INSTRUCTION

MANUAL

Wi-Fi (Wireless Communication) Function

Instruction Manual

Introduction

What You Can Do Using the Wi-Fi



(Wireless Communication)

Functions

(CANON iMAGE

GATEWAY)

(6) Send images to a

Web service

(1) Communicate with a smartphone

(5) Print images using

a Wi-Fi printer

(3) Save images to

Canon Connect

Station

(4) Operate remotely

using EOS Utility

(2) Send images

between cameras

Introduction

(1)qCommunicate with a smartphone (p.19, 47, 55)

Connect the camera to a smartphone or tablet via Wi-Fi and use the

dedicated application “Camera Connect” to operate the camera

remotely or view images stored in the camera.

In this manual and on the camera’s LCD monitor, “smartphone”

refers to smartphones and tablets.

(2)zSend images between cameras (p.61)

Connect this camera and other Canon cameras with built-in wireless

communication functions via Wi-Fi and send images between them.

(3)Save images to Connect Station (p.73)

Hold the camera close to Connect Station (sold separately) to

connect to it via Wi-Fi and save images to it.

(4)DOperate remotely using EOS Utility (p.77)

Connect the camera to a computer via Wi-Fi and operate the

camera remotely using EOS Utility (EOS software).

(5)lPrint images using a Wi-Fi printer (p.83)

Connect the camera to a printer supporting PictBridge (Wireless

LAN) via Wi-Fi to print images.

(6)wSend images to a Web service (p.95)

Share images with your family and friends or share images using

various Web services via CANON iMAGE GATEWAY, an online

photo service for Canon users (free registration required).

Update the Connect Station firmware to the latest version.

CANON iMAGE GATEWAY Web services are not supported in certain

countries and areas. For information on supported countries and areas,

refer to the Canon Web site (www.canon.com/cig).

Introduction

This camera can be connected easily to a smartphone compatible with

Bluetooth low energy technology* via Wi-Fi. For details, see page 19.

* Hereafter referred to as “Bluetooth”.

This camera is compatible with NFC (Near Field Communication) that

enables you to easily establish a Wi-Fi connection between the camera

and a smartphone or Connect Station (sold separately). For details, see

page 47 or 73.

This camera enables you to establish a Wi-Fi connection by displaying

the Wi-Fi function menu with the <k> button. For details, see the

pages describing how to connect the camera to each device or a Web

service via Wi-Fi.

Wi-Fi Connection Using the BluetoothFunction

Wi-Fi Connection Using the NFC Function

Wi-Fi Connection Using the <k> Button

Note that Canon cannot be held liable for any loss or damage from

erroneous wireless communication settings when using the camera. In

addition, Canon cannot be held liable for any other loss or damage caused

by use of the camera.

When using wireless communication functions, establish appropriate

security at your own risk and discretion. Canon cannot be held liable for

any loss or damage caused by unauthorized access or other security

breaches.

In this manual, the term “access point” indicates wireless LAN

routers, etc. that relay Wi-Fi connections.

The camera does not come with an interface cable.

Icons in this Manual

<6> : Indicates the Main Dial.

<5> : Indicates the Quick Control Dial.

<W><X><Y><Z> : Indicates the direction of the shift or move

when the key on the Quick Control Dial is

pressed.

<0> : Indicates the Setting button.

* In addition to the above, the icons and symbols used on the camera’s buttons

and displayed on the LCD monitor are also used in this manual when discussing

relevant operations and functionality.

(p.**) : Reference page numbers for more information.

: Warnings to prevent potential problems during operation.

: Supplemental information.

Conventions Used in this Manual

This manual is structured as follows. After finishing preparation for a

Wi-Fi connection in “Getting Started”, see the corresponding pages to

set up a Wi-Fi connection according to your needs.

