Duet 700 ~ 7th Edition ~ 31st October ’01 ~ 3845

Duet 700

User Guide

Caller Display* Telephone

This product is intended for connection to analogue public

s itched telephone net orks and private s itchboards in the

United Kingdom.

Duet 700 ~ 7th Edition ~ 31st October ’01 ~ 3845

Date of purchase:

Place of purchase:

erial number:

Purchase price:

For guarantee purposes,

proof of purchase is

required, so please keep

your receipt.

If anything is missing, please

contact your place of purchase

immediately.

Duet 700

telephone with

line cord attached.

Screws and

wall plugs for

wall-mounting.

Caller Display

Leaflet

General

Simply clean your Duet 700 with a

damp (not wet) cloth, or an antistatic

wipe.

Never use household polish as this

may damage the product.

Never use a dry cloth as this may

cause static shock.

Do not open the Duet 700. This could

expose you to high voltages or other

risks.

Never dispose of batteries in a fire.

There is a serious risk of explosion

and/or the release of highly toxic

chemicals.

Environmental

Do not expose to direct sunlight.

We recommend that you do not place

the product on antique/veneered wood

to avoid damage.

Do not stand your product on carpets

or other surfaces which generate fibres,

or place it in locations preventing free

flow of air over its surfaces.

Do not submerge any part of your

product in water and do not use it in

damp or humid conditions, such as in

bathrooms.

Do not expose your product to fire,

explosive or other hazardous conditions.

Introduction

Unpacking your

Duet 700

For your records

Safety information

Recall

Set

Secrecy

Redial

Store

Dial

Duet 700 ~ 7th Edition ~ 31st October ’01 ~ 3845

In this guide

At a glance 1

Setting up 4

Using your

Duet 700 telephone 5

Making and ending calls 5

Call timer 5

Visual ring indicator 5

Storing and dialling names

and numbers 8

Character map 9

Using Caller Display 12

Calls List 12

Help 16

eneral information 18

Guarantee 18

Technical in ormation 19

Switchboard compatibility 19

Wall mounting 20

Index 21

Duet 700 ~ 7th Edition ~ 31st October ’01 ~ 3845

Setting up

NOTE

Please read the instructions

carefully before use, and keep

this user guide for future

reference.

Battery low warning

The battery low icon is

displayed when the batteries

are nearing the end of their

useful life. If the batteries get

too low or are completely flat

the icon will not be displayed.

IMPORTANT

Changing the batteries

Disconnect your Duet 700 from

the phone line. Replace the

batteries. The information in

your Duet 700 will be retained

for a minimum of 10 minutes

without batteries fitted.

Helpline

If you experience any

difficulties with your Duet 700

please contact the Helpline on

0845 330 0092.

Follow these easy steps to

get your Duet 700 telephone

ready for use. If you do not install any

batteries your Duet 700 will

still allow you to make calls,

but the display will remain

blank. The batteries power

the display, Caller Display

facility and retains information

stored in the memory.

Remove the battery cover

and insert 3xAA batteries.

(not included)

1Connect

ZZZ

2Connect the

telephone line cord

1Install the batteries

Duet 700 ~ 7th Edition ~ 31st October ’01 ~ 3845

Using your Duet 700

telephone

Lift the handset. You

will hear a dial tone.

Enter the telephone

number. The number

will be shown on the

display and dialled.

The last number

dialled is stored in the

redial memory.

Press the REDIAL

button. The number is

shown on the display

and dialled

automatically.

Call timer

Your Duet 700 automatically

times the duration of all

outgoing and incoming calls.

The call timer is shown on

the display:

Making and ending calls

Visual ring indicator

The light on the back of the

handset will flash red to

indicate when there is an

incoming call.

When using Caller Display

the light will also flash green

To make a call

Replace the handset.

You can also press the

hookswitch if you

wish to make a follow

on call.

To end a call

1Connect

ZZZ

To redial the last

number

Redial

NOTE

If you are redialling a number

when connected to a

switchboard, wait until you

hear a dial tone, then press

the 9button, wait again for

a dial tone and then press

REDIAL. This applies even

if 9is stored in REDIAL.

00:14

KEYPAD

Duet 700 ~ 7th Edition ~ 31st October ’01 ~ 3845

When on a call you can

talk to someone in the

same room, without

your caller hearing.

During a call press

the SECRECY button.

The LED will flash to

indicate that secrecy

is on. You can talk and

your caller will not

hear you.

To resume your call

press the SECRECY

button again. The LED

will stop flashing.

1Connect

ZZZ

To switch secrecy on

and o

Secrecy

1Connect

ZZZ

To adjust the speaker

volume

Set

Press the SET button.

The display will show

the current volume

level: HANDSET VOL 3

There are 5 levels.

1= quietest. 5= loudest.

Press the UP/DOWN

button to increase or

decrease the volume.

The display will show

the volume increase

or decrease. Hold the

handset to your ear to

see which volume level

suits you.

Press the SET button

to confirm the level

chosen.

The display will show

RINGER VOL.

If you do not wish to

change the ringer

volume setting, replace

the handset.

to indicate you have unviewed

new calls in your calls list.

See page 12.

NOTE

The speaker volume will reset

to volume level 3 when you

replace the handset.

NOTE

The following settings can only

be adjusted when the telephone

is off the base.

