WIDE ANGLE

FIELD ZOOM LENS

SUPER 55

HIGH MTF PERFORMANCE

The next generation of 16:9 format has

become more widespread world-wide.

The height of the 16:9 format is 20%

shorter than that of the current 4:3

format, thus the scanning lines are 20%

greater(Fig.1). As a result, higher

resolution is required for the 16:9

format. In order to achieve this, the

SUPER55 provides the optimum

balance of aberrations by Hi-UD glasses

(High Index Ultra Low Dispersion

glass) and Canon's unique fluorite. The

SUPER55 succeeds in having the

higher MTF performance,

correspondent to 6MHz, necessary for

the 16:9 format.

CANON "CROSSOVER" SYSTEM

All the Super series of lenses, including

the new Super 55 are now optionally

available with "CROSSOVER"

compatibility. The 4 position extender

turret incorporates a 0.8x

"CROSSOVER" unit in addition to

the normal extenders i.e. 1.0x, 1.5x, or

2.0x (Fig.2). When the CCD switches

to the 4:3 mode, the extender turret

rotates to the 0.8x position. The 0.8x

"CROSSOVER" unit reduces the

diameter from 11mm to 9mm thus

shortening the focal length to produce

an identical picture angle. In essence,

the 0.8x "CROSSOVER" unit acts as a

1.0x extender for the switched 4:3

aspect ratio. Fig.3 shows the relation

between focal length and the

magnification of the extenders.

PJ55x9B IE 9-500mm 1:1.4

SUPER

535.9 384

F.B.=48 in air

122 122

125

135.5

150

DIMENSIONS

The extremely high performance levels of the "55xSuper" with its 9mm wide angle have been prefered over all other lenses in its class.

This lens will now be appreciated even more in the 16:9 format.

The new and improved "Super 55" can include Canon's optional "Crossover System" which accommodates for the loss of wide angle

in the 4:3 mode in some of the dual aspect ratio switchable camera systems. The redesigned circuitry of the "Super 55" realizes

improvements in RF noise protection and its improved mechanical design offers a modern look with easy accessibility for user

friendly maintenance. Of course , the "Super 55" includes the best features of the 55xSuper like the superb wide angle of 9mm , the

light weight of 18kg and the extremely sharp picture quality even at the telephoto side.

Fig.1

0.8X

1.5X

or Spare

(Option)

Crossover

(optional)

Fig.2

CROSSOVER SYSTEM

16:9 Scanning Lines

16:9 (dia 11mm) 4:3 (dia 9mm)

Extender

Focal Length

F stop Extender

Focal Length

F stop

0.8X 1.0X

7.4-407mm

1.4

1.0X

9-500mm

1.4 1.2X

9-500mm

1.4

2.0X

18-1000mm

2.8 2.4X

18-1000mm

2.8

Fig.3

WIDE ANGLE

FIELD ZOOM LENS

4:3

16:9

80%

100%

SWITCHABLE 4 : 3 (with crossover unit)16 : 9

Zoom Ratio

Built-in Extender

Range of Focal Length

Maximum Relative

Aperture

Angular Field of View

Minimum Object

Distance (M.O.D.)

Object Dimensions

at M.O.D.

Size

Weight (Approx)

Built-in Pattern Projector

NORMAL 4 : 3

1.02.01.02.01.01.22.4

55

9500mm 181000mm 9500mm 181000mm 7.4407mm 9500mm 181000mm

1:1.4 at 9~202mm

1:2.8 at 500mm 1:2.8 at 18~404mm

1:5.6 at 1000mm 1:1.4 at 9~202mm

1:2.8 at 500mm 1:2.8 at 18~404mm

1:5.6 at 1000mm 1:1.4 at 7.4~216mm

1:2.35 at 407mm 1:1.4 at 9~202mm

1:2.8 at 500mm 1:2.8 at 18~404mm

1:5.6 at 1000mm

52.1



40.3



at 9mm

1.01



0.76



at 500mm

27.5



20.8



at 18mm

0.50



0.38



at 1000mm 56.1



33.4



at 9mm

1.10



0.62



at 500mm 29.9



17.1



at 18mm

0.55



0.31



at 1000mm

52.1



40.3



at 7.4mm

1.01



0.76



at 407mm

43.6



33.0



at 9mm

0.83



0.62



at 500mm 22.6



17.1



at 18mm

0.41



0.31



at 1000mm

2.2m from front lens vertex

(with macro M.O.D:0.4m)

190



143cm at 9mm

3.4



2.6cm at 500mm 95



71cm at 18mm

1.7



1.3cm at 1000mm

207



117cm at 9mm

3.7



2.1cm at 500mm 103



58cm at 18mm

1.9



1.1cm at 1000mm

190



143cm at 7.4mm

3.4



2.6cm at 407mm 155



117cm at 9mm

2.8



2.1cm at 500mm 77



58cm at 18mm

1.4



1.1cm at 1000mm

244(W)260(H)549(L)mm

18kg (39.7lbs)

optionally available

Note ; SUPER 55 for 1/2 inch cameras is also available.

For details , please contact Canon office.

SPECIFICATIONS

ACCESS WINDOW FOR

EASY MAINTENANCE

•Easy adjustment of lens functions (Built-

in pattern projector, Iris gain) through a

large-size window.

