Bushpower WM102-7C Manuel utilisateur
Bushpower
100 Links Road
StMary’s NSW 2760
Phone: +61 2 98333 444
www.bushpower.com.au
4
Air Hose
Pressure Gauge
Quick Coupling
Tyre Chuck
Battery Clamps
Accessories
BUSHPOWER TWIN CYLINDER
150PSI
AIR COMPRESSOR
WM102-7C
1
IMPORTANT SAFETY INFORMATON
READ THIS MANUAL CAREFULLY TO AVOUD INJURY OR
POSSIBLE PROPERTY DAMAGE:
1. Do not disassemble the compressor.
2. Do not attempt repairs or modifications. All repairs MUST be
performed by Bushpower.
3. Do not use the compressor close to or in a wet environment.
4. For use with 12Volt systems only
5. Never leave the unit unattended whist in operation.
6. Not to be operated by children.
7. This compressor will be become hot during and remain hot after
the unit is off for some time. Only touch the on/off switch or
move the unit by the handle.
8. The compressor is fitted with an over temperature cut off, if the
compressor gets too hot it will turn off until the temperature drops
to normal.
9. Remove the compressor from power supply when not in use.
10. Only inflate tyres or other objects to recommended pressures, over
inflation may cause damage.
11. Never operate the compressor near flammable liquids or in wet
areas.
12. Only operate the compressor with the supplied accessories.
2 3
OPERATING INSTRUCTIONS:
1. Always operate the compressor within the maximum pressure
rating of the unit.
2. Do not run the compressor for longer than the maximum duty
cycle (refer to specifications)
3. Connect compressor to power source ensuring it is in the OFF po-
sition.
4. Attach quick disconnect coupler to air compressor
5. Screw tyre chuck onto tyre valve (finger tight).
6. Turn on the compressor and inflate until desired pressure is
reached.
7. To deflate tyre gently unscrew tyre chuck until air is heard being
released, continue until desired pressure is reached and disconnect
tyre chuck.
8. In Line pressure gauge:
• To gain an accurate pressure reading the air compressor
should be in the off position.
Operating the LED light
The light switch is located next to main on/off switch, to turn on main
LED light push the switch to the “1” position, to operate the flashing
red LED push the switch to the “=“ position.
Description: Rating:
Voltage 12Volt DC
Maximum Amperage 23Amps
Maximum Pressure 150psi
Max Duty Cycle @ 20°c 40psi 40mins
Maximum Air Flow 85L/min
