ATS-S324 kit

QUICK SETUP GUIDE

Typical gate setup & geometry

Gate motor manual release

Kit wiring diagram

Control panel guide & safety

Complete kit for a single swing gate weighing

up to 400kg / max. width 3m

TO BE READ IN CONJUNCTION WITH THE FULL INSTRUCTION MANUAL

CONTENTS

DIR10

Pair of Photocells

AF43S

Radio Frequency Card

top-a433n

Tuned Antenna

ZL65

Control Panel

ATS30DGS

Motor

ATS-S324: KIT CONTENTS

topd4rks

Rolling code Transmitter

RGSM001S

Gateway Module

RSE

Connection Card

SIM

May be preinstalled in

RGSM001S

1Kit Contents

2Safety Instructions

3Typical Gate Setup

4Geometry

5Manual Release Instructions

6Wiring Diagram

7Pre-installed SIM Card

8Initial Power On

9Commissioning the RGSM

10 Commissioning via App

11 Commissioning via Panel

12 Safety Options

13 Replacing the SIM Card

14 Optional Accessories

2SAFETY INSTRUCTIONS

When correctly installed in compliance to installation instructions and adhering to all

current electrical, mechanical and manufacturer regulations, your automation system

will provide a high degree of safety and problem free operation.

Please take note of the following warnings that must be followed in order to

prevent accidents during your gate operation:

• Do not allow children to play near the gate.

• Keep all remote control operating devices out of the reach of children.

• Do not pass through the gate whilst in operation. Wait until they are fully open before passing through.

• Do not stop unnecessarily when passing through the gate.

• Keep feet away from the bottom of the gate during operation.

• Do not operate the gate by remote control unless they are in view.

• Do not attempt to block or interfere with the gate movement during operation.

• Under no circumstances should you attempt to modify the gate automation system.

• Ensure that your gate is serviced at 3 to 12 month intervals (dependent on number of openings) by your installation/

maintenance company.

• Report any signs of malfunction to your installation/maintenance company immediately.

• In the case of malfunction, isolate the power supply, release any additional locking mechanism, manually open the

gate (see manual release instruction booklet) and call your installation/maintenance company.

• If you are in any doubt regarding the operation of your gate, call your installation/maintenance company.

3 TYPICAL GATE SETUP

OUTSIDE OF GATES

INSIDE OF GATES

1ATS Motor 4Flashing Light (optional) 72nd set of Photocells (optional)

2Control Panel 5Selector Keypad (optional) 8Mechanical End Stop (not supplied)

3Reception Antenna 6Photocells (on outside of gate posts) 9Photocell column (optional accessory)

CONTROL PANEL

PHOTOCELLS

• The control panel should be mounted in an accessible position and not directly behind the gates, to avoid a

potential crushing hazard.

• Use cable glands to connect the devices to the control panel. One of these must be used exclusively for the

power supply cable.

• All holes should be sealed to avoid ingression and maintain the IP54 protection rating.

Only a competent service provider should open the enclosure

and adjust the settings.

• The photocells are used in pairs, one transmitter and one receiver.

• They should be installed between 500-600mm from the ground, facing each other.

• Power for the photocells is taken from the control panel 24v AC.

• The maximum range of the photocell should always be observed.

When the photocell beam is broken, the control panel can be programmed on how to react.

Please see ‘Safety’ section for more information.

4 GEOMETRY

• The greater the motor angle, the greater

the opening speed and the slower the

gear motor’s thrust.

• The smaller the motor angle, the slower

the opening speed and the greater the

gear motor’s thrust.

• Lubricate the bushing and ﬁt it into one of the holes on the post bracket.

• The bracket holes allow the opening angle to be changed.

Opening A (mm) B (mm) E (mm) F (mm) C max. (mm)

90°130 130 960 1220 50

90°150 220 910 1290 150

90°120 270 890 1300 200

120°180 130 910 1300 50

Preliminary checks

Side hung gate GEOMETRY (3m)

Tick

1. Check that the gate structure is sturdy enough, the hinges work eciently and that there is

no friction between the ﬁxed and moving parts

2. Make sure that measurement Cdoes not exceed the value shown in the reference table

3. Make sure that you have ﬁtted opening and closing mechanical gate stops

OUTward OPENING gates

For outward opening gate geometry

please refer to the full Installation Manual.

5 MANUAL RELEASE

The ATS telescopic swing gate operators have a manual release lock beneath a hatch on

the top of the motors.

