Cambo PCF Manuel utilisateur
PCF
Full Controlled Head
INSTRUCTION MANUAL
EN
Please read this manual carefully before using the PCF!
Version
1.0
2
3
Index:
1. Key Features PCF ........................................................................5
2. Warnings....................................................................................5
3. Operating the PCF.......................................................................6
4. Pivoting......................................................................................7
5. Tilting.........................................................................................8
6. Rotating .....................................................................................9
7. Adjusting the PCF friction..........................................................10
8. Malfunction measures..............................................................11
4
Thank you for purchasing a Cambo product
The PCH is a tripod head which features geared rotational movement around
the X- and Y-Axis and Z-Axis (top) and double (top and bottom plate) manual
rotation around the Z-axis. This enables the PCF to be used as a normal ball
head for fast levelling adjustment as well as a precision gear head for fine
levelling adjustments.
5
1. Key Features PCF
360º manual panning at the top and bottom plate
360º geared panning at the top plate
Position click indication every 90º at the top and bottom plate
140º X-axis tilt (30º backwards 110º forward)
Separate manual (fast) or geared (fine) movement around the X-axis
140º Y-axis pivot (30º backwards 110º forward)
Separate manual (fast) or geared (fine) movement around the Y-axis
X-, Y- and Z-axis rotate over the same point
When X-, Y- and Z-axis locking knobs are open the PCH can move freely
like a normal spherical head.
Adjustable geared friction
Adjustable manual friction
Arca compatible clamp
4 large spirit levels
Durable stainless steel 3/8’’ and 1/4’’ tripod mounting options.
2. Warnings
Always! support the camera when unlocking one of the PCF locking
knobs.
Keep your camera supported until all locking knobs are back in locking
position.
Apply no more than 4Kg to the PCF
6
3. Operating the PCF
Figure 1 PCF operation knobs.
A
QR knob
B
Top spirit levels
C
Geared pivot adjustment knob
D
Manual pivot adjustment locking knob
E
Bottom plate rotation index locking knob
F
Geared tilt adjustment knob
G
Bottom spirit levels
H
Manual tilt adjustment locking knob
I
Top plate rotation index locking knob
J
Geared top plate rotation adjustment knob
7
4. Pivoting
Figure 2 PCF Pivot movements
For pivoting the PCF manually:
make sure to support your camera before unlocking
Rotate locking knob [D] Counter clockwise (CCW) to unlock
manual operation
Manually push to the desired position
Rotate locking knob [D] Clockwise (CW) to lock it into position
For pivoting the PCF geared:
Make sure knob [D] is locked
Rotate knob [C] CW for pivoting to the right
Rotate knob [C] CCW for pivoting left
Maximum pivot movement 110º left, 30º right
8
5. Tilting
Figure 3 PCF tilt movements
For tilting the PCF manually:
make sure to support your camera before unlocking
Rotate locking knob [H] CCW to unlock the manual operation
Manually push to the desired position
Rotate locking knob [H] CW to lock it into position
For tilting the PCF geared:
Make sure knob [H] is locked
Rotate knob [F] CW for pivoting to the right
Rotate knob [F] CCW for pivoting left
Maximum tilt movement 110º forward, 30º backward
9
6. Rotating
To rotate the camera, unlock either locking knob [E] (rotate CCW to
unlock) for manual rotation around the bottom plate, or knob [I] to
rotate around the top plate. Both rotating movements have position
click indications every 90º for fast positioning. The top plate is fitted
with a 360º scale for precise positioning. Use knob [J] for geared
rotation around the Z-axis.
To prevent the locking knobs from interfering with the housing or base
plates that exceed the size of the bottom plate, both locking knobs have
been fitted an indexing feature. By pulling the locking knob outward [1.]
the locking knob can be rotated [2.] to any desired position.
Figure 4 PCF index locking knobs
10
7. Adjusting the PCF friction
It is possible to fine tune the PCF manual control friction to your own
preference. Note that fine tuning the PCF friction is a precise task and
should be performed with great care to prevent damages or
malfunctioning.
Fine tuning the manual friction:
Figure 5 PCF manual friction adjustment
1. Rotate locking knobs [D] and [H] CCW until they come off the
threaded axis.
2. Use an 8mm wrench to turn the M5 locking nut CW to apply
more friction or CCW to apply less friction.
3. Re-apply locking knobs [D] and [H] by rotating them CW over
the threaded axis.
