UNDER-MOUNT HOOD
Use and Installation Manual
CVU306C-SS
Important Safety Notice
READ ALL INSTRUCTIONS BEFORE INSTALLING AND OPERATING THIS APPLIANCE
Pg 1
This is the safety alert symbol. This symbol alerts you to potential hazards that can hurt you and
others. All safety messages will follow the safety alert symbol “ ” and the word “WARNING”.
The manufacturer and/or distributor/reseller declines all responsibility in the event of failure to observe the
instructions given here for installation, maintenance and suitable use of the product. The manufacturer and/
or distributor/reseller further declines all responsibility for injury due to negligence and the warranty
of the unit automatically expires due to improper maintenance. The manufacturer and/or
distributor/reseller will not be held responsible for any damages to personal property or real estate or any
bodily injuries whether caused directly or indirectly by the range hood.
•The installation in this manual is intended for qualified installers, service technicians or persons
with similar qualified background. Installation and electrical wiring must be done by qualified
professionals and in accordance with all applicable codes and standards, including fire-rated
construction.
•DO NOT attempt to install this appliance yourself. Damage or Injury could result from
installing the unit due to lack of appropriate electrical and technical background.
•Due to the size and weight of this range hood, at least two people are recommended for
installation to reduce the risk of fire, electric shock, or injury to persons.
•Range hood may have very sharp edges; wear protective gloves if it is necessary to remove any
parts for installing, cleaning or servicing.
•Ensure any nearby electrical service are OFF and stay OFF until the completion of installation
to reduce the risk of electrical shock, short-circuit, electrical spark which may cause injury or
damage. For general ventilating use only.
•DO NOT use to exhaust hazardous or explosive materials and vapors.
•In order to ensure the safe operation of fuel-burning heating equipment, it's air flow needs to
be to be considered for proper combustion. Follow the heating equipment manufacturer’s
guideline and safety standards such as those published by the National Fire Protection
Association (NFPA), and the American Society of Heating, Refrigeration and Air Conditioning
Engineers (ASHRAE), and the local code authorities.
•To reduce the risk of fire and to disperse air properly, make sure to vent air outside. Sufficient
household air flow is required for the proper combustion of fuel-burning heating equipment,
and the exhaustion of their gases.
Excessive Weight
Require three or more persons to
move and install this range hood.
Spinal or other bodily injuries
could occur if it is not followed.
Burn Hazard!
Light bulb may become extremely hot when turned ON. DO NOT touch bulb until
switched OFF and cooled. Touching hot bulbs could cause serious burns.
Severe Injury
Rotating fan can cause severe
injury. Stay clear of fan when
power is present.
Electrical Shock Hazard
Do not perform service on an electrically live
system. Disconnect the main electrical supply
before servicing this device. Touching
electrical connectors or other exposed
electrical circuitry inside this range hood when
they are energized could result in death,
serious bodily injury, or property damage.
Your safety and the safety of others is very important. We have provided many important safety
messages in this manual and on your appliance. Always read and obey all safety messages. All
safety messages will tell you what the potential hazard is, tell you how to reduce the chance of
injury, and tell you what can happen if the instructions are not followed.
Important Safety Notice
Pg 2
TO REDUCE THE RISK OF A STOVE TOP GREASE FIRE:
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A STOVE TOP GREASE FIRE:
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A GAS LEAKS:
•Ducted fans MUST always be vented to the outdoors.
•DO NOT vent exhaust into spaces between walls, crawl spaces, ceiling, attics or garages.
•Any old duct work should be cleaned or replaced if necessary to avoid the possibility of a grease fire.
•Check all joints on duct work to insure proper connection and all joints should be properly taped.
•Use only metal ductwork and this unit MUST be grounded.
•Before servicing or cleaning unit, turn OFF circuit breaker or fuse at the service panel. Lock the
service panel to prevent power from being switched ON accidentally.
•When cutting or drilling into wall or ceiling, be careful not to damage electrical wiring or other
hidden utilities.
•All electrical wiring must be properly installed, insulated and grounded.
•Use this unit only in the manner intended by the manufacturer. If you have questions, contact
the vendor.
•DO NOT touch the bottom side of the range hood directly after usage because it may be hot. Wait
until it has cooled.
