cnMatrix EX2K Switch
Basic Configuration Guide
cnMatrix EX2K Basic Configuration Guide
Copyright2021CambiumNetworks.Allrightsreserved.(v2.10) 1
Thank you for choosing the cnMatrix switch, a Cambium Networks communications device. Before you begin
installing the switch, verify you have all the package contents available, and a PC with SSH client, such as PuTTY or
OpenSSH SSH Client.
Package Contents
Rack mount ears (2x) with screws (8x) are included with the 16-port,
28-ports and 52-ports models.
(Spare rack mount ears: MX-EXTXFULLA-0)
A rack mount kit for the 10-port models can be ordered as an optional
accessory: MX-EXTXHALFA-0
cnMatrix Switch
EX2010 models:
EX2028 models:
EX2016M-P model:
EX2052 models:
Power Cord (separate accessory)
cnMatrix EX2K Basic Configuration Guide
Copyright2021CambiumNetworks.Allrightsreserved.(v2.10) 2
Product Overview
The cnMatrix switch comes in eight SKUs to support various deployment scenarios:
Model Name / Part
Number
Number
of Ports
Power
over
Ethernet
Throughput Switch
cnMatrix EX2010
/
MX-EX2010xxA-0
10 No 20 Gbps
cnMatrix EX2010-P
/
MX-EX2010PxA-0
10 Yes 20 Gbps
cnMatrix EX2028
/
MX-EX2028xxA-0
28 No 128 Gbps
cnMatrix EX2028-P
/
MX-EX2028PxA-0
28 Yes 128 Gbps
cnMatrix EX2052
/
MXEX2052GxxA00
52 No 176 Gbps
cnMatrix EX2052-P
/
MXEX2052GxPA00
52 Yes 176 Gbps
cnMatrix EX2K Basic Configuration Guide
Copyright2021CambiumNetworks.Allrightsreserved.(v2.10) 3
cnMatrix EX2052R-P
/
MXEX2052GxPA10
52 Yes 176 Gbps
cnMatrix EX2016M-P
/
MXEX2016MxPA00
16 Yes 86 Gbps
Powering Up
Connect the power cord to the power inlet, and then plug the power cord into a wall socket.
For the EX2052R-P model, first install the removable power supply (CRPS) into the power supply slot in the rear of
the switch. The CPRS is sold as a separate accessory. The CRPS are available in AC or DC input options
Connect the power cord (separate accessory) to the CRPS power inlet, and then plug the power cord into a wall
socket.
For the EX2052R-P model, please purchase an approved power supply (CRPS) through an authorized dealer.
Example:
Model: ZRE-1AB0K2 Cambium p/n: MXCRPSAC1200A0
When the switch is booting up, the illuminated Cambium Networks logo will be blinking blue. When the
switch is fully up and running, the illuminated Cambium Networks logo is solid blue.
Default Configuration
IP address 192.168.0.1 is automatically configured on Out-Of-Band Management Port (MGMT).There is no default IP
address In Band Network Ports.
cnMatrix EX2K Basic Configuration Guide
Copyright2021CambiumNetworks.Allrightsreserved.(v2.10) 4
Note: DHCP is enabled by default on In Band Ports (VLAN1).
Defaultlogininformation:
Username: admin
Password: admin
Configure Management PC
1 In Windows, double-click the Control Panel command. The Control
Panel window is displayed.
2 In the Control Panel window, select the View network status and
tasks option. The Network and Sharing Center window is displayed.
3 Click the Change adapter settings option. The Network Connections
window is displayed.
4 Double-click the interface. The interface Properties window is
displayed.
5 Select the Internet Protocol Version 4 (TCP/IPv4) option. Click OK.
6 Set The IP address of the interface to 192.168.0.10 and the Subnet
mask to 255.255.255.0
Logging in to the switch
1
Use PuTTY SSH client.
cnMatrix EX2K Basic Configuration Guide
Copyright2021CambiumNetworks.Allrightsreserved.(v2.10) 5
2 On the PuTTY Configuration
window, in the Host Name field,
enter the 192.168.0.1 IP address
and in the Port field, enter the 22
value.
