Cabletron Systems MMAC-Plus 9E423-24 Manuel utilisateur

MMAC-Plus

™

Module Local Management

9E423-24 Module Specific Appendix

9031671

DRAFT

Appendix

9E423-24 Module Speciﬁc

Information

Introduction

This appendix contains local management information that is speciﬁc to the 9E423-24

Ethernet Switch Module.

The 9E423-24 Ethernet Switch Module is a 25-port switching module with:

• 24 front panel Ethernet ports (2 RJ-71 Telco connectors)

• 1 Internal Network Bus (INB) backplane port

Each front-panel port of the 9E423-24 can be conﬁgured to operate in the Full Duplex

mode. This conﬁguration allows each port to provide a full 20 Mbps of bandwidth.

Modifying Fields and User Privileges

To modify ﬁelds on this module, you must have read-write or super-user privileges. If

you have read-only privileges, you can view information; however, you cannot

modify any ﬁelds. For more information about user privileges and community names,

see the

MMAC-Plus Module Local Management User’s Guide.

9E423-24 Module Speciﬁc Information

Module Interface Codes

The 9E423-24 Ethernet Switch Module has 29 interfaces. The table below lists the

identifying number, name, and description of each interface.

Table 1. 9E423-24 Module Interface Codes

Interface

Number

Interface

Name

Interface

Description

1 SMB1 1 Mbps System Management Bus

2 SMB10 10 Mbps System Management Bus

3 HOST

4 LOCAL

5 INB Internal Network Bus

6 ENET1 Ethernet Front Panel Port 1

7 ENET2 Ethernet Front Panel Port 2

8 ENET3 Ethernet Front Panel Port 3

9 ENET4 Ethernet Front Panel Port 4

10 ENET5 Ethernet Front Panel Port 5

11 ENET6 Ethernet Front Panel Port 6

12 ENET7 Ethernet Front Panel Port 7

13 ENET8 Ethernet Front Panel Port 8

14 ENET9 Ethernet Front Panel Port 9

15 ENET10 Ethernet Front Panel Port 10

16 ENET11 Ethernet Front Panel Port 11

17 ENET12 Ethernet Front Panel Port 12

18 ENET13 Ethernet Front Panel Port 13

19 ENET14 Ethernet Front Panel Port 14

20 ENET15 Ethernet Front Panel Port 15

21 ENET16 Ethernet Front Panel Port 16

22 ENET17 Ethernet Front Panel Port 17

23 ENET18 Ethernet Front Panel Port 18

Appendix

Use the numbers listed in Table 1 to conﬁgure the module’s default interface (see the

General Conﬁguration Screen).

24 ENET19 Ethernet Front Panel Port 19

25 ENET20 Ethernet Front Panel Port 20

26 ENET21 Ethernet Front Panel Port 21

27 ENET22 Ethernet Front Panel Port 22

28 ENET23 Ethernet Front Panel Port 23

29 ENET24 Ethernet Front Panel Port 24

Table 1. 9E423-24 Module Interface Codes

Interface

Number

Interface

Name

Interface

Description

9E423-24 Module Speciﬁc Information

Full Duplex Conﬁguration Screen

The 9E423-24 Full Duplex Conﬁguration Screen displays the port number, operation

mode, link status, and port status of the module’s 24 ports (12 ports at a time).

Figure 1. 9E423-24 Full Duplex Conﬁguration Screen

MMAC-Plus Local Management

Full Duplex Configuration

Module Name: 9E423-24 Firmware Revision: 01.XX.08

Slot Number: 12 BOOTPROM Revision: 01.00.01

PORT# OPERATION MODE LINK STATUS PORT STATUS

1 STANDARD ENET No Link ENABLED

2 STANDARD ENET No Link ENABLED

3 STANDARD ENET No Link ENABLED

4 STANDARD ENET No Link ENABLED

5 STANDARD ENET No Link ENABLED

6 STANDARD ENET No Link ENABLED

7 STANDARD ENET No Link ENABLED

8 STANDARD ENET No Link ENABLED

9 STANDARD ENET No Link ENABLED

10 STANDARD ENET No Link ENABLED

11 STANDARD ENET No Link ENABLED

12 STANDARD ENET No Link ENABLED

SAVE [ 13-24 ] SET ALL PORTS: FULL EXIT RETURN

Appendix

Full Duplex Conﬁguration Screen Fields

OPERATION MODE

(Modiﬁable) - This ﬁeld lets you determine whether the

speciﬁed port will transmit and receive data separately or simultaneously. You can set

this ﬁeld to one of the following values:

• STANDARD ENET - The port can either transmit data or receive data, but not both

at the same time. Therefore, the port is running at 10 Mbps (this is the default).

