entroview

user guide

entroview user guide

To let the caller gain access, press Unlock.

Replace the handset to complete the call.

Press the Privacy button or Adjust the ringer volume with the slider.

If you do not wish to be disturbed, press Privacy. The button will illuminate and the ringer is silenced. Press the

button again to turn the ringer back on.

Lift the handset to answer an incoming call. The video monitor will display for the length of the call.

When someone calls

While on a call

Silence a call

keep it quiet

Privacy

Unlock

Adjust

Low Med Hi

installation guide

Cat 5e / Cat 6 / CW1308 6 Pair Minimum.

This does not allow for redundant cables. If this is a requirement then the installer must allow for this during

installation.

10 Pair CW1308 recommended for cable runs exceeding 70 metres.

Any unused cores to be tied to system 0v.

* NOTE: If DS is required the internal ringer can be enabled and the BZ connection is not required, freeing up the Orange wire.

cable specification

wiring diagram

Privacy

Unlock

Adjust

ENTROVIEW

PLUS

PRIVAC YDOOR OPEN

V T

V-

V+

EX To Sou nders or Beacons Only

BZ*

V-

V+

Suggested Colour Code

Cat 5 / Cat 6

DR - White/Blue+Blue/White

VT - White/Orange+Orange/Whit

0V - White/Green+White/Brown

BZ - White/Grey

S2 - Green/White

S1 - Brown/White

DS - Grey/White

V- - Red/Blue

V+ - Blue/Red

Suggested Colour Code

6 Pair CW1308

White/Blue

Blue

White/Orange

*Orange

White/Green

Green

White/Brown

Brown

CB*

Optional

Door Bell

entroview user guide

Press the Menu button to turn the screen on.

Press Menu to cycle through the on screen display options.

Press + or – to adjust the selected parameter. Once adjusted

the settings will store and the screen will turn off.

Switches 1, 2 & 3 select the privacy function options. Privacy

can be: disabled completely, set to latch on/off or set to time

out after a preset time (see table: 0 = OFF 1 = ON).

Switch 4is for 1 way systems and should be ON for normal

use.

Switch 5is not used.

Switch 6selects video termination and should be ON for

normal use.

video setup

option switches

ENTROVIEW

PRIVACY DOOROPEN

3 Position Call

Tone Volume

Low Med Hi

V-

V+

PL12

Option Switches

12 34 56

1 2 3 Time

0 0 0

0 0 1 Disabled

0 1 0 5 mins

0 1 1 30 mins

1 0 0 1 hr

1 0 1 4 hrs

1 1 0 8 hrs

1 1 1 12 hrs

entroview user guide

To adjust the ringtone press and hold Privacy to start the ringer. Press Privacy to select the ringtone options and

press Door Open to store.

ringtones

CAME S.p.A.

Came cancelli automatici S.p.A.

is certied for Quality and Environment

UNI EN ISO 9001

UNI EN ISO 14001

BS OHSAS 18001

YOU MAY NOT EVEN PARTIALLY REPRODUCE THIS DOCUMENT

CAME RESERVES THE RIGHT TO MAKE ANY CHANGES TO THIS DOCUMENT AT ANY TIME

THE DATA AND INFORMATION SHOWN IN THIS CATALOGUE ARE SUBJECT TO CHANGE WITHOUT OBLIGATION TO GIVE PRIOR NOTICE BY CAME S.P.A, E&OE

CAME ENTROTEC

5 Ashwood Court

Oakbank

Livingston

EH53 0TL

Tel: 01506 886230

Support: 01506 886235

came.com/kms
