Quick Setup Guide

Wireless CABLE/DSL

Router-g

WBR2-G54

Preparation

This Quick Setup Guide will quickly and easily guide through installing this

product. For advanced setup and conﬁguration instructions, please refer to

the Online Manual on the AirNavigator CD-ROM or the Buffalo Support Web

Page.

Package Contents Checklist

◗Wireless CABLE/DSL Router-g (WBR2-G54)

◗ Utility CD-ROM w/ User Manual

◗ Quick Setup Guides

◗ AC Adapter

◗ 7ft. Ethernet Cable

◗Warranty Statement

If any of the contents are missing or damaged, please contact the retailer or

reseller from which this product was purchased.

www.buffalotech.com/wireless PY00-29012-DM20

Step 1 - Gathering Information

Depending on the type of broadband internet service you are subscribed to,

different types of information may be needed to complete the setup. Acquiring

this information in advance will make the setup of your AirStation router simple

and quick. A quick call to your service provider’s customer or technical support

number will provide you with the needed information if you are unsure. If you

are connecting to the internet via DSL service, then PPPoE information will most

likely be required from your ISP.

Recording the AirStation’s LAN MAC Address

The LAN MAC address of the AirStation is the default ESS-ID (SSID) and is

found on the back of the AirStation body as shown in the illustration above.

MAC Addresses are 12-digit codes comprised of numbers and letters. When

inputting MAC Addresses for custom conﬁgurations, a semi-colon (:) is used to

separate every two digits. ex: 00:07:40:00:00:00

The LAN or Wired MAC address is the

default ESS-ID (SSID) of the AirStation.

The LAN MAC address is located on the

back of the AirStation clearly labeled.

Step 2 - Connecting Cables to the AirStation

Depending on the type of broadband internet service you are subscribed

to, different types of information may be needed to complete the setup.

Acquiring this information in advance will make the setup of your AirStation

router simple and quick. A quick call to your service provider’s customer

or technical support number will provide you with the needed information if

you are unsure. If you are connecting to the internet via DSL service, then

PPPoE information will most likely be required from your ISP.

1. Power down the cable or DSL modem and the computer which will be

used to conﬁgure the AirStation router.

2. Plug the cable or DSL’s LAN Ethernet cable into the AirStation’s WAN

port. Initially, you may need to unplug this cable from your computer,

hub or other router.

3. Plug the provided Ethernet cable into a LAN port on the AirStation and

plug the other end into your computer’s Ethernet adapter’s (NIC)

port. If you plan to initially conﬁgure the AirStation wirelessly (not

recommended), you may skip this step.

4. Power on your cable or DSL modem and wait one full minute, Power

on the AirStation router, wait one full minute, and then power on the

computer which will be used to conﬁgure the AirStation. If the red

DIAG light on the AirStation is lit or ﬂashing after several minutes

of being powered on, please consult Buffalo Technology Technical

Support.

Deciding on a Mode for Initial AirStation Conﬁguration

◗Wired Connection (recommended)

◗ Wireless Connection

Step 3 - If not already done in the previous step, connect your

computer to the AirStation

Buffalo recommends using a wired connection, meaning your computer is

physically connected to the AirStation with a CAT5 straight cable plugged into

one of the four LAN ports. This type of setup will eliminate possible setup

problems due to any issues with the wireless adapter on the computer being

used to conﬁgure the AirStation.

A Web browser version 4.5 or later is can be used to conﬁgure the AirStation.

◗ Wired Conﬁguration

◗ Wireless Conﬁguration

■NOTE: If conﬁguring via a Wired Conﬁguration, please skip to the next page!

Windows 2000/XP

If there is no Ethernet adapter available on the computer being used to conﬁgure

the AirStation, a wireless conﬁguration may be performed using a correctly

installed 802.11b or 802.11g wireless adapter.

To conﬁgure the AirStation via a wireless connection, establish a connection to

the AirStation using the setup instructions that came with the wireless client card

or adapter that you are using.

Windows 98SE/ME

If there is no Ethernet adapter available on the computer being used to conﬁgure

the AirStation, a wireless conﬁguration may be performed using a correctly

installed 802.11b or 802.11g wireless adapter.

To conﬁgure the AirStation via a wireless connection, establish a connection to

the AirStation using the setup instructions that came with the wireless client card

or adapter that you are using.

Identifying the Proper AirStation

The default SSID of the AirStation is its LAN MAC Address which was addressed

on Page 2 of this Quick Setup Guide. Using your wireless card’s software or

Windows XP’s Wireless Zero Conﬁg, connect to the Wireless Network that

broadcasts the LAN MAC Address of your AirStation as its SSID. Please consult

the documentation that came with your wireless client card or adapter for further

assistance.

Step 4 - Conﬁgure your Computer’s IP Address

For Windows 98SE/ME

- Right-click on Network Neighborhood or My Network Places and select

Properties.

