BT QUARTET 3000 Manuel utilisateur

Quartet 3000 user guide ~ 3rd Edition ~ 3rd September ’02 ~ 4398

Quartet 3000

Additional Handset and Charger

User

Guide

This handset is only

compatible with the

Quartet 3100 and

Quartet 3500. You

will not be able to

ma e or receive calls

using additional

handsets until they

have been registered

to the Quartet base

unit. If you register

to a Quartet 3500

base you can access

the full answering

machine features.

This equipment is not designed for making

emergen y telephone alls when the power fails.

Alternative arrangements should be made for

a ess to emergen y servi es.

Quartet 3000 user guide ~ 3rd Edition ~ 3rd September ’02 ~ 4398

Please open this page for an ‘at a glance’

guide to your Quartet 3000

Quartet 3000 user guide ~ 3rd Edition ~ 3rd September ’02 ~ 4398

Contact points

At a glance

Charger

Handset fascia

Option buttons

Lets you select options within each

menu that are shown on the display.

Talk button

Press to make or receive a call.

Recall/Call Waiting button

For use with a switchboard/PBX

and BT Select Services.

Also allows you to use the Call

Waiting feature.

Aerial

Should be extended to obtain the

best signal and reception available.

Clear button

Use to delete unwanted digits or

characters and to exit the menu.

Up and Down buttons

Use to scroll up and down through

the menu options.

eypad

Last number redial/Pause button

Redials up to 5 of the last numbers

called, or press to enter a pause in a

stored number.

Quartet 3000 user guide ~ 3rd Edition ~ 3rd September ’02 ~ 4398

Safety information

General

Only use the power supply unit included with

the product. Using an unauthorised power

supply will invalidate your guarantee and may

damage the telephone. The item code for the

power supply unit is 003313, as stated on the

underside of the charger.

For the handset use only the approved

rechargeable battery pack. Under no

circumstances should non-rechargeable

batteries be used. Using unapproved batteries

will invalidate your guarantee and may damage

the telephone.

Radio signals transmitted between the handset

and base may cause interference to some

hearing aids.

Do not dismantle the handset or charger.

This could expose you to high voltages or

other risks. Contact the Helpline for repairs.

Never dispose of batteries in a ﬁre. There is

a serious risk of explosion and/or the release

of highly toxic chemicals.

Cleaning

Simply clean the handset and charger with

a damp (not wet) cloth, or an anti-static wipe.

Never use household polish as this will

damage the product. Never use a dry cloth

as this may cause a static shock.

Environmental

Do not expose to direct sunlight.

The product may heat up when the battery

is being recharged. This is normal. However,

to avoid damage we recommend that you do

not place the product on antique/veneered

wood.

Do not expose your product to ﬁre, explosive

or other hazardous conditions.

There is a slight chance that your phone

could be damaged by an electrical storm.

We recommend that you unplug the power

and telephone line cord for the duration of

the storm.

Quartet 3000 user guide ~ 3rd Edition ~ 3rd September ’02 ~ 4398

Plug the power supply cord into the

socket located on the bottom of the

charger.

You must charge your handset for

24 hours before use.

1Plug the power supply cord

into the charger

Setting up

Unpacking your

Quartet 3000

Check that your Quartet 3000 is

complete. If anything is missing, please

contact your place of purchase

immediately.

Quartet 3000 handset

Quartet 3000 charger

Power supply unit

Follow these steps to get your Quartet

3000 handset and charger ready for use.

Quartet 3000 user guide ~ 3rd Edition ~ 3rd September ’02 ~ 4398

Note (cont)

If you are making a call and the handset

battery is running low you will hear a

warning tone every 10-15 seconds.

Place the handset on the charger to

recharge.

However, the charge capacity of rechargeable

battery packs will reduce with time as they

wear out, so reducing the talk/standby time

of the handset. Eventually they will need to

be replaced. New battery packs can be

obtained from the Helpline. Please see your

main Quartet user guide for instructions

on how to install a new battery pack.

Note

When fully charged and in good condition,

the handset will provide up to 7 hours

talktime or 72 hours standby.

4Leave the handset to

charge for 24 hours

Helpline

If you have any difﬁculties setting up

or using your Quartet 3000 please

call the Helpline on 0870 605 8047.

Make sure the red charging light at the

front of the charger comes on.

2Connect the power supply

into a power soc et and

switch on

3Place the handset on the

charger

Quartet 3000 user guide ~ 3rd Edition ~ 3rd September ’02 ~ 4398

The display will show

Press

Page On Base Until Base Beeps

Press and hold the base unit

PAGE button. When you hear a

beep release the PAGE button.

The display will show

Handset

Registered

Your handset is automatically

assigned the next available

handset number. For example

your main Quartet 3100 or 3500

handset is already registered as

Handset 1 so if this is your first

additional handset it will become

Handset 2, if it is your second it

will show Handset 3 and so on.

The handset will then show the

standby screen:

00:00

Handset 2

Registering your handset

You must register your Quartet 3000

additional handset before it can be used

with your Quartet 3100 or 3500 base unit.

Please ensure you only have

the handset you wish to

the instructions below.

Once charged, your additional

handset will show the following

screen:

Press the OK options button.

To register your Quartet 3000

handset

Handset ?

Exit OK

To set the time

Quartet 3000 user guide ~ 3rd Edition ~ 3rd September ’02 ~ 4398

Press the OK option button to

confirm.

You will hear a confirmation

tone.

Press the CLEAR button until

you return to the standby

screen.

