BT RELATE 700 Manuel utilisateur

Relate 700

Caller Display Telephone

User guide

Please open this page for an ‘At a glance’

guide to your Relate 700 Caller Display.

Relate 700 CD

✱

REDIAL Call My Bill

SET UP

©TO START

PRESS 'A'

AND FOLLOW

THE ARROWS

©KEY-IN THE

NUMBER

YOU WANT

TO STORE

©SELECT ONE

OF THE TEN

MEMORY

KEYS

©TO CONFIRM

THE NUMBER

PRESS ‘B'

©WHEN YOU

WANT TO

INFORM ‘B'

OF THE

NUMBERS

THAT

QUALIFY

FOR YOUR

Discount

PRESS ‘C'

ACCOUNT NO.

....................

CLR.

RECALL

DIAL

SECRECY

NO............................................

At a glance

Handset clip

Rotate for wall

mounting to secure

handset firmly in

position.

See page 20

Recall button

Lets you use BT

Select Services and

services with

switchboards/PBXs.

See page 12

Dial button

Press to dial

displayed numbers.

See page 15

Telephone No.

label

Secrecy button

(& light)

Allows you to talk to

someone in the

same room, without

your caller hearing.

See page 10

Display

Shows Caller

Display information,

stored/dialled

phone numbers.

Clear button

Lets you delete

entries from the

caller display list.

See page 15

▲ ▼ Up and Down

scroll buttons

Provides access to

and lets you scroll

through the caller

display list.

See page 14

Confirm button B

Confirms that you

have stored a number.

See page 9,11,12

Call My Bill

button

Press for billing

information. Can be

overwritten and used

as an extra direct

memory button.

See page 11

Start button A

Lets you store numbers

under the one-touch

memory buttons.

See page 9,11,12

One-touch memory

buttons 1-10

Allows one-touch dialling

of stored numbers (each

up to 24 digits).

See page 9

Redial button

Redials the last

number called.

See page 8

C button

Lets you register a

number for a Friends &

Family discount. Can be

used as an extra direct

memory button.

See page 9,11,12

RINGER

VOLUME

LOW

OFF

Relate 700 CD

✱

REDIAL Call My Bill

SET UP

©TO START

PRESS 'A'

AND FOLLOW

THE ARROWS

©KEY-IN THE

NUMBER

YOU WANT

TO STORE

©SELECT ONE

OF THE TEN

MEMORY

KEYS

©TO CONFIRM

THE NUMBER

PRESS ‘B'

©WHEN YOU

WANT TO

INFORM ‘B'

OF THE

NUMBERS

THAT

QUALIFY

FOR YOUR

Discount

PRESS ‘C'



ACCOUNT NO.

....................

CLR.

RECALL

DIAL

SECRECY

NO............................................



Ringer volume switch

Lets you adjust the ringer

between High, Low and Off.

See page 7

Battery

compartment

See page 6

Memory label

Lets you keep a

reference of numbers

stored in the memory.

See page 10

In this guide

At a glance 1

Introduction 4

Setting up 5

Using your Relate 700 8

Using the Caller Display 13

Help 18

Technical information 19

Wall mounting 20

Index 21

Hints and tips boxes

In this user guide, we’ve included helpful tips

and useful notes. They are shown in a grey box.

Introduction In order for your

Relate 700 Caller Display to receive and display messages,

you must subscribe to the BT Caller Display Service.

For more information call BT on Freefone 0800 800150

Your Relate 700 Caller Display has

been designed for ease of use and

made to the very high standards

set by BT.

We thank you for making the right

choice and expect that you will have

many years of quality service.

Please read the instructions carefully

before use and keep this user guide

for future reference.

For your records

Date of purchase:

Place of purchase:

Serial number:

(on the underside of the machine)

Purchase price:

For warranty purposes, proof of

purchase is required, so please keep

your receipt.

Emergency calls

The emergency services can be

contacted in the UK by dialling 999.

