Installing Your Multifunction

to Your Network for the First Time

PIXMA MX340

Windows OS

<< Previous Next >>

Installing Your Multifunction

to Your Network for the First Time

PIXMA MX340

Windows OS

Preparing to Connect My Multifunction to My Network 3

Network Requirements 3

Notes on Wireless Connection 4

Installing the Drivers & Software 5

Preparing to Connect My Multifunction

To My Network << Previous Next >>

Network Requirements

Before connecting the machine to the network, make sure that configuration of the computer and access point or router is

complete, and that the computer is connected to the network.

Wireless Connection

Before connecting the machine to the network, the computer needs to be connected to the network. Make sure that

configuration of the computer and access point or router is complete.

Preparing to Connect My Multifunction

To My Network << Previous Next >>

Notes on Network Connection

•The configuration, router functions, setup procedures and security settings of

the network device vary depending on your system environment. For details,

refer to your device's instruction manual or contact its manufacturer.

•In an office setup, consult your network administrator

•If you connect to a network that is not protected with security measures, there

is a risk of disclosing data such as your personal information to a third party.

•If an error message appears or if you have trouble with the network

connection, refer to the printed manual: Network Setup Troubleshooting.

•Place the machine and computer on the same network segment.

An "Ad-hoc connection,"which establishes a direct

connection to the computer over a wireless connection

without using an access point, is not supported.

Software Installation

To use the machine by connecting it to a computer, software including the drivers needs to be copied (installed) to the computer's hard disk. The

installation process takes about 20 minutes. (The installation time varies depending on the computer environment or the number of application

software to be installed.)

Installing the Drivers & Software

IMPORTANT

•Log on as the administrator (or a member of the Administrators group).

•Quit all running applications before installation.

•Do not switch users during the installation process.

•Internet connection may be required during the installation. Connection fees may apply. Consult the internet service provider.

•It may be necessary to restart your computer during the installation process. Follow the on-screen instructions and do not remove the

Setup CD-ROM during restarting. The installation resumes once your computer has restarted.

•If the firewall function of your security software is turned on, a warning message may appear that Canon software is attempting to access

the network. If such a warning message appears, set the security software to always allow access.

<< Previous Next >>

Installing the Drivers & Software

If you connect the machine via wireless LAN setup cable before installing the software:

Installing the Drivers & Software

For Windows 7

1. Remove the wireless LAN setup cable connected to

your computer.

2. Proceed to Step 1.

For Windows Vista/Windows XP

This dialog box may appear.

1. Remove the wireless LAN setup cable connected to your

computer. If the dialog box closes, proceed to Step 1.

2. Click Cancel.

3. Proceed to Step 1.

<< Previous Next >>

Do not connect the wireless LAN setup cable yet. Software installation

requires temporary use of the wireless LAN setup cable.

Step Two

Click Run Msetup4.exe on the AutoPlay screen, then click Yes or

Continue on the User Account Control dialog box.

If the User Account Control dialog box reappears in following steps,

click Yes or Continue.

Step One

Turn on the computer, then insert the Setup CD-

ROM into the CD-ROM drive. If you are using

Windows, the setup program starts automatically.

<< Previous Next >>

Installing the Drivers & Software

Note:

If the program does not start automatically, double-click the

CD-ROM icon in Computer or My Computer. When the CD-

ROM contents appear, double-click MSETUP4.EXE.

<< Previous Next >>

Step Three

Click Easy Install

The drivers, application software, and on-screen manuals are

installed.

Note:

If you want to select particular items to install, click Custom

Install.

Step Four

Click Install

Installing the Drivers & Software

Step Six

Easy-WebPrint EX is Web print software that is installed on the

computer when installing the supplied software. Internet Explorer 7

or later is required to use this software. An Internet connection is

required for installation.

Select Next or Skip. Selecting Next will download and install the

Easy-WebPrint EX software.

Step Five

Select Use the printer on network, then click Next.

<< Previous Next >>

Installing the Drivers & Software

Step Seven

When the Printer Detection screen appears, click Next.

IMPORTANT

If the Printer Connection screen appears instead of the screen above, the

connection method is not correctly selected in 5.

Follow on-screen instructions and proceed with the installation. Click Exit on

the installation complete screen, then start again from 2 and be sure to select

Use the printer on network in 5.

<< Previous Next >>

Installing the Drivers & Software

Step Eight

Make sure the machine is turned on, then click OK.