•Make sure to inspect shipment and it's contents as soon shipment is received.
•Plug in and test range hood and all its functions, (refer to Range Hood Operations, Page 15),
directly after receiving shipment, and before scheduling an installer.
•Clean grease laden surfaces frequently.
•Clean the range hood frequently.
•Keep all surfaces clean from grease or oil build up.
•Grease should not be allowed to accumulate on fan, baffle, spaces, filter, any surfaces of the range
hood or surrounding area.
•Always turn range hood ON when cooking at high heat or when cooking flaming foods. Use high
settings on cooking range only when necessary.
•Never leave burners or cook top at high settings unattended. Boil overs cause smoking and greasy
spillovers that may ignite. Heat oils slowly on low or medium settings.
•Always use appropriate cookware and utensils size.
•Always use cookware appropriate for the size of the surface element.
•SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, then turn OFF the burner.
BE CAREFUL TO PREVENT BURNS. NEVER PICK UP A FLAMING PAN—you may be burned.
•KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames DO NOT
go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT or dial your local emergency
service immediately.
•DO NOT USE WATER, including wet dishcloths or towels — a violent steam explosion may result.
Use an extinguisher ONLY if:
• You know you have a Class A, B, C extinguisher, and you already know how to operate it.
• The fire is small and contained in the area where it is started.
• The fire department is being called.
• You can fight the fire while maintaining a safe exit path.
•Extinguish any open flame.
•DO NOT turn on the range hood fan or any type of ventilator.
•DO NOT turn on the lights or any type of appliance.
•Open all doors and windows to disperse the gas. If you still smell gas, call the gas company and
fire department, or dial your local emergency service immediately.
Pg 3
Level
Powered
Drill Flat & Phillips
Screwdrivers
Measuring
Tape
Utility Knife
Marker
or Pencil
Table of Contents
Tools Needed
INSTALLATION
Tools Needed...............................................................3
Parts Supplied.............................................................4
Venting Requirements.............................................5
Height & Clearance...............................................5-6
Duct Size Upgrade Calculator .............................6
Venting Methods.......................................................7
Electrical Requirements .........................................8
Advanced Preparation ...........................................8
Installation Overview..............................................12
Installation.............................................................13-14
USE AND CARE
Range Hood Operations
Troubleshooting
Use and Care Information
Electric Schematic
......................................15
......................................................16
....................................17
..................................................17
MAINTENANCE
Cleaning, Replacing Filter & Light Bulb
WARRANTY
Coverage & Exclusions.........................................20
.....18-19
Disclaimer..................................................................21
Preparation..............................................................9-11
Hood Dimensions.......................................................4
Pg 4
Parts Supplied
Hood Dimensions
Qty.: 6 pcs.
(for drywall only)
3.25" x 10" Adapter for
horizontal evacuation Top cover for square
exhaust connector
Baffle Filters
Qty.: 6 pcs.
6" Adapter for vertical
evacuation
•Vent system must terminate to the outside
(roof or side wall).
•DO NOT terminate the vent system in an
attic or other enclosed area.
•DO NOT use 4” (10.2 cm) laundry-type wall
caps.
•Use metal/aluminum ducting only. Rigid
metal/aluminum ducting is recommended.
•Always keep the duct clean to ensure
proper airflow.
•Calculate the following figures before
installation:
1. Distance from the floor to the ceiling.
*(less than 108").
2. Distance between the floor to the
countertop/stove. (Recommend* 28” to
about 36”).
3. Distance between the countertop/stove
to the range hood. (Recommended 28"
to ~31").
Height of range hood body and chimney
covers combined.
•A distance of 28” to 31” is recommended
between stove top and the bottom of
range hood.
•28" is the lowest recommended for safe
operation; 31" is only recommended for
efficient operation, but can be mounted
higher.
•It is recommended that the range hood
be vented vertically through the roof
through 6” (15.24 cm) or larger round
metal/aluminum vent work.
•The size of the vent should be uniform.
•Use no more than three 90° elbows.
•For best results, attempt to make a
minimum of 24" (61 cm) of straight vent
between the elbows if more than one
elbow is used.
•DO NOT install two elbows together.
•The length of vent system and number of
elbows should be kept to a minimum to
provide efficient performance.
