DAB+ FM DIGITAL RADIO

INSTRUCTION MANUAL

BR10DAB

The Gold Technical Support Line: 1902 215 259

www.bushaustralia.com.au

Personal Product Support

(Charges will apply at $2.95 per minute)

BR10DAB

Introduction

Thank you for buying this Bush product, which is designed to give you many years of trouble-free

service.

You may already be familiar with using a similar unit, but please take time to read these instructions.

They are designed to familiarise you with the unit’s many features and to ensure you get the very best

from your purchase.

Safety is important

Your safety and the safety of others is important.

Please therefore, ensure you read the “Safety Instructions” before you operate this unit.

Warranty

In the unlikely event that your product fails to work normally, please call the below free phone number to

discuss the problem with one of our qualified service engineers.

Australia.

Bush Warranty: 1800 509 394

New Zealand

Bush Warranty: 0800 450 259

BR10DAB

Ensure that you read all of the safety instructions before using this unit.

Safety Considerations

Position the power cable and other connected cables so that they are not likely to

be walked on, pinched or where items can be placed on or against them.

Do not use the unit in humid or damp conditions.

Do not allow the unit to get wet.

Never allow children to insert foreign objects into holes or slots on the unit.

The ventilation should not be impeded by covering the openings with items such as

newspapers, tablecloths, curtains, etc. This may cause overheating.

No naked flame sources, such as lit candles, should be placed on the unit.

Do not expose the unit to dripping or splashing, and no objects filled with liquids,

such as vases, should be placed on the apparatus.

Do not place the unit in closed bookcases or racks without proper ventilation.

Cleaning

Disconnect the unit from the mains supply before cleaning.

Do not use any liquids or aerosol cleaners, as this may damage the unit. Use a

soft, dust free cloth.

Servicing

There are no user serviceable parts in the unit. When servicing, refer to qualified

service personnel.

Consult your dealer if you are ever in doubt about the installation / operation /

safety of the product.

Safety Instructions

BR10DAB

Contents

Your DAB Radio

What is DAB

Getting Started

Battery Operation

Using DAB Radio

Using FM Radio

Trouble Shooting / Technical Specification

7-8

10-17

18-22

BR10DAB

1. LCD Display

2. + Button

3. - Button

4. SELECT/NAV. Button

5. MODE Button

6. SCAN Button

7. ON Button

8. OFF Button

9. MENU Button

10. INFO Button

11. PRESET Button

12. PHONE Jack

13. LOUD SPEAKER

14. ROD ANTENNA

15. DC Jack

Your DAB Radio

8910

BR10DAB

DAB was developed in Europe by a consortium of broadcasters and manufacturers

DAB uses digital compression techniques to transform the source material, i.e. music

and speech, into better quality audio.

Interference free reception

Analogue systems suffer from an effect called “multipath distortion”. This is caused

because waves do not behave in an orderly fashion, but bounce and reflect off

buildings etc. DAB sees this as an advantage and uses the direct and reflected signals

to actually reinforce the end result, allowing for better service more of the time.

No need to re-tune

A single DAB frequency can be used to cover the whole of the Australia, so solving

Scolling text

Broadcasters can transmit text to your radio. This way you can read the name of the DJ,

artist, song title or any other information they choose.

DAB+ coverage

Check you local coverage at www.digitalradioplus.com.au

many of the problems experienced with the earlier analogue system DAB scan

automatically tune-in all of the available stations in your area.

What is DAB

BR10DAB

Carefully remove your DAB Receiver from the box. You may wish to store the packaging

for future use.

In the Box

Inside the box you will find:

DAB Radio (Main Unit)

Power Adapter

User Guide

Positioning your DAB Radio

Place your DAB Receiver on a flat / stable surface that is not subject to vibrations.

Avoid the following locations:

Where it is exposed to direct sunlight.

Where it is close to heat radiating sources.

Where the humidity is high and ventilation is poor.

Where it is dusty.

Adjusting the Rod Antenna

The aerial should be extended to ensure good reception in both DAB and FM radio

modes. It may be necessary to alter the position of the DAB RADIO and /or aerial to

achieve the best signal.

Using Headphones

You will require headphones (not include) fitted with a 3.5 mm diameter stereo plug. The

Headphone socket is located on the top of this unit. Headphones are not supplied with this

DAB Receiver.

Getting Started

BR10DAB

Operation the Unit

Insert the power adapter output jack to connect the marked on the unit. After this

connection is made, insert the power adapter into the wall outlet. Your DAB Receiver

requires a mains supply of 240V AC ~ 50Hz. Press the ON button to power on unit

and press the OFF button to off the power.

Adjusting the Volume

Press the

- / +

buttons to increase/ decrease the volume sound.

If navigating within a list first push the SELECT/NAV. Button to exit and then use

the volume button as usual.

BR10DAB

Fit 4 x 1 .5V C-size batteries (not included), referring to the polarity markings inside

the battery compartment. Never mix old and new batteries. Finally, replace the cover.

For battery operation, switch off the mains supply and remove the cable from the power

socket Battery operation will be selected automatically.

CAUTION: Danger of explosion if batteries are incorrectly replaced.

Replace only with the same equivalent type. If you are not going to use

the unit for an extended period, please remove the batteries to avoid

damage.

Before installing batteries (not included), ensure that the DAB Receiver is

disconnected from the mains supply.

Remove the battery compartment cover on the back of the unit by carefully pushing

the two lugs down. The battery cover can then be lifted away.

Battery Operation

BR10DAB

Changing DAB Stations

If the DAB Receiver is in FM mode, press the MODE button to select DAB mode.

Press the SELECT/NAV button, the station name will start to flash and then use

the

- / +

buttons to move through the list.

Push the SELECT/NAV Button to confirm selection & start DAB broadcast (or

timeout after 5 sec).

Browsing DAB, to select a service push the SELECT/NAV button to enable

navigation and then use the

- / +

buttons to browse the service list, and press

SELECT/NAV button to select the service displayed.

When a station has been selected the display will show the information of the radio

station.

Switching On for the first time

Insert the power adapter into the unit. Now insert the power adapter into the wall outlet.

Press the ON button to turn on your DAB Receiver for the first time DAB mode is

selected automatically. The DISPLAY will illuminate and “ Welcome to Radio ” will be

displayed.

The following screen will be displayed A bar graph indicates the progress of the

search - the number of stations found increases as the scan progresses.

When the scan is complete, the DAB Receiver will then select the first available

station - stations are listed in numerical then alphabetic order. The station list is

retained in memory so the next time you switch the DAB Receiver on, the station

search does not take place. If there are no stations found, check that adequate DAB

coverage exists in your area.

Using DAB Radio

Progress bar

Number of stations found
