Canon BJC-S530D Manuel utilisateur

S530D

Photo Printer

Quick Start Guide

S530D QSG.book Page i Tuesday, May 7, 2002 4:14 PM

Canon S530D Photo Printer Quick Start Guide.

this guide may not be reproduced in any form, in whole or in part, without the prior written consent

of Canon U.S.A., Inc.

Disclaimer

The purpose of this guide is to aid end users by summarizing pertinent information about your Canon

S530D Photo Printer. All statements, technical information and recommendations in this guide are

believed reliable, but the accuracy and completeness thereof are not guaranteed or warranted, and

they are not intended to be, nor should they be understood to be, representations or warranties

concerning the products described.

Speciﬁcations are subject to change without notice.

As an E

NERGY

TAR

partner, Canon U.S.A. Inc., has determined that this product meets

the E

NERGY

TAR

guidelines for energy efﬁciency.

All information regarding non-Canon products was compiled from publicly available information.

No representation is made regarding the accuracy thereof.

Trademarks

Canon is a registered trademark of Canon Inc. PhotoRecord is a trademark of Canon Information

Systems Research Australia. Macintosh, Mac and the Mac logo are registered trademarks of Apple

Computer, Inc., registered in the U.S. and other countries. CompactFlash is a trademark of SanDisk

Corporation. Memory Stick is a trademark of Sony Corporation. SmartMedia is a trademark of

Toshiba Corporation. Microdrive is a trademark of International Business Machines Corporation.

All other product and brand names are trademarks of their respective owners.

Canon U.S.A., Inc.

One Canon Plaza

Lake Success, NY 11042

Printed in Thailand

S530D QSG.book Page ii Tuesday, May 7, 2002 4:14 PM

iii

Contents

Chapter 1: Basic Printing

Turning Your Printer On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

What Is a Printer Driver? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Selecting the S530D Photo Printer for Use . . . . . . . . . . . . . . . . . . . 2

Using Specialty Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Cancelling a Print Job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Setting Driver Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Changing the Page Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Chapter 2: Advanced Print Features

Using Recommended Paper or Specialty Media . . . . . . . . . . . . . . 14

Smoothing Rough or Jagged Edges . . . . . . . . . . . . . . . . . . . . . . . . 14

Optimizing Color Photographs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Adjusting Print Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Adjusting Color Balance, Brightness and Saturation . . . . . . . . . . 18

Saving and Recalling Driver Settings . . . . . . . . . . . . . . . . . . . . . . . 20

Chapter 3: Printing Without a Computer

Basic Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Printing Photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Print Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Maintenance Procedures for Direct Printing . . . . . . . . . . . . . . . . . 34

Using the Memory Card Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Chapter 4: Printing Maintenance

Monitoring Ink Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Replacing Ink Tanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Aligning the Print Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Printing a Nozzle Check Pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Cleaning the Print Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

S530D QSG.book Page iii Tuesday, May 7, 2002 4:14 PM

Contents

Chapter 5: Using Your Photo Applications

What is Exif Print? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Installing the Photo Applications . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Using the Photo Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Using Easy-PhotoPrint for Windows . . . . . . . . . . . . . . . . . . . . . . . . 52

Printing on Canon Photo Paper Pro for Borderless Printing 4" x 6" . . . . 56

Chapter 6: Troubleshooting

Tips for Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Customer Care Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Appendix

Installing the Printer Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Uninstalling the Printer Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Registering Your Canon Product . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Limited Warranty—U.S. Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Index

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

S530D QSG.book Page iv Tuesday, May 7, 2002 4:14 PM

Chapter 1: Basic Printing

Congratulations on purchasing your new Canon

S530D Photo Printer!

This chapter describes basic features of your S530D Photo Printer and provides

instructions on how to set up and print documents and photographs.

The following topics are presented in this chapter:

•

Turning Your Printer On and Off

•

What Is a Printer Driver?

•

Selecting the S530D Photo Printer for Use

•

Using Specialty Media

•

Cancelling a Print Job

•

Setting Driver Options

•

Changing the Page Setup

This Quick Start Guide describes some of the features of your

S530D Photo Printer and how to use them. For more detailed

information, view the

S530D User’s Guide

on the Setup

Software & User’s Guide CD-ROM.