3 Click Open. The login prompt is
displayed.
4 In the cnMatrix login prompt enter
the default username: admin
5 In the Password prompt enter the
default login password: admin
Management Port
Used for Managing the
switch.It provides out of band
network connectivity for
management of the switch.
cnMatrix EX2K Basic Configuration Guide
Copyright2021CambiumNetworks.Allrightsreserved.(v2.10) 6
Hardware Overview
Specifications
cnMatrix Models EX2028-P EX2028 EX2010-P EX2010
MTBF (hours) 285.350.90 432.283.26 338.917.20 806.354.10
Power budget 400W n/a 100W n/a
Power supply AC/Internal AC/Internal AC/Internal AC/Internal
Weight 3.96 kg (8.75 lb) 2.77 kg (6.1 lb) 1.99 kg (4.375 lb) 1.6 kg (3.5375 lb)
Dimensions 44 x 4.4 x 25 cm
(17.3 x 1.75 x 9.85 in)
44 x 4.4 x 20.9 cm
(17.3 x 1.75 x 8.22 in)
21 x 4.4 x 25 cm
(8.26 x 1.75 x 9.85 in)
21 x 4.4 x 25 cm
(8.26 x 1.75 x 9.85 in)
LEDs per port Link/Activity, PoE Link/Activity, PoE Link/Activity, PoE Link/Activity, PoE
Rack mountable Yes 1U Yes 1U Yes 1U Yes 1U
Operating Temperature -0°C to + 50°C
(+32°F to + 122°F)
-0°C to + 50°C
(+32°F to + 122°F)
-0°C to + 50°C
(+32°F to + 122°F)
-0°C to + 50°C
(+32°F to + 122°F)
Operating humidity +55° at 95% RH +55° at 95% RH +55° at 95% RH +55° at 95% RH
Storage temperature -40°C to +70°C
(-40°F to +158°F)
-40°C to +70°C
(-40°F to +158°F)
-40°C to +70°C
(-40°F to +158°F)
-40°C to +70°C
(-40°F to +158°F)
Power LED
cnMatrix Logo (Power) LED
is continuously blue – the
switch is operational.
cnMatrix Logo (Power) LED
is blinking blue – the switch is
initializing.
Ports
Data ports used for traffic
forwarding. Orange
border ports indicate
PoE+ up to 30W.
(802.3af/at)
Green border ports
indicate PoE+ up to
60W. (802.3af/at/bt)
Fiber Ports
1 Gig/10 Gig fiber ports
(SFP+).
The 10-port cnMatrix
provides 1 Gig fiber ports
(SFP).
Console
RJ45
connection for
console access.
Reset button
Simple reboot:
Press and
release within 10
seconds.
Factory default:
Press and hold
for > 10 seconds
cnMaestro LED
Blinking blue: Connecting to
cnMaestro.
Solid blue: Connected to
cnMaestro.
cnMatrix EX2K Basic Configuration Guide
Copyright2021CambiumNetworks.Allrightsreserved.(v2.10) 7
Specifications (cont’d)
cnMatrix Models EX2052
EX2052-P
EX2052R-P EX2016M-P
MTBF (hours) 393,648 238,063 202,977 385,242
Power Budget n/a 400W CRPS dependent 240W
Power Supply AC/Internal AC/Internal CRPS (not internal) AC/Internal
Weight 3.6 kg (7.93lb) 5.4kg (11.90lb) 4.3 kg (9.48 lb)
Or 5.2 kg (11.46lb)
3.6 kg (7.93 lb)
Dimensions 44 x 4.4 x 20.9 cm
(17.3 x 1.75 x 8.22 in)
44 x 4.4 x 35 cm
(17.3 x 1.75 x 13.78 in)
44 x 4.4 x 35 cm
(17.3 x 1.75 x 13.78 in)
44 x 4.4 x 25 cm
(17.3 x 1.75 x 9.85 in)
LEDs per port Link/Activity Link/Activity, PoE Link/Activity, PoE Link/Activity, PoE
Rack mountable Yes 1U Yes 1U Yes 1U Yes 1U
Operating Temperature -0°C to +50°C (+32°F
to +122°F)
-0°C to +50°C (+32°F to
+122°F)
-0°C to +50°C (+32°F to
+122°F)
-0°C to +50°C
(+32°F to +122°F)
Operating humidity +55° at 95% RH +55° at 95% RH +55° at 95% RH +55° at 95% RH
Storage temperature -40°C to +70°C
(-40°F to +158°F)
-40°C to +70°C
(-40°F to +158°F)
-40°C to +70°C
(-40°F to +158°F)
-40°C to +70°C
(-40°F to +158°F)
Safety Notice
Legal and Reference Information
This chapter provides legal notices including software license agreements.