•The vent system must have a damper.
If roof or wall cap already has a damper,
DO NOT use the supplied damper
(if applicable).
For the most efficient & quiet operation:
Pg 5
Venting Requirements Height & Clearance
•Use aluminum foil tape or equivalent to seal
all joints in the vent system.
•Use caulking to seal exterior wall or roof
opening around the cap.
* Due to different ceiling height configurations,
recommended height may not be applicable.
4. Ceiling
Height
Under
Cabinet
Range Hood
36”
Counter
Top
Cabinet
Range
Hood
Height
Cabinet
Height
Countertop/
Stove
Min: 27"
Max. 30"
Duct Deductions:
Each 90° bend 9 ft
Each 45° bend 5 ft
Each 6” to 3 ¼” x 10” transition 7 ft
Side wall cap with damper 1 ft
Roof Cap (with factory Damper) 1 ft
•A minimum of 6” round (standard for this range hood) or 3 ¼” x 10” rectangular duct
(not supplied) must be used to maintain maximum airflow efficiency.
•ALWAYS, when possible, reduce the number or transitions and turns. If long duct run is
required, increase duct size. If a reducer is used, install a long reducer instead of a pancake
reducer. Any reductions of duct size will restrict and decrease airflow; to maximize airflow
flow efficiency place any reducers furthest away from any bends or transitions.
•If turns or transitions are required, install them as evenly distanced as possible, and as far
away from the range hood as possible.
•Please use the Duct Size Upgrade Calculator below to compute the total available duct run
when using elbows, transitions and caps.
•It is important to install the hood at the proper mounting height. Hoods mounted too low
are considered unsafe and could result in heat damage and fire hazard; while hoods
mounted too high are harder to reach and will lose general effectiveness.
•Minimum mount height between stove top to hood bottom should be no less than 28“. Any
less is considered unsafe and not recommended.
•Maximum mount height between stove top to hood bottom can be higher than 31 inch*, but
it is not recommended due to the loss in efficiency.
•If available, refer to your stove top manufacturer’s height clearance requirements and
recommended hood mounting height above range.
* Due to different ceiling height configurations, recommended height may not be applicable.
Minimum Duct Size:
•Round - 6” minimum.
•Rectangular - 3 ¼” x 10” minimum (requires an 6” to 3 ¼” x 10” adapter, not supplied)
IMPORTANT:
Pg 6
Height & Clearance
Duct Size Upgrade Calculator
•Minimum duct size recommended is 6” round (or 3 ¼” x 10” rectangular). Maximum duct
length recommend is 50 ft. Any duct length over 50 ft is recommended to use a larger
diameter duct size.
•Survey the installation application and record the estimated length of ducting required or
used for that application. Record the number of bends, angle of bends, and/or any
transitional pieces used. Each bend or transition will reduce air flow and reduce the
recommended duct length.
Duct Deduction Calculation Example:(1)
90° bend, (1) 3¼” x 10” transition, (2) 45°
bends, (1) sidewall cap with damper (with
factory damper not installed)
-9ft + -7ft + -5ft + -5ft + -1ft = -27ft
Deduct 27 ft from 50 ft, giving you 23 ft of
available straight ducting before it is
recommended to upgrade your ducting size.
•This range hood is factory set for venting through the roof or wall.
•Vent work can terminate either through the roof or wall. To vent through a wall, a 90°
elbow is needed.
•NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces,
ceiling, attics or garages. All exhaust must be ducted to the outside.
•Use metal/aluminum duct work only.
•Fasten all connections with sheet metal screws and tape all joints with aluminum foil
tape or equivalent.
•Use caulking to seal exterior wall or roof opening around the cap.
IMPORTANT:
Pg 7
Venting Methods
Horizontal Wall Venting Vertical Roof Venting
Type 2
Type 1
3 1/4" x 10" rectangular vent
adapter behind the range hood
Type 1 Type 3:
Type 2
3 1/4" x 10" rectangular vent
adapter on top of the range hood
Type 3
6" round vent adapter on the
top of the range hood.
IMPORTANT: Observe all governing ordinances and local codes.
(Please consult with a qualified electrician for any electrical wiring)
It is the customer’s responsibility:
•To contact a qualified electrical installer.