- Select the Conﬁguration tab, scroll down to TCP/IP and press Properties.

- Select Obtain IP address automatically and Obtain DNS Server address

automatically.

- Click OK to close Internet Protocol (TCP/IP) Properties

- Click OK to close Network Connection Properties

- Close Network Connections window

For Windows 2000/XP

- Click Start => Settings => Control Panel

- Double click on the Network Connections icon.

- Right-click on Local Area Network Connection and select Properties.

■NOTE: If a wireless connection is being used, you will be required to right-

click on the Wireless Connection and select Properties.

- Scroll down to Internet Protocol (TCP/IP ) and press Properties.

- Select Obtain IP address automatically and Obtain DNS Server address

automatically.

- Click OK to close Internet Protocol (TCP/IP) Properties

- Close Network Connections and Control Panel windows

Refer to your Operating System documentation for further instructions on how

to navigate to your TCP/IP Properties.

Step 6 - Conﬁgure the AirStation

Step 5 - Access the AirStation Conﬁguration Pages

Launch your Web browser and type 192.168.11.1 in the address ﬁeld of the

Web browser window and click “Go.”

*If you have previously modiﬁed the AirStation and changed the LAN

IP address, enter the custom LAN IP address to access the AirStation

conﬁguration pages.

If at any time you wish to restore settings to factory defaults, press the red INIT

button on the underside of the AirStation for 15 seconds. During this process

the red DIAG light will ﬂash rapidly. Do not let go of the INIT button until the red

DIAG light has stopped ﬂashing rapidly.

The User name and password ﬁeld

will open.

Enter “root” as the User name

Leave the password ﬁeld blank.

Click OK.

◗Advanced

Select this option for advanced settings of your AirStation. For more information

on conﬁguring advanced settings of your AirStation, please refer to the User

Manual on the AirNavigator CD or the Buffalo Wireless Support Web Site:

http://www.buffalotech.com/wireless/support

◗Default Settings

If at any time you wish to restore settings to factory defaults, press the red INIT

button on the back of the AirStation for 15 seconds. During this process the red

DIAG light will light up. Once it has lit up, you can stop pressing the INIT button.

The restore process can take up to two minutes.

This completes the basic AirStation Conﬁguration. To change advanced settings,

please consult the Online Manual on the CD-ROM or go to the Buffalo Support

Web Site: http://www.buffalotech.com/wireless/support

◗DSL

Select this option if your internet

connection is provided by a

DSL provider. Most DSL providers

require PPoE settings to be entered.

◗Cable

Select this option if your internet

connection is provided through your

cable provider. Most cable providers

require no aditional settings except to

obtain an IP.

■NOTE: After selecting either the DSL or Cable wizard, please choose

the proper selections that are applicable to your internet service provider. A

veriﬁcation test will be run at the end of the wizard.

The ﬁrst page of the conﬁguration offers 3 distinct buttons for DSL, Cable, and

Advanced settings. Select the appropriate type of internet service, referencing

the information you collected during the preparation steps if needed.

The AirStation can be re-conﬁgured anytime via a Web browser using a wired

or wireless connection by entering 192.168.11.1 in the URL address ﬁeld of the

Web browser and pressing the Enter key on the keyboard.

Additional Information:

AOSS (AirStation One-Touch Secure System)

The WBR2-G54 supports Buffalo’s AOSS system for connecting AOSS

compatible wireless clients to the WBR2-G54. For information about AOSS,

please refer to the AOSS Supplement which is included in the WBR2-G54

package contents.

IP Addressing

To verify your IP settings for static or automatic addressing, click Start, select

Settings (if present) and click Control Panel. Within Control Panel, double-

click Network or Network Connections depending on your Operating System.

You can then right-click and select Properties for your wired or wireless

connections. Within the properties, you can view the properties of your TCP/IP

protocol.

Generally, you will want to be sure that “Obtain an IP address automatically”

is selected to allow easier connections. To manually renew IP addressing

conﬁgurations for your connection, follow these steps:

◗Click Start and Run. A dialog box will appear where you can type

COMMAND into the ﬁeld provided and click OK.

◗An MS-DOS prompt will launch. Enter IPCONFIG /RELEASE and

press the Enter key on the keyboard to release your current IP

conﬁguration. Next, enter IPCONFIG /RENEW and press the Enter

key to seek new settings from a DHCP server. (This may take a few

moments).

◗Type IPCONFIG /ALL. This will display all the IP conﬁgurations for your

wired or wireless connection.

◗The Default Gateway address listed in the results is usually the IP

address of the AirStation. If no IP addresses are listed or your wireless

adapter displays a 169.254.XXX.XXX address, retrace the setup steps

to verify correct installation.

◗Type EXIT to close out the DOS window.

