Bush BR20DAB Manuel utilisateur

DAB+ DIGITAL RADIO

WITH TOUCH CONTROL

INSTRUCTION MANUAL

BR20DAB

The Gold Technical Support Line: 1902 215 259

www.bushaustralia.com.au

Personal Product Support

(Charges will apply at $2.95 per minute)

BR20DAB

Introduction

Thank you for buying this Bush product, which is designed to give you many years of trouble-free

service.

You may already be familiar with using a similar unit, but please take the time to read these instructions.

They are designed to familiarise you with the unit’s many features and to ensure you get the very best

from your purchase.

Safety is important

Your safety and the safety of others is important.

Please therefore, ensure you read the “Safety Instructions” before you operate this unit.

Warranty

In the unlikely event that your product fails to work normally, please call the below free phone number to

discuss the problem with one of our qualified service engineers.

Australia.

Bush Warranty: 1800 509 394

New Zealand

Bush Warranty: 0800 450 259

BR20DAB

Ensure that you read all of the safety instructions before using this unit.

Safety Considerations

Position the power cable and other connected cables so that they are not likely to

be walked on, pinched or where items can be placed on or against them.

Do not use the unit in humid or damp conditions.

Do not allow the unit to get wet.

Never allow children to insert foreign objects into the holes or slots on the unit.

The ventilation should not be impeded by covering the openings with items such as

newspapers, tablecloths, curtains, etc. This may cause overheating.

No naked flame sources, such as lit candles, should be placed on the unit.

Do not expose the unit to dripping or splashing, and no objects filled with liquid,

such as vases, should be placed on or near the apparatus.

Do not place the unit inside a closed bookcase or cabinet without proper ventilation.

Cleaning

Disconnect the unit from the mains power supply before cleaning.

Do not use any liquids or aerosol cleaners, as this may damage the unit. Use a

soft, dust free cloth.

Servicing

There are no user serviceable parts in the unit. When servicing, refer to qualified

service personnel.

Consult your retailer if you are ever in doubt about the installation / operation /

safety of the product.

Safety Instructions

BR20DAB

What’s in the box?

Contents

Introduction

Safety Instructions

What’s in the box

Your DAB+ Radio

What is DAB+

Get Going

Daily Use DAB+

Daily Use FM

Troubleshooting/

Technical Specification

Warranty

8-13

14-17

DAB+ Radio

User Guide AC Power Cord

BR20DAB

Select/Scroll Up/Down

Scroll or Select between

the menu options.

Volume Control Knob

To adjust the sound level.

Standby Button

To switch between the

Standby or ON modes.

BBS Button

Press to turn on or off

the extra bass effect.

Mute Button

To turn off the sound

completely.

Scan Button

Press to search the next

available broadcast.

Preset Button

Press and hold to store

favourite stations and

press again to recall.

Display Button

Press to change the

station information

showing on the LCD

Display.

Antenna Rod

Pull and extend for

better reception.

LCD Display

Show current information.

AC Power Socket

To connect to AC Power Cable.

ON/OFF Switch

To turn the main unit power

ON or OFF.

Mode Button

Press to switch between

DAB+ & FM mode.

Menu Button

Press to select the menu

options.

AUX In Socket

To connect your MP3 device

or iPod.

Headphone Jack

To connect your Headphones.

Your DAB+ Radio

BR20DAB

DAB+was developed in Europe by a consortium of broadcasters and manufacturers

DAB+uses digital compression techniques to transform the source material, i.e. music

and speech, into better quality audio.

Interference free reception

Analogue systems suffer from an effect called “multipath distortion”. This is caused

because waves do not behave in an orderly fashion, but bounce and reflect off

buildings etc. DAB+sees this as an advantage and uses the direct and reflected signals

to actually reinforce the end result, allowing for better service more of the time.

No need to re-tune

A single DAB+frequency can be used to cover the whole of the Australia, so solving

Scolling text

Broadcasters can transmit text to your radio. This way you can read the name of the DJ,

artist, song title or any other information they choose.

DAB+ coverage

Check you local coverage at www.digitalradioplus.com.au

many of the problems experienced with the earlier analogue system DAB+scan

automatically tune-in all of the available stations in your area.

What is DAB+

BR20DAB

2Turn the wall outlet power on, then press the power switch at the rear of the unit to

the ON position.

1Connect the mains power cord to the AC Input (at the rear of the unit), then connect

the power cord to your desired wall outlet.