•To assure that the electrical installation is adequate and in conformance with National
Electrical Code, ANSI/NFPA 70 — latest edition*, or CSA Standards C22. 1-94, Canadian
Electrical Code, Part 1 and C22. 2 No. 0-M91 - latest edition** It is your responsibility to
be aware of and adhere to all building, fire, electrical, safety, and any other applicable
codes with regards to the installation and use of this range hood.
•Provide a circuit protected power service; preferably a Ground Fault Circuit Interrupter
("G.F.C.I."): 120-volt, 60 Hz, AC, with at least 5-amps of available service.
•Enlist a qualified electrician to ensure the range hood and electrical lines are adequately
grounded and properly protected. NEVER electrically ground to a gas pipe.
•IMPORTANT: Save this Installation Guide for future reference and/or electrical inspector
use.
•The range hood should be connected with a circuit breaker protected power service.
•Wire sizes (copper wire only) and connections must conform with the rating of the
appliance as specified on the model/serial rating label. Wire sizes must conform to
the requirements of the National Electrical Code and any and all local codes and
ordinances. A U.L. - or C.S.A. - listed conduit connector must be provided at
each end of the power supply cable (at the range hood and at the junction box).
Pg 8
Electrical Requirements
Advanced Preparation
Advanced Preparations:
1. Familiarize yourself with the controls of the range hood
by reading through Range Hood Operations, Page 15.
2. Place the range hood on a flat, stable surface. Connect
the range hood to a designated standard outlet (please
refer the product label for the suitable voltage of this
unit) and turn on the range hood. Verify all operations
of the range by referring to Range Hood Operations,
on Page 15.
Place all supplied parts and required hardware on a flat, stable surface and verify
the presence of all supplied parts listed on Page 4.
Carefully remove the white plastic protective coat from the range hood.
Excessive Weight
Require three or more persons to
move and install this range hood.
Spinal or other bodily injuries
could occur if it is not followed.
3.
4.
Pg 9
Preparation
NOTE: To avoid damage to your hood, prevent debris from entering the vent opening.
Decide the location of the venting pipe from the hood to the outside. Refer to Venting
Methods on page 7.
•A straight, short vent run will allow the hood to perform more efficiently.
•Try to avoid as many transitions, elbows, and long run as possible. This may reduce the
performance of the hood.
•Use aluminum foil tape to seal joints between pipe sections.
•For installing under the cabinet with recessed bottom, attach 4-inch wide wood filler
strips (not provided) on each side. Refer to Figure 1.
•Using references in Hood Dimensions drawing on Page 14, create access opening for
electrical wires and hood exhaust under the cabinet.
CAUTION: If moving the cooking range is necessary to install the hood, turn OFF the
power on of an electric range at the main electrical box. SHUT OFF THE GAS BEFORE
MOVING A GAS RANGE.
•Puncture the knockout holes (for mounting under the cabinet) on the hood as shown
in Figure 2.
•If necessary, attach two rubber pads with 3M adhesive tapes to the back corners of
the hood to reduce noise and vibration.
Figure 1 Figure 2
There are three ways to vent the hood exhaust:
1. Vertically through the top of the hood using the round 6” transition
adapter.
2. Vertically through the top of the hood using the 3.25" x 10" transition
adapter.
3. Horizontally through the back of the hood using the 3.25" x 10"
transition adapter.
Determine your preferred exhaust method, mount the appropriate
adapter on the hood, and decide the location of the venting pipe from the
hood to the outside. Refer to Venting Methods on page 7.
Autres manuels pour CVU306C-SS
1
Table des matières
Langues :
Autres manuels Caloric hotte de ventilation
Caloric
Caloric CVW102 Manuel utilisateur
Caloric
Caloric CVWSV30Z-SS Caractéristiques techniques
Caloric
Caloric CVU306C-SS Manuel utilisateur
Caloric
Caloric CVW206 Manuel utilisateur
Caloric
Caloric CVI28-SS Manuel utilisateur
Caloric
Caloric CVP1030-SS Manuel utilisateur
Caloric
Caloric CVW502 Manuel utilisateur
Caloric
Caloric CVWSV30F-SS Caractéristiques techniques