Windows

Driver features, instructions and screen captures

described in this guide reﬂect Windows XP and may be and/

or look different for Windows

98, Me and Windows 2000.

Also, in various procedures, users are instructed to click the

Properties button. However, depending upon the application

you are using, you may see the Preferences button or another

button instead.

Macintosh

Driver features, instructions and screen

captures described in this guide reﬂect Mac

OS 8.6 – 9.x,

and may be and/or look different for Mac OS X.

S530D QSG.book Page 1 Tuesday, May 7, 2002 4:14 PM

Basic Printing

Turning Your Printer On and Off

To turn your printer on or off, press the POWER button.

•

The POWER lamp will ﬂash green when warming

up or when a print job is being sent to the printer.

•

The POWER lamp will glow a steady (non-ﬂashing)

green when the printer is ready for use or when

the print job is complete.

•

If the POWER lamp ﬂashes orange, see “Handling

Error Messages” on page 69.

What Is a Printer Driver?

Most computers require special software to link the programs you use to create

documents or images with the printer. This special software, called a

printer

driver

, converts the information from the software application into a format that

the printer can understand, and provides other handy features, such as

monitoring the levels of ink in the printer.

Selecting the S530D Photo Printer for Use

If the S530D is the only printer connected to your computer, it will be used

automatically every time you print. However, if your computer has access to

multiple printers, you can set the S530D as the default (main) printer.

To set the S530D as the default printer in Windows

Click

Start

, then:

•

Windows XP:

Select

Control Panel

, then

Printers and Other Hardware

, then

Printers and Faxes

•

Other Windows versions:

Select

Settings

, then

Printers

Right-click the

Canon S530D

printer icon, then click

Set as Default Printer

The Canon S530D printer icon will now display with a checkmark that

indicates it is the default printer.

POWER button

S530D QSG.book Page 2 Tuesday, May 7, 2002 4:14 PM

Basic Printing

To select the S530D from within a Windows application:

If another printer is set as the default printer, you can still select the Canon

S530D for a speciﬁc print job from within most applications.

From the

File

menu, click

Windows XP:

Select

Canon S530D

from the list, then click

Apply

Other Windows versions:

Click

To select the S530D in Mac

OS:

Click

Apple

, then

Chooser

Click the

S530D

printer icon. Close the Chooser. The S530D will remain the

default printer until another is selected.

Using Specialty Media

For optimal results, Canon recommends that you use genuine Canon media with

your S530D Photo Printer. Be sure to follow all instructions on storing, handling

and printing on the media.

Media to Avoid

Never load the following types of media into your S530D Photo Printer. These

media could produce poor quality and jam or damage the printer:

•

Folded paper

•

Excessively curled or wrinkled paper

•

Damp paper

•

Excessively thin or thick paper (less than 17 lb. or more than 28 lb.)

•

Paper with adhered photos, stickers, etc.

•

Envelopes with an embossed or treated surface

•

3-hole punched paper

•

Paper with any type of attached fasteners, ribbons, etc.

Menus vary from application to application. Consult your

application’s user documentation if the Print option is not listed.

S530D QSG.book Page 3 Tuesday, May 7, 2002 4:14 PM

Basic Printing

Loading Guidelines for Canon Specialty Media

For optimal results, Canon recommends that you use genuine Canon

media with your S530D Photo Printer. See the

S530D User’s Guide

on the

Setup Software & User’s Guide CD-ROM for more speciﬁc paper handling

instructions.

Media Type Sheet Feeder Load Limit Lever Position

Canon Photo Paper Plus Glossy

1 sheet Left

Canon Matte Photo Paper

10 sheets Left

Plain paper

100 sheets (17 – 28 lb.) Left

Canon High Resolution Paper

80 sheets Left

Canon Photo Paper Pro

1 sheet Left

Canon Photo Paper Pro 4" x 6"

20 sheets Left

Canon Photo Paper Pro for Borderless Printing 4" x 6"

20 sheets Left

Canon High Gloss Photo Film

1 sheet Left

Canon Glossy Photo Paper

1 sheet Left

Canon Glossy Photo Cards

20 sheets Left

Canon Transparencies

30 sheets Left

Canon Banner Paper

1 sheet (up to 6 connected sheets) Right

Canon T-Shirt Transfers

1 sheet Right

#10 Envelopes

10 envelope Right

Some Canon Specialty media includes a loading support sheet to

facilitate paper feeding.