Structure of This Manual

1Getting Started (p.11)

2Connecting to a Bluetooth-

compatible Smartphone via

Wi-Fi (p.19)

3Connecting to an NFC-

compatible Smartphone via

Wi-Fi (p.47)

4Connecting to a Smartphone

via Wi-Fi with the <k> Button

(p.55)

5Connecting to Another Camera

via Wi-Fi (p.61)

6Connecting to Connect Station

via Wi-Fi (p.73)

7Connecting to EOS Utility via

Wi-Fi (p.77)

8Connecting to a Printer via

Wi-Fi (p.83)

9Sending Images to a Web

Service (p.95)

Advanced Wi-Fi

Connection (p.107)

Mainly describes how to

establish a Wi-Fi connection,

using an access point.

A smartphone or computer can

be connected to the camera via

Wi-Fi while maintaining a Wi-Fi

connection to an access point.

Reconnecting via Wi-Fi (p.125)

Checking and Operating Connection Settings (p.131)

Troubleshooting Guide (p.137)

Reference (p.157)

Introduction 2

What You Can Do Using the Wi-Fi (Wireless Communication)

Functions ..........................................................................................2

Conventions Used in this Manual .....................................................5

Structure of This Manual ................................................................... 6

Getting Started 11

Setting Wi-Fi Settings .....................................................................12

Preparation for Smartphones..........................................................15

Preparation for Web Services .........................................................16

Connecting to a Bluetooth-compatible Smartphone

via Wi-Fi 19

Bluetooth Connection......................................................................20

Establishing a Bluetooth Connection ..............................................21

Establishing a Wi-Fi Connection .....................................................25

Operating the Camera Using a Smartphone...................................28

[Bluetooth function] Screen..........................................................31

Removing a Paired Device’s Registration.......................................32

Sending Images to a Smartphone from the Camera ......................33

Specifying Viewable Images ...........................................................43

Connecting to an NFC-compatible Smartphone

via Wi-Fi 47

Wi-Fi Connection to an NFC-compatible Smartphone....................48

Establishing a Wi-Fi Connection .....................................................50

Sending Images from the Camera to a Smartphone ......................53

Contents

Connecting to a Smartphone via Wi-Fi

with the <k> Button 55

Establishing a Wi-Fi Connection..................................................... 56

Connecting to Another Camera via Wi-Fi 61

Establishing a Wi-Fi Connection..................................................... 62

Sending Images to the Other Camera............................................ 64

Connecting to Connect Station via Wi-Fi 73

Saving Images................................................................................ 74

Connecting to EOS Utility via Wi-Fi 77

Establishing a Wi-Fi Connection..................................................... 78

Operating the Camera Using EOS Utility ....................................... 82

Connecting to a Printer via Wi-Fi 83

Establishing a Wi-Fi Connection..................................................... 84

Printing Images .............................................................................. 86

Print Settings .................................................................................. 89

Sending Images to a Web Service 95

Establishing a Wi-Fi Connection..................................................... 96

Sending Images to a Web Service ................................................. 97

Contents

Advanced Wi-Fi Connection 107

Checking the Type of Access Point ..............................................109

Establishing a Wi-Fi Connection with WPS (PBC Mode).............. 110

Establishing a Wi-Fi Connection with WPS (PIN Mode) ............... 114

Connecting to a Detected Network Manually via Wi-Fi................. 118

Reconnecting via Wi-Fi 125

Reconnecting via Wi-Fi .................................................................126

Connecting to a Bluetooth-connected Smartphone via Wi-Fi ....... 128

Registering Multiple Connection Settings .....................................130

Checking and Operating Connection Settings 131

Changing or Deleting Connection Settings ...................................132

Clearing Wireless Communication Settings to Default .................134

View Info Screen........................................................................... 135

Troubleshooting Guide 137

Responding to Error Messages ....................................................138

Troubleshooting Guide..................................................................151

Wireless Communication Function Notes..................................... 153

Security ......................................................................................... 155

Checking Network Settings...........................................................156

Contents

Reference 157

[Wireless communication settings] Screen.............................. 158

[Wi-Fi settings] Screen................................................................ 159

Virtual Keyboard Operation .......................................................... 160

Setting up the IP Address Manually ............................................. 161

Wireless Communication Status................................................... 163

Specifications ............................................................................... 165

Wireless Communication Function Precautions........................... 166

Index............................................................................................. 168
