ENGLISH

Wired LAN Instruction Manual

INSTRUCTION

MANUAL

EOS-1D X Mark II (G)

Using the camera’s wired LAN functions enables you to do the

following:

Introduction

What You Can Do Using the Wired LAN Functions

Use EOS Utility to shoot, view, and

download images remotely

FTP Transfer

WFT Server

Transfer images to an FTP server

Synchronize time between the same

camera models

Use a web browser to shoot, view, and

download images remotely

EOS Utility

Smartphone

Sync the Camera Time

Use a smartphone to shoot, view, and

download images remotely

Chapter List

Introduction 2

Basic Network Settings 7

Transferring Images to an FTP Server 21

Operating Remotely Using EOS Utility 39

Operating Remotely Using WFT Server 43

Operating Remotely Using a Smartphone 59

Synchronizing the Camera Time 67

Terminating the Connection and Reconnecting 71

Checking and Operating Connection Settings 75

Troubleshooting Guide 87

Reference 103

Introduction 2

Chapter List ...................................................................................... 3

Conventions Used in this Manual..................................................... 6

Basic Network Settings 7

LAN Cable Connection..................................................................... 8

Preparation....................................................................................... 9

Basic Communication Function Settings........................................ 12

Displaying the Connection Wizard ................................................. 16

Transferring Images to an FTP Server 21

Configuring FTP Server Connection Settings ................................ 22

Transferring Images Individually..................................................... 27

Batch Transfer ................................................................................ 32

Viewing Transferred Images........................................................... 37

Operating Remotely Using EOS Utility 39

Configuring EOS Utility Connection Settings ................................. 40

Using EOS Utility............................................................................ 42

Operating Remotely Using WFT Server 43

Configuring WFT Server Connection Settings ............................... 44

Displaying WFT Server .................................................................. 46

Viewing Images .............................................................................. 49

Shooting Remotely [Camera control] ............................................. 51

Shooting Remotely [Simple control] ............................................... 56

Operating Remotely Using a Smartphone 59

Configuring Smartphone Connection Settings ............................... 60

Operating the Camera Using a Smartphone .................................. 62

Specifying Viewable Images........................................................... 64

Contents

Synchronizing the Camera Time 67

Synchronizing the Time...................................................................68

Terminating the Connection and Reconnecting 71

Terminating the Connection ............................................................72

Reconnecting ..................................................................................73

Checking and Operating Connection Settings 75

Displaying the Connection Settings Screen....................................76

Changing Settings...........................................................................78

Saving and Loading Settings ..........................................................82

Function Settings Screen................................................................84

Troubleshooting Guide 87

Responding to Error Messages ......................................................88

Troubleshooting Guide..................................................................100

Checking Network Settings...........................................................101

Reference 103

Creating and Registering Captions...............................................104

Setting IP Address Manually.........................................................106

Wired LAN Specifications..............................................................108

Index ............................................................................................. 113

In this manual, the term “access point” indicates wireless LAN access

points, wireless LAN routers, etc. that relay a LAN connection.

These instructions should be followed only after setting up your LAN

and FTP server environments. For information about setting up the

environments, refer to the documentation provided with each device

or contact the manufacturer.

Read the Camera Instruction Manual and familiarize yourself with

operating the camera before following the instructions on camera

options.

Icons in this Manual

<6> : Indicates the Main Dial.

<5> : Indicates the Quick Control Dial.

<9> : Indicates the Multi-controller.

<0> : Indicates the Setting button.

* In addition to the above, the icons and symbols used on the camera’s buttons

and displayed on the LCD monitor are also used in this manual when discussing

relevant operations and functionality.

(p.**) : Reference page numbers for more information.

: Warnings to prevent potential problems during operation.

: Supplemental information.

Basic Assumptions

All operations explained in this manual assume that the power

switch is set to <1>.

It is assumed that all the menu settings, Custom Functions, etc. are

set to their defaults.

Conventions Used in this Manual

Image transfer, remote shooting, or viewing images requires adequate

knowledge of configuring your wired LAN and FTP server. Canon cannot

provide support for configuring wired LANs or FTP servers.

Note that Canon cannot be held liable for any loss or damage to the

camera from erroneous network or FTP server settings. In addition, Canon

cannot be held liable for any other loss or damage caused by use of the

camera.

When using wired LAN functions, establish appropriate security at your

own risk and discretion. Canon cannot be held liable for any loss or

damage caused by unauthorized access or other security breaches.

Basic Network Settings

Complete the basic network settings by using the menu

screen on the camera’s LCD monitor.

Connecting a LAN Cable

Open the Ethernet RJ-45 terminal

cover, then connect the camera to a

computer, access point, etc. with a

LAN cable.

Use a highly shielded Category 5e or higher STP (Shielded Twisted

Pair) Gigabit Ethernet cable.

The connection types shown below are available for connecting the

camera to a computer, smartphone, etc. over a LAN.

LAN Cable Connection

LAN Cable

Connection Types

LAN cable

Wireless

Access point or

router

LAN cable

The connection instructions help you connect the camera to a network

that is already set up.

Connect a device such as a computer or smartphone to the network in

advance so that you can connect it to the camera.

[FTP trans.]

You can transfer captured images to an FTP server.

Images can be automatically transferred as you shoot them, or you

can select images to be transferred later.

Computer Operating Systems

Use of [FTP trans.] requires that one of the following operating

systems be installed on a computer. In addition, the computer must

be set up as an FTP server in advance.

• Windows 8, Windows 8 Pro, Windows 8.1, Windows 8.1 Pro

• Windows 7 (Professional, Enterprise, or Ultimate Edition for

32- or 64-bit systems)

• Windows Vista (Business, Enterprise, or Ultimate Edition for

32- or 64-bit systems)

For instructions on setting up a computer as an FTP server, refer to

the documentation provided with each device or contact the

manufacturer.

Note that the following operating systems cannot be used

because FTP server functionality is not provided.

• Windows 7 Home Premium

• Windows Vista Home Premium or Home Basic Edition

Preparation

[EOSUtility]

You can perform remote shooting over a wired LAN using EOS

Utility (EOS software).

In addition to remote shooting, almost all EOS Utility camera

operations are supported, because this option utilizes a wired LAN

instead of an interface cable.

Requires a computer with EOS Utility (EOS software) installed.

[WFTserver]

You can perform advanced remote shooting or view images stored

in the camera by connecting to the camera from a web browser on a

computer, smartphone, or other device, as easily as accessing a

website.

Browsers

The following operating systems and web browsers have been

confirmed to be compatible with this camera. Depending on your

environment, operation may differ.

Windows 8.1, Windows 7: Google Chrome Ver. 44

Windows 8.1, Windows 7: Internet Explorer 11

OS X (operating system version 10.10): Safari Ver. 8.0

iOS (operating system version 8.4): Safari

Android (operating system version 4.4): Google Chrome

* Operation on the above operating systems and web browsers cannot be

guaranteed for all the terminals.

* Not available unless the web browser is set to allow cookies.

* Not available unless the web browser is set to use JavaScript.

* Movies cannot be played back unless the web browser supports HTML 5.
