Canon EOS 80D (W) Guide d'installation

Basic Instruction Manual

Instruction manuals (PDF files) and software can be downloaded

from the Canon Web site (p.4, 233).

www.canon.com/icpd

Camera

Wireless Function

EOS 80D (W)

The Camera Basic Instruction Manual covers the most basic operations

and functions.

Camera Basic Instruction Manual

EOS 80D (W)

The EOS 80D (W) is a digital single-lens reflex camera featuring a fine-

detail CMOS sensor with approx. 24.2 effective megapixels, DIGIC 6,

high-precision and high-speed 45-point AF (Cross-type AF point: Max.

45 points), max. approx. 7.0 fps continuous shooting, Live View

shooting, Full High-Definition (Full HD) movie shooting, and wireless

functions (Wi-Fi/NFC).

Before Starting to Shoot, Be Sure to Read the Following

To avoid botched pictures and accidents, first read the “Safety

Precautions” (p.14-16) and “Handling Precautions” (p.17-19). Also, read

this manual carefully to ensure that you use the camera correctly.

Refer to This Manual while Using the Camera to Further

Familiarize Yourself with the Camera

While reading this manual, take a few test shots and see how they

come out. You can then better understand the camera. Be sure to store

this manual safely, too, so that you can refer to it again when necessary.

Testing the Camera Before Use and Liability

After shooting, play images back and check whether they have been

properly recorded. If the camera or memory card is faulty and the

images cannot be recorded or downloaded to a computer, Canon

cannot be held liable for any loss or inconvenience caused.

Copyrights

images or copyrighted music and images with music on the memory

card for anything other than private enjoyment. Also be aware that

certain public performances, exhibitions, etc., may prohibit photography

even for private enjoyment.

Introduction

Before starting, check that all the following items are included with your

camera. If anything is missing, contact your dealer.

* Battery Charger LC-E6 or LC-E6E is provided. (The LC-E6E comes with a

power cord.)

The camera does not come with an interface cable or HDMI cable.

The Instruction Manuals provided are listed on the next page.

If you purchased a Lens Kit, check that the lenses are included.

Depending on the Lens Kit type, lens instruction manuals may also be

included.

Be careful not to lose any of the above items.

Item Check List

Battery Pack

LP-E6N

(with protective

cover)

Battery Charger

LC-E6/LC-E6E*

Camera

(with body cap)

Wide Strap

When you need Lens Instruction Manuals, download them from the Canon

Web site (p.4).

The lens instruction manuals (PDF) are for lenses sold individually. Note

that when purchasing the lens kit, some of the accessories included with the

lens may not match those listed in the Lens Instruction Manual.

Camera and Wireless Function Basic Instruction

Manual

The booklet is the Basic Instruction Manual.

More detailed Instruction Manuals (PDF files) can be

downloaded from the Canon Web site.

1Download the Instruction Manuals (PDF files).

Connect to the Internet and access the following Canon Web site.

www.canon.com/icpd

Select your country or region of residence and download the

Instruction Manuals.

Instruction Manuals Available for Download

• Camera Instruction Manual

• Wireless Function Instruction Manual

• Camera and Wireless Function Basic Instruction Manual

• Lens Instruction Manuals

• Software Instruction Manuals

2View the Instruction Manuals (PDF files).

Double-click a downloaded Instruction Manual (PDF file) to open

it.

To view the Instruction Manuals (PDF files), Adobe Acrobat

Reader DC or other Adobe PDF viewer (most recent version

recommended) is required.

Adobe Acrobat Reader DC can be downloaded free from the

Internet.

To learn how to use a PDF viewer, refer to its Help section.

Instruction Manuals

Downloading and Viewing the Instruction Manuals (PDF Files)

Software can be downloaded from the Canon Web site (p.233).

The following cards can be used with the camera regardless of

capacity: If the card is new or was previously formatted by another

camera or computer, format the card with this camera (p.58).

SD/SDHC*/SDXC* memory cards

* UHS-I cards supported.

When shooting movies, use a large-capacity card with a reading/writing

speed class at least as high as shown in the following table.

If you use a slow-writing card when shooting movies, the movie may

not be recorded properly. Also, if you play back a movie on a card

with a slow reading speed, the movie may not play back properly.

To check the card’s reading/writing speed, refer to the card

manufacturer’s Web site.

Compatible Cards

Cards that Can Record Movies

Movie Recording Size (p.207) Recording Formats

MOV MP4

ALL-I (For editing) UHS Speed Class 3

or faster -

IPB (Standard)

L: 87-SD Speed Class 10

or faster

Other than above

-SD Speed Class 6

or faster

IPB (Light) -SD Speed Class 4

or faster

In this manual, “card” refers to SD memory cards, SDHC memory

cards, and SDXC memory cards.

*The camera does not come with a card for recording images/

movies. Please purchase it separately.

Quick Start Guide

1Insert the battery (p.30).

To charge the battery, see page 28.

2Insert the card (p.31).

With the card’s label facing

toward the back of the

camera, insert it into the card

slot.

3Attach the lens (p.41).

Align the lens’s white or red mount

index with the camera’s mount

index of the same color.

4Set the lens’s focus mode

switch to <f> (p.41).

5Set the power switch to <1>,

then set the Mode Dial to <A>

(Scene Intelligent Auto) (p.72).



Turn the Mode Dial while holding down

the lock release button at the center.



All the necessary camera settings will

be set automatically.

White index Red index

Quick Start Guide

6Flip out the LCD monitor (p.34).

When the LCD monitor displays the

date/time/zone setting screens, see

page 37.

7Focus on the subject (p.44).

Look through the viewfinder and

aim the viewfinder center over the

subject.

Press the shutter button halfway,

and the camera will focus on the

subject.

If necessary, the built-in flash will be

raised.

8Take the picture (p.44).

Press the shutter button completely

to take the picture.

9Review the picture.

The captured image will be

displayed for approx. 2 sec. on the

LCD monitor.

To display the image again, press

the <x> button (p.216).

To shoot while looking at the LCD monitor, see “Live View

Shooting” (p.173).

To view the images captured so far, see “Image Playback” (p.216).

To delete an image, see “Erasing Images” (p.229).

Icons in this Manual

<6> : Indicates the Main Dial.

<5> : Indicates the Quick Control Dial.

<9> <W> <X> <Y> <Z>: Indicates the Multi-controller and the push

direction.

<0> : Indicates the Setting button.

0, 9, 7, 8: Indicates that each function remains

active for approx. 4 sec., 6 sec., 10 sec.,

or 16 sec. after you let go of the button.

* In addition to the above, the icons and symbols used on the camera’s buttons

and displayed on the LCD monitor are also used in this manual when discussing

relevant operations and functionality.

3: Indicates a function that can be changed by pressing the

<M> button to change its settings.

O: When shown on the upper right of a page, it indicates that

the function is available only in the Creative Zone modes

(p.25).

(p.**) : Reference page numbers for more information.

: Warning to prevent shooting problems.

: Supplemental information.

: Tips or advice for better shooting.

: Troubleshooting advice.

Basic Assumptions

All operations explained in this manual assume that the power switch

is set to <1> and the <R> switch is set down (Multi function

lock released) (p.35, 48).

It is assumed that all the menu settings and Custom Functions are

set to their defaults.

The illustrations in this manual show the camera attached with the

EF-S18-135mm f/3.5-5.6 IS USM lens as an example.

Conventions Used in this Manual