• FULL DUPLEX - The port can transmit and receive data at the same time.

Therefore, the port is running at 20 Mbps.

To set one Ethernet port to Full Duplex (for example, port 1):

1. Use the arrow keys to highlight

STANDARD ENET

in the Operation Mode ﬁeld

(to the right of port 1).

2. Press the

Space

Bar

until

FULL DUPLEX

appears in the ﬁeld.

3. Use the arrow keys to highlight the

SAVE

command on the bottom line of the

screen.

4. Press the

Return

key.

To set all 24 Ethernet ports to Full Duplex:

1. Use the arrow keys to highlight the

SET ALL PORTS

ﬁeld.

2. Press the

Space

Bar

until you see

FULL

3. Use the arrow keys to highlight the

SAVE

command on the bottom line of the

screen.

4. Press the

Return

key.

LINK STATUS

(Read-only) - Indicates whether there is a physical connection from

this port to another 10 Base-T device. One of the following values appears:

• Link - There is a 10 Base-T link signal present; there is a valid physical connection

from this port to another 10 Base-T device.

• No Link - There is no 10 Base-T link signal present; there is no valid physical

connection from this port to another 10 Base-T device.

9E423-24 Module Speciﬁc Information

PORT STATUS

(Read-only) - Indicates whether the port has been turned on or off

administratively. You will see one of the following values:

• ENABLED - The port is turned on administratively.

• DISABLED - The port is turned off administratively.

Displaying Information About Other Ports

To display information about other ports:

1. Use the arrow keys to highlight

[1-12]

(for the ﬁrst 12 ports) or

[13-24]

(for the last

12 ports) at the bottom of the Full Duplex Conﬁguration Screen.

2. Press the

Return

key.

Enable or disable ports from the Bridge Conﬁguration screen.

NOTE

Appendix

Port Statistics Screen

The 9E423-24 Port Statistics Screen displays information and statistics about the

module’s 24 Ethernet ports.

Figure 2. 9E423-24 Port Statistics Screen

MMAC-Plus Local Management

PORT STATISTICS

Module Name: 9E423-24 Firmware Revision: 01.XX.08

Slot Number: 12 BOOTPROM Revision: 01.00.01

PORT #: 1

OCTETS: 747881

PACKETS: 5079 LINK STATUS: No Link

TOTAL ERRORS: 0

COLLISIONS: 0 PORT TYPE: RJ71

CRC/ALIGNMENT ERRORS: 0

UNDERSIZE PACKETS: 0 PORT STATUS: ENABLED

OVERSIZE PACKETS: 0

FRAGMENTS: 0 APPLICATION: BRIDGING

JABBERS: 0

BROADCASTS: 4489 OPERATION MODE: STANDARD ENET

MULTICASTS: 586

PORT #: 1EXIT RETURN

9E423-24 Module Speciﬁc Information

Port Statistics Screen Fields

PORT #

(Read-only) - Indicates the current port for which statistics are displayed.

OCTETS

(Read-only) - Displays the number of octets transmitted and received.

PACKETS

(Read-only) - Displays the number of packets transmitted and received.

TOTAL ERRORS

(Read-only) - Displays the total number of errors on this port.

COLLISIONS

(Read-only) - Displays the total number of collisions detected on this

port.

CRC/ALIGNMENT ERRORS

(Read-only) - Displays the number of packets with bad

Cyclic Redundancy Checks (CRC) that have been received from the network. The

CRC is a 4-byte ﬁeld in the data packet that ensures that the transmitted data that is

received is the same as the data that was originally sent. Alignment errors are due to

misaligned packets.

UNDERSIZE PACKETS

(Read-only) - Displays the number of packets received

whose size was less than the minimum Ethernet frame size of 64 bytes, not including

preamble.

OVERSIZE PACKETS

(Read-only) - Displays the number of packets received whose

size exceeded 1518 data bytes, not including preamble.

FRAGMENTS

(Read-only) - Displays the total number of packets received that were

not an integral number of octets in length or that had a bad Frame Check Sequence

(FCS), and were less than 64 octets in length (excluding framing bits but including

FCS octets).

