Canon PIXMA MP620 series Manuel

Hardware Setup

Follow setup instruction on pages 2-8 of the Getting Started Guide

Wireless LAN Setup

Before starting please locate and write down your access point settings:

Network Name (also called SSID):

Network password (if applicable):

1345

Use the Easy-Scroll Wheel (A) or the

or button to select Settings,

then press the OK button.

Select Device

settings, then press

the OK button.

Select LAN settings,

then press the OK

button.

Select Change

wireless/wired, then

press the OK button.

Select Wireless LAN

active, then press the

OK button.

USB

Turn on the computer, then

insert the Setup CD-ROM into

the CD-ROM drive.

Connect one end of the USB cable

to the computer and the other to the

machine.

Make sure the machine is turned on.

Double-click the Setup icon.

If the CD-ROM folder does

not open automatically,

double-click the CANON_IJ

icon on the desktop.

Canon

(A)

Makesure to read this manual before using the machine. Please keep it in hand for future reference.

Getting Started

=Read Me First=

series

Photo All-In-One

For USB, Wired LAN and all Windows connections see Getting Started Guide.

PIXMA MP620

Macintosh Wireless Setup

Driver/Software Install

For information on setup when printing from multiple

computers, see the Getting Started Guide.

Enter your Administrator

Name and Password.

Click OK.

If you do not know your

administrator name or

password, click .

ame

continue

Click Easy Install. Click Restart.

When computer restarts, Canon IJ

Network Tool starts automatically.

Follow on-screen instructions.

a. On the Canon IJ Network Tool

screen, select LAN connection

b. Click OK

a. Select Setup in the drop down menu

b. Select MP620 series in Printers

c. Click OK

a. Turn off the printer

b. Disconnect the USB cable and

place the printer where it will be used

c. Turn the printer back on

d. Click Next

a. When the Access Points screen

appears, select an access point (SSID)

b. Enter your Network Password

(if applicable)

c. Click Connect

Driver/Software Install

For Users With One Access Point

For Users With Multiple Access Points (Wireless Routers) Proceed to Section 4B

continued...

576

Proceed to section 5

Click Manual Setup

a. Enter the Network Name (SSID) that

you would like the printer to join

b. Choose your Encryption Method

from the drop down menu

c. Click Connect

a. Check the Authentication Type

b. Click Next

a. Enter your Passphrase

b. Click Next

Check the settings and click Finish Click Connect

4BFor Users With Multiple Access Points

(For example: AirPort Extreme AND Time Capsule)

a. On the Canon IJ Network Tool

screen, select LAN connection

b. Click OK

a. Select Setup in the drop down menu

b. Select MP620 series in Printers

c. Click OK

8 9

a. Turn off the printer

b. Disconnect the USB cable and

place the printer where it will be used

c. Turn the printer back on

d. Click Next

Proceed to page 56 of the Getting Started

Guide, “Loading Paper”

Apple, AirPort Extreme, Macintosh and Time Capsule are

trademarks of Apple, Inc., registered in the U.S. and other

countries.

To check whether the

new location is better,

click Remeasurement.

Measurement of the

communication status is

performed again.

Confirm the measurement results,

then click Finish.

Ensure that is displayed in

Connection performance between

the printer and the access point.

The Printer Setup Utility and Canon

IJ Network Scanner Selector will

start up.

On the Connection Performance

Measurement dialog box, click

Next.

a. Wait for a while, then select

Canon MP620 series

b. Click Add

The alphanumeric string after Canon

MP620 series is the machine's MAC

address.

If the machine has not been detected,

make sure of the following.

The machine is turned on.–

The firewall function of any security–

software is turned off.

Wireless LAN Connection: The–

computer is connected to the access

point.

The machine is not set to use access–

control (MAC address filtering).

a. Confirm that a check mark

is displayed

b. Click Exit to close the dialog

box

a. On the Canon IJ Network

Scanner Selector screen

select Canon MP620

series Network in TWAIN

Data Source Name and the

MAC address of the machine

in Network Device List

b. Click Apply to use the

machine as a scanner

Measure Wireless Performance

Complete the Setup

Getting Help from Canon

Visit www.canontechsupport.com

Call 1-800-828-4040

Monday - Friday (excluding holidays), during the warranty period

1 2 3

20081010-US-Web-V01 ©CANON INC. 2008 PRINTED IN U.S.A.
