Canon PIXMA MX340 Series Manuel

Installing Your Multifunction to

Additional Computers on Your Network

PIXMA MX340/ PIXMA MX350/ PIXMA MX870

Windows OS

<< Previous Next >>

Installing Your Multifunction to

Additional Computers on Your Network

PIXMA MX340/ PIXMA MX350/ PIXMA MX870

Windows OS

Preparing to Connect My Multifunction to My Network 3

Network Requirements 3

Important Information You Need Before Adding Your Multifunction 4

Downloading & Installing the Drivers 5

Download the Driver 5

Installing the Driver 8

<< Previous Next >>

Network Requirements

Before connecting the machine to the network, make sure that configuration of the computer and access point or router is

complete, and that the computer is connected to the network.

Notes on Network Connection

•The configuration, router functions, setup procedures and security settings of the network device vary depending on your

system environment. For details, refer to your device's instruction manual or contact its manufacturer.

•The machine cannot be used over a wireless and wired connection at the same time.

Wireless Connection

Connect to your network environment over a wireless connection.

Preparing to Connect My Multifunction

To My Network << Previous Next >>

Preparing to Connect My Multifunction

To My Network << Previous Next >>

Be sure to prepare an access point.

Important Information You Need Before Adding Your Multifunction

The following information is required to connect to your access point or router.

•Access Point Name/Network Name:

Also referred to as SSID. A name to identify the specific access point.

•Network Key:

Also referred to as encryption key, WEP key or WPA/WPA2 passphrase, Pre-Shared key.

A password required to set to prevent unauthorized access to communication.

Check your access point or router for the following information, and then write it down.

NOTE: For details on how to check the following information, refer to the manual of your access point or router, or contact its manufacturer.

An "Ad-hoc connection," which establishes a direct

connection to the computer over a wireless connection

without using an access point, is not supported.

Downloading and Installing the Drivers

Downloading the Driver

To use the machine by connecting it to a computer, software including the drivers needs to be copied (installed) to the computer's hard disk. The

installation process takes about 20 minutes. (The installation time varies depending on the computer environment or the number of applications

to be installed.)

<< Previous Next >>

Step One

Go to the Drivers & Software for your model

MX340

MX350

MX870

Step Two

Select your operating system in the Select OS dropdown

menu.

Downloading and Installing the Drivers << Previous Next >>

Step Three

In the Drivers section, click the Download icon for the MP Driver

example: MX340

*The File Name varies by model

Downloading and Installing the Drivers << Previous Next >>

Step Four

On the next screen, read the information and instructions and click I Agree - Begin Download

Select [Save] or [Run]. If [Run] is selected, the file will be automatically installed

If [Save] is selected, once the file has been downloaded, double-click it to begin the installation process

IMPORTANT:

•Quit all running applications before installation.

•Log on as the administrator (or a member of the Administrators group).

•Do not switch users during the installation process.

•Internet connection may be required during the installation. Connection fees apply.

•It may be necessary to restart your computer during the installation process. Follow the on-screen instructions. The

installation resumes once your computer has restarted.

If the firewall function of your security software is turned on, a warning message may appear that Canon software is attempting

to access the network. If such a warning message appears, set the security software to always allow access.

Step One

Click Next on the Welcome screen.

Step Two

Select your place of residence and click Next.

Installing the Driver

NOTE: If a User Account Control screen appears, click Continue or Yes (depending on Windows version) to continue.

NOTE: If the same screen reappears in subsequent steps, click Continue or Yes.

Downloading and Installing the Drivers << Previous Next >>

Step Four

Select Use the printer on network, then click Next

Step Three

Click Yes for the License Agreement.

Downloading and Installing the Drivers << Previous Next >>

If the Please Allow All Install Wizard Processes screen

appears, click Next.

Installation starts. Follow any on-screen instructions to

install the software.

Downloading and Installing the Drivers << Previous Next >>

Step Five

Turn on the printer then click OK..

Step Six

On the Detected Printers List, select the printer (if more than one is

listed), then click Next.