•

Canon Glossy Photo Cards: Do not use the loading support sheet

provided with the package.

•

Canon Glossy Photo Paper: Do not use the loading support sheet

provided with the package.

S530D QSG.book Page 4 Tuesday, May 7, 2002 4:14 PM

Basic Printing

Loading Media into the S530D

Follow these instructions and tips for loading media into the printer.

•

To prevent paper jams, always fan the sheets and align the edges before you

load them into the printer.

•

Handle media carefully by its edges.

•

Never touch the print surface (the glossy or brighter white side of the sheets).

•

Dirt or ﬁngerprints on the print surface will adversely affect print quality.

•

To prevent changes in color, never stack printed sheets after they have

been printed.

•

Cover printed sheets with one sheet of plain paper to protect the printed

surface, even if you intend to store them in clear plastic folders.

To load plain paper or other Canon media

Make sure the paper

thickness lever is set

correctly for the media used.

Pinch and slide the paper

guide completely to the left.

Fan the edges of the sheets

to remove static cling.

Tap the edges of the stack

against a ﬂat surface so the

stack is aligned.

Insert the media into the paper rest, with the print side facing up.

Slide the paper guide right to the edge of the media until ﬁrmly in place.

7. Select the correct media setting in the printer driver. (See “Chapter 2:

Advanced Print Features” on page 13.

For more information on loading media, see the S530D User’s

Guide on the Setup Software & User’s Guide CD-ROM.

Paper thickness

lever Print side

Load limit

mark

Paper guide

S530D QSG.book Page 5 Tuesday, May 7, 2002 4:14 PM

Basic Printing

Caring for Your Photographs

The Canon S530D Photo Printer will generate spectacular results for printing

photographs, especially when used with Canon specialty media. All images are

susceptible to fading over time, but proper care of prints made from your S530D

Photo Printer will ensure that print quality lasts long into the future.

Many environmental factors can impact how long a printout will last before

noticeable image fading occurs. Exposure to sunlight or other light sources,

humidity, temperature, exposure to cigarette smoke and ozone are just some of

the factors that can impact image permanence. While many of these variables

cannot be controlled, there are basic measures that you can take to prolong

image quality:

•Use Canon Photo Paper Pro and genuine Canon inks. Try Canon Photo

Paper Pro or Canon Photo Paper Pro for Borderless Printing (4"x 6").

Both papers are speciﬁcally designed to work with genuine Canon inks.

•Mount images under glass to reduce exposure to ozone, cigarette smoke and

other environmental factors that can degrade images.

•Keep printed images out of direct sunlight or other intense light sources.

S530D QSG.book Page 6 Tuesday, May 7, 2002 4:14 PM

Autres manuels pour BJC-S530D

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Canon Imprimante

Canon

Canon iP3500 - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon MAXIFY GX2000 Series Guide de configuration

Canon

Canon MP560 - PIXMA Color Inkjet Manuel utilisateur

Canon

Canon Pixma MG2400 Series Manuel utilisateur

Canon

Canon Sure shot 80 tele Manuel utilisateur

Canon

Canon PIXMA TR8520 Manuel utilisateur

Canon

Canon iPF750 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon MG2900 Series Manuel utilisateur

Canon

Canon FAXPHONE L100 Manuel utilisateur

Canon

Canon imagePROGRAF iPF6350 Guide de l'utilisateur

Canon

Canon PIXMA MX392 Instructions d'utilisation

Canon

Canon PIXMA MP970 Manuel utilisateur

Canon

Canon imageCLASS 2220 Manuel utilisateur

Canon

Canon MF543x MF542x Manuel utilisateur

Canon

Canon CLBR 460ps Manuel utilisateur

Canon

Canon PIXMA G400 Series Manuel utilisateur

Canon

Canon iPF610 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon laser Shot LBP 3300 Manuel utilisateur

Canon

Canon imageRUNNER ADVANCE DX C3800 Series Manuel utilisateur

Canon

Canon iR2016J Manuel de service

Canon

Canon i900D Series Manuel utilisateur

Canon

Canon PIXMA TS300 series Manuel utilisateur

Canon

Canon Color imageRUNNER LBP3460 Manuel utilisateur

Canon

Canon iPF755 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
