Candy CLD135-86S Manuel utilisateur
31000955 CLD135-86S
Service Manual
31000955 CLD135-86S 0529 (13/07/2005)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2009 Gias S.r.L.
2 Programs disc 40002760 0601 (03/01/2006)
2 Programs disc 41017864 0601 (03/01/2006)
15 Cam disc 41000265 0601 (03/01/2006)
19a Button 0/1 41013656
31 Control panel 40002762
32 Dispenser drawer front 40002751
40 Insert 41013917
47 Table top front frame 91602091
48 R/H side frame 03940707
48a L/H side frame 03940708
49 Top rear frame 91601680
49g Trade mark plate 91617795
51 Work top 03410177
60 Hinge 91700102
62 Door surround 41013807
63 Door glass 91600903
65a Door catch with spring service pack 49005361
67 Glass door with frame 41014003
67d Counter ring 41013808
73a Screw 09031030
76 Cabinet assy 04230909
77 Rear panel 97911044
78 Socle 41006148
79 Rear foot 92606474
80 Front foot 92692300
94c Filter knob with gasket 06015493
97d Filt hous w/filter cartridge 91941772
101 Dispenser drawer 92953249 0601 (03/01/2006)
101 Dispenser drawer 41013614 0601 (03/01/2006)
103 Rack 91601905
109 Dispenser bottom section assy 92967918 0601 (03/01/2006)
109b Dispenser bottom section 41013608 0601 (03/01/2006)
31000955 CLD135-86S 0529 (13/07/2005)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2009 Gias S.r.L.
110 Dispenser top section 03870774 0601 (03/01/2006)
110 Dispenser top section 41013609 0601 (03/01/2006)
111 Water injector nozzle 92149327
112 Distribution connecting rod 92884212 0601 (03/01/2006)
113 Lever 06012914
114 Driving lever 41000950 0601 (03/01/2006)
114a Hose clip 92470061
116 Cam 06012915
118 Spring 92483148 0601 (03/01/2006)
131 Hose clip 92470020
131a Hose clip 92470194
132 Hose 03320039 0601 (03/01/2006)
132 Hose 40004134 0601 (03/01/2006)
133 Hose clip 92470012
134 Solenoid valve 41014223 0601 (03/01/2006)
134 Solenoid valve 41013616 0601 (03/01/2006)
138 Drain hose 92693373
138a Drain house elbow 92689587
138b Hose clamp 92895051
142 Fill hose 92250869
151b Motorized selector 22 settings 41003735 0601 (03/01/2006)
151g selector 22 settings 41014503 0601 (03/01/2006)
153 Pressure switch 40001161 0601 (03/01/2006)
153 Pressure switch 40004263 0601 (03/01/2006)
157 Harness 40002750 0601 (03/01/2006)
157 Harness 40004088 0601 (03/01/2006)
157d 7 Way connection 97911473
157e 6 Way connecton 97911481
157f 11 Way connecton 97911499
157h 12 Way connection 27719027
157n Timer harness 91201360
157p Motor to module harness 91201485
157r Harness x potentiometer 91201489
31000955 CLD135-86S 0529 (13/07/2005)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2009 Gias S.r.L.
157x Flat cable 41005128
157z Flat cable WD 41009792
158 Mains block 91623678
161d Drain/recycle pump complete 97922819
162 Door safety device 91201208
164 Anti jamming filter radio 41010141
178 Motor connector 27719213
202 Drum 04060378
203 Tub 97923664 0614 (03/04/2006)
203 Tub 40004219 0614 (03/04/2006)
204a Front flange 04240204
205 Drum shaft assy 41001233
211 Bolt 97923474
215 Tub gasket 92131689
217 Seal retainer 91406201
219 Bolt 21446068
221 Nut 92424209
225a Gasket 92445626
230 Tub gasket clip 91750458
230a Tub gasket clip 90488603
232 Heater holder 97910301
242a R/H support spring 41003859
242b L/H support spring 41003858
244 Washer 92430206
244a Counter weight washer 92430214
246 Bolt 92419472
246a Bolt 97911507
246b Slide 09078825
246c Clamp 97910061 0614 (03/04/2006)
248 Lower balance weight 41001227
251a Telescopic shock absorber 04320358 0614 (03/04/2006)
31000955 CLD135-86S 0529 (13/07/2005)
Ref. Descrizione - Description - Beschreibung - Descripcion
Fine
Ending
Fin
End
Fin
Inizio
Beginning
Debut
Begin
Inicio
Ricambio
Part No.
Piece
E-Teil
Pieza
Copyright 2009 Gias S.r.L.
251a Telescopic shock absorber 41017168 0614 (03/04/2006)
251c Washer 97910509
251d Nut 97915565
251e Shoch absorber pin 41017173 0614 (03/04/2006)
251f Antinoise bush 41017169 0614 (03/04/2006)
259 Support 92673961
271 Door gasket 91620118
272 Discharge pipe 41001241
273 Fill pipe 91620033
274 Pressure switch air chamber 91611202
275 5x8 hose 66655741 0601 (03/01/2006)
275 5x8 hose 40004272 0601 (03/01/2006)
276 Steam hose 03860581
277 Hose spring 90386137
278a Hose clip d44 92470137
279 Hose clip 92470285
286 Heater 91201546
287g Thermostat 92212687
287m NTC probe 91201325
290 Drum pulley 03850285
292 Drive belt 92130442
292b Bottom panel 04230907
292c Clips 92473636
328 Control panel electronic module 41013732
328a Electronic module container 41013677
328f Pcb protection 41013672
328g WD display board with led 41014109 0601 (03/01/2006)
328g WD display board with led 41013733 0601 (03/01/2006)
330 Screw x hinge 97917587
424 R/H Balance weight 03940637
425 L/H Balance weight 03940581
432 Steam condenser 09200413
