User Manual
Broadband ADSL2+ Modem Router
WBMR-HP-GNV2
www.bualotech.com
35011767 ver.01
WBMR-HP-GNV2 User Manual 1
Contents
Chapter 1 - Product Overview .........................................5
Features .................................................................................. 5
Air Navigator CD Requirements .............................................. 6
150 Mbps High Speed Mode ................................................... 6
Package Contents ................................................................... 6
Hardware Overview ................................................................. 7
Front Panel LEDs / Back Panel ..................................................... 7
Top ................................................................................................. 9
Bottom ............................................................................................ 10
Right Side ...................................................................................... 10
Chapter 2 - Placing Your AirStation ................................11
Vertical Placement .................................................................. 11
Horizontal Placement .............................................................. 12
Wall-Mounting ......................................................................... 13
Chapter 3 - Installation .....................................................14
Automatic Setup ...................................................................... 14
Manual Setup .......................................................................... 14
Gathering Information ............................................................. 17
Chapter 4 - Conguration ................................................19
How to Access the Web-Based Conguration Utility ............... 19
Conguration Utility Menus ..................................................... 21
Setup ....................................................................................... 23
Internet/LAN ............................................................................ 25
Internet ........................................................................................... 25
WBMR-HP-GNV2 User Manual 2
DDNS (Router Mode only) ............................................................. 29
Route ............................................................................................. 31
Wireless Cong ....................................................................... 32
WPS ............................................................................................... 32
AOSS ............................................................................................. 33
Basic .............................................................................................. 35
Advanced ....................................................................................... 39
WMM .............................................................................................. 40
MAC Filter ...................................................................................... 42
Security (Router Mode only) ................................................... 43
Firewall (Router Mode only) ........................................................... 43
IP Filter (Router Mode only) ........................................................... 44
VPN Pass Through (Router Mode only) ........................................ 45
LAN Cong .............................................................................. 46
Port Forwarding (Router Mode only) .............................................. 46
DMZ (Router Mode only) ............................................................... 48
UPnP (Router Mode only) .............................................................. 48
QoS (Router Mode only) ................................................................ 49
Admin Cong ........................................................................... 50
Name ............................................................................................. 50
Password ....................................................................................... 51
Time/Date ...................................................................................... 52
NTP ................................................................................................ 53
ECO ............................................................................................... 54
Access ........................................................................................... 56
Log ................................................................................................. 57
Save/Restore ................................................................................. 58
Initialize/Restart ............................................................................. 59
Update ........................................................................................... 60
Diagnostic ............................................................................... 61
System Info .................................................................................... 61
Logs ............................................................................................... 63
Packet Info ..................................................................................... 64
WBMR-HP-GNV2 User Manual 3
Client Monitor ................................................................................. 65
Ping ................................................................................................ 66
DSL Connection ............................................................................. 67
Chapter 5 - Connect to a Wireless Network ...................68
Automatic Secure Setup (AOSS/WPS) ................................... 68
Windows 7/Vista (Client Manager V) ............................................. 69
Windows XP (Client Manager 3) .................................................... 70
Other Devices (e.g. Game Console) .............................................. 70
Manual Setup .......................................................................... 71
Windows 7 (WLAN AutoCong) ..................................................... 71
Windows Vista (WLAN AutoCong) ............................................... 72
Windows XP (Wireless Zero Conguration) ................................... 75
Mac OS X (AirPort) ........................................................................ 76
Chapter 6 - Trouble Shooting ..........................................77
Cannot connect to the Internet over wired connection. ........... 77
Cannot access the web-based conguration utility. ................ 77
Cannot connect to the network wirelessly. .............................. 78
You forgot AirStation’s SSID, Encryption Key, or Password. ... 78
The link speed is slower than 150 Mbps (Maximum link speed is
only 65 Mbps). ......................................................................... 78
Other Tips ................................................................................ 79
Appendix A - Specications ............................................81
Appendix B - Default Conguration Settings ................ 82
WBMR-HP-GNV2 User Manual 4
Appendix C - TCP/IP Settings ..........................................87
Windows 7 ............................................................................... 87
Windows Vista ......................................................................... 88
Windows XP ............................................................................ 89
Mac OS X ................................................................................ 90
Appendix D - Restoring the Default Conguration .......91
Appendix E - Regulatory Compliance Information ........92
Appendix F - Environmental Information .......................96
Appendix G - GPL Information ........................................97
Appendix H - Warranty Information ................................98
WBMR-HP-GNV2 User Manual 5
Chapter 1 - Product Overview
Features
Supports IEEE802.11n and IEEE802.11b/g
With support for current Wireless-N, Wireless-G, and Wireless-B standards, the AirStation can transfer
data to and from all standard 2.4 GHz wireless clients.