To manually release the gates:

1. Open the hatch covering the lock A.

2. Insert release key into lock Band turn clockwise C.

3. With your other hand ﬁrmly open the gate. The gate should be manually released. Now fully open the gate carefully at

the same speed as the automatic operator.

4. To re-engage, close the gate and turn the key back to its original position D. Attempt to manually move the gate to

ensure it is fully engaged.

Basic Maintenance: Hints & Tips

• Open manual release cover & spray locking

mechanism with suitable penetrating lubricant.

• Lubricate gate hinges.

• Manually release the gates at least once per month.

ALWAYS isolate the power supply as

instructed by your installer (even in a

power cut).

Release any additional locking

device ﬁtted to the gate (eg. electric

lock etc).

a B C

6 wiring diagram

230

120

GND1 2 3P 7 10 TS 2 CX CY A B GNDS1 A B

-STB

M2 N2 ENC2M1 N1 ENC15E1110

L N

RSE

ZL65

Control Panel

AF43S

Plug-in

RSE

Set RSE jumper

to OFF

TOP-A433N

Antenna

Cable/length

RG58

Max. 5m

DIR

Photocells

Cable/length

RX 4 Core 0.5mm Flex

TX 4 Core 0.5mm Flex

1m - 30m

+ -

10 2 TX C NC TX 2

RX TX

RGSM001S

Gateway Module

Cable/length

Max 3m power

10 2 A B GND

ATS30DGS

Gate motor

Cable/length

1m - 20m = 3 Core 1.5mm

20m - 30m = 3 Core 2.5mm

Mains Supply

230 V AC

Cable/length

1m - 20m = 3 Core 1.5mm

20m - 30m = 3 Core 2.5mm

TITLE7pre-installed sim card

The pre-installed SIM card is an IOT/M2M multi SIM complete with 480MB data allowance and 3 year life term.

Under average usage of 3-4 gate manoeuvres per day, the data should last approximately 3 years.

In case you use up the 480MB data volume before the end of the 3-year term, you can easily add another 480MB data

volume by making a top-up, details of which can be found here:

www.cameconnect.co.uk/gsmmodule

Due to situations outside of our control, CAME cannot guarantee signal strength or availability and therefore will not be

held liable for lack of service.

came automation

internet

came cloud

setup app

for the installer

GET IT ON

App Store

GET IT ON

automation app

for the end user

GET IT ON

App Store

GET IT ON

System Frequency Approx. Movements Est. SIM Life Based on Usage

Occasional Usage Approx. 5 gate manoeuvres per

week

4-7 Years*

Average Usage** Approx. 3-4 gate manoeuvres

per day

3-4 Years

High Usage Approx. 5+ gate manoeuvres per

day, multiple scenarios running

1-3 Years

* SIM will expire after 3-4 years. (CAME guarantees 3 years with some tolerance for shelf life consideration)

** We anticipate SIM provided will have sufﬁcient data for Average Usage (as shown above) lasting approx. 3 years

TITLE

7pre-installed sim card

The pre-installed SIM card is an IOT/M2M multi SIM complete with 480MB data allowance and 3 year life term.

Under average usage of 3-4 gate manoeuvres per day, the data should last approximately 3 years.

In case you use up the 480MB data volume before the end of the 3-year term, you can easily add another 480MB data

volume by making a top-up, details of which can be found here:

www.cameconnect.co.uk/gsmmodule

Due to situations outside of our control, CAME cannot guarantee signal strength or availability and therefore will not be

held liable for lack of service.

came automation

internet

came cloud

setup app

for the installer

GET IT ON

App Store

GET IT ON

automation app

for the end user

GET IT ON

App Store

GET IT ON

System Frequency Approx. Movements Est. SIM Life Based on Usage

Occasional Usage Approx. 5 gate manoeuvres per

week

4-7 Years*

Average Usage** Approx. 3-4 gate manoeuvres

per day

3-4 Years

High Usage Approx. 5+ gate manoeuvres per

day, multiple scenarios running

1-3 Years

* SIM will expire after 3-4 years. (CAME guarantees 3 years with some tolerance for shelf life consideration)

** We anticipate SIM provided will have sufﬁcient data for Average Usage (as shown above) lasting approx. 3 years

8initial power ON

OUT1OUT2

Keycode

123456789ABCDE F

MATR

54051 6

300mAE GSM – 900 33dBm

DCS – 1800 30dBm

869.5MHz 14dBm

24V

CONNECT

123 4

GND

10+

COM

IN2

COM

IN1

–

1A 30V

RGSM001S

1 2

1GSM LED (Blue)

After a few seconds the LED will ﬂash 1x/sec indicating the RGSM001S is registered on a GSM network.

