MICROWAVE OVEN

INSTRUCTION MANUAL

CMGA20SDLWLI

IMPORTANT SAFETY INSTRUCTIONS

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

IMPORTANT SAFEGUARDS

The following basic precautions should always be followed

when using electrical appliance:

1. Read all instructions before using.

2. Make sure the voltage in your living area corresponding to

the one shown on the rating label of the appliance. And the

wall socket is properly grounded.

3. To reduce the risk of fire in the oven cavity:

a. Do not overcook the food.

b. Remove wire twist -ties from paper or plastic bags before

placing bags in the oven.

c. Do not heat oil or fat for deep drying as the temperature of

oil cannot be controlled.

d. After use wipe the waveguide cover with a damp cloth,

followed by dry cloth to remove any food splashes and

grease. Built -up grease may overheat and begin to cause

smoke or catch fire.

e. If materials inside the oven should smoke or ignite, keep

oven door closed, turn oven off and disconnect the power

supply.

f. When heating food in plastic or paper containers, keep an

eye on the oven due to the possibility of ignition.

4. To reduce the risk of explosion and sudden boiling:

a. WARNING: Liquids and other foods must not be heated in

sealed container since they are liable to explode; Baby

bottles fitted with a screw cap or teat are considered to be

sealed containers.

b. Use the wide -mouthed container to cook liquid, and the

cooked liquid should not be removed out immediately. Several

moments should be waited before removing. In order to

avoid possible hazards caused by delayed eruptive boiling

of liquids.

c. Potatoes, sausage and chestnut should be peeled or

pierced before cooking. Eggs in their shell, whole hard -boiled

eggs should not be heated in microwave ovens since they

may explode, even after microwave heating has ended.

d. The contents of feeding bottles and baby food jars are to

be stirred or shaken and the temperature is to be checked

before consumption, in order to avoid burns.

5. If the supply cord is damaged, it must be replaced by the

manufacturer or its service agent or a qualified technician in

order to avoid a shock hazard.

6. After cooking, the container is very hot. Using gloves to

take out the food and avoid steam burns by directing steam

away from the face and hands.

7. Slowly lift the furthest edge of dishes cover and microwave

plastic wrap and carefully open popcorn and oven cooking

bags away from the face.

8. To prevent the turntable from breaking:

a. Let the turntable cool down before cleaning.

b. Do not place hot foods or utensils on the cold turntable.

c. Do not place frozen foods or utensils on the hot turntable.

9. Make sure the utensils do not touch the interior walls

during cooking.

10. Only use utensils that are suitable for use in microwave

ovens.

11. Do not store food or any other things inside the oven.

12. Do not operate the oven without any liquid or food inside

the oven. This would do damage the oven.

13. When the appliance is operated in the combination mode,

children should only use the oven under adult supervision

due to the temperatures generated.

14. Any accessories not recommended by the manufacturer

may cause injuries to persons.

15. Do not use outdoors.

16. Save these instructions.

17. WARNING: If the door or door seals are damaged or the

oven is malfunctioned, the oven must not be operated until it

has been repaired by a competent person;

18. WARNING: It is hazardous for anyone other than a

competent person to carry out any service or repair

operation that involves the removal of a cover which gives

protection against exposure to microwave energy;

19. If smoke is emitted, switch off or unplug the appliance

and keep the door closed in order to stifle any flames;

20. Microwave heating of beverages can result in delayed

eruptive boiling; therefore care must be taken when handling

the container;

21. Do not use harsh abrasive cleaners or sharp metal

scrapers to clean the oven door glass since they can scratch

the surface, which may result in shattering of the glass.

22. The lamp of microwave oven is not intended for other

purposes.

23. The appliances are not intended to be operated by means

of an external timer or separate remote -control system.

24. This appliance is intended to be used in household and

similar applications, such as:

• Staff kitchen areas in shops, offices and other working

environments;

• Farm houses;

• By clients in hotels, motels and other residential environ-

ments;

• Bed and breakfast type environments.

