Canon GX7010 Manuel utilisateur
Leia Informações Importantes e Sobre
Segurança (adendo) primeiro.
Para Começar
Lea primero Información de seguridad
e información importante (apéndice).
Guía de inicio
Getting Started
Read Safety and Important Information
(addendum) first.
Segurando a impressora
As ilustrações e as capturas de tela usadas neste manual são da GX7000 series. As informações especícas do modelo são
indicadas por ícones.
Instalando a impressora......................................................................................................página 1
Conectando a um computador, smartphone ou tablet.................................página 6
Cómo sujetar la impresora
Las ilustraciones y las capturas de pantalla que se utilizan en esta publicación son de la serie GX7000. La información especíca
de un modelo se indica mediante iconos.
Instalación de la impresora ...............................................................................................página 1
Conexión con un ordenador, teléfono inteligente o tableta.......................página 6
Installing the Printer...................................................................................................................page 1
Connecting to a Computer, Smartphone or Tablet............................................... page 6
Holding the Printer
The illustrations and screenshots used in this book are from the GX7000 series. Model-specic information is indicated by icons.
1
ENGLISH
Setting Up the Printer
1. Box Contents
•
Ink Bottles
•
Power Cord
• Phone Cable
•
Setup CD-ROM
•
Safety and Important Information
•
Getting Started (this manual)
2. Removing Packing Materials
1 Remove and dispose of any packing materials
and orange tape.
• Using the printer with orange tape or packing
material still attached, may cause the printer to
malfunction.
2 Open the scanning unit / cover, remove and
dispose of the orange tape and protective
material inside.
a b
3 Close the scanning unit / cover.
• Open the scanning unit / cover fully and then close it.
b
a
Caution
Watch your ngers.
3. Turning on the Printer
1 Connect the power cord.
Back
For Setup, visit the URL
https://ij.start.canon
or scan the code with your mobile device
•
Follow the instructions below if you do not have an internet connection.
2
Setting Up the Printer
2 Open the operation panel and press the ON
button.
3 Scroll and tap to select your language, and then
tap Yes .
4 If the following screen appears, tap your
country or region to select.
5 Set the date, and then tap OK.
6 Set the time, and then tap OK.
7 Tap OK.
4. Pouring Ink
Important
This product requires careful handling of ink. Ink may splatter
when the ink tanks are lled with ink. If ink gets on your clothes or
belongings, it may not come o.
1 Open the scanning unit / cover.
3
ENGLISH
2 Open the ink tank cover and tank cap on the left
of the printer.
3 Hold the ink bottle upright and gently twist the
bottle cap to remove.
Check!
BK
4 Align the nozzle of the ink bottle with the inlet.
5 Slowly stand the ink bottle upside down and
push down to pour the ink.
• If the ink does not pour, gently remove the ink bottle
and try again.
ab
6 Gently remove the ink bottle from the inlet.
• Be careful not to spill the ink.
b
a
7 Replace the tank cap securely.
8 Close the ink tank cover securely.
9 Repeat steps 2 through 8 to pour all ink into the
corresponding ink tanks on the right.
Check!
CM Y
4
Setting Up the Printer
10 Close the scanning unit / cover.
• Open the scanning unit / cover fully and then close it.
b
a
Caution
Watch your ngers.
5. Loading Paper
1 Tap OK.
2 Remove the cassette from the printer.
• Pull out Cassette 1 (upper) from the printer.
3 Slide apart the paper guides.
• Slide the right paper guide to the right edge. Align
the front paper guide with the Letter or A4 mark.
4 Load Letter or A4 sized plain paper.
• Place the paper against the front paper guide, and
align the right paper guide to the width of the paper.
a b
5 Replace the cassette.
6 Pull out the paper output tray.
5
ENGLISH
7 Tap OK.
• The alignment process prints out one double sided
sheet. Wait without touching the paper until the
screen in step 8 appears.
8 Tap Next.
• Follow the on-screen instructions to continue setup.
This includes making selections related to sending
information.
Refer to "Sending Information To Canon" in Safety
and Important Information.
9 Check that the following screen appears.
If you will use the printer without connecting any other
devices, setup is now complete.
Select the connection method that best matches how you
will use the printer.
• To use the printer without connecting to any other
devices
Setup is now complete.
To set up a fax, see "Using Fax
Function" on page 8.
• To use the printer connecting to a computer or
smartphone
Proceed to the next page.
6-a
6
Setting Up the Printer
Computer Smartphone
Computer and
smartphone
Connecting to a Computer
If you are using multiple computers, perform these steps on each computer.
1 Access the Canon website from your computer.
2 Select Set Up.
3 Enter your printer's model name and click Go.
4 Click Start.
5 Click (B) Connecting to a Computer/Smartphone.
• The following steps are for Windows users.
6 Click Download.
7 Run the downloaded file.
• Follow the on-screen instructions. This may take some time.
• To connect to a smartphone as well, see "6-b. Connecting to a Smartphone" on page 7.
• To set up a fax, see "Using Fax Function" on page 8.
What device are you connecting?
6-a. Connecting to a Computer
Using the Setup CD-ROM
Double click EasySetup.exe in the CD-ROM, and then continue from step 3. If you do not have an
internet connection, open the win folder in the CD-ROM and double click SETUP.exe. This will install
the printer driver.
6-b
7
ENGLISH
1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.
• Search for "Canon PRINT" in App Store, or Google Play.
• Access the Canon website to download the app.
2 Open your smartphone's Wi-Fi settings. Check that the network name (SSID) that starts
with "Canon_ij_" appears.
(Example of iOS screen)
The network name (SSID) that starts with "Canon_ij_"
• If "Canon_ij_" appears Proceed to step
3
.
• If "Canon_ij_" does not appear Proceed to step
4
.
3 Tap the network name (SSID) that starts with "Canon_ij_".
4 Open the installed app, and follow the on-screen instructions in the app to add your
printer.
Connecting to a Smartphone
If you are using multiple smartphones, perform these steps on each smartphone.
6-b. Connecting to a Smartphone
• Once you have added your printer, you can print from your smartphone. To print photos, see
"Loading Paper" on page 8.
• To set up a fax, see "Using Fax Function" on page 8.
8
1 Open the rear tray cover and extend the paper
support. 2 Slide the right-hand side paper guide to the far
right.
3 Load several sheets of paper with the print side
facing up and slide the side paper guide against
the edge of the paper stack.
a
b
Transporting Your Printer
When relocating the printer, check the following. Refer to the Online Manual for details.
Check that the position of the ink valve lever is closed.
Pack the printer in a plastic bag in case ink leaks.
• Pack the printer in a sturdy box so that it is placed with its
bottom facing down, using sucient protective material
to ensure safe transport.
• Do not tilt the printer. Ink may leak.
• Please handle with care and ensure the box remains at
and NOT turned upside down or on its side, as the printer
may be damaged and ink in the printer may leak.
• When a shipping agent is handling transport of the
printer, have its box marked "THIS SIDE UP" to keep the
printer with its bottom facing down. Mark also with
"FRAGILE" or "HANDLE WITH CARE".
Loading Paper
Using Fax Function
The fax function of your printer requires setup. Refer to FAX Setup Guide.
■Access the FAX Setup Guide
1 Access the Canon website.
2 Click See Recommended Functions.
3 Click Functions/Services.
4 Click Setting Up the FAX.