Please note that you need to

set the time on each individual

handset that you register to

your main Quartet 3100 or 3500

base unit.

The time will not be set

automatically unless you

subscribe to a Caller Display

Service.

Press the UP or DOWN button

until the display shows

Handset

Settings

Press the OK option button.

The display will show

Time

Setting

Press the OK option button.

The first digit will be flashing.

Enter the current time in 24

hour format, e.g.

09:24

Note

If you subscribe to a Caller Display

Service from your Network Provider

the time will be set when you receive

your first call.

Function

Answer a call/End a call

Ma e a call

Redial a number from the redial list

Store a number in the directory

Dial a number in the directory

Adjust the earpiece volume

Secrecy on/off

Transfer call to another handset

View and dial the Calls list

Adjust handset ringer volume

Adjust base ringer volume

Quartet 3000 user guide ~ 3rd Edition ~ 3rd September ’02 ~ 4398

Using your Quartet 3000 handset

Your Quartet 3000 can be used with the Quartet 3100 or Quartet 3500. Please refer to your main Quartet

user guide for a complete list of product features and operating instructions.

Quic guide to most commonly used handset settings and functions

Button combination

, , to scroll through to entry, to dial number displayed.

, , display shows Enter Name, enter name using keypad, ,

display shows Enter N mber, enter the number, .

, , to scroll through to entry, press to dial number displayed.

During a call, press to increase or decrease volume.

During a call, press and release to switch ON. Press and release

again to switch OFF.

During a call, press , enter handset number to transfer to .

, to scroll through list, to dial entry displayed press .

or until display shows

Handset Settings

, , display shows

Ringer Vol me

, to select volume required.

or until display shows

Base Settings

, , display shows

Ringer Vol me

, to select volume required.

New OK

Save

Sec Sec

Tran

Quartet 3000 user guide ~ 3rd Edition ~ 3rd September ’02 ~ 4398

Function

Switch answering machine

ON/OFF:

Using the Quartet 3500 base

Using the handset

Record own Answer and Record

outgoing message

Record own Answer Only

outgoing message

Set answer mode

Play new messages:

Using the Quartet 3500 base

Using the handset

Record memo message

Adjust Quartet 3500 base unit

loudspea er volume

Button combination

Press and release

or until display shows Answer Off On, press either or .

or until display shows Answer Settings, OK,

or until display shows O tgoing Message, OK, display shows

Answer and Record, OK, New, after tone speak message then press

or until display shows Answer Settings, OK,

or until display shows O tgoing Message, OK,

or until display shows Answer Only, OK, New, after tone speak

message then press

or until display shows Answer Settings, OK,

or until display shows Answer Mode, OK,

or to highlight either Answer and Record or Answer Only, OK,

Press and hold

, New.

or until display shows Record Memo, OK, after tone speak memo

then press

to increase volume

to decrease volume

Quic guide to most commonly used answering machine settings and functions

if registered to the Quartet 3500 base unit

Ans

On Off

Off On

Vol

Play

Table des matières

Autres manuels BT Combiné

BT Diverse 2000 Manuel utilisateur

BT SYNERGY Manuel utilisateur

BT DIVERSE 5400 ADDITIONAL Manuel utilisateur

BT BT DIVERSE 5100 Manuel utilisateur

BT FREESTYLE 4500 Manuel utilisateur

BT FREESTYLE 6 ADDITIONAL Manuel utilisateur

BT CALLER DISPLAY 1000 Manuel utilisateur

BT SYNERGY 2100 Manuel utilisateur

BT agile Manuel utilisateur

BT CALLER DISPLAY 1000 Manuel utilisateur

BT VERVE 3000 EXECUTIVE Manuel utilisateur

BT DIVERSE 5400 Manuel utilisateur

BT DIVERSE 5100 ADDITIONAL Manuel utilisateur

BT DIVERSE 5300 Manuel utilisateur

BT CALLER DISPLAY 1000 Manuel utilisateur

BT Diverse 2000 Manuel utilisateur

BT 2000 Executive Manuel utilisateur

BT Freestyle 6 Manuel utilisateur

BT DIVERSE 6100 Manuel utilisateur

BT FREESTYLE 2000 Manuel utilisateur

BT QUARTET 2000 Manuel utilisateur

BT SYNERGY 3005 Manuel utilisateur

BT Diverse 5200 Manuel utilisateur

Manuels Combiné populaires d'autres marques

Swissvoice

Swissvoice ePure HD Manuel utilisateur

Philips

Philips TD6736/BH051P Manuel utilisateur

ASCOM

ASCOM I62 - Manuel utilisateur

LG-Ericsson

LG-Ericsson LIP-9010 Manuel utilisateur

GE 1583 Manuel utilisateur

iiNet

iiNet Handset Manuel utilisateur

ASCOM

ASCOM 9p23 Manuel utilisateur

AT&T

AT&T DLP70110 Manuel utilisateur

AirCell

AirCell ST 3100 Manuel utilisateur

Eaton

Eaton HHIR-LCD-PROG Instructions de montage

Mitel

Mitel 112 Manuel utilisateur

SBC

SBC SBC-381H Manuel utilisateur

Mitel

Mitel 5602 Manuel utilisateur

ASCOM

ASCOM d81 Messenger Instructions d'installation

SpectraLink

SpectraLink 7522 Manuel utilisateur

Avaya

Avaya L100 Series Comment utiliser

ooma

ooma HD2 Handset Manuel utilisateur

Yealink

Yealink IPW56 Manuel utilisateur