Set

Duet 700 ~ 7th Edition ~ 31st October ’01 ~ 3845

NOTE

When the ringer is switched

off the red ring indicator light

will continue to flash to

indicate an incoming call. The

ringer will remain switched off

until you lift the handset again.

It is not possible to switch the

ringer off permanently.

There are five levels

of contrast to choose

from (1-5).

Press the SET button

three times. The display

will show the current

level: CONTRAST 3

Use the switch on the

left hand side of the

handset to adjust the

contrast level.

Press the SET button

to confirm the level

chosen. The selected

contrast will remain

until changed.

The display will show

the next menu option,

BACKLIGHT OFF. If

you do not want to

change this setting

replace the handset.

1Connect

ZZZ

To adjust the display

contrast

Set

The Duet 700 can be

set to one of three

different ringer

volumes, or you can

switch the ringer off.

Volume 3 = High,

Volume 2 = Medium,

Volume 1 = Low

Press the SET button

twice. The display

will show the current

ringer volume:

RINGER VOL 2.

Use the UP/DOWN

button to increase or

decrease the volume.

If you want to turn

the ringer off, press the

0button. The display

will show RINGER OFF.

Press the SET button

to confirm the level

chosen. The selected

volume will remain

until changed.

The display will show

the next menu option,

CONTRAST. If you do

not want to change

this setting replace the

handset.

1Connect

ZZZ

To adjust the ringer

volume

Set

Duet 700 ~ 7th Edition ~ 31st October ’01 ~ 3845

NOTE

Setting the backlight to off

will conserve the battery life.

NOTE

During storing ignore any

Network announcements.

Your Duet 700 has a

backlight which lights

up the displays.

When switched on the

display will light up for

20 seconds when you

lift the handset or if

your telephone rings.

Pressing a button if the

backlight has timed out

will reactivate it for a

further 20 seconds.

Press the SET button

4 times. The display

will show the current

setting: BACKLIGHT ON

Use the switch on the

left hand side of the

handset to change the

setting to on or off.

Press the SET button

to confirm the setting.

The selected setting

will remain until

changed. The display

will return to its

previous state.

1Connect

ZZZ

To switch the backlight

on or o

Set

You may need to use

the RECALL button if

you are connected

to a switchboard/PBX

(Private Branch

Exchange), contact

your PBX supplier for

further information.

The RECALL button is

also used for BT Select

Services.

For more information

on BT’s Select Services

call BT on Freefone

0800 800 150.

To use the Recall button

Recall

Storing and dialling

names and numbers

You can store up to 50 of

your most frequently used

names and telephone

numbers in the memory.

Use the DOWN button

to move to the next

space.

To enter M press the

6button.

Press the STORE

button to confirm.

You can also enter a

space by pressing the

DOWN button twice

or by pressing the 0

button.

The display will show

how many entries

have been stored, e.g.

STORED 18/50

Duet 700 ~ 7th Edition ~ 31st October ’01 ~ 3845

Lift the handset.

Press the STORE

button. The display

will prompt you to

enter the number:

ENTER NUMBER

Enter the number.

Press the STORE

button to confirm.

The display will then

prompt you to enter a

name: ENTER NAME

Enter the name using

the letters on the

keypad.

Entering names

For example, if you

wish to store the name

TOM:

To enter the letter T

press the 8button once.

Use the DOWN button

to move to the next

space.

To enter O press the

6button three times.

Store

Quick guide to

Character map

PQRS

ABC TUV

DEF X Y Z

GHI space

JKL <>-- +

MNO

KEYPAD

1Connect

ZZZ

To store a name and

number in the memory

Duet 700 ~ 7th Edition ~ 31st October ’01 ~ 3845

Press the DIRECTORY

button.

Use the UP/DOWN

buttons to scroll to the

number you require.

Press the DIAL

button. The number

will be shown on the

display and dialled

automatically.

Press the DIRECTORY

button.

Use the UP/DOWN

buttons to scroll to the

number and name you

wish to delete.

Press the DELETE

button. The display

will show DELETE?

To confirm press the

DELETE button again.

The display will show

DELETED.

The display will show

the new number of

entries stored e.g:

STORED 17/50.

1Connect

ZZZ

To delete stored names

and numbers

1Connect

ZZZ

To dial rom the

Manuels Téléphone populaires d'autres marques

GE 2-9480 Manuel utilisateur

Geemarc

Geemarc PHOTOPHONE 155 Manuel utilisateur

D-Link

D-Link DWR-720/PW Manuel utilisateur

Interquartz

Interquartz Gemini IQ333 Manuel utilisateur

SSS Siedle

SSS Siedle HT 840-0 Manuel utilisateur

Motorola

Motorola TITANIUM Manuel utilisateur

Panasonic

Panasonic ICX Manuel utilisateur

LG H870DS Manuel utilisateur

Samsung

Samsung GT-I9500 Manuel utilisateur

AT&T

AT&T Trimline 205 Manuel utilisateur

Selta

Selta zenyth 600 Manuel utilisateur

Doro

Doro AFTI 20 Manuel utilisateur

UNIQCELL

UNIQCELL A1 Manuel utilisateur

Panasonic

Panasonic KX Series Manuel utilisateur

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manuel utilisateur

NEC

NEC SV8500 Manuel utilisateur

Teledex

Teledex PEARL Manuel utilisateur

Ericsson

Ericsson Dialog 3213 Manuel utilisateur
