Starter Guide

Set Up the Machine

Before Setting Up the Machine

Remove all shipping tape on the machine.

When moving the machine, be sure at least two people carry it using the provided hand grips on the left and

right sides, as seen in the illustration right.

●

Do You Have Everything?

Machine●Paper Cassette (Optional)●Handset (Optional)●

Handset Cradle (Optional)*●Bracket (Optional)*●Screws (x2 for each type) (Optional)*●

Cartridge●Power Cord●Telephone Cable●

Ferrite Core**●Screw***●Screwdriver instruction label***●

Destination Label●

Starter Guide●User Software CD****●Registration Card●

Limited Warranty Notice●Unpacking Instructions●Basic Operation Guide●

User Manual CD (Reference Guide)●

* Included with the optional handset. (See “Install Handset (Optional),” on p. 10.)

** Use by attaching to a USB cable. Included with the LASER CLASS 830i and the optional network printer kit for the LASER CLASS 810. (See “Installation

Procedure for USB Connection,” on p. 23.)

*** Used when the optional handset is installed.

**** Included with the LASER CLASS 830i and the optional network printer kit for the LASER CLASS 810.

The machine illustration may diﬀer slightly from your machine.

Use the screw that is included with the machine, to secure the right cover and machine frame when attaching the handset

–

Manuals for the Machine

"ASIC

/PERATIONå

'UIDE

2EFERENCEå'UIDE

3ETUP

)NSTALLATION

(ANDLINGå

THEå-ACHINE

5SINGåTHEå$RIVERS.ETWORKå

&UNCTIONS

3TARTERå

'UIDE

Starter Guide (This Document)

Basic Operation Guide: Operation features, maintenance, speciﬁcations, functions you can use without being

connected to a network

Reference Guide (located on the User Manual CD): Operation features, maintenance, speciﬁcations, all functions

including those that use a network or driver

PCL Driver Guide (located on the User Software CD): PCL printer driver installation and instructions

UFR II Driver Guide (located on the User Software CD): UFRII LT printer driver installation and instructions

Fax Driver Guide (located on the User Software CD): Fax driver installation and instructions

Assistance:

If you have a problem with your machine and you cannot solve it by referring to the manuals listed above, please

contact our Canon Authorized Service Facilities or the Canon Customer Care Center at 1-800-828-4040 between

the hours of 8:00 A.M. to 8:00 P.M. EST Monday through Friday and 10:00 A.M. to 8:00 P.M. on Saturday.

●

Install Cartridge

Remove the toner cartridge from the bag. Keep the bag

for future use.

Do not open the drum protective shutter (A).

Gently rock the toner cartridge 5 or 6 times to distribute

toner evenly.

Remove the seals (2 places).

Bend back the blue plastic pull tab as in the illustration

above.

Do not remove the pull tab as it is used to pull out the toner

when the cartridge needs replaced.

Pull out the seal completely.

Do not pull out the seal at an angle.

Open the left cover.

Hold the toner cartridge by its handle. Insert the toner

cartridge into the machine with the arrows (A) on the

toner cartridge pointing toward the machine.

The left edge (A) and the right side protrusions (B, C) of

the toner cartridge should be aligned with the guides

inside the machine. The Blue plastic pull tab should be

pulled up as illustrated in step 4.

Push the toner cartridge to make sure it is properly set in

the machine.

Do not touch the ﬁxing assembly (A) as it becomes very hot

during use.

Close the left cover.

Be careful not to get your ﬁngers caught.

If you cannot close the left cover, do not force it to close. Open

the cover and make sure the toner cartridge is properly set in

the machine.

–

Load Paper

Pull out the paper cassette until it stops.

Fan the paper stack and even the edges of the paper

stack.

Load the paper stack print side up.

Make sure the back edge of the paper stack touches the rear

paper end guide (C), the paper stack should not exceed the load

limit mark (A), and the load is under the hooks (B) on the paper

guides.

Gently insert the paper cassette as far as it will go.

Be careful not to get your ﬁngers caught.

For loading paper in the multi-purpose tray, see Chapter 2,

“Document and Paper,” in the Basic Operation Guide, Reference

Guide > What This Machine Can Do > Loading Paper.

Set Up the Paper Cassette to Fit the Paper Size

Incline the rear paper end guide until it is unlocked, then

remove it from the paper cassette.

Attach the guide to the slots of the desired paper size.

Connect the Power Cord and Turn On the Machine

Connect the power cord into the rear socket and the wall

outlet and press the [I] side of the main power switch to

ON.

When restarting the machine, wait at least 10 seconds

before turning the main power back on.

FAX

The machine enters standby mode.

<LEFT COVER OPEN / CLOSE COVER> is displayed:

Make sure that the left cover is closed properly.

(See “Install Cartridge” on p. 4.)

<TONER IS NOT SET / INSERT TONER> is displayed:

Make sure that the toner cartridge is installed properly.

(See “Install Cartridge” on p. 4.)

<TONER LOW / PREPARE NEW TONER> is displayed:

If this message is displayed after a new toner cartridge

has been set in place, reset the toner cartridge after

shaking it slowly ﬁve, or six times. (See“Install Cartridge”

on p. 4.)

●

Connect Telephone Cables

Connect the supplied telephone cable to the line jack (A) and the wall jack.

Connect your external telephone to the external device jack (B) if required.

If you want to use an external telephone and receive faxes, you will need to set up the receiving mode. (See “Set the Machine for Receiving

Faxes,” on p. 17.)
