to photos is produced by use of BC-30 and BC-33/BC-34 photo BJ cartridges.

*Out-of-Ink Function

This machine has a function which detects when ink has run out. It also detects when the cartridges of

machines equipped with color communications are out of ink. The presence/absence of ink in the ink

chamber is detected by reflecting ink sensor.

Copy Function

This machine can be used as a 360dpi ×360 dpi high resolution full color copier. With a monochrome

document (including half-tone), up to 99 pages can be copied at one time at the speed of a maximum of 3

pages/minute.

Full Color & 256 Gradation Grayscale Scanner

Using graphics or OCR software which conforms to the TWAIN standard, full color and 256-gradation

grayscale images with a quality of 30dpi ~ 600 dpi can be read into a computer. Reading in can be done at

a resolution of 300dpi, and can be enhanced to 600dpi using the included MultiPASS Suite.

PC Fax

By connecting this machine to a computer, a fax can be transmitted from the included MultiPASS Suite

or from a Windows application, and a received image can be saved to the computer as-is without printing

it out.

1-2

MultiPASS C755 Chapter 1: General Description

2. SPECIFICATIONS

2.1 General Specification

Type Desktop

Body colour Art gray

Power source 98 ~ 132V AC, 48 ~ 62 Hz

Power consumption Standby 6.0 W

Max. 44.9 W (when 100% black copy)

Usage environment. 50.0°F ~ 90.5°F (10°C ~ 32.5°C), 20%~85% RH, 570 ~ 760

mmHg (760 ~ 1013 hPa)

Horizontal ±3° or less

Operating noise Measured in accordance with ISO standards

Operating :47 dB(A) or less

Dimensions (W ×D ×H) 17.20" ×16.85" ×8.15" (437 mm ×428 ×207 mm)

(Not including Trays)

Weight 14.55 lbs (6.6 kg) Including trays

2.2 Communication Specification

Applicable lines PSTN (Public Switched Telephone Network)

Applicable Services DRPD (Distinctive Ring Pattern Detection)

Handset None

Transmission method Half-duplex

Transmission control protocol ITU-T T30 binary protocol/ECM protocol/

ITU-T V.8 protocol/V.34 protocol/ECM protocol

Modulation method

G3 image signals ITU-T V.27ter (2.4k, 4.8k bps)

ITU-T V.29 (7.2k, 9.6k bps)

ITU-T V.17 (TC7.2k, TC9.6k, 12k, 14.4k bps)

ITU-T V.34 (2.4k, 4.8k, 7.2k, 9.6k, 12k, 14.4k, 16.8k, 19.2k,

21.6k, 24k, 26.4k, 28.8k, 31.2k, 33.6k bps)

G3 procedure signals ITU-T V.21 (No.2) (300bps)

ITU-T V.8 300bps

ITU-T V.34 600 bps, 1200 bps

(With automatic fallback function)

Coding Black/white ITU-T T.4 Coding method (MH, MR)

ITU-T T.6 Coding method (MMR)

ITU-T T.82/T.85 Coding method (JBIG)

Color ITU-T T.81 Coding method (JPEG)

Error correction ITU-T T30 (ECM)

Canon express protocol (CEP) None

1-3

MultiPASS C755 Chapter 1: General Description

Time required for transmission protocol

Pre-message Post-message Post-message *3

Protocol Protocol *1Protocol *2

Mode (between pages) (after pages)

G3 standard approx.18 sec. approx.4 sec. approx.4 sec.

V.8/V.34 approx.8 sec. approx.2 sec. approx.2 sec.

*1 Time from when other facsimile is connected to the line until image transmission begins.

*2 Post-message (between pages): Time from after one document has been sent until

transmission of the next document starts if several pages are transmitted.

*3 Post-message (after last pages): Time from after image transmission is completed until

line is switched from facsimile to telephone.

Minimum transmission time 10 msec (G3), 0 msec (G3, ECM)

Transmission output level From 0 to -15 dBm

Receive input level From -3 to -43 dBm

Modem IC FM336

2.3 Color Communication Specification

ITU-T recommendation ITU-T T.30 ANNEX E (JPEG Color Fax)

T.4 ANNEX E (JPEG Header)

T.42 (Color space for Color Fax)

T.81 (JPEG)

Scanning Document size A4

Printing paper size A4

Resolution 200×200 dpi

Picture element 8 bit

Coding JPEG

Color space CIELAB

Illuminant Data CIE Standard Illuminant D50

Sub sample 4:1:1 (=Lab)

Autres manuels pour MultiPASS C755

Table des matières

Autres manuels Canon Imprimante

Canon

Canon Color imageRUNNER LBP3460 Manuel utilisateur

Canon

Canon imageRUNNER ADVANCE DX C5870i Guide d'installation

Canon

Canon PIXMA iX6820 Manuel utilisateur

Canon

Canon g3000 series Guide de configuration

Canon

Canon PIXMA MG7120 Mode d’emploi

Canon

Canon iPF610 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon SELPHY ES2 Manuel utilisateur

Canon

Canon imagePROGRAF W7200 Manuel utilisateur

Canon

Canon imageRUNNER ADVANCE DX 4700 Series Manuel utilisateur

Canon

Canon iP6600D - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon PIXMA G7070 Guide de configuration

Canon

Canon TS3100 Series Manuel utilisateur

Canon

Canon Oce VarioPrint 6000 MICR Series Manuel utilisateur

Canon

Canon iP6700D - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon N 1000 Manuel utilisateur

Canon

Canon MAXIFY GX4070 Manuel utilisateur

Canon

Canon C3226i Manuel utilisateur

Canon

Canon MG6600 Series Guide de configuration

Canon

Canon MB2720 Manuel utilisateur

Canon

Canon BJC-250 Series Manuel utilisateur

Canon

Canon MP980 series Manuel utilisateur

Canon

Canon TS5100 series Manuel utilisateur

Canon

Canon Pixma Pro9500 Series Manuel

Canon

Canon PIXMA MG8250 Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