2POWER LED (Green)

The LED will ﬂash 5x/sec indicating the RGSM001S is not yet conﬁgured on the Connect platform

Power on the control board.

to check motor direction using control panel

CAUTION, Ensure the gate movement area is clear of all obstructions

Check the motor direction A2– ON

Press and hold

The gate should open, if not reverse the motor cables (Connections M2, N2)

Leave the gate leaf in the halfway position.

Installer Tip

If the RGSM001S is located

in a concealed area and a low

GSM signal observed a 2m

extension cable and bracket is

available to purchase.

This then allows the aerial to

be located in a more suitable

position. Part No:

806SA-0050

TITLE9 commissioning the rgsm

3.1 Open the App and log in

using your technician details

as registered.

3.2 Select “CAME Connect

connection”.

3.3 Select “Site

management”.

3.4 Fill in a site “Name” and

“Description” and then press

“Add”.

2.1 Select “Register as

technician”.

2.2 Fill in your details and

then “Conﬁrm”.You will

receive an email containing

your log in information

and request to conﬁrm the

account. Should the email not

arrive, please check your junk

folder.

download the

connect setup app

adding the rgsm gateway

to your technician account

technician

connect setup app

If you have an existing account, please move to step 3.

Important!

The installation must be carried out

by skilled and qualified personnel

Mr Wilson, Sills Road, DE74 2US

1.1

GET IT ON

App Store

GET IT ON

Installer Tip

The Name and Description entered

here, can be used to identify the

site location.

Name: Mr Wilson, Sills Rd, DE74 2US

Description: Mr Wilson, Sills Rd,

DE74 2US

This shows in the Installers

Setup App, under the site

management list.

Table des matières

Autres manuels CAME ouvre-porte

CAME

CAME RSDN002 Manuel utilisateur

CAME

CAME 8K01MI-0523 Manuel utilisateur

CAME

CAME Ferni Series Manuel utilisateur

CAME

CAME TOP-864EE Manuel utilisateur

CAME

CAME F1000 Manuel utilisateur

CAME

CAME AGTK200V03 Manuel utilisateur

CAME

CAME BXL04AGS Manuel utilisateur

CAME

CAME FROG-AV Manuel utilisateur

CAME

CAME FROG series Manuel utilisateur

CAME

CAME FA70230 Manuel utilisateur

CAME

CAME BXV Tall Series Manuel utilisateur

CAME

CAME BKS08AGS Manuel utilisateur

CAME

CAME Sipario Series Guide de configuration

CAME

CAME FTX20DGC Manuel utilisateur

CAME

CAME BXV04AGS Manuel utilisateur

CAME

CAME BKV15AGE Manuel utilisateur

CAME

CAME BXV04AGE Manuel utilisateur

CAME

CAME PB1100 Manuel utilisateur

CAME

CAME FROG series Manuel utilisateur

CAME

CAME BK-221 Manuel utilisateur

CAME

CAME 119RW45 Manuel utilisateur

CAME

CAME FE40230 Manuel utilisateur

CAME

CAME FA4024CB Manuel utilisateur

CAME

CAME 806LA-0050 Manuel utilisateur

Manuels ouvre-porte populaires d'autres marques

Elite

Elite CSW200UL Manuel utilisateur

SOMFY

SOMFY FX230 Manuel utilisateur

Aprimatic

Aprimatic ONDA 500 Manuel utilisateur

Turnstiles

Turnstiles FSW 900 Manuel utilisateur

Erreka

Erreka BUL BL33 Mode d'emploi

Erreka

Erreka VULCAN S Manuel utilisateur

Beninca

Beninca R1-2 WBV Manuel utilisateur

Erreka

Erreka VULCAN D Manuel utilisateur

Motorline professional

Motorline professional FORT Mode d’emploi

Beninca

Beninca BOB5024 Manuel utilisateur

AGA

AGA GATEMASTER 900 HD Manuel utilisateur

Chamberlain

Chamberlain MotorLift HC280ML Manuel utilisateur

SOMFY

SOMFY Dexxo RTS Pro Manuel utilisateur

Cardin

Cardin BL Series Manuel utilisateur

Westfalia

Westfalia 85 27 06 Manuel utilisateur

Extel

Extel VERA Manuel utilisateur

Comunello Automation

Comunello Automation ABACUS 220 Manuel utilisateur

Mighty Mule

Mighty Mule 200 E-Z GATE OPENER UL325 SERIES Manuel utilisateur