Using Headphones

To listen to this radio via the Headphones Jack, a pair of headphones (not supplied)

with a 3.5mm diameter stereo plug and 8-32 ohm impedance is required. Plug the

headphones into the Headphone Jack on the side of the DAB+ Radio.

When the headphones are connected, the speaker sound is automatically turned off.

Insert 6 “C” type batteries into the battery compartment, following the polarity

diagram on the inside.

Then replace the Battery Compartment Cover. Make sure it clicks into place.

4Using the DAB+ Radio with Batteries

The DAB+ Radio can be powered by 6 “C” types batteries. This allows the DAB+

Radio to be used outside or away from your wall power outlets.

To remove the Battery Compartment Cover, press the 2 retaining clips firmly and pull

away from the DAB+ Radio.

Using AUX IN

To listen to your iPod or MP3 player, connect an audio cable (not supplied) to the

AUX IN Socket located on the side of the DAB+ Radio. Then connect the other end of

the cable to your auxiliary device, i.e. iPod or MP3 player. You will now be able to

listen to your favourite songs on your iPod or MP3 Player.

Get going

BR20DAB

Switching On

To turn on the DAB+ Radio, ensure the power switch on the rear of the unit is set

to the ON position.

Press the STANDBY button on the touch panel.

To turn the DAB+ Radio off, press the STANDBY button again.

Progress bar

Number of stations found

Daily Use DAB+

Adjusting the Volume

To increase the volume, turn the volume control knob clockwise.

To decrease the volume, turn the volume control knob anti-clockwise.

You can also press the MUTE button to turn the sound off. To turn the sound

back on, press the MUTE button again.

BBS (Bass boost System) function

The bass sounds can be enhanced by selecting the bass boost system.

Press the BBS button to enhance the bass frequencies

To turn off the bass boost system, press the BBS button again.

Listening to the DAB+ Radio

Press the STANDBY button to turn the DAB+ Radio on.

The following screen will be displayed. A bar graph indicates the progress of the

initial search - the number of stations found increases as the scan progresses.

When the scan is complete, the DAB+ Radio will then select the first available

station. Stations are listed in numerical then alphabetic order. The station list is

retained in memory so the next time you switch the DAB+ Radio on, the station

search does not take place. If there are no stations found, check that you have

adequate DAB+ coverage in your area. You can find this out by visiting

www.digitalradio.com.au and using their online post code checker.

Please note: You should also run a full scan to make sure all stations are stored.

BR20DAB

Using the Menu

Press the MENU button to enter the menu. Rotate the SELECT button to scroll

through the options described below.

Full Scan

Press the MENU button to access the menu.

Rotate

the SELECT button until “Full scan” is displayed.

Push the SELECT button to activate a full scan for all available DAB+ stations.

Manual Tune

It is possible to manually tune your radio to a specific channel/frequency and add this

to the station list. This function can be used to obtain the optimum reception for a

specific channel/frequency.

Press

the MENU button to access the menu.

Rotate the SELECT button until “Manual tune” is displayed.

Press the SELECT button to confirm.

Rotate the SELECT button to select the desired channel/frequency.

Press the SELECT button, a rectangle will be displayed on the second line of the

display.

The position of this rectangle indicates the signal strength (the further towards the

right, the greater the signal strength)

Adjust the position of the antenna to obtain the optimum signal strength.

Push the SELECT button to confirm.

Daily Use DAB+

BR20DAB

Daily Use DAB+

Changing DAB+ Stations

DON’T FORGET!

If no new station is selected the DAB+ Radio will display the currently playing

station after 15 seconds.

From time to time new DAB+ stations may be added to the DAB+ station list.

If you wish to see if any new stations have been added, press the SCAN button to

activate a full scan.

Storing DAB+ Presets

You can preset up to 10 DAB+ stations for easy access as follows:

Rotate the Scroll Up/Down knob to scroll through the stations in the station list.

Press the Scroll Up/Down button to select a new station from the list.

Press the SELECT button to confirm. The radio will tune to the new station.

Tune to the station you wish to preset (see ‘Changing DAB+ Stations’).

Press and hold the PRESET button, preset position 1 will show on the display.

Rotate the SELECT/Scroll Up/Down button to select the required preset memory

position.

Press the SELECT button to save the current station into the specified preset

location.

Selecting a Preset Station

Press the PRESET button briefly, preset position 1 will show on the display.

Rotate the SELECT/Scroll Up/Down button to select the desired preset.

Push the SELECT button to confirm.

DON’T FORGET!

If you select a preset location that has not been programmed with a station,

"Preset empty" will be displayed.

The DAB+ Radio will return to the previously selected station after a few seconds.