Buffalo Technology

Technical Support

Buffalo Technology offers Toll-Free Technical Support 24 hours a day, 7 days a

week for this product. Customers in the United States and Canada can obtain

technical support using the following information:

◗Online Help: Available on the AirNavigator CD enclosed with your

purchase.

◗Web www.buffalotech.com/wireless

◗E-mail info@buffalotech.com

◗Telephone 866-752-6210 (USA & Canada only)

The constantly evolving state of wireless products and operating systems

requires Buffalo Technology to occasionally release updated software to take

advantage of new technologies and to comply with industry standards. For

the most recent software, ﬁrmware, driver, and technical whitepaper releases

available, please visit the Buffalo Technology website.

FCC Compliance Statement - See owners manual for complete statement.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference,

and (2) this device must accept any interference received, including interference

that may cause undesired operation.

R&TTE Compliance Statement - See owners manual for complete statement

This equipment complies with all the requirements of the DIRECTIVE 1999/5/

EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of 9 March 1999

on radio equipment and telecommunication terminal Equipment and the mutual

recognition of their conformity (R&TTE).

is part of MELCO INC., the global manufacturers of IT peripherals, including memory, networking,

and multimedia products, inside many of the world’s computers. All trademarks are property of their

respective owners.

Autres manuels pour AirStation WBR2-G54

Table des matières

Autres manuels Buffalo Routeur sans fil

Buffalo

Buffalo AirStation WBR2-G54 Manuel utilisateur

Buffalo

Buffalo AirStation Nfiniti WZR-AG300NH Manuel utilisateur

Buffalo

Buffalo AirStation Draft-N WZR-G300N Manuel utilisateur

Buffalo

Buffalo WCR-G300 Manuel utilisateur

Buffalo

Buffalo WZR-G240 Manuel utilisateur

Buffalo

Buffalo WBMR-G54 Manuel utilisateur

Buffalo

Buffalo AirStation WBR2-G54 Manuel utilisateur

Buffalo

Buffalo Nfiniti WHR-HP-GN Manuel utilisateur

Buffalo

Buffalo WHR-G300N V2 Manuel utilisateur

Buffalo

Buffalo AirStation Nfiniti WZR-HP-G300NH Manuel utilisateur

Buffalo

Buffalo AirStation Turbo G WHR-HP-G54 Manuel utilisateur

Buffalo

Buffalo AIRSTATION WBR-G54 Manuel utilisateur

Buffalo

Buffalo AirStation Draft-N WZR-G300N Manuel utilisateur

Buffalo

Buffalo AirStation WYR-G54 Manuel utilisateur

Buffalo

Buffalo AirStation WHR-G54S Manuel utilisateur

Buffalo

Buffalo AirStation Turbo G WHR-HP-G54 Manuel utilisateur

Buffalo

Buffalo AirStation Nfiniti WZR-AG300NH Manuel utilisateur

Buffalo

Buffalo AirStation WHR-HP-AG108 Manuel utilisateur

Buffalo

Buffalo AIRSTATION WBR-G54 Manuel utilisateur

Buffalo

Buffalo AirStation G54 WLA-G54C Manuel utilisateur

Buffalo

Buffalo Nfiniti AirStation Draft-N WZR2-G300N Manuel utilisateur

Buffalo

Buffalo WHR-G54S : WIRELESS-G 125* HIGH-SPEED BROADBAND ROUTER & ACCESS... Manuel utilisateur

Buffalo

Buffalo Wireless-G High Speed ADSL2+ Modem Router Manuel utilisateur

Buffalo

Buffalo AirStation WHR3-G54 Manuel utilisateur

Manuels Routeur sans fil populaires d'autres marques

Milesight

Milesight UG67 Manuel utilisateur

Airlogic

Airlogic AirSync Class 1 Manuel du propriétaire

Samsung

Samsung WCH730B Manuel utilisateur

TELEFONICA

TELEFONICA USB Adapter Manuel utilisateur

NETGEAR

NETGEAR PowerLINE WiFi 1000 Series Manuel utilisateur

Askey

Askey RAC2V1K Manuel utilisateur

Alloy

Alloy WLF2454AP-S Manuel utilisateur

TP-Link

TP-Link TL-WR542G Manuel utilisateur

NETGEAR

NETGEAR WNR2000v4 Manuel utilisateur

Hama

Hama 53120 Manuel utilisateur

Intellinet

Intellinet 524582 Manuel utilisateur

Asus

Asus RT-N10P Manuel utilisateur

D-Link

D-Link DIR-506L Manuel utilisateur

Sapido

Sapido GR297n Manuel utilisateur

Asus

Asus DSL-N55U Manuel utilisateur

AMTC

AMTC WR7502 Manuel utilisateur

Compaq

Compaq CP-2W - iPAQ Connection Point Manuel utilisateur

SMC Networks

SMC Networks WBR14-N2 FICHE Manuel utilisateur