Dual speed mode
Dual speed mode makes wireless transmission faster by using 2 channels, allowing 150 Mbps data
transmission.
Support AOSS and WPS
Both AOSS (AirStation One-touch Secure System) and WPS (Wi-Fi Protected Setup) are supported.
These automatic connection standards make connection with compatible wireless devices easier.
Security Features
The AirStation is equipped with following security features:
• AOSS
• WPS
• WPA-PSK (TKIP/AES)
• WPA2-PSK(TKIP/AES)
• WPA/WPA2 mixed PSK
• WEP(128-bit and 64-bit)
• Privacy Separator
• MAC address access restriction
• Deny Any Connection/SSID stealth feature
• Setting screen with password
• Firewall feature with easy rules
Automatic Channel Selection
Monitors wireless interference and automatically assigns the clearest, best channel.
Initialization
To restore settings back to the factory defaults, hold down the Reset button on the bottom of the
unit.
Browser Based Administration
This unit can be easily congured from a web browser on your computer.
WBMR-HP-GNV2 User Manual 6
Chapter 1 Product Overview
Air Navigator CD Requirements
The AirStation wireless router and access point works with most wired and wireless devices.
However, the automatic installation program on the CD requires a connected Windows 7, Vista or
XP computer to run. If you use the AirStation with a dierent operating system, you will have to
congure your network settings manually from a browser window.
150 Mbps High Speed Mode
150 Mbps is the link speed when using Wireless-N mode. It represents actual wireless data speeds,
including overhead. Because the overhead is not available for user data transfer, usable wireless
throughput will be substantially slower.
Package Contents
The following items are included in your AirStation package. If any of the items are missing, please
contact your vender.
• WBMR-HP-GNV2 ..........................................................................................................................1
• Detachable antenna...................................................................................................................1
• AC adapter .....................................................................................................................................1
• Stand for vertical/horizontal/wall-mounting ....................................................................1
• Screws for wall-mounting ........................................................................................................2
• LAN cable .......................................................................................................................................1
• DSL cable ........................................................................................................................................ 1
• Air Navigator CD .......................................................................................................................... 1
• Quick Setup Guide ...................................................................................................................... 1
1
3
2
5
6
4
78
9
Chapter 1 Product Overview
WBMR-HP-GNV2 User Manual 7
Hardware Overview
Front Panel LEDs / Back Panel
1Power LED
On (Green) : The AC adapter is connected.
O (Green) : The AC adapter is not connected.
Shows AirStation status.
2 blinks (Red) *1 : Flash ROM error.
3 blinks (Red) *1 : Wired Ethernet LAN error.
4 blinks (Red) *1 : Wireless LAN error.
5 blinks (Red) *1 : Network error.
9 blinks (Red) *1 : System error.
Continuously
blinking (Red) *2 :
Updating rmware, saving settings, or initializing settings.
WBMR-HP-GNV2 User Manual 8
Chapter 1 Product Overview
*1 Turn o AirStation rst, wait for a few seconds, then turn it back on.
*2 If the Power LED keeps blinking, do not turn o the AirStation nor unplug its power
cable.