25. The microwave oven is intended for heating food and

beverages. Drying of food or clothing and heating of warming

pads, slippers, sponges, damp cloth and similar may lead to

risk of injury, ignition or fire.

26. This appliance can be used by children aged from

8 years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and

understand the hazards involved. Children shall not play

with the appliance. Cleaning and user maintenance shall not

be made by children unless they are older than 8 and

supervised. Keep the appliance and its cord out of reach of

children less than 8 years.

27. This appliance is not intended for use by persons

(including children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

28. Children should be supervised to ensure that they do not

play with the appliance.

29. A steam cleaner is not to be used.

30.The door or the outer surface may get hot when the

appliance is operating.

31. WARNING: Accessible parts may become hot during

use. Young children should be kept away.

32. During use the appliance becomes hot. Care should be

taken to avoid touching heating elements inside the oven.

33. The surfaces are liable to get hot during use.

: CAUTION: HOT SURFACE

Household use only

INSTALLATION

1. Take out all the packing. If there is a safe film over the oven,

tear it off before Use. Check carefully for damage. If any,

immediately notify dealer or send to the manufacturer’s

service center.

2. Microwave ovens must be placed under dry and

non-corrosiveness environments, kept away from heat and

humidity, such as gas burner or water tank.

3. To ensure sufficient ventilation, the distance of the back of

microwave to the wall should be at least 10 cm, the side to

the wall should be at least 5 cm, the free distance above the

top surface at least 20 cm. the distance of the microwave to

the ground should be at least 85 cm.

4. The position of the oven shall be such that it is far from

the TV, Radio or antenna as picture disturbance. The

distance should be more than 5m.

5. The appliance must be positioned so that the plug is

accessible, and must ensure a good grounding in case

leakage, ground loop can be formed to avoid electric shock.

6. The microwave oven must be operated with the door closed.

7. The microwave oven must not be placed in a cabinet.

The microwave oven is intended to be used freestanding.

8. As there is manufacturing residue or oil remained on the

oven cavity or heat element, it usually would smell the odor,

even a slight smoke, It is normal case and would not occur

after several times use, keep the door or window open to

ensure good ventilation. So it is strongly recommended to

set the oven to grill mode and operate dry several times.

CLEANING

MICROWAVE OVEN CARE

CAUTION

The oven should be cleaned regularly and any food deposits

removed.

WARNING

1. Remove the power cord from the wall outlet before cleaning.

Don't immerse the appliance in water or other fluids when

cleaning.

2. Failure to maintain the oven in a clean condition could

lead to deterioration of the surface that could adversely

affect the life of the appliance and possibly result in a

hazardous situation

3. Never use hard detergent, gasoline, abrasive powder or

metal brush to clean any part of the appliance

4. Do not remove the waveguide cover

5. When the microwave oven has been used for a long time,

there may be some strange odors exist in oven, Following

3 methods can get rid of them:

a. Place several lemon slices in a cup, then heat with high

Micro Power for 2-3 min.

b. Place a cup of red tea in oven, then heat with high micro

power.

c. Put some orange peel into oven, and then heat them with

high Micro Power for 1 minute.

6. WARNING: Only allow children to use the oven without

supervision when adequate instructions have been given so

that the child is able to use the oven in a safe way and

understands the hazards of improper use;

TIPS FOR CLEANING

Details for cleaning door seals, cavity and adjacent parts:

Exterior:

Wipe the enclosure with a dampened soft cloth

Door:

Using a dampened soft cloth, wipe clean the door and window

Wipe the door seals and adjacent parts to remove any spill

or spatter

Wipe the control panel with a slightly dampened soft cloth

Interior walls:

Wipe clean the cavity with a dampened soft cloth

Wipe clean the waveguide cover to remove any food splashed

Turntable/ Rotation ring/ Rotation axis:

