BT CALLER DISPLAY 1000 Manuel utilisateur

User Guide

Interactive screenphone

Please open this page for an ‘at a glance’

guide to your .

Please open this page for a further

‘at a glance’guide to your .

At a glance

New calls indicator

Visual alert for new calls.

Full QWERTY Keyboard

For use with E-Mail

directory and notepad.

Phone Line LED

Lights when the phone

line is unplugged.

Volume button

Adjusts the ringer and

speaker volumes.

Handsfree button

Use to dial and hold a

telephone conversation

without lifting the handset.

Mail

Lets you send and receive

E-Mail and send faxes.

Directory

Lets you access 150 name and

numbers stored in the directory.

Calls

Lets you access incoming,

outgoing and reminder list calls.

Save button

Save up to 4 screens of information

when connected to a service.

Retrieve button

Displays saved

information.

BT Services

Press for fast and easy use

of BT’s Select Services.

Town Centre

Fully ADSI compatible

allowing interactive access

to participating companies;

- Home Banking

- Home Shopping

- Information Services

Text size button

Press to choose between

3 different text sizes.

Multi Function buttons

Use to choose between the

options offered on screen.

Classified

Direct Dial national and

local advertisers.

Navigation Arrows

Lets you move the cursor

or highlight an option for

selection.

Enter button

Lets you make a selection.

Acts as the = button in

calculator mode.

Redial button

Redials the last number

you called.

eas icom

100 0

564

897

✱

TEL:

Secrecy

Allows you to talk to someone

in the same room, without your

caller hearing you.

Recall button

For use with switchboards.

Assistant button

Use for the organiser and

calculator features.

New Calls : 0

New Mails : 0

eas icom

100 0

Telephone On/Off Hook

Attach your printer here

(available seperately)

Extension in use

Receiving information

Secrecy On/Off Password

Movement arrows

New Calls: 0

Number of new

calls received.

New Mails: 0

Number of new

mails received.

Attached telephone line cordMains power cable with 3-pin adaptor

10:24am

Time

AA text size

Battery low

8 APR

Today’s date.

printer

Your Screen

New Calls : 0

New Mails : 0

Send and receive E-Mail

The enables you to

send and receive E-Mail messages

around the world without needing a computer.

You can also send faxes direct to any standard

fax machine.

Personal Directory

Easily store and quickly access up

to 150 names and numbers, as well

as E-Mail addresses and fax numbers in the

directory.

Caller Display

You can view information about calls

you have received, making it easy to

track and deal with callers.

Town Centre

Saves time by providing a fast track

route to interactive home shopping

and services direct to your home.

Classified

Dial Direct for a complete and up-to-

date list of entries in the UK Yellow

Pages.You can search for companies on a national

or local basis.

Pull-out QWERTY keyboard

Compact keyboard lets you type

E-Mails, faxes and directory entries.

With the AAbutton (next to the screen), you

also have a choice of three on-screen text sizes.

Key features

In this guide

At a glance 1

Introduction 4

Installation 5

Using your 7

Mail 9

Calls 13

Directory 15

Town Centre 17

Classified 18

Assistant 19

Connecting to a switchboard 21

Maintenance 22

Help 23

Technical information 24

Index 25

User Guide

Interactive screenphone

564

897

✱

TEL:

eas icom

1000

For your records

For warranty purposes, proof of purchase is

required, so please keep your receipt.

Personal Emergency Numbers

Date of purchase:

Place of purchase:

Serial number (on the base of the telephone):

Purchase price:

Introduction

Your has been designed for ease of use and made to the

high standards set by BT.

INSTALLATION

You can expect your to give you

many years of trouble-free service.

Please read the instructions carefully before use

and keep this User Guide for future reference.

Unpacking your

If anything is missing, please contact your place

of purchase immediately.

●with

telephone line cord attached

●Mains adaptor

●4 X AA size batteries

●User Guide

Plan the location of your

Make sure your is within 2

metres of the phone and mains sockets.

Turn your upside down.

Use the end of a ballpoint pen (or similar) to

remove the battery compartment cover.

Insert batteries as shown.

1 Insert back-up batteries

If you do not have modern phone sockets, call

Freefone 0800 800 150 and ask for a BT

engineer to come and fit the correct type. This

is a chargeable service.

Installation

Follow these steps to set up your ready for use.

Important

If there is a power failure and you do not have

back-up batteries fitted, the telephone will still

work normally, but the caller display function

will not operate and your ’s screen

will go blank. Information stored in the memory

will be lost.

2 Plug the mains power adaptor into

to the

3Connect the telephone line cord into

to the telephone line socket

INSTALLATION

TIME

Press TIME.

KEYPAD

Enter the time, using the 12-hour clock,

e.g. for 9.30, dial 0930. Press to select

AM or PM.

Press OK to confirm the time.

EXIT

Press EXIT.

Press the button on the front of the

phone marked – +.

+Press for louder ringer volume.

–Press for softer ringer volume.

Your is now ready for use.

The screen comes on and asks you to dial BT

free to receive information into your phone that

will make BT Select Services easier to use.

Press buttons in order shown

DIAL

Press DIAL and follow the on-screen

prompts.

When you have stored the BT

information, you can access the range

of BT Select Services quickly and easily

by pressing the BUTTON to the left of

the screen with below it.

If the BT server is busy or unavailable

you can dial it manually later by phoning

0800 328 1949.

DATE

Press DATE.

KEYPAD

Enter the correct date, e.g. for

6 January 1999, dial 06 01 1999.

Press OK to confirm the date.

4Plug the power adaptor into a

socket and switch on

5Call BT free to download

important information

6 To set the date

7 To set the time

8 To set the ringer volume

INSTALLATION