You may also dial 112, which is valid

in any country that is a member of the

European Community.

If your Relate 700 Caller Display is

connected to a PBX (switchboard), you

may have to dial an access number

before 999 to contact the emergency

services.

Some switchboards cannot dial out

during a power failure.

Customer Helpline

Should you have problems with

your machine, call the Relate 700

Caller Display Helpline on

LoCall

1 Plan where to situate

your Relate 700 Caller

Display

Situate your Relate 700 Caller Display

close enough to a telephone socket

so that telephone line cord will reach.

Do not stand it on carpets or other

similar surfaces that generate fibres.

Your Relate 700 Caller Display can be

wall-mounted. For more details on

how to wall-mount your Relate 700,

see ‘Wall- mounting’ on page 20.

Check that your Relate 700 Caller

Display is complete. When you

unpack, you should have:

•Relate 700 Caller Display

telephone with telephone line

cord attached.

•Bracket for wall mounting

•2 screws and wallplugs

Setting up Follow these steps to get your

Relate 700 Caller Display ready for use

4 Insert batteries

To fit batteries

Your Relate 700 Caller Display

takes 4 x AA batteries (not supplied).

1Turn the phone over and remove

the battery cover.

2Slide each battery into the

compartment, as shown above.

Take care to insert each battery

the right way round.

3Replace the battery cover.

2 Check your telephone

wall socket

If you do not have a modern phone

socket, call BT on Freefone 0800

800 150 and ask for an engineer to

come and fit the correct socket.

This is a chargeable service.

3 Plug your Relate 700

Caller Display into the

BT socket

Setting up

It is important to maintain the

batteries in your Relate 700 Caller

Display. Without battery power, display

features will only work when you lift

the handset. You can use the telephone

to make and receive calls at all times.

Battery low indication

When the batteries need replacing,

the display shows the battery low

icon

If you do not install batteries, the

display will show the battery low

icon while the handset is off-hook.

5 Set the ringer volume

The ringer volume switch is located

on the underside of your Relate 700

Caller Display. there are three

settings:

HIGH

A loud ring; your Relate 700 Caller

Display is preset to this position.

LOW

A quiet ring.

OFF

No ring - if you don’t want to be

disturbed.

6 Time and date

This is set when you receive your

first call, after you have registered

as a Caller Display customer.

Your Relate 700 Caller Display is

now ready for use.

Setting up

RINGER

VOLUME

LOW

OFF

NEW

CALL

00:00

NEW

CALL

00:00

Using the memory to

store and dial numbers

To store names and numbers

You can store up to ten names and

numbers (each up to 24 digits long)

under the one-touch memory

buttons. At the same time you can

numbers for extra savings.

1Remove the memory label.

2Lift the handset. Display shows

ON LINE. The first arrow light

comes on.

Using your Relate 700

Making and receiving

calls

To make a call

1Lift the handset. Display shows

ON LINE.

2Dial the number you require.

To end the call, replace the handset.

To receive a call

•When the phone rings lift the

handset to answer the call.

To redial the last number

1Lift the handset. Display shows

ON LINE.

2Press the REDIAL button.

The last number dialled is shown

on the display and is redialled

automatically.

Instructions are also shown

underneath the memory label.

REDIAL

Relate 700 CD

✱

REDIAL Call My Bill

SET UP

©TO START

PRESS 'A'

AND FOLLOW

THE ARROWS

©KEY-IN THE

NUMBER

YOU WANT

TO STORE

©SELECT ONE

OF THE TEN

MEMORY

KEYS

©TO CONFIRM

THE NUMBER

PRESS ‘B'

©WHEN YOU

WANT TO

INFORM ‘B'

OF THE

NUMBERS

THAT

QUALIFY

FOR YOUR

Discount

PRESS ‘C'



ACCOUNT NO.

....................

CLR.

RECALL

DIAL

SECRECY

NO............................................



NEW

CALL

00:00 ON LINE
