BWI Eagle 38UL-2000-DC Manuel utilisateur

AIR-EAGLE SR

38UL-2000-DC

2.4 GHz RF Receiver

SGS Certification #

SGSNA/19/SUW/00017

Document Date: 10/19/2021

Product Rev: 10

38UL-2000-DC

Page 1

WARRANTY STATEMENT

BWI Eagle Inc. warrants the Air-Eagle Remote Control System, if properly used and installed, will be free

from defects in material and workmanship for a period of 1 year after date of purchase. Said warranty to

include the repair or replacement of defective equipment. This warranty does not cover damage due to

external causes, including accident, problems with electrical power, usage not in accordance with product

instructions, misuse, neglect, alteration, repair, improper installation, or improper testing. This limited

warranty, and any implied warranties that may exist under state law, apply only to the original purchaser of

the equipment, and last only for as long as such purchaser continues to own the equipment. This warranty

replaces all other warranties, express or implied including, but not limited to, the implied warranties or

merchantability and fitness for a particular purpose. BWI Eagle makes no express warranties beyond

those stated here. BWI disclaims without limitation, implied warranties of merchantability and fitness for a

particular purpose. Some jurisdictions do not allow the exclusion of implied warranties so this limitation

may not apply to you. To obtain warranty service, contact BWI Eagle for a return material authorization.

When returning equipment to BWI Eagle, the customer assumes the risk of damage or loss during

shipping and is responsible for the shipping costs incurred.

SIGNAL RANGE

Max range statements are estimates based on a clear line of sight with few interferences. Actual range will

vary based on transmitting power, orientation of transmitter and receiver, height of transmitting and

receiving antennas, weather conditions, electronic interference, terrain, and physical obstacles, including

but not limited to; walls, building structures, trees (foliage), metal objects, and landscape (hills, mountains).

WIRELESS STOP SYSTEMS WORK IN CONJUCTION WITH

HARD-WIRED SYSTEMS.

Wireless Stop and E-Stop devices must work in conjunction with a hard-wired

system. A wireless system should never be considered a primary life-saving device.

At least one hard-wired switch must be available in the event the wireless signal is

lost. Failure to comply may result in serious injury or death to personnel and

damage to equipment.

38UL-2000-DC

Page 2

6.70”

2.25”

5.50”

4.80”

6.30”

2.40”

4.80”

2.50”

3.50”

9.45”

Ø 0.365”

Thru Hole

(4) Places

Ø 0.200”

Thru Hole

(6) Places

INTRODUCTION

We have partnered with SGS (the world's leading inspection, verification, testing and certification

company) to confirm that our products meet the specific and stringent requirements of UL and CSA.

SGS testing is designed to ensure products always operate safely, even under extreme circumstances.

The AIR-EAGLE SR is an SGS certified RF system designed for short to medium range wireless remote

control of electrical apparatus in a variety of industrial applications. Systems can consist of any number

of receivers and handheld or contact input transmitters working together. This receiver is equipped with 4

independent relays that can switch 5 amps @ 120VAC or 30VDC. The relays are user programmable for

momentary or toggle/latching operation and can be directly interfaced with the customer's equipment or

P.L.C. Eight user selectable frequencies allow multiple systems to be used in the same area. Capable of

receiving remote signals transmitted from up to 600 feet away, the Air-Eagle SR Receiver utilizes spread-

spectrum technology and provides the utmost in security and reliability.

DIMENSIONS

38UL-2000-DC

Page 3

INSTALLATION

Please read through this document in its entirety before proceeding with installation.

1. DISCONNECT power from all equipment before proceeding with installation.

2. Mount the control unit in a suitable location that allows the user to easily remove the lid of the

enclosure for wiring access. When possible, select a location that is not directly beside high energy

transformers or large inductive relay housings. It is recommended to allow for a minimum of 2.0”

clearance on all sides of the unit’s housing & mounting plate. The power and control wiring exiting

thru the provided cord grips should have ample room to bend without excessive stress. It is also

important that any coax cable connected to the TNC connector have room to bend without “kinking”.

3. Install relay wiring to terminal strip (TER1).

4. Attach supplied rubber duck antenna to TNC connector on the right side of the unit.

5. Connect supplied DC power input cable to your external power source.

Note 1: (6) #10 thru holes & (4) 1/4-20 thru holes are provided on the mounted plate to secure the unit)

Note 2: The recommended power/control wire sizes to the terminal strip ranges from 24 AWG

(0.205mm2) (min) to 18 AWG (0.823mm2) (max).