JABBERS

(Read-only) - Displays the total number of packets received that were

longer than 1518 octets (excluding framing bits, but including Frame Check Sequence

(FCS) octets), and were not an integral number of octets in length or had a bad Frame

Check Sequence.

BROADCASTS

(Read-only) -

Displays the number of broadcasts received.

MULTICASTS (Read-only) - Displays the number of multicasts received.

LINK STATUS (Read-only) - Displays one of the following values:

• Link

• No Link

• N/A

Appendix

PORT TYPE (Read-only) - Displays one of the following values:

• AUI

• BNC

• EPIM-x

• MMF SMA

• MMF ST

• RJ45

• RJ71

• SMF ST

PORT STATUS (Read-only) - Indicates the administrative status of the selected port.

Possible values are ENABLED and DISABLED.

APPLICATION (Read-only) - Displays BRIDGING, indicating that the port is

operating as a bridge with a high-speed backbone connection.

OPERATION MODE (Read-only) - Displays one of the following values:

• STANDARD ENET - The port can either transmit data or receive data, but not both

at the same time. Therefore, the port is running at 10 Mbps.

• FULL DUPLEX - The port can transmit and receive data at the same time.

Therefore, the port is running at 20 Mbps.

PORT # (Modiﬁable) - Selects the port for which statistics are to be displayed.

Displaying Statistics for Another Port

To display statistics for another port:

1. Use the arrow keys to highlight the Port # ﬁeld at the bottom of the screen.

2. Press the Space Bar to increment (or press the Backspace key to decrement) the

port number.

3. Press the Return key (neither the read-only Port # ﬁeld nor the statistics will

change until you press the Return key).

Exiting the Port Statistics Screen

To exit the Port Statistics screen:

Use the arrow keys to highlight RETURN and press the Return key.

Autres manuels pour MMAC-Plus 9E423-24

Table des matières

Autres manuels Cabletron Systems Matériel réseau

Cabletron Systems

Cabletron Systems MMAC-M3FNB Manuel utilisateur

Cabletron Systems

Cabletron Systems WPIM-RT1 Manuel utilisateur

Cabletron Systems

Cabletron Systems SPECTRUM FRX6000 Manuel utilisateur

Cabletron Systems

Cabletron Systems TPMIM-22 Manuel utilisateur

Cabletron Systems

Cabletron Systems DLM6C-AA Manuel utilisateur

Cabletron Systems

Cabletron Systems NBR-220 Manuel de programmation

Cabletron Systems

Cabletron Systems TRMIM-22 Manuel utilisateur

Cabletron Systems

Cabletron Systems Environmental Module TM 9C300-1 Manuel utilisateur

Cabletron Systems

Cabletron Systems CyberSWITCH HSIM-W6 Manuel utilisateur

Cabletron Systems

Cabletron Systems HSIM-W87 Manuel utilisateur

Cabletron Systems

Cabletron Systems 9C300-1 Guide de démarrage rapide

Cabletron Systems

Cabletron Systems WPIM T1 Manuel utilisateur

Cabletron Systems

Cabletron Systems Netlink FRX4000 Manuel utilisateur

Cabletron Systems

Cabletron Systems SPECTRUM TRMMIM Manuel utilisateur

Cabletron Systems

Cabletron Systems HSIM-FE6 Manuel utilisateur

Cabletron Systems

Cabletron Systems BRIM-T6 Manuel utilisateur

Cabletron Systems

Cabletron Systems MMAC-Plus 9A128-01 Manuel de programmation

Cabletron Systems

Cabletron Systems HSIM HSIM-G01 Manuel utilisateur

Cabletron Systems

Cabletron Systems Device Management Module Dec GigaSwitch Manuel utilisateur

Cabletron Systems

Cabletron Systems MMAC-M5FNB Manuel utilisateur

Cabletron Systems

Cabletron Systems Expansion module DELHE-UA Manuel utilisateur

Cabletron Systems

Cabletron Systems STS-5SU Manuel utilisateur

Cabletron Systems

Cabletron Systems CRBRIM-W/E Manuel utilisateur

Cabletron Systems

Cabletron Systems CyberSWITCH HSIM-W6 Manuel utilisateur

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

ADC

ADC DSX-1 Manuel

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur
