Instruction Manual
TEMPERATURE CONTROLLER
8400
8400 EXTENDED
© Bürkert 2000 Subject to technical change without notice
ENGLISH
ENGLISH
Temperature Controller 8400
Table of Contents
1 SAFETY RECOMMENDATIONS........................................................................................................... 4
1.1 Utilisation .................................................................................................................................................................................4
1.2 Precautions at installation and commissioning .......................................................................................5
1.3 Conformity to standards.............................................................................................................................................. 5
2 DESCRIPTION .............................................................................................................................................. 6
2.1 Design......................................................................................................................................................................................... 6
2.2 Measuring principle ......................................................................................................................................................... 6
2.3 Available versions .............................................................................................................................................................7
2.4 Accessories ............................................................................................................................................................................7
3 TECHNICAL DATA ...................................................................................................................................... 8
4 INSTALLATION ...........................................................................................................................................12
4.1 General recommendations ................................................................................................................................... 12
4.2 Mounting on the pipe ................................................................................................................................................ 12
8400 3
ENGLISH
ENGLISH
4.3 Electrical connection.................................................................................................................................................. 13
4.3.1 Connectors .......................................................................................................................................................... 13
4.3.2 Version with transistor output (NPN / PNP) ........................................................................ 14
4.3.3 Version with relay output ......................................................................................................................... 15
5 PROGRAMMING ........................................................................................................................................16
5.1 General recommendations ................................................................................................................................... 16
5.2 Functionalities .................................................................................................................................................................. 16
5.3 Programming keys ....................................................................................................................................................... 17
5.4 Default Configuration ................................................................................................................................................ 17
5.5 Normal Mode .................................................................................................................................................................... 18
5.6 Possible switching modes of the controller............................................................................................ 19
5.7 Calibration Mode ........................................................................................................................................................... 20
5.8 Simulation Mode ............................................................................................................................................................ 23
6 MAINTENANCE ..........................................................................................................................................24
6.1 Cleaning ................................................................................................................................................................................ 24
6.2 Error messages............................................................................................................................................................... 24
7 ANNEX ............................................................................................................................................................26
7.1 Examples of connections with the 8400 ................................................................................................. 26
7.2 Description of the label of the controller.................................................................................................. 29
ENGLISH
ENGLISH
Temperature Controller 8400
1 SAFETY RECOMMENDATIONS
Always respect the safety instructions marked by the symbol
opposite as well as those included in the manual.
1.1 Utilisation
The 8400 or 8400 Extended controller has only been designed to
measure the temperature of a liquid or a gas.
There will be no manufacturer warranty for damages caused by
unexpected handling or wrong usage of the device. The warranty on the
device becomes invalid if any modification or change is made on the
device.
The device should only be installed and repaired by specialist
staff.
The user is not allowed to work on the cables inside the housing.
If any difficulties may occur with the product during installation,
please contact your nearest Bürkert sales office for assistance.
8400 5
ENGLISH
ENGLISH
1.2 Precautions at installation and commissioning
- When the device is powered and the cover is open, protection
against electric shocks is not ensured.
- Always ensure the materials in contact with the medium to
measure are chemically compatible.
- To clean the device, only use chemically compatible products.
When dismounting the controller from the pipe, take all the
necessary precautions linked to the process.
Always ensure the tightness between the controller and the
pipe.
1.3 Conformity to standards
EMC: EN 50 081-1, 50 082-2
Security: EN 61 010-1
Vibration: EN 60068-2-6
Shock: EN 60068-2-27
ENGLISH
ENGLISH
Temperature Controller 8400
2.1 Design
The temperature controller 8400 or 8400 Extended is made up of an
electronic module and a measuring element. It may switch a solenoid
valve, activate an alarm or establish a control loop.
The switching point can be adjusted by means of the three keys located
under the display. The adjustment can optionally be carried out by
means of a 4-20 mA loop via an external controller.
The controller housing can be turned by 180°.
The electrical connection is carried out via a DIN 43650 connector
(type 2508) and/or an M12 multipin connector.
2.2 Measuring principle
The controller uses a Pt100 measuring resistance.
The controller 8400 is fitted with a 46-mm long sensor.
The controller 8400 Extended is available with a 100-mm or a 200-mm
long sensor.
2 DESCRIPTION
8400 7
ENGLISH
ENGLISH
2.3 Available versions
2.4 Accessories
Order code table for the 8400 and 8400 Extended versions
Order codes
M12 female connector, 5 pins, to be wired 917 116
M12 connector, 5 pins, moulded on a shielded cable (2 m) 438 680
M12 female coupler module for AS-Interface cable, 2 pins (AS-Interface version only) 440 653
Order code table for the accessories
Power Input Output Electrical connection Sensor Order codes
supply length G1/2NPT1/2RC1/2
12-30 VDC --- NPN DIN 43650 connector 46 mm 434 872 434 877 427 448
12-30 VDC --- PNP DIN 43650 connector 46 mm 434 876 434 878 427 449
12-30 VDC --- NPN and PNP M12 connector 46 mm 436 501 436 507 436 504
12-30 VDC --- Relay M12 and DIN 43650 connectors 46 mm 436 503 436 509 436 506
12-30 VDC --- Relay M12 and DIN 43650 connectors 100 mm 550053 - -
12-30 VDC --- Relay M12 and DIN 43650 connectors 200 mm 550054 - -
12-30 VDC 4...20 mA ext. Setpoint Relay M12 and DIN 43650 connectors 46 mm 440 456 440 460 440 458
AS-Interface --- Relay and AS-Interface M12 and DIN 43650 connectors 46 mm 440 455 440 459 440 457
ENGLISH
ENGLISH
Temperature Controller 8400
3 TECHNICAL DATA
General features
Pipe diameter any type of pipe with a DN ≥15 and a 1/2 ‘’ threaded connection piece (G, NPT or Rc)
Medium temperature +125 °C (+257 °F) max.
Fluid pressure max. PN 16
Measuring range -40° C...+125° C (-40° F…+257° F)
(with ambient temperature between 0 and +40° C (+32° F and +104° F))
-40° C...+90° C (-40° F…+194° F)
(with ambient temperature above +40° C (+104° F))
Switching accuracy ±0.5° C (0...80° C)
±1° F (+32° F…+176° F)
±1.5° C (outside 0...80° C)
±2.5° F (outside +32° F…+176° F)
Response time for a one step
increment from 0 °C to 100 °C 7 s (10% to 90% of the increment)
Repeatability 0.4%
Sensor element Pt100
Electrical features
Installation class
(overvoltage class) 2
Power supply 12-30 VDC
Max current consumption 750 mA (with load) (versions with PNP output)
80 mA (without load) (Relay version)
Protection against
polarity reversal yes
Transistor output NPN and/or PNP, open collector, 700 mA max, NPN output: 0,2-30 VDC and PNP output:
supply voltage (see example in the Annex)
or
8400 9
ENGLISH
ENGLISH
Relay output Relay version: 250 VAC, 3 A max. or 30 VDC, 3 A max. ; programmable
Relay+AS-Interface or relay+External Setpoint versions:48 VAC, 3 A max. or 30 VDC,
3 A max.; programmable
External setpoint input 4-20 mA (option)
ASI interface field bus (option)
Protection against
short-circuits yes for the transistor output
Type of cable recommended shielded, wire section between 0.14 and 0.5 mm2
Electrical connection
NPN version DIN 43650 connector (supplied)*
PNP version DIN 43650 connector (supplied)*
NPN/PNP version M12 female connector, 5 pins (not supplied)
Relay version (with or without
External setpoint board) DIN 43650 connector (supplied)* and M12 female connector, 5 pins (not supplied)
Relay+AS-Interface version DIN 43650 connector (supplied)* and M12 female connector, 2 pins (not supplied)
* EaseOn with 2511 connector on request
Housing
Housing material polycarbonate, fiber glass reinforced
Front plate polyester
Parts in contact
with the medium stainless steel 316L (DIN 1.4404), FPM in the standard versions (EPDM as an option)
Protection rating IP 65, connectors being plugged-in and tightened
Environment
Ambient temperature 0 to +60° C (+32° F to +140° F)
Relative humidity < 80%, non condensated
ENGLISH
ENGLISH
Temperature Controller 8400
Dimensions (mm)
3 TECHNICAL DATA
94 13,5
SW 27
G1/2'' - NPT1/2'' - Rc1/2''
61
103,5
16,5
29,5
ø 4
M12
54,2
ENTER
ENTER
0........9
0........9
....
O
U
T
DIN 43650
30
8400
