HS-290 Instruction Booklet

C.T.M. MOBILITY SCOOTER

Instruction BookletHS-290

TABLE OF CONTENTS

INTRODUCTION

IMPORTANT PRECAUTIONS

ELECTROMAGNETIC INTERFERENCE AND WARNINGS

IDENTIFICATION OF PARTS

OPERATING YOUR SCOOTER

DISASSEMBLING YOUR SCOOTER

ASSEMBLING YOUR SCOOTER

CHARGING THE BATTERIES

CARE AND MAINTENANCE

TROUBLESHOOTING

TECHNICAL SPECIFICATIONS

--------------------------------------------------------1

----------------------------------------2

----3

----------------------------------------6

-------------------------------------9

-----------------------------11

----------------------------------13

--------------------------------------14

----------------------------------------15

------------------------------------------------16

------------------------------------18

Instruction BookletHS-290

If you have any question, you can contact :

or your local dealer:

INTRODUCTION

Thank you and congratulation on purchasing your new C.T.M. Mobility Scooter.

It is designed to provide you with transportation ability indoors and outdoors.

We pride ourselves on providing safe and comfortable products. Our goal is to ensure your

complete satisfaction. We sincerely hope you enjoy your C.T.M. Mobility Scooter.

Please read and observe all warning and instruction provided in owner's manual before you

operate with various convenient function of this scooter. Also, please retain this booklet for

future reference.

C.T.M.HOMECARE PRODUCT, INC.

13815 Magnolia Ave. #B, Chino CA 91710

Toll Free : 1-866-466-8168 Tel : 909-590-1388 Fax : 909-590-3365

E-Mail : [email protected] http : //www.ctmhomecare.com

Instruction BookletHS-290

IMPORTANT PRECAUTIONS

•Only one person at a time could ride a C.T.M. Mobility Scooter.

•Maximum load is 115 kgs / 253 pounds.

•Turn key off before getting on or off your scooter.

•Always drive carefully with your feet on legrcom and be aware of others in your area.

•Always use pedestrian crossing wherever possible. Take extreme care when crossing

roads.

•Do not drive on slope exceeding 8 degree, and take extreme care when turning on slope.

•Do not use full power when turning to sharp corner.

•Do not drive scooter unless seat and tiller are locked and secured in driving position.

•Do not use scooter if rear anti-tip wheels are damaged for removed.

•Take extra care and drive in low speed when backing up, riding downhill or on uneven

surface climbing and curb.

•Scooter may not operate well in high humidity.

•Never put your scooter in neutral when staying on slope.

•Follow all traffic laws when you ride in vicinity of public roads.

Instruction BookletHS-290

Powered wheelchairs and motorized scooters may be susceptible to electromagnetic

interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources

such a radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios,

and cellular phones. The interference (from radio wave sources) can cause the motorized

scooter to release its brakes, move by itself, or move in unintended directions. It can also

permanently damage the motorized scooter control system. The intensity of the interfering

EM energy can be measured in volts per meter (V/m). Each motorized scooter can resist

EMI up to certain intensity. This is called its "immunity level." The higher the immunity

level, the greater the protection. At this time, current technology is capable of achieving

at least a 20 V/m immunity level, which would provide useful protection from the more

common sources of radiated EMI. This immunity level of this motorized scooter model

is not known.

There are a number of sources of relatively intense electromagnetic fields in the everyday

environment. Some of these sources are obvious and easy to avoid. Others are not

apparent and exposure is unavoidable. However, we believe that by following the warnings

listed below, your risk to EMI will be minimized.

1.Hand-held portable transceivers (transmitters-receivers) with the antenna mounted

directly on the transmitting unit. Examples include: citizens band (CB) radios, "walkie

talkie," security, fire, and police transceivers, cellular telephones, and other personal

communication devices;

2.Medium-range mobile transceivers, such as those used in police cars, fire trucks,

ambulances, and taxis. These usually have the antenna mounted on the outside of

the vehicle; and

CAUTION: It is very important that you read this information regarding the possible

effects of Electromagnetic Interference on your motorized scooter.

Some cellular telephones and similar devices transmit signals while they

are ON, even when not being used.

The sources of radiated EMI can be broadly classified into three types：

SAFETY INFORMATION ON

ELECTROMAGNETIC INTERFERENCE (EMI)

Instruction BookletHS-290

3.Long-range transmitters and transceivers such as commercial broadcast transmitters

(radio and TV broadcast antenna towers) and amateur (HAM) radios.

Because EM energy rapidly becomes more intense as one move closer to the transmitting

antenna (source), the EM fields from hand-held radio wave sources (transceivers) are of

special concern. It is possible to unintentionally bring high levels of EM energy very close

to the motorized scooter control system while using these devices. This can affect motorized

scooter movement and braking. Therefore, the warnings listed below are recommended to

prevent possible interference with the control system of the motorized scooter.

