BT Diverse 2000 Manuel utilisateur
Diverse 2000
Executive Handset
user guide
This handset is also compatible with the
Diverse 2-Line and Diverse ISDN.
Please refer to main user manual for
instructions.
The Diverse 2000 Executive Handset is
not compatible with the Diverse 1000.
To be used with Diverse 2000 base
station or Diverse 2000 Handset
Charger.
Check that your Diverse 2000
Executive Handset is complete.
When you unpack you should have:
•Diverse 2000 Executive Handset.
•Handset carrying clip.
•Two nickel cadmium (NiCad).
rechargeable batteries.
•Battery compartment cover.
For your records
For warranty purposes, proof of
purchase is required, so please keep
your receipt.
See page 33 for more information about
your handset PIN.
Please open this page for a further
‘at a glance’ guide to your Diverse 2000
Executive Handset.
Date of purchase:
Place of purchase:
Purchase price:
My Executive Handset PIN is:
12
ABC 3
DEF
4
GHI 5
JKL 6
MNO
7
PQRS 8
TUV 9
WXYZ
#
✱0
RCL PWR
.
a A
At a glance
Power
For switching the
handset ON and OFF.
Recall
For use with switchboards
and BT Select Services.
Phone (green)
Used to make and
answer calls.
End Call (red)
Used to end a telephone call.
Menu
Brings up the menu
onto the display.
Option buttons
Lets you select from the
menu options on the display.
Display
Belt clip
Re-chargeable battery cover
12
yy
2
3
In this guide
At a glance 1
Introduction 4
Setting up 8
Registering a new Diverse
2000 Executive Handset
with a base station 12
Using the Diverse
2000 Executive Handset 17
Additional features 33
Maintenance 49
Help 50
Technical information 54
Index 56
Hints and tips boxes
In this user guide, we have included
helpful tips and important information
shown in grey boxes.
4
Introduction
Please read the instructions carefully
before use and retain this user guide for
future reference. For comprehensive
instructions see your main Diverse user
guide.
Building up a phone system
You can add further handsets to build
up a comprehensive and easy-to-use
cordless telephone system. You can use
up to six separate handsets (8 with the
Diverse 2-Line and Diverse ISDN) with
each Diverse base station and up to four
base stations with each handset. Please
refer to your base station user guide for
more comprehensive information of the
configurations that are possible.
As this product is rechargeable, it is
normal that a certain amount of heat
will be produced in its day-to-day
operation. Whilst this is entirely safe we
would advise against placing the phone
on antique, veneered or wooden surfaces
as damage may occur.
5
WARNING
1 Use only approved nickel-cadmium
(NiCad) rechargeable batteries.
Never use any other batteries, or
conventional alkaline batteries.
Using such batteries could destroy
the battery casing, which is
dangerous.
Recommended batteries should have a
power rating of 600m Ah 1.2V.
Suitable batteries are listed on page 7
(batteries are available from the Diverse
helpline on 0345 908070 and your
local BT shop).
2Do not combine different battery types
in the same handset.
3Do not try to use any power supply
except the one provided, otherwise you
may permanently damage your Diverse.
It will also result in non-compliance with
EN41003: 1993, and will invalidate the
approval given to this apparatus.
4Do not use non-BT Diverse charging
units; this could damage the batteries.
5Research has shown that in certain
cases, medical equipment can be
affected by cordless telephones. A
distance of at least one metre should
therefore be observed between the
telephone and medical equipment. All
regulations on the usage of cordless
phones issued by medical institutions
should also be followed.
6The Diverse handset can also interfere
with other electrical equipment e.g.
answering machines, TV and radio sets,
clock radio/ alarms and computers if
6
WARNING cont.
placed too close. It is recommended you
place your Diverse handset at least one
metre away from such appliances to
avoid any risk of interference.
7If you wear a hearing aid, please note
that the Diverse works by sending radio
signals between the base station and
handset. These signals can interfere
with hearing aids, causing a humming
noise.
8There is a slight chance that your
phone could be damaged by an
electrical storm. We recommend that
you unplug your Diverse from the
mains power and telephone line socket
during storms.
9Do not use your phone in bathrooms,
near fire or water, or in areas where
there is a danger of explosion.
10 Clean the handset and base station with
a damp cloth (not wet) or anti static
wipe. Never use a dry cloth or spray
cleaning fluid directly onto the phone.
11 Do not dispose of your batteries in
normal household rubbish and do not
place in water or a fire.
General cleaning
Simply clean the handset and base station
with a damp (not wet) cloth or antistatic
wipe. Never use a dry cloth as this may
cause a static shock. Never spray cleaning
fluid directly onto the telephone.
7
Approved rechargeable batteries
Use only the rechargeable battery types
listed below and do not mix two types in
the same handset:
Batteries can be obtained from the
Diverse Helpline on 0345 908070 or
your local BT shop.
Nickel-cadmium
Saft RC6
Panasonic P-60 AA/1P
Philips R6 NC-P
UCAR RC6
DAIMON ACCU 1000
Varta Accu Plus Ni-Cd 1.2V No. 5006
Sanyo N-3U
Energizer Eveready RC 6
GP 60AA KC
The handset has a range of up to 300
metres outside and up to 50 metres in
buildings, depending on the type of
construction.
8
Important
When replacing batteries always use
good quality nickel cadmium (NiCad)
rechargeable AA types with at least
600mAh capacity in order to achieve
the specified operating time. Never
use other batteries or conventional
alkaline batteries. They could result
in a short circuit or destroy the
battery casing. Recommended
rechargeable batteries are available
from the Diverse Helpline 0345
908070 and the BT Shop.
1
2
Setting Up
1 Install the rechargeable
batteries in the handset
The handset uses the two AA size nickel
cadmium (NiCad) batteries, which are
supplied. To install them, insert the
batteries as indicated on the label inside
the battery compartment and slide the
battery compartment cover shut. The
battery compartment cover may be
found in the packaging with the
batteries.