EXCELLENT SERVO SYSTEM

•Faster and quieter servo system

•••maximum speed zoom:0.8 sec

focus:0.8 sec

•Low power consumption

WIDE ANGLE OF 9MM

WITH REDUCED

DISTORTION

(ZOOM RATIO:55X)

LATERAL CHROMATIC

ABERRATION

•Full zoom range•••••maximum=6 microns

HIGH AND FLAT MTF

•Realization of high contrast in all areas of the

picture (center and corner)

PROTECTION FILTER (Optional)

COUNTERMEASURES AGAINST

"GHOSTING" AND "FLARES"

•New coatings and anti-reflection paint achieve

the elimination of "ghosting" and "flares"

COUNTERMEASURES AGAINST RADIO

FREQUENCY NOISE

(INTERFERENCE)

SERVO SYSTEM MATCHING ROBOTIC

REQUIREMENTS

•High resolution zoom and focus servo - 12 bit repeatability

10 BIT IRIS COMPATIBILITY

•High resolution iris control

4-POSITION TURRET

(built in extender, pattern projector,

master lens, crossover unit).

•Micro Computer Controlled

Turret.

*Built in Effect Filter available as

option e.g Cross, Sunny, etc.

VERSATILE

ZOOM/FOCUS

CONTROLLERS

(See figure on the next page )

•New ergonomic design.

•Countermeasures against dust,

rain, and radio interference.

CROSSOVER COMPATIBILITY (Optional)

•For use with 16:9/4:3 switchable cameras.

MACRO FUNCTION-M.O.D.=0.4M

ZOOM FOCUS

OPERATION SYSTEM

NO. DESCRIPTION CODE

3 Servo Module SMJ-NO2

Flexible Zoom Controller FZP-T61

Flexible Focus Controller FFP-T61

Flexible Cable 30"

Flexible Module FMJ-452

BG2-5205

BG2-1558

BG2-1557

BG2-5305

LENS SYSTEM

1-b

1-a

Switch Box

(Optional)

2-a

2-b

2-c

Lens Supporter

(optional)

APPLICATION

Manual Flexible Cable Drive Flexible Cable Drive 4, 6, 7 5, 6, 7

Semi-Servo Servo Flexible 1, 3 5, 6, 7

Full-Servo Servo Servo 1, 3 2, 3

OPERATION

ZOOM FOCUS

COMPOSITION

NO. DESCRIPTION CODE

1-a Zoom Demand ZDJ-A01

Zoom Demand W/Shot Box ZPJ-A01

Focus Demand FDJ-I01

Focus Demand FDJ-H01

Focus Demand W/Shot Box FPJ-K02

BG2-5122

BG2-5529

BG2-5001

BG2-5003

BG2-5506

1-b

2-a

2-b

2-c

PUB. BE98-200 0398D3 PRINTED IN JAPAN

North & South America

Canon USA, Inc.

Broadcast Equipment Div. (Headquarters)

400 Sylvan Avenue Englewood Cliffs, NJ 07632

Tel:(201)816-2900

(800)321-4388

Fax:(201)816-2909

Chicago

100 Park Blvd. Itasca, IL 60143

Tel:(630)250-6231 Fax:(630)250-0399

Atlanta

5625 Oakbrook Pkwy. Norcross, GA 30093

Tel:(770)849-7895 Fax:(770)849-7888

Los Angeles

15955 Alton Parkway lrvine, CA 92718

Tel:(714)753-4330 Fax:(714)753-4337

Dallas

3200 Regent Blvd. lrving, TX 75063

Tel:(972)409-8871 Fax:(972)409-8879

Latin America

Tel:(954)349-6975 Fax:(201)816-2909

Canada

Canon Canada, Inc.

Optics Division 6390 Dixie Road Mississauga,

Ontario Canada, L5T 1P7

Tel:(905)795-2012 Fax:(905)795-2140

Brasil

Canon Do Brasil Industiria

Comercio Ltda Av. Do Caf, 277 6-Andar Torreé

B Vila Guarani, Sao Paulo Cep:04311-000

Tel:55-11-5070-7103 Fax:55-11-5070-7301

Europe/Africa/Middle East

The Netherlands Headquarters

Canon Europa N.V.

TV Products Department Bovenkerkerweg 59-61

1185 XB Amstelveen

Tel:+31(0)20-5458905 Fax:+31(0)20-5458203

Email:tvprod @ cenv. canon.nl

Home Page address:

www. europe. canon. com/products/tvprod/

France

Canon Photo Video France

11, 'Le Doublon'AV, Dubonnet 92407 Courbevoie-

Cedex

Tel:+33(0)1-49040608 Fax:+33(0)1-49040699

E-mail:dp @ cpv. canon. fr

United Kingdom

Canon UK LTD.

TV Products Department Unit 1a, The Fleming

Centre Fleming Way Crawley West Sussex RH10

2NN

Tel:+44(0)1293-524-358 Fax:+44(0)1293-562-008

E-mail:TV_lenses @ cuk. canon. co. uk

Germany

Canon Euro Photo

Industrial Products Department Siemensring

90-92 47877 Willich

Tel:+49(0)2154-495491 Fax:+49(0)2154-495498

E-mail:[email protected]

Australia

Canon Australia Pty. Ltd.

Optical Products Division 1 Thomas Holt Drive

North Ryde, NSW 2113

Tel:+61(0)2-9805-2000 Fax:+61(0)2-9805-2444

Asia

Canon Singapore PTE. LTD.

2 Alexandra Road #03-01A Delta House

Singapore 159919

Tel:(65)276-6864 Fax:(65)271-4226

Japan

Canon Inc.

20-2, Kiyohara-Kogyo-Danchi, Utsunomiya-shi,

Tochigi-ken, 321-3292

Tel:+81(0)28-667-8669 Fax:+81(0)28-667-8672

Specifications subject to change without notice.