2Security LED (Amber)
Indicates security status.
O : AOSS or Encryption is not set.
On : AOSS/WPS activated; accessed to exchange security keys.
Encryption has been set.
2 blinks : The unit is waiting for an AOSS or WPS security key.
Blinking : AOSS/WPS error; failed to exchange security keys.
Note : The Security LED is lit if an encryption key has been set.
3Wireless LED (Green)
Indicates wireless LAN status.
On : Wireless LAN is transmitting.
O : Wireless LAN is not active.
4DSL LED (Green)
Indicates DSL status.
On : The DSL port is connected.
5Internet LED
Indicates Internet status.
On (Green) : Connected to Internet
Blinking (Green) : Communicating over Internet
On (Red) : Not connected to Internet
O : Operating in bridge mode
6DC Connector
Connect the included AC adapter here.
7LAN LED (Green)
On : An Ethernet device is connected.
Blinking : An Ethernet device is communicating.
8LAN Port
Connect your computer, hub, or other Ethernet devices to these ports. This switching hub
supports 10 Mbps, 100 Mbps connections.
9DSL Port
Connect your ADSL line to this port.
10
11
Chapter 1 Product Overview
WBMR-HP-GNV2 User Manual 9
Top
10 AOSS Button To initiate AOSS, hold down this button until the Security LED ashes
(about 1 second). Then, push or click the AOSS button on your wireless
client device to complete the connection. Both devices must be powered
on for this to work.
11 Antenna connector Screw on the antenna here.
Table des matières
Autres manuels Buffalo Routeur réseau
Buffalo
Buffalo AirStation Turbo G WHR-HP-G54 Manuel utilisateur
Buffalo
Buffalo AirStation Nfiniti WZR-HP-G300NH Manuel utilisateur
Buffalo
Buffalo AirStation Nfiniti WZR-HP-AG300H Manuel utilisateur
Buffalo
Buffalo AirStation WZR-1750DHP Manuel utilisateur
Buffalo
Buffalo AirStation NFINITI WHR-HP-G300N Manuel utilisateur
Buffalo
Buffalo WCR-HP-GN Manuel utilisateur
Buffalo
Buffalo WBMR-HP-GN Manuel utilisateur
Buffalo
Buffalo AIRSTATION WBR-G54 Manuel utilisateur
Buffalo
Buffalo WZR-D1800H Manuel utilisateur
Buffalo
Buffalo AirStation Turbo G WHR-HP-G54 Manuel utilisateur
Buffalo
Buffalo AirStation WZR-600DHP2 Manuel utilisateur
Buffalo
Buffalo AirStation NFINITI High Power WHR-300HP Manuel utilisateur
Buffalo
Buffalo AirStation WZR-900DHP Manuel utilisateur
Buffalo
Buffalo AirStation WZR-1750DHP Manuel utilisateur
Buffalo
Buffalo AirStation WZR-600DHP Manuel utilisateur
Buffalo
Buffalo AirStation HighPower WBMR-HP-GNV2 Manuel utilisateur
Buffalo
Buffalo AirStation Nfiniti WZR-HP-AG300H Manuel utilisateur
Buffalo
Buffalo AirStation WHR-HP-G125 Manuel utilisateur
Buffalo
Buffalo AirStation WLI-H4-D1300 Manuel utilisateur
Buffalo
Buffalo AirStation NFINITI WHR-HP-G300N Manuel utilisateur
Manuels Routeur réseau populaires d'autres marques
NETGEAR
NETGEAR FS526T - Switch Manuel utilisateur
Korenix
Korenix JetNet 5710G Series Manuel utilisateur
Automated Logic
Automated Logic ZN551 Manuel du propriétaire
Cisco
Cisco ASR 1000 Series Manuel de l'opérateur
EnGenius
EnGenius ESR-9710 Manuel utilisateur
Cisco
Cisco 805 Series Instructions d'utilisation et de sécurité
