BT FREESTYLE 65 Manuel utilisateur

PaperJet 65 user guide – Edition 3 – 8.10.01

PaperJet 65

Plain Paper Fax, Copier, Colour Printer,

Telephone and Digital Answering Machine

User

Guide

This product is intended to be connected to analogue

networks and pri ate switching systems in the

United Kingdom.

This product has not been designed for making emergency

telephone calls when the power fails. Alternati e arrangements

should be made for access to emergency ser ices.

PaperJet 65 user guide – Edition 3 – 8.10.01

Please open this page for an ‘at a glance’

guide to your PaperJet 65.

PaperJet 65 user guide – Edition 3 – 8.10.01

Please open this page for a ‘further at

a glance’ guide to your PaperJet 65.

PaperJet 65 user guide – Edition 3 – 8.10.01

At a glance

Document outlet

Outlet for received faxes, copied

documents and originals.

Display screen

Control panel

Document feeder

width guides

Adjust to fit the width

of your document for A4,

Letter and Legal sizes.

Document feeder

Holds up to 5 sheets placed face

down for faxing or copying.

Paper feeder width guide

Adjust to fit the width of your

paper for A4, Letter and Legal

sizes.

Plain paper sheet feeder

Max. capacity 40 sheets of

80gsm paper.

Paper support

Handset

Mains power socket

Telephone line socket

Cover

Open the cover

for changing the

print cartridge

and clearing

document jams

Loudspeaker

Error

Delete

Memo

Messages

123

456

789

STD Play HalfTones

䊴䊳

I䊴䊴

䊳䊳I

䊳/II

PaperJet 65

Stop

Monitor

Start

Function

Recall

RX Mode Resolution Contrast

Speed Dial Last TX External

Clear Pause

Volume

Copy

&...

PaperJet 65 user guide – Edition 3 – 8.10.01

Error

Delete

Memo

Messages

123

456

789

STD Play Half Tones

䊴䊳

I䊴䊴

䊳䊳I

䊳/II

PaperJet 65

Stop

Monitor

Start

Function

Recall

RX Mode Resolution Contrast

Speed Dial Last TX External

Clear Pause

Volume

Copy

&...

Reduction/Enlargement button. Reduces and

enlarges copies to either 70% or 140%.

Resolution button. Allows you to choose text or

photo resolution for copies.

Contrast button. Adjusts the contrast of

documents to be copied.

Copy button. Press to start copying a document.

Error light. Indicates a problem when sending or

receiving a fax.

Stop button. Stops the current operation.

Returns the fax machine to standby.

Monitor button. Press to get dialling tone.

Start button. Press to send a fax. Confirms an

option chosen from the menu. During a call, press

to receive a fax.

Function button. Function button lets you select

options from the menus.

RX Mode/Hold button. Selects reception

methods for faxes. When on a phone call, press to

put a caller on hold. They hear a beep.

Resolution/Volume – button. Adjust the

resolution of documents to be faxed. Select next

option from a menu.

Decrease loudspeaker volume

Contrast/Volume button. Adjust the contrast

of documents to be faxed. Select previous option

from a menu.

Increase loudspeaker volume

Recall button.

Speed Dial/Clear button. Used to speed dial a

stored number. Deletes incorrect settings and

characters.

Last Number/Pause button. Press once to

display last number dialled. If you have a

document in the ADF it shows the last fax

number, if not it shows the last telephone number

called. Press again to dial the number

displayed.When dialling or storing a number,

press to enter a pause.

External button. Connects you to an outside line

when connected to a switchboard.

PaperJet 65 user guide – Edition 3 – 8.10.01

Print head holder

Optical scanner

Socket or PC cable connection

Key features

PaperJet 65 user guide – Edition 3 – 8.10.01

Plain paper fax

Holds up to 40 sheets of A4 paper for ink

jet quality printing.

21 page memory

If you run out of ink or paper while

receiving a fax the document will be stored

in the memory and automatically printed out when

the new paper or ink has been added.

Copier with zoom

Make single or multiple copies of

documents. Enlarge copies to 140% or

reduce to 70%

One touch and speed dial memories

10 one touch memories and 31 speed dial

memories can each store a fax number,

phone number and name. Easy to display and scroll

through the memories.

Mono/colour printer for PC

Print documents from your PC.

Interchangeable black and colour

cartridges let you print in colour whenever required.

IMPOR AN

o print from your PC

A Bi-directional parallel printer cable is required.

To print in colour, a colour ink cartridge is

required. These items are not supplied with the

machine and must be purchased separately.

In this guide

PaperJet 65 user guide – Edition 3 – 8.10.01

At a glance 2

Introduction 7

Safety information 8

Setting up 9

sing your PaperJet 65 15

Sending faxes 15

To broadcast a document 19

Using the one-touch memories 21

Using the speed-dial memories 22

Reports and lists 24

Ma ing and receiving phone calls 26

Copying documents 28

sing the answering machine 29

Recording capacity 33

Remote access 36

Additional features 38

Polling 42

Caller Display 44

Call Sign (Distinctive ringing) 45

Connecting to a switchboard 46

Help 48

Maintenance 53

Technical information 58

Index 60

Introduction

PaperJet 65 user guide – Edition 3 – 8.10.01

For your records

Date of purchase:

Place of purchase:

Serial number (on base of unit):

Proof of purchase is required for warranty purposes,

so please keep your receipt.

he following items are not included with your

PaperJet 65 but are required for PC printing and

printing of colour documents

NO E

Using the PC print facility

Please refer to the separate PaperJet 55/65 PC

Printing Guide.

Unpacking your PaperJet 65

When you unpack you should have:

PaperJet 65 with attached

mains power cable and

fitted 3-pin plug.

Telephone line cord

Starter print cartridge

Printer cable

Colour cartridge

Handset with cord

Paper support

Document holders for use

with torn, thin or small pages

CD with PaperJet 55/65 PC software

PaperJet 55/65 PC Printing Guide

Cartridge storage container

Never put foreign bodies into the fax machine.

Their accidental contact with powered parts may

cause a fire or electric shocks.

Do not expose to direct sunlight.

Do not stand your fax machine on carpets or other

surfaces which generate fibres, or place it in

locations preventing free flow of air over its surfaces.

Do not submerge any part of your fax

machine in water and do not use it in damp

or humid conditions such as bathrooms.

Do not expose your fax machine to fire,

explosive or other hazardous conditions.

There is a slight chance that your fax

machine could be damaged by an electrical

storm. We recommend that you unplug the

power and telephone line cord for the duration of

the storm.

Safety information

PaperJet 65 user guide – Edition 3 – 8.10.01