Wash with mild soap water

Rinse with clean water and allow drying thoroughly

PRODUCT INSTRUCTION

⑦

⑤

②

①③④⑥

⑧

Waveguide cover

1) Door lock

Microwave oven door must be properly closed in order for it to

operate

2) Viewing window

Allow user to see the cooking status

3) Rotating axis

The glass turntable sits on the axis; the motor underneath it

drives the turntable to rotate

4) Rotating ring

The glass turntable sits on its wheels; it supports the turntable

and helps it to balance when rotating

5) Turntable

The food sits on the turntable, its rotation during operation

helps to cook food evenly

CAUTION

- Place the rotating ring first

- Fit the turntable onto the rotating axis and make sure that it is

geared in properly

6) Control panel

See below in details (the control panel is subject to change

without prior notice)

7) Waveguide cover

It is inside the microwave oven, next to the wall of control

panel.

WARNING

Never remove the waveguide cover

8) Grill rack

Use to place the roasting food.

Table des matières

Langues :

Autres manuels Candy Four à micro-ondes

Candy

Candy GB1730MX Manuel utilisateur

Candy

Candy DIVO G25CO Manuel utilisateur

Candy

Candy MIC 20G DFB Manuel utilisateur

Candy

Candy CMG 7517 DS UK Manuel utilisateur

Candy

Candy CMWA23TNDB Manuel utilisateur

Candy

Candy CBGM 30 DS Manuel utilisateur

Candy

Candy MIG1730DX Manuel utilisateur

Candy

Candy MIC 305 X Manuel utilisateur

Candy

Candy MIC25GDFX-6 Manuel utilisateur

Candy

Candy CMXG 30DS-04 Manuel utilisateur

Candy

Candy CMG 2071DS Manuel utilisateur

Candy

Candy MIG440VNTX Manuel utilisateur

Candy

Candy MIC303 Manuel utilisateur

Candy

Candy Timeless CMWA23TNDB-07 Manuel utilisateur

Candy

Candy DIVO G25 CO Manuel utilisateur

Candy

Candy CMWA20TNDB-07 Manuel utilisateur

Candy

Candy CMXW20DR Manuel utilisateur

Candy

Candy MIC440TX Manuel utilisateur

Candy

Candy MOS20X Manuel utilisateur

Candy

Candy CMXG30DB-SASO Manuel utilisateur

Candy

Candy CMW 2070M Manuel utilisateur

Candy

Candy CMXG 25DCS-04 Manuel utilisateur

Candy

Candy 38000002 CMW700E Manuel utilisateur

Candy

Candy CMXW20DB-SASO Manuel utilisateur

Manuels Four à micro-ondes populaires d'autres marques

Daewoo

Daewoo KOG-574R0S Manuel utilisateur

LG MH7040SS Manuel utilisateur

Sharp

Sharp R-895(AL)M Manuel utilisateur

Dometic

Dometic DOTRM13W Manuel utilisateur

Sanyo

Sanyo EM-X680 Manuel utilisateur

Sharp

Sharp R-393M Manuel utilisateur

KitchenAid

KitchenAid KMCX4510 Instructions d'installation

Smeg

Smeg S45MCX1 Manuel utilisateur

Russell Hobbs

Russell Hobbs RHM2044 Manuel utilisateur

Sunbeam

Sunbeam SMW759 Manuel utilisateur

Gallet

Gallet FMOE230S Manuel utilisateur

Bosch

Bosch CEG732X.1B Manuel utilisateur

Dometic

Dometic Roadmate 230 Manuel utilisateur

Samsung

Samsung SJ0396W Manuel utilisateur

Sanyo

Sanyo EM-P494WS Manuel utilisateur

Sharp

Sharp R-240 Manuel utilisateur

Electrolux

Electrolux EMS2840 Manuel utilisateur

Daewoo

Daewoo KOC-984T2S13 Manuel utilisateur