TERMINAL STRIP WIRING

Terminal 1

Negative (-) 10 –24 VDC

Terminal 2

Positive (+) 10 –24 VDC

Terminal 3

CH1 Dry Contact Input (Common)

Not used on this model

Terminal 4

CH1 Dry Contact Input

Terminal 5

CH2 Dry Contact Input (Common)

Terminal 6

CH2 Dry Contact Input

Terminal 7

N/O Relay 1

Terminal 8

C Relay 1

Terminal 9

N/C Relay 1

Terminal 10

N/O Relay 2

Terminal 11

C Relay 2

Terminal 12

N/C Relay 2

Terminal 13

N/O Relay 3

Terminal 14

C Relay 3

Terminal 15

N/C Relay 3

Terminal 16

N/O Relay 4

Terminal 17

C Relay 4

Terminal 18

N/C Relay 4

38UL-2000-DC

Page 4

38UL-2000-DC

Page 5

CONTROLS & INDICATORS

POWER/TX

LED1

Dual color LED. Illuminates red while receiver is booting up; changes to

green when boot-up is successful and unit is ready to operate. If this LED

fails to turn green, power unit off for 15-20 seconds, then reapply power.

LED2

Illuminates green while relay 1 is energized

LED3

Illuminates green while relay 2 is energized

LED4

Illuminates green while relay 3 is energized

LED5

Illuminates green while relay 4 is energized

REL1 –REL4

Four SPDT output control relays

RF2

RF Module that transmits/receives data

SEL1

Seven dip switches for selecting relay options and operating frequency

APPROVALS

SGS Certified

SGSNA/19/SUW/00017

United States (FCC)

MCQ-XBEE3

Canada (IC)

1846A-XBEE3

Europe (CE)

ETSI

Australia

RCM

Brazil

ANATEL 06329-18-01209

38UL-2000-DC

Page 6

RELAY MODES OF OPERATION

Auto Reset (Maintained Momentary)

When signal is received from an authorized transmitter, the relay will energize. The relay will maintain

the energized state as long as the transmitter is sending the signal. The relay de-energizes when the

transmitted signal stops.

Toggle Reset (Toggle Latch)

When a signal is received from an authorized transmitter, the relay will energize and latch. The relay

stays energized until the same signal is received again, at which time it unlatches and de-energizes.

Latching Reset (True Latch

When a signal is received from an authorized transmitter, the relay will energize and latch. The relay

stays energized until a different signal is received from the transmitter, at which time it unlatches and

de-energizes. i.e. –Transmission from Input 1 of authorized transmitter energizes and latches relay 1.

Transmission from Input 2 of an authorized transmitter de-energizes relay 1.

RELAY & FREQUENCY SETUP

The unit is shipped from the factory

with SEL1 switches in the open

positions. All four relays will operate as

maintained momentary and unit is

receiving commands on frequency

one. If you wish to change these

default settings, follow the instructions

below:

1. *IMPORTANT*

Disconnect power from unit

2. Remove top cover.

3. Select desired relay operation

and/or frequency using the

table.

4. Reattach cover.

5. Reconnect power to unit.

6. Programming is complete.

RELAY CONFIGURATION

SEL1

SW#

OPEN

CLOSED

SW1

Relay #1 momentary

(default)

Relay #1 toggle/latch

SW2

Relay #2 momentary

(default)

Relay #2 toggle/latch

SW3

Relay #3 momentary

(default)

Relay #3 toggle/latch

SW4

Relay #4 momentary

(default)

Relay #4 toggle/latch

Maintained Momentary –Relay mimics button or input –

when depressed or closed, relay will be energized; when

released, relay de-energizes.

Toggle Latch –Relay changes and holds its state each time

the corresponding button or input is depressed or closed.

FREQUENCY SETUP

NETWORK

FREQUENCY

SW5

SW6

SW7

1 (default)

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

OPEN

CLOSED

Note –SW8 & SW9 not used on this model

38UL-2000-DC

Page 7

SPECIFICATIONS

DC Power Input

10 –24 VDC @ 10 Watts

Relay Contacts

SPDT 5 amp @ 120VAC or 30VDC per channel

Fuse Protected

2 amp

Receiver Frequency

2.4 GHz Spread Spectrum

Receiver Range

Up to 600 feet

Note: Range figures are estimates, based on free-air terrain with limited sources of interference.

Actual range will vary based on transmitting power, orientation of transmitter and receiver, height of

transmitting antenna, height of receiving antenna, weather conditions, interference sources in the

area, and terrain between receiver and transmitter, including, but not limited to, indoor and outdoor

structures such as walls, metal objects, trees, buildings, hills, and mountains.

