Buffalo DriveStation HD-CEIU2 Manuel utilisateur

www.buffalotech.com

DriveStation HD-CEIU2

User Manual

DriveStation USB Hard Drive HD-CEIU2

Thank you for purchasing a Bualo DriveStation External Hard Drive.

• DriveStation USB Hard Drive

• Power Adapter

• USB Cable

• IEEE1394 (FireWire) Cable

• Quick Setup Guide

• Warranty Statement

Package Contents

Back Panel Layout

IEE1394

4pin (to PC)

Plug for power

adapter

USB (to PC)

Power button

IEE1394

6pin (to PC)

Power LED

Green: USB mode

Orange: IEEE1394 mode

Installation

On a Windows computer, the

new drive will be available in

My Computer.

By default it will use the rst

available drive letter and will

be named HD-CEIU2.

With a Mac, the new drive will

appear on the desktop.

Connect the power adapter to a

surge protector or power outlet

and to the DriveStation.

Then, use either the USB

cable or the IEEE1394 cable to

connect the DriveStation to your

computer.

Change the power mode switch

on the back to “AUTO”.

The power LED will glow and

your computer will install the

drive automatically.

#761

1((

Format

By default, the DriveStation is formatted with FAT32, allowing it to be used

with OS X, Windows operating systems. If you’re going to use

it with programs that generate lesizes larger than 4GB, such as backup

or video editing software, reformat the DriveStation as an NTFS drive

(Windows), or a Mac OS Extended drive (Mac).

NTFS formatting process is included in DriveNavi.exe located in

DriveStation.

Optional Utilities

The DriveStation includes several optional utilities. To install and use

these utilities, follow Installation menu located on your DriveStation or

download from our website (http://www.bualotech.com).

Note: Disk Formatter, SecureLockWare, and eco Manager are supported on

Windows PC only.

The TurboUSB utility improves data transfer speeds for your DriveStation.

Memeo AutoBackup (Memeo LifeAgent on a MAC PC) is available

for backing up documents, multimedia les, and other les from your

Windows PC to the DriveStation. A license for using Memeo on a single PC

or workstation is included with your DriveStation.

Disk Formatter lets you easily reformat your DriveStation.

SecureLockWare encrypts the data on your DriveStation, preventing the

data from being accessed by anyone but you.

The eco Manager for HD lets you put the DriveStation into Sleep mode to

save power.

To learn more about installing and using these utilities, refer to each

individual manuals located on your DriveStation.

Troubleshooting

FAQ

The following is a list of common issues with the DriveStation. Following

each issue are possible resolutions.

I see the DriveStation in My Computer but I cannot access it.

The drive requires formatting. Try using the Disk Formatter Utility available

on our website www.bualotech.com. Consult the manual for the Disk

Formatter Utility for more help.

I cannot see the DriveStation in My Computer.

Verify that the POWER light is on. If it is not, then ensure that the power

switch is in the ON position.

Try toggling the POWER MODE switch right below the power switch. The

POWER MODE switch toggles whether the device is powered up via a USB

signal (“AUTO”) or purely based on the power switch’s position (“ON”).

If you have installed eco Manager utility, then verify that the DriveStation

was not put into sleep mode. Consult the manual for the eco Manager

Utility for additional help.

Verify that the hard drive inside the DriveStation is spinning. This

can be veried by placing your hand on the sides of the case and feeling

for a slight vibration. Also, after the DriveStation has been powered on

for fteen minutes or more it will begin to get warm. If neither of the

proceeding tests veried that the hard drive is spinning, then please contact

technical support for further assistance.

My backup program can’t save les to the DriveStation.

Reformat your DriveStation with NTFS, Mac OS Extended, or XFS. FAT32 is

limited to 4GB lesizes.

Technical Specications

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference,

and (2) this device must accept any interference received, including interference

that may cause undesired operation.

IEEE1394 Standards: IEEE1394a

USB Standards: USB Specication Rev. 2.0

Seek Time: Max. 11 milliseconds

Transmission Speed: Max. 480 Mbps(USB2.0)

/ Max. 400Mbps(IEEE1394a)

Power Supply: external, AC100-240V 50/60Hz

Power Consumption: Max. 24 W, Average 12 W

Dimensions (W x H x D): 1.8 x 6.9 x 6.1 in. (45 x 175 x 156 mm)

Weight: 2.6 lb. / 1.2 kg

Operating Environment: 41 - 95 degree F / 5 - 35 degree C

20-80 % humidity (non-condensing)

OS Compatibility: Windows 2000, XP, Vista,

Mac OS X 10.2.7 or later

FCC Warning

This is a Class B product. In a domestic environment, this product may cause

radio interference, in which

case the user may be required to take adequate measures.

CE Mark Warning

• The equipment that you have purchased required the extraction and use of

natural resources for itsproduction.

• The equipment may contain hazardous substances that could impact health

and the environment.

• In order to avoid the dissemination of those substances in our environment

and to diminish the load on natural resources, we encourage you to use the

appropriate take-back systems.

• The take-back systems will reuse or recycle most of the materials of your end

of life equipment appropriately.

• The crossed-out wheeled bin symbol invites you to use those systems.

• If you need more information on the collection, reuse and recycling systems,

please contact your local or regional waste administration.

Environmental Information

Memo

USA/Canada Technical Support is available 24 hours a day, 7 days a week

toll-free: 866-752-6210

email: info@buffalotech.com

Europe Technical Support:

Buffalo Technology provides technical

support in English, German, French, Italian and

Spanish. For opening hours and relevant telephone numbers,

please go to: http://www.buffalo-technology.com/contact

35010608-01 1-01 C20-005