Other types of hand-held devices, such as cordless phones, laptop

computers, AM/FM radios, TV sets, CD players, and cassette players,

and small appliances, such as electric shavers and hair dryers, so far

as we know, are not likely to cause EMI problems to your motorized

scooter.

Motorized Scooter Electromagnetic Interference：

Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur

radio (HAM) transmitters, two-way radios, and cellular phones can affect motorized scooters.

Following the warnings listed below should reduce the chance of unintended brake release

or motorized scooter movement which could result in serious injury.

1.Do not operate hand-held transceivers (transmitters-receivers), such as citizens band

(CB) radios, or turn ON personal communication devices, such as cellular phones, while

the motorized scooter is turned ON;

2.Be aware of nearby transmitters, such as radio or TV stations, and try to avoid coming

close to them;

3.If unintended movement or brake release occurs, turn the motorized scooter OFF as

soon as it is safe;

Warnings：

Instruction BookletHS-290

4.Be aware that adding accessories or components, or modifying the motorized scooter,

may make it more susceptible to EMI; and

5.Report all incidents of unintended movement or brake release to the distributor listed

on the inside front cover of this manual. Note whether there is a source of EMI nearby.

1.20 volts per meter (V/m) is a generally achievable and useful immunity level against

EMI (as of May 1994). The higher the level, the greater the protection.

2.The immunity level of this product is unknown.

There is no easy way to evaluate their effect on the overall immunity

of the motorized scooter.

Important Information：

Instruction BookletHS-290

Flip Up Armrest

Seat Lock Knob

Seat Rotating Lever

Expandable Legroom

Puncture Proof Tires

One Piece

Battery Pack

Luxury Padded Foldable

Tiller Angle

Adjustment

Self-Diagnostic Warning LightsBattery Gauge

Thumb Lever Thumb Lever

Speed Dial Anti-Tip Wheels

Rear

Compartment

Cover

Armrest Width

Adjustment

Thumbscrews

Armrest Width

Adjustment

Thumbscrews

Free-Wheeling lever

Horn Button Key(Inserted into

key Switch)

Front Basket

Figure 1 - HS-290 Front View

Figure 2 - HS-290 Top Control Panel Figure 3 - HS-290 Back View

IDENTIFICATION OF PARTS

Before attempting to drive this scooter on your own, it is important that you

familiarize yourself with the controls, and how to operate.

Instruction BookletHS-290

Figure 4

Function Of Parts：

TOP CONTROL PANEL

•Speed Dial Knob

The Rabbit means fast and turtle means slow. By turning this knob, you can control total

speed transferred to thumb controls.

•HeadLight Switch

To switch headlight on & off by pressing the headlight switch.

•Self Diagnostic Warning Light

Flashing indicates there is a problem within scooter. See page 16 for more information.

•Battery Gauge

There are five green LED lights. When all LED are on, batteries are fully charged. When

only two lights are on, batteries need to be recharged.

ADJACENT TO TOP CONTROL PANEL

•Thumb Lever

Pushing right thumb lever forward moves scooter forward. Pushing left thumb lever

forward will move scooter backward. (This configuration can be reversed if required

by local authorized dealer.) While in use, this lever is also your accelerator. The further

you depress the thumb lever, the faster you will go. (NOTE: subject to the position of

the rabbit/turtle control).

AT BASE OF TILLER

•Tiller Angle Adjustment

Push downward on the lever to loosen, and move tiller to adjust. The lever will lock tiller

automatically in 3 different angles.

BELOW SEAT

•Seat Lock Knob

Turn seat lock knob counterclockwise to loose. Turn it clockwise to lock seat in position.

•Seat Rotating Lever

By pulling lever upwards to rotate to different

direction.

•Armrest Width Adjustment Thumbscrews

Loosen the two thumbscrews to adjust arm width;

tighten again to lock into desired position.

Left and

right

adjustment

Counterclockwise

to loose

Instruction BookletHS-290

Figure 5

Figure 6

•Legroom Adjuster

There are 4 holes on front and rear frame tube to adjust legroom. First, remove battery

pack, pull the toggle latch (figure. 5) to loosen and pull the detent pin (figure. 6) to

remove. Once position is located, insert the pin to desired position, and push toggle

latch to lock.

REAR BODY

•Rear Compartment Cover

Open the compartment Cover to access on-board charger (A). (figure. 7)

•Anti-Tip Wheels

Help keep scooter from tipping over.

•Free-Wheeling Lever

When lever (B) (figure. 7) is in N (Neutral) position, scooter can be moved without power.

When lever is in D (Drive) position, scooter can be driven. Normal position is D.

Figure 7

(A)

(B)