Attention
Intentional or unintentional changes or modifications to the equipment must not be made unless under the
express consent of the party responsible for compliance. Any such modifications could void the user’s
authority to operate the equipment and will void the manufacturer’s warranty.
The following topics are described in this chapter:
Cambium Networks End User License Agreement on Page ____
Open Source Components incorporated in the Hardware and associated notices on Page ____
Hardware Warranty on Page ____
cnMatrix EX2K Basic Configuration Guide
Copyright2021CambiumNetworks.Allrightsreserved.(v2.10) 8
Cambium Networks End User License Agreement
ACCEPTANCE OF THIS AGREEMENT
In connection with Cambium Networks’ delivery of certain proprietary software or products containing
embedded or pre-loaded proprietary software, or both, Cambium Networks is willing to license this certain
proprietary software and the accompanying documentation to you only on the condition that you accept all
the terms in this End User License Agreement (“Agreement”). IF YOU DO NOT AGREE TO THE TERMS
OF THIS AGREEMENT, DO NOT USE THE PRODUCT OR
INSTALL THE SOFTWARE. INSTEAD, YOU MAY, FOR A FULL REFUND, RETURN THIS PRODUCT
TO THE LOCATION WHERE YOU ACQUIRED IT OR PROVIDE WRITTEN VERIFICATION OF
DELETION OF ALL COPIES OF THE SOFTWARE. ANY USE OF THE SOFTWARE, INCLUDING BUT
NOT LIMITED TO USE ON THE PRODUCT, WILL CONSTITUTE YOUR ACCEPTANCE TO THE TERMS
OF THIS AGREEMENT.
DEFINITIONS
In this Agreement, the word “Software” refers to the set of instructions for computers, in executable form
and in any media, (which may include diskette, CD-ROM, downloadable internet, hardware, or firmware)
licensed to you. The word “Documentation” refers to electronic or printed manuals and accompanying
instructional aids licensed to you. The word “Product” refers to Cambium Networks’ fixed wireless
broadband devices for which the Software and Documentation is licensed for use.
GRANT OF LICENSE
Cambium Networks Limited (“Cambium”) grants you (“Licensee” or “you”) a personal, nonexclusive, non-
transferable license to use the Software and Documentation subject to the Conditions of Use set forth in
“Conditions of use” and the terms and conditions of this Agreement. Any terms or conditions relating to the
Software and Documentation appearing on the face or reverse side of any purchase order, purchase order
acknowledgment or other order document that are different from, or in addition to, the terms of this
Agreement will not be binding on the parties, even if payment is accepted.
CONDITIONS OF USE
Any use of the Software and Documentation outside of the conditions set forth in this Agreement is strictly
prohibited and will be deemed a breach of this Agreement.
1. Only you, your employees or agents may use the Software and Documentation. You will take all
necessary steps to insure that your employees and agents abide by the terms of this Agreement.
2. You will use the Software and Documentation (i) only for your internal business purposes; (ii) only
as described in the Software and Documentation; and (iii) in strict accordance with this Agreement.
3. You may use the Software and Documentation, provided that the use is in conformance with the
terms set forth in this Agreement.