RF Networks

Eight Independent Network Frequencies

Operating

Temperature

-10oC to +55oC

Altitude

Under 2000 Meters

Enclosure

Polycarbonate, IP66 Approved

Weight

Approx 2.11 lbs.

SGS CLASSIFICATIONS

---Per UL 60730-1 and CAN/CSA E60730-1

Automatic Control and Electrically Operated Control

Incorporated Control and an Independently Mounted Control

Type 1.C Action; Micro-Interruption

PTI of Materials Used for Insulation: Material Group IIIb

Electrical Shock Risk: Class II Control

Period of Electrical Stress Across Insulating Parts Supporting Live Parts: Long

Period

Pollution Degree 2

Number of Cycles of Activation: 30,000 (Relay)

38UL-2000-DC

Page 8

ACCESSORIES

STANDARD ANTENNA (INCLUDED)

2.4GHz TNC Portable “Rubber Duck” Antenna

49-1201

MOBILE/BASE ANTENNAS (OPTIONAL)

Used to help achieve max range in non-line-of-sight and line-of-sight applications.

Contact BWI Eagle for recommendations.

2.4GHz Thru-Hole/Bracket Mount Mobile Antenna

49-2201

2.4GHz Magnet Mount Mobile Antenna

49-2202

2.4GHz Omni Directional Base Antenna

49-3201

2.4GHz Yagi Directional Base Antenna

49-3202

HIGH QUALITY COAX CABLE

Used to connect external antennas to control unit.

Flex Coax Cable w/Connectors

(Available in 5’, 15’, 25’, 30’, 40’, 60’, 80’, and 100’ lengths)

49-4000-XX

(XX = length in feet)

BULKHEAD EXTENSION

Used to provide an external antenna connection when mounting control unit

inside another enclosure.

TNC Male to TNC Bulkhead Cable Assembly

(Available in 2’, 4’, and 7’ lengths)

49-5004-X-ISO

(X = length in feet)

REPAIR STATEMENT

NO USER-SERVICEABLE PARTS! RETURN TO THE MANUFACTURER FOR SERVICE!

38UL-2000-DC

Page 9

Blank

Autres manuels pour 38UL-2000-DC

Table des matières

Autres manuels BWI Eagle Récepteur

BWI Eagle

BWI Eagle AIR-EAGLE XLT 441-20100-AC Manuel

BWI Eagle

BWI Eagle AIR-EAGLE SR 38-2000-VBR-DC Manuel

BWI Eagle

BWI Eagle Air-Eagle XLT PLUS 461-8000-AC Manuel utilisateur

BWI Eagle

BWI Eagle 461-8000-DC Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE XLT Manuel

BWI Eagle

BWI Eagle AIR-EAGLE XLT Manuel

BWI Eagle

BWI Eagle AIR-EAGLE XLT Manuel

BWI Eagle

BWI Eagle AIR-EAGLE XLT Manuel

BWI Eagle

BWI Eagle 461-8000-AC Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE XLT PLUS 461-20800-DC Manuel

BWI Eagle

BWI Eagle AIR-EAGLE XLT PLUS 461-5000-AC Manuel

BWI Eagle

BWI Eagle AIR-EAGLE SR 38-2000-VBR Manuel

BWI Eagle

BWI Eagle AIR-EAGLE XLT Manuel

BWI Eagle

BWI Eagle AIR-EAGLE XLT 441P-8D-ESTOP-DC Manuel utilisateur

BWI Eagle

BWI Eagle Air-Eagle SR 38-2000-DC Manuel

BWI Eagle

BWI Eagle AIR-EAGLE SR PLUS Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR 38HC-2000-DC Manuel

BWI Eagle

BWI Eagle AIR-EAGLE SR 38-2020 Manuel

BWI Eagle

BWI Eagle AIR-EAGLE SR 38-20800-DC Manuel

BWI Eagle

BWI Eagle AIR-EAGLE XLT 44P-8-ESTOP Manuel

BWI Eagle

BWI Eagle AIR-EAGLE XLT 441AN/DP-5-0002-120VAC Manuel

BWI Eagle

BWI Eagle 441-8000-AC Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR 38-5000-AC Manuel

BWI Eagle

BWI Eagle AIR-EAGLE XLT 441-20100-DC Manuel

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Kramer

Kramer 631R Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur

Dish Network

Dish Network Satellite Television Manuel utilisateur
