Canon PIXMA MG6320 Manuel

Installing Your Multifunction to

Additional Computers on Your Network

PIXMA MG6320

Windows OS

<< Previous Next >>

Installing Your Multifunction to

Additional Computers on Your Network

PIXMA MG6320

Windows OS

Preparing to Connect My Multifunction To My Network 3

Network Requirements 3

Notes on Wireless Connection 4

Using the Machine from Additional Computers 5

<< Previous Next >>

Preparing to Connect My Multifunction

To My Network

Network Requirements

Before connecting the machine to the network, make sure that configuration of the computer and access point or router is

complete, and that the computer is connected to the network.

Wireless Connection

Before connecting the machine to the network, the computer needs to be connected to the network. Make sure that

configuration of the computer and access point or router is complete.

<< Previous Next >>

Preparing to Connect My Multifunction

To My Network << Previous Next >>

Notes on Network Connection

•The configuration, router functions, setup procedures and security settings of

the network device vary depending on your system environment. For details,

refer to your device's instruction manual or contact its manufacturer.

•In an office setup, consult your network administrator

•If you connect to a network that is not protected with security measures, there

is a risk of disclosing data such as your personal information to a third party.

•If an error message appears or if you have trouble with the network

connection, refer to the printed manual: Network Setup Troubleshooting.

•Place the machine and computer on the same network segment.

An "Ad-hoc connection," which establishes a direct connection to the computer

over a wireless connection without using an access point, is not supported.

A wireless Access Point or Router is required to use your printer on a wireless LAN

Using the Machine from Additional Computers

Software Installation

If the machine is already connected to a wireless connection, it can be used from additional computers on the same network. Connection to the

network is confirmed automatically. Only the software needs to be installed. It is not necessary to make any changes or settings on the printer

itself.

IMPORTANT

•Log on as the administrator (or a member of the Administrators group).

•Quit all running applications before installation.

•If the firewall function of your security software is turned on, a warning message may appear that Canon software is attempting to access

the network. If such a warning message appears, set the security software to always allow access.

A step-by-step walk through of the wireless setup is built in to the installation routine of the software that shipped with your PIXMA.

Insert the Setup CD-ROM* that came with your printer into your CD-ROM drive of each computer you wish to use with the printer and

proceed through the easy to follow instructions

*Note: If you don’t have or cannot use the Setup CD-ROM, you can still install the software on the computer by using a file downloaded

from our web site. Click here for information

<< Previous Next >>

Using the Machine from Additional Computers

<< Previous Next >>

Installing the PIXMA MG6320 on Additional Computers

Follow any preliminary on-screen instructions. When the following screen appears, click Next .

Installing the Drivers & Software

<< Previous Next >>

Network connection is automatically confirmed. . Continue to follow any remaining On-screen instructions to install the software. On the

Software Installation List screen, select any software to be installed. MP Drivers is required for the printer to be able to print and scan and

cannot be de-selected. My Image Garden and Quick Menu* are highly recommended to take full advantage of your printer’s features.

*Note: If you are using the downloaded Mini

Master Setup file, only the MP Drivers will

be installed.

You can download the additional software

applications from the Software section of the

Drivers & Software page where you obtained

the Mini Master setup file.

Installing the Drivers & Software

<< Previous Next >>

Continue to follow on-screen instructions. Click Complete on the Setup Completion window.

Follow any remaining on-screen instructions to finish and exit the setup program.

Installing the Drivers & Software

<< Previous

Installing the PIXMA MG6320 on Your Wireless Network

If you can’t find your CD-ROM, you may download the MG6300 series Mini Master Setup, which includes the same step-by-step installation as

the CD-ROM, by following the instructions below:

1. Click here to access the MG6320 Drivers & Software page.

2. Select the operating system and version of your computer (see example below).

3. Expand the ‘Drivers’ section, if necessary, by clicking the red triangle.

4. Click on ‘MG6300 series Mini Master Setup’ .

5. After reading the details and disclaimer, click ‘I Agree –Begin Download’ and save the file to your computer.

6. Once the download is complete, double-click the file from its download location to begin the installation.

Return to Setup instructions