4. Portions of the Software and Documentation are protected by United States copyright laws,
international treaty provisions, and other applicable laws. Therefore, you must treat the Software
like any other copyrighted material (for example, a book or musical recording) except that you may
either: (i) make 1 copy of the transportable part of the Software (which typically is supplied on
diskette, CD-ROM, or downloadable internet), solely for back-up purposes; or (ii) copy the
transportable part of the Software to a PC hard disk, provided you keep the original solely for
backup purposes. If the Documentation is in printed form, it may not be copied. If the
Documentation is in electronic form, you may print out 1 copy, which then may not be copied. With
regard to the copy made for backup or archival purposes, you agree to reproduce any Cambium
Networks copyright notice, and other proprietary legends appearing thereon. Such copyright
notice(s) may appear in any of several forms, including machine-readable form, and you agree to
reproduce such notice in each form in which it appears, to the extent it is physically possible to do
so. Unauthorized duplication of the Software or Documentation constitutes copyright infringement,
and in the United States is punishable in federal court by fine and imprisonment.
cnMatrix EX2K Basic Configuration Guide
Copyright2021CambiumNetworks.Allrightsreserved.(v2.10) 9
5. You will not transfer, directly or indirectly, any product, technical data or software to any country for
which the United States Government requires an export license or other governmental approval
without first obtaining such license or approval.
TITLE AND RESTRICTIONS
If you transfer possession of any copy of the Software and Documentation to another party outside of the
terms of this agreement, your license is automatically terminated. Title and copyrights to the Software and
Documentation and any copies made by you remain with Cambium Networks and its licensors. You will
not, and will not permit others to: (i) modify, translate, decompile, bootleg, reverse engineer, disassemble,
or extract the inner workings of the Software or Documentation, (ii) copy the look-and-feel or functionality
of the Software or Documentation; (iii) remove any proprietary notices, marks, labels, or logos from the
Software or Documentation; (iv) rent or transfer all or some of the Software or Documentation to any other
party without Cambium’s prior written consent; or (v) utilize any computer software or hardware which is
designed to defeat any copy protection device, should the Software and Documentation be equipped with
such a protection device. If the Software and Documentation is provided on multiple types of media (such
as diskette, CD-ROM, downloadable internet), then you will only use the medium which best meets your
specific needs, and will not loan, rent, lease, or transfer the other media contained in the package without
Cambium’s written consent. Unauthorized copying of the Software or Documentation, or failure to comply
with any of the provisions of this
Agreement will result in automatic termination of this license.
CONFIDENTIALITY
You acknowledge that all Software and Documentation contain valuable proprietary information and trade
secrets and that unauthorized or improper use of the Software and Documentation will
result in irreparable harm to Cambium Networks for which monetary damages would be inadequate and for
which Cambium Networks will be entitled to immediate injunctive relief. If applicable, you will limit access
to the Software and Documentation to those of your employees and agents who need to use the Software
and Documentation for your internal business purposes, and you will take appropriate action with those
employees and agents to preserve the
confidentiality of the Software and Documentation, using the same degree of care to avoid unauthorized or
improper disclosure as you use for the protection of your own proprietary software, but in no event less
than reasonable care. You have no obligation to preserve the confidentiality of any proprietary information
that: (i) was in the public domain at the time of disclosure; (ii) entered the public domain through no fault of
yours; (iii) was given to you free of any obligation to keep it confidential; (iv) is independently developed by
you; or (v) is disclosed as required by law provided that you notify Cambium Networks prior to such
disclosure and provide Cambium Networks with a reasonable opportunity to respond.
RIGHT TO USE CAMBIUM’S NAME
Except as required in “Conditions of use”, you will not, during the term of this Agreement or thereafter, use
any trademark of Cambium Networks, or any word or symbol likely to be confused
with any Cambium Networks trademark, either alone or in any combination with another word or words.
TRANSFER
The Software and Documentation may not be transferred to another party without the express written
consent of Cambium Networks, regardless of whether or not such transfer is accomplished by physical or
electronic means. Cambium’s consent may be withheld at its discretion and may be conditioned upon
transferee paying all applicable license fees and agreeing to be bound by this Agreement.
UPDATES
During the first 12 months after purchase of a Product, or during the term of any executed Maintenance
and Support Agreement for the Product, you are entitled to receive Updates. An “Update” means any code
in any form which is a bug fix, patch, error correction, or minor enhancement, but excludes any major feature
added to the Software. Updates are available for download at the support website.
Table des matières
Autres manuels Cambium Networks Changer
